LEXUS LS500 2019 Owners Manual

4919-1. For owners
LS500_OM_(U)_1810 9
For owners ATTENTION●
Ne fixez rien et ne posez rien sur des
emplacements tels que la planche de
bord, la garniture du volant et la partie
inférieure du tableau de bord.
Ces éléments peuvent se transformer
en projectiles lorsque les coussins
gonflables conducteur, passager avant
et genoux SRS se déploient.
●
Ne fixez rien aux portes, à la vitre du
pare-brise, aux vitres latérales, aux
montants avant et arrière, au rail latéral
de toit et à la po ignée de maintien.
●
Ne suspendez aucun cintre ou objet
dur aux crochets à vêtements. Tous
ces objets pourraient se transformer
en projectiles et causer des blessures
graves, voire mortelles en cas de
déploiement des coussins gonflables
rideaux SRS.
●
Si un cache en vinyle est placé sur la
zone où le coussin gonflable de
genoux SRS se déploie, assurez-vous
de le retirer. ●
N'utilisez aucun accessoire de siège
recouvrant les zones de déploiement
des coussins gonflables latéraux SRS,
car il risque de gêner le déploiement
des coussins gonflables SRS. De tels
accessoires peuvent empêcher les
coussins gonflables latéraux de
fonctionner correcte ment, désactiver
le système ou entraîner le déploiement
accidentel des coussins gonflables
latéraux, occasionna nt des blessures
graves, voire mortelles. ●
Évitez de faire subir des chocs ou des
pressions excessives aux parties ren-
fermant les composants de coussins
gonflables SRS ou aux portes avant.
En effet, cela pourra it entraîner un dys-
fonctionnement des coussins gonfla-
bles SRS. ●
Ne touchez aucun composant
immédiatement après le déploiement
(gonflage) des coussins gonflables
SRS, car ils peuvent être chauds. ●
Si vous avez des di fficultés à respirer
après le déploiement des coussins
gonflables SRS, ouvrez une porte ou
une vitre pour faire entrer de l'air frais,
ou bien descendez du véhicule si cela
ne présente pas de danger. Essuyez
tout résidu dès que possible afin
d'éviter d'éventuelle s irritations de la
peau.
●
Si les partie s renfermant les coussins
gonflables SRS, comme les garnitures
du volant et des montants avant et
arrière, sont endommagées ou cra-
quelées, faites-les remplacer par votre
concessionnaire Lexus.
●
Ne placez rien sur le siège du pas-
sager avant, comme un coussin par
exemple. Cela a pour conséquence de
répartir le poids du passager sur toute
la surface du siège, ce qui empêche le
capteur de détecter correctement le
poids du passager. En conséquence,
les coussins gonflables frontaux SRS
du passager avant risquent de ne pas
se déployer en cas de collision.

492 9-1. For owners
LS500_OM_(U)_1810 ATTENTION■
Modification et mise au rebut des
composants du système de coussins
gonflables SRS
Ne mettez pas votre véhicule au rebut et
ne procédez à aucune des modifications
suivantes sans consulter votre conces-
sionnaire Lexus. Les coussins gonflables
SRS peuvent ne pas fonctionner cor-
rectement ou se déployer (se gonfler)
accidentellement, prov oquant la mort ou
de graves blessures. ●
Installation, dépo se, démontage et
réparation des coussins gonflables
SRS●
Réparations, modifications, démon-
tage ou remplacement du volant, du
tableau de bord, de la planche de
bord, des sièges ou de leur garnissage,
des montants avant, latéraux et arrière,
des rails latéraux de toit, des panneaux
de porte avant, des garnitures de
porte avant ou des haut-parleurs de
porte avant●
Modifications du panneau de porte
avant (par exemple, perçage d'un trou
dans le panneau)●
Réparations ou modi fications des ailes
avant, du pare-chocs avant ou des
flancs de l'habitacle
●
Installation d'un protège-calandre
(pare-buffle, pare-kangourou, etc.), de
chasse-neige, de treuils ou d'un
porte-bagages de toit
●
Modifications du système de suspen-
sion du véhicule
●
Installation d'appa reils électroniques
tels que les émetteurs/récepteurs
radios mobiles et les lecteurs CD
●
Modifications de votre véhicule pour
une personne atteinte d'un handicap
physique

