LEXUS LS500 2018 Owners Manual

1413-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) 3
Before driving
This function can be used to prevent
children from accidentally opening or
closing a passenger window.
Press the switch. The indicator will come on and the pas-
senger windows will be locked.
The passenger wind ows can still be
opened and closed using the driver’s
switch even if the lock switch is on.
■
The power windows can be operated
when
The engine switch is in IGNITION ON
mode. ■
When the battery is disconnected
The window lock switch is disabled. If nec-
essary, press the window lock switch after
reconnecting the battery.WARNING●
The jam protection function may not
work if something gets jammed just
before the window is fully closed. Be
careful not to get any part of your body
jammed in the window.■
Catch protection function●
Never use any part of your body or
clothing to intentio nally activate the
catch protection function.●
The catch protection function may not
work if something gets caught just
before the window is fully opened. Be
careful not to get any part of your body
or closing caught in the window.
Preventing accidental operation
(window lock switch)
A

142 3-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) *
:If equipped
■
Opening and closing
1 Opens the moon roof *
The moon roof tilts up and then fully opens.
2 Closes the moon roof **
: Lightly press either side of the moon roof
switch to stop the moon roof partway.■
Tilting up and down
1 Tilts the moon roof up *
2 Tilts the moon roof down *
*
: Lightly press either side of the moon roof
switch to stop the moon roof partway. ■
The moon roof can be operated when
The engine switch is in IGNITION ON
mode. ■
Operating the moon roof after turning
the engine off
The moon roof can be operated for approx-
imately 45 seconds after the engine switch
is turned to ACCESSORY mode or turned
off. It cannot, howeve r, be operated once
either front door is opened. ■
Jam protection function
If an object is dete cted between the moon
roof and the frame while the moon roof is
closing or tilting down, travel is stopped and
the moon roof opens slightly. ■
Sunshade
The sunshade can be opened and closed
manually. However, the sunshade will open
automatically when the moon roof is
opened. ■
Door lock linked moon roof operation ●
The moon roof can be opened and
closed using the mechanical key. *

( → P.437)●
The moon roof can be opened using the
wireless remote control. *
( → P.96)*
: These settings must be customized at
your Lexus dealer.
■
When the moon roof does not close nor-
mally
Perform the following procedure:
1 Stop the vehicle.
2 Press and hold th e “CLOSE” switch. *
The moon roof will close, reopen and pause
for approximately 10 seconds. Then it will
close again and stop at the completely
closed position.
3 Check to make sure that the moon roof
is completely closed and then release
the switch. *
: If the switch is released at the incorrect
time, the procedure will have to be per-
formed again from the beginning.
If the moon roof does not fully close even Moon roof *
Use the overhead switches to open
and close the moon roof and tilt it
up and down.
Operating the moon roof

1433-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) 3
Before driving after performing the above procedure cor-
rectly, have the vehicle inspected by your
Lexus dealer. ■
If the moon roof does not move normally
If the moon roof does not open or close
normally or the automatic opening function
does not operate, perform the following ini-
tialization procedure.
1 Stop the vehicle.
2 Press and hold the “DOWN” switch. *
The moon roof will stop at the tilt-up posi-
tion. After that, it will op en, close, tilt up, tilt
down, and stop at the fully closed position.
3 Confirm that the moon roof has com-
pletely stopped and release the switch. *
: If you release the switch while the moon
roof is moving, perform the procedure
again from the beginning.
If, after performing the above procedures
correctly, the moon roof still does not open
or close normally or the automatic opening
function does not operate, have the vehicle
inspected by your Lexus dealer. ■
Moon roof open warning buzzer
A buzzer sounds and a message is shown
on the multi-information display in the
instrument cluster when the engine switch
is turned off and the driver’s door is opened
with the moon roof open. ■
Customization
Some functions can be customized.
( → P.468)
WARNING
Observe the following precautions.
Failure to do so may cause death or seri-
ous injury.
■
Opening the moon roof
●
Do not allow any passengers to put
their hands or heads outside the vehi-
cle while it is moving.
●
Do not sit on top of the moon roof. ■
Opening and closing the moon roof ●
The driver is responsible for moon roof
opening and closing operations.
In order to prevent accidental opera-
tion, especially by a child, do not let a
child operate the moon roof. It is possi-
ble for children and other passengers
to have body parts caught in the moon
roof. ●
Check to make sure that all passen-
gers do not have any part of their body
in a position where it could be caught
when the moon roof is being operated.
●
When using the wireless remote con-
trol or mechanical key and operating
the moon roof, oper ate the moon roof
after checking to make sure that there
is no possibility of any passenger hav-
ing any of their body parts caught in
the moon roof. Also, do not let a child
operate moon roof by the wireless
remote control or mech anical key. It is
possible for children and other passen-
gers to get caught in the moon roof.
●
When exiting the vehicle, turn the
engine switch off, carry the key and
exit the vehicle along with the child.
There may be accidental operation,
due to mischief, etc., that may possibly
lead to an accident.