493
LS500_OM_(U)_1810 Index .
What to do if... (Troubleshooting)
........................................................ 494
Alphabetical Index.................... 497

494 What to do if... (Troubleshooting)
LS500_OM_(U)_1810 1-1.What to do if... (Troubleshooting)
What to do if... (Troubleshooting)  If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
(  P.432)
 If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. (  P.432)
 Is the electronic key battery weak or
depleted? (  P.399)
 Is the engine switch in IGNITION
ON mode? When locking the doors, turn the engine
switch off. ( 
P.166 )
 Is the electronic key left inside the
vehicle? When locking the doors, make sure that
you have the electronic key on your per-
son.  The function may not operate prop-
erly due to the condition of the radio
wave. (  P.113)
 Is the child-protector lock set? The rear door cannot be opened from
inside the vehicle when the lock is set.
Open the rear door from outside and then
unlock the child-protector lock. ( 
P.103 )
 The function to prevent the elec-
tronic key from being left inside the
trunk will operate and you can open
the trunk as usual. Take the key out
from the trunk. (  P.109)
 Did you press the engine switch
while firmly depressing the brake
pedal? (  P.164)
 Is the electronic key anywhere
detectable inside the vehicle?
(  P.112)
 Is the steering wheel unlocked?
(  P.164)
 Is the electronic key battery weak or
depleted?If you have a problem, check the
following before contacting your
Lexus dealer.
The doors cannot be locked,
unlocked, opened or closed You lose your keys
The electronic key does not
operate properly
The doors cannot be locked or
unlocked The rear door cannot be opened
The trunk lid is closed with the
electronic key left inside
If you think something is wrong The engine does not start

4951-1. What to do if... (Troubleshooting)
LS500_OM_(U)_1810 495What to do if... (Troubleshooting)
In this case, the engine can be started in a
temporary way. ( 
P.434 )
 Is the battery discharged?
(  P.435)
 It is locked automatically to prevent
theft of the vehicle. (  P.164)
 Is the window lock switch pressed? The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( 
P.144 )
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY mode for a period of
time. (  P.166)
 The seat belt reminder light is flash-
ing Are the driver and the front passenger
wearing the seat belts? ( 
P.418 )
 The parking brake indicator is on Is the parking brake released? ( 
P.174 )
Depending on the situation, other
types of warning buzzer may also sound. (  P.415, 425)
 Did anyone inside the vehicle open
a door during setting the alarm? The sensor detects it and the alarm sounds.
( 
P.65 )
Do one of the following to deactivate
or stop the alarms:
 Unlock the doors.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine. (The alarm will be
deactivated or stopped after a few
seconds.)
 Is the message displayed on the
multi-information display? Check the message on the multi-informa-
tion display. ( 
P.425 )
 When a warning light turns on or a
warning message is displayed, refer
to P.415, 425.The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed
When a problem has occurred
If you have a flat tire

496 What to do if... (Troubleshooting)
LS500_OM_(U)_1810  Slow down the vehicle, drive with
extra caution, and take your vehicle
to the nearest Lexus dealer or
authorized tire dealer as soon as
possible to have the tire replaced.
(  P.429)
 Try the procedure for when the vehi-
cle becomes stuck in mud, dirt, or
snow. (  P.443) The vehicle becomes stuck