144 3-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) *
: If equipped
■
Opening and closing the elec-
tronic front roof sunshade
1 Opens the electronic front roof
sunshade *
2 Closes the electronic front roof
sunshade *
If the panoramic moon roof is not fully
closed, it will close fully before the elec-
tronic front roof sunshade closes. *
: Lightly press either side of the front roof
sunshade switch to stop the electronic
front roof sunshade partway.
■
Opening and closing the elec-
tronic rear roof sunshade 
Rear roof sunshade switch
Press the rear roof sunshade switch. Lightly press the switch while the elec-
tronic rear roof sunshade is opening/clos-
ing will stop the operation.WARNING■
Jam protection function●
Never use any part of your body to
intentionally activate the jam protec-
tion function.●
The jam protection function may not
work if something gets caught just
before the moon roof is fully closed.
Also, the jam protection function is not
designed to operat e while the moon
roof switch is being pressed. Take care
so that your fingers, etc. do not get
caught. Panoramic moon roof *
Use the overhead switches to oper-
ate the panoramic moon roof and
electronic roof sunshade.
Operating the panoramic moon
roof

1453-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) 3
Before driving Press the switch ag ain will operate the
electronic rear roof sunshade in the oppo-
site direction.

Rear Multi Operation Panel
1 Display the Home screen
( → P.308) and then touch
“Shade/Lamp”.
2 Touch the button for the desired
operation.
Closes the electronic rear roof sun-
shade
Opens the electronic rear roof sun-
shadeIf a button is touched while the electronic
rear roof sunshade is opening/closing, the
opening/closing operation will stop.
■
Tilting the panoramic moon roof up
and down
Press the tilt switch. When the panoramic moon roof is tilted
up, the electronic front roof sunshade will
open. The panoramic moon roof can be tilted
down only when it is in the tilt-up position.
Lightly press the switch while the pan-
oramic moon roof is operating will stop the
operation.
■
Opening and closing the pan-
oramic moon roof
1 Opens the panoramic moon roof *
When the panoramic moon roof is opened,
the electronic front roof sunshade will
open.
The panoramic moon roof can be opened
from the tilt-up position.
2 Closes the panoramic moon roof **
: Lightly press either side of the pan-
oramic moon roof switch to stop the
panoramic moon roof partway.
■
The panoramic moon roof can be oper-
ated when
The engine switch is in IGNITION ON
mode.A
B

146 3-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) ■
Operating the panoramic moon roof
after turning the engine off
The panoramic moon roof and electronic
roof sunshade can be operated for approxi-
mately 45 seconds afte r the engine switch
is turned to ACCESSORY mode or turned
off. It cannot, however, be operated once
the driver’s door is opened. ■
Jam protection function
If an object is detected between the pan-
oramic moon roof and the frame in the fol-
lowing situations, travel is stopped and the
panoramic moon roof opens slightly: ●
The panoramic moon roof is closing or
tilting down.●
The electronic roof sunshade is closing.■
Door lock linked panoramic moon roof
operation●
The panoramic moon roof can be
opened and closed using the mechanical
key. *
( → P.437)●
The panoramic moon roof can be
opened using the wireless remote con-
trol. *
( → P.96)*
: These settings must be customized at
your Lexus dealer.■
When the panoramic moon roof or elec-
tronic front roof sunshade does not
close normally
Perform the following procedure:
1 Stop the vehicle.
2 Turn the engine switch to IGNITION
ON mode.
3 Press and hold the “CLOSE” switch or
the front roof sunshade close switch.
Continue pressing the switch for
approximately 10 seconds after the
panoramic moon roof or electronic
front roof sunshade closes and reopens.
The panoramic moon roof and elec-
tronic front roof sunshade will start to
close. *
4 Check that the panoramic moon roof
and electronic front roof sunshade are
fully closed and release the switch. *
: If the switch is released at the incorrect
time, the procedure will have to be per- formed again from the beginning.
If the panoramic moon roof or electronic
front roof sunshade does not fully close
even after performing the above procedure
correctly, have the vehicle inspected by
your Lexus dealer. ■
When the electronic rear roof sunshade
does not close normally
Perform the following procedure:
1 Stop the vehicle.
2 Turn the engine switch to IGNITION
ON mode.
3 Press and hold the rear roof sunshade
switch. Continue pressing the switch for
approximately 10 seconds after the
electronic rear roof sunshade closes
and reopens. The elec tronic rear roof
sunshade will start to close. *
4 Check that the electronic rear roof sun-
shade are fully closed and release the
switch. *
: If the switch is released at the incorrect
time, the procedure will have to be per-
formed again from the beginning.
If the panoramic moon roof or electronic
front roof sunshade does not fully close
even after performing the above procedure
correctly, have the vehicle inspected by
your Lexus dealer. ■
If the panoramic moon roof or elec-
tronic front roof sunshade does not
move normally
If the panoramic moon roof or electronic
front roof sunshade does not open or close
normally or the automatic opening function
does not operate, perform the following ini-
tialization procedure.
1 Stop the vehicle.
2 Turn the engine switch to IGNITION
ON mode.
3 Fully close the panoramic moon roof
and electronic front roof sunshade.
4 Press and hold th e “CLOSE” switch. *
The electronic front roof sunshade will open
after approximately 10 seconds. Then the
panoramic moon roof will open, close, tilt
up and tilt down. After that, the electronic
front roof sunshade will fully close and stop.

1473-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) 3
Before driving 5 Check that the panoramic moon roof
and electronic front roof sunshade are
fully closed and release the switch. *
: If the switch is released at the incorrect
time, the procedure will have to be per-
formed again from the beginning.
If, after performing the above procedures
correctly, the panoramic moon roof and
electronic front roof sunshade still does not
open or close normally or the automatic
opening function does not operate, have
the vehicle inspected by your Lexus dealer. ■
If the electronic rear roof sunshade
does not move normally
If the electronic rear roof sunshade does
not open or close normally or the automatic
opening function does not operate, per-
form the following initialization procedure.
1 Stop the vehicle.
2 Turn the engine switch to IGNITION
ON mode.
3 Open the rear roof sunshade.
4 Press and hold the rear roof sunshade
switch. *
Continue pressing th e switch for approxi-
mately 10 seconds after the electronic rear
roof sunshade closes. The electronic rear
roof sunshade will be gin operating again
and stop at the fully closed position.
5 Check that the electronic rear roof sun-
shade are fully closed and release the
switch. *
: If the switch is released at the incorrect
time, the procedure will have to be per-
formed again from the beginning.
If, after performing the above procedures
correctly, the electronic rear roof sunshade
still does not open or close normally or the
automatic opening function does not oper-
ate, have the vehicle inspected by your
Lexus dealer.
■
Panoramic moon roof open warning
buzzer
A buzzer sounds and a message is shown
on the multi-information display in the
instrument cluster when the engine switch
is turned off and the driver’s door is opened
with the panoramic moon roof open. ■
Customization
Some functions can be customized.
( → P.468)
WARNING
Observe the following precautions.
Failing to do so may cause death or seri-
ous injury. ■
Opening and closing the electronic
roof sunshade ●
Check to make sure that all passen-
gers do not have any part of their body
in a position where it could be caught
when the electronic sunshade is being
operated. ●
Do not let a child operate the elec-
tronic sunshade. Closing the elec-
tronic roof sunshade on someone can
cause death or serious injury.
■
Opening the panoramic moon roof
●
Do not allow any passengers to put
their hands or heads outside the vehi-
cle while it is moving.
●
Do not sit on top of the panoramic
moon roof.

148 3-5. Opening, closing the windows and moon roof
LS500_OM_OM50F54U_(U) WARNING■
Opening and closing the panoramic
moon roof●
The driver is responsible for pan-
oramic moon roof opening and closing
operations. In order to prevent acci-
dental operation, especially by a child,
do not let a child operate the pan-
oramic moon roof. It is possible for
children and other passengers to have
body parts caught in the panoramic
moon roof.●
Check to make sure that all passen-
gers do not have any part of their body
in a position where it could be caught
when the panoramic moon roof is
being operated.
●
When using the wireless remote con-
trol or mechanical key and operating
the panoramic moon roof, operate the
panoramic moon roof after checking
to make sure that there is no possibility
of any passenger having any of their
body parts caught in the panoramic
moon roof. Also, do not let a child
operate panoramic moon roof by the
wireless remote control or mechanical
key. It is possible for children and other
passengers to get caught in the pan-
oramic moon roof. ●
When exiting the vehicle, turn the
engine switch off, carry the key and
exit the vehicle along with the child.
There may be accidental operation,
due to mischief, etc., that may possibly
lead to an accident. ■
Jam protection function ●
Never use any part of your body to
intentionally activa te the jam protec-
tion function. ●
The jam protection function may not
work if something gets caught just
before the panoramic moon roof or
electronic roof sunshade is fully
closed. Also, the jam protection func-
tion is not designed to operate while
the switch is being pressed. Take care
so that your fingers, etc. do not get
caught. ■
To prevent burns or injuries
Do not touch the area between the
underside of the panoramic moon roof
and the electronic sunshade. Your hand
may get caught and you could injure
yourself. Also, if the vehicle is left in direct
sunlight for a long time, the underside of
the panoramic moon roof could become
very hot and could cause burns.
NOTICE
■
To prevent damage to the panoramic
moon roof ●
Before opening the panoramic moon
roof, make sure that there are no for-
eign objects, such as stones or ice,
around the opening.
●
Do not hit the surface or edge of the
panoramic moon roof with hard
objects.
■
After the vehicle has been washed or
rained on
Before opening the panoramic moon
roof, wipe any water off the panoramic
moon roof. Otherwise, water may enter
the cabin when the panoramic moon roof
is opened.

149
LS500_OM_OM50F54U_(U) 4 4
Driving Driving .
4-1. Before driving
Driving the vehicle ..................... 150
Cargo and luggage ................... 156
Vehicle load limits ...................... 158
Trailer towing ............................... 159
Dinghy towing ............................. 159
4-2. Driving procedures
Engine (ignition) switch ........... 160
Automatic transmission........... 163
Turn signal lever.......................... 169
Parking brake .............................. 170
Brake Hold.................................... 173
4-3. Operating the lights and wipers
Headlight switch ......................... 175
AHB (Automatic High Beam)
......................................................... 178
Windshield wipers and washer
......................................................... 180
4-4. Refueling
Opening the fuel tank cap...... 185
4-5. Using the driving support sys-
tems
Lexus Safety System+A........... 187
Lexus Safety System+ .............. 194
PCS (Pre-Collision System) (vehi-
cles with Lexus Safety Sys-
tem+A) ....................................... 200
PCS (Pre-Collision System) (vehi-
cles with Lexus Safety System+)
......................................................... 210 FCTA (Front Cross Traffic Alert)
........................................................ 218
LTA (Lane Tracing Assist) ...... 221
LKA (Lane-Keeping Assist)
........................................................ 231
RSA (Road Sign Assist).......... 238
Dynamic radar cruise control with
full-speed range........................ 241
BSM (Blind Spot Monitor) ..... 251
PKSA (Parking Support Alert)
....................................................... 256
Intuitive parking assist ............. 257
RCTA (Rear cross traffic alert)
function....................................... 264
RCD (Rear Camera Detection)
function....................................... 268
PKSB (Parking Support Brake)
......................................................... 271
Parking Support Brake function
(static objects) ......................... 277
Parking Support Brake function
(rear-crossing vehicles) ...... 282
Parking Support Brake function
(rear pedestrians) .................. 286
Driving mode select switch .. 289
Electronically modulated air sus-
pension ........................................ 291
Driving assist systems.............. 294
4-6. Driving tips
Winter driving tips .................... 299

150 4-1. Before driving
LS500_OM_OM50F54U_(U) 4-1.Before driving
■
Starting the engine
→ P.160 ■
Driving
1 With the brake pedal depressed,
shift the shift position to D.
( → P.163)Check that the shift position indicator
shows D.
2 If the parking brake is in manual
mode, release the parking brake.
( → P.170)
3 Gradually release the brake pedal
and gently depress the accelerator
pedal to accelerate the vehicle. ■
Stopping
1 With the shift position in D, depress
the brake pedal.
2 If necessary, set the parking brake.If the vehicle is to be stopped for an
extended period of time, shift the shift posi-
tion to P. ( → P.166)
■
Parking the vehicle
1 With the shift position in D, depress
the brake pedal to stop the vehicle
completely.
2 If the parking brake is in manual
mode, set the parking brake.
( → P.170)
3 Shift the shift position to P.
( → P.166) 4 Press the engine switch to stop the
engine.
5 Slowly release the brake pedal.
6 Lock the door, making sure that you
have the electronic key on your
person. If parking on a hill, block the wheels as
needed. ■
Starting off on a steep uphill
1 Make sure that the parking brake is
set and shift the shift position to D. Hill-start assist control will operate.
( → P.294)
2 Gently depress the accelerator
pedal.
3 Release the parking brake. ■
Driving in the rain ●
Drive carefully when it is raining, because
visibility will be reduced, the windows
may become fogged-up, and the road
will be slippery. ●
Drive carefully when it starts to rain,
because the road surface will be espe-
cially slippery. ●
Refrain from high speeds when driving on
an expressway in the rain, because there
may be a layer of wa ter between the tires
and the road surface, preventing the
steering and brakes from operating prop-
erly.
■
Engine speed while driving
In the following conditions, the engine
speed may become high while driving. This
is due to automatic up-shifting control or
down-shifting implementation to meet driv-
ing conditions. It does not indicate sudden
acceleration.
●
The vehicle is judged to be driving uphill
or downhill
●
When the accelerato r pedal is released
●
When the brake pedal is depressedDriving the vehicle The following procedures should be
observed to ensure safe driving:
Driving procedure