4971-1. What to do if... (Troubleshooting)
LS500_OM_(U)_1810 497Alphabetical Index
Alphabetical Index A
A/C
Air conditioning filter ...............................398
Front automatic air conditioning system
...........................................................................313
Micro dust and pollen filter.....................319
Rear automatic air conditioning system
......................................................................... 323
ABS (Anti-lock Brake System).............. 294
Warning light ................................................. 417
Active stabilizer suspension system .... 295
Adaptive Front-lighting System (AFS) .. 181
Adaptive Variable Suspension System295
AFS (Adaptive Front-lighting System) .. 181
Air conditioning filter ................................. 398
Air conditioning system
Air conditioning filter ...............................398
Front automatic air conditioning system
...........................................................................313
Micro dust and pollen filter.....................319
Rear automatic air conditioning system
......................................................................... 323
Airbags
Airbag operating conditions..................... 31
Airbag precautions for your child ........ 34
Correct driving posture .............................23
Curtain shield airbag operating condi-
tions ...................................................................32
Curtain shield airbag precautions ....... 34
Front passenger occupa nt classification
system ............................................................. 40
General airbag precautions ................... 34
Locations of airbags.................................... 29
Modification and disposal of airbags ..37
Side airbag operating conditions ..........32
Side airbag precautions ............................ 34
Side and curtain shield airbags operating
conditions.......................................................32
Side and curtain shield airbags precau-
tions .................................................................. 34
SRS airbags ..................................................... 29 SRS warning light........................................ 416
Alarm ................................................................... 65
Warning buzzer .......................................... 415
Anchor brackets ..................................... 46, 55
Antennas (smart acc ess system with
push-button start)..........................................111
Anti-lock Brake System (ABS).............. 294
Warning light .................................................417
Approach warning...................................... 243
Armrest............................................................ 344
Assist grips ..................................................... 344
Audio system-linked display ...................... 85
Automatic headlight leveling system ... 180
Automatic High Beam ................................182
Automatic light control system................ 179
Automatic transmission .............................. 167
M mode ............................................................ 172
Paddle shift switches ...... .......... ..........171, 172
Snow mode...................................................... 171
Auxiliary boxes ................................... 339, 341
Average fuel economy................................. 82
Average vehicle speed ................................ 82
B
Back-up lights
Replacing light bulbs ............................... 404
Battery
Battery checking ....................................... 380
If the battery is discharged ....................435
Preparing and checking before winter
......................................................................... 300
Warning light ................................................ 416
Blind Spot Monitor (BSM)....................... 250
Boost gauge...................................................... 83
Brake
Brake hold ....................................................... 177
Fluid........................................................ 379, 451
Parking brake ................................................174
Warning light ................................................ 415
Brake assist .................................................... 294
Break-in tips.................................................... 155

498 Alphabetical Index
LS500_OM_(U)_1810 Brightness control
Instrument panel light control ........75, 79
BSM (Blind Spot Monitor)....................... 250
Buzzer
Hands off steering wheel alert (LTA)
............................................................. 236, 236 C
Card key ............................................................ 96
Care
Aluminum wheels ..................................... 358
Exterior .......................................................... 358
Interior ...............................................................361
Seat belts..........................................................361
Cargo capacity............................................... 162
Cargo net ....................................................... 340
Center Display ............................................. 306
Chains ............................................................... 301
Child restraint system
Fixed with a LATCH system .................. 53
Fixed with a seat belt................................... 49
Front passenger occupa nt classification
system ............................................................. 40
Points to remember .................................... 45
Riding with children ..................................... 45
Types of child restraint system installation
method ........................................................... 46
Using an anchor bracket .......................... 55
Child safety
Airbag precautions...................................... 34
Battery precautions ....................... 381, 439
Child restraint system................................. 46
Heated steering wheel and seat heater
precautions................................................ 327
How your child should wear the seat belt
............................................................................ 25
Moon roof precautions ............................146
Panoramic moon roof precautions ... 150
Power window lock switch..................... 144
Power window precautions ................... 143
Rear door child-protectors ................... 103 Removed electronic key battery precau-
tions .............................................................. 400
Seat belt extender precautions.............. 25
Seat belt precautions .................................. 45
Trunk precautions....................................... 104
Child-protectors........................................... 103
Cleaning
Aluminum wheels ..................................... 358
Exterior........................................................... 358
Interior .............................................................. 361
Radar sensor .......................................192, 198
Seat belts ......................................................... 361
Clock ................................................ 73, 76, 345
Clock light ........................................................331
Coat hooks..................................................... 344
Coin holder .................................................... 337
Condenser ..................................................... 378
Console box .................................................. 338
Consumption screen ...................................... 91
Cooling system..............................................377
Engine overheating.................................. 440
Cornering lights .............................................. 181
Cruise control
Dynamic radar cruise control with
full-speed range .......................... 237, 247
Cup holders ................................................... 337
Current fuel consumption .......................... 82
Curtain shield airbags .................................. 29
Customizable features .............................. 466
D
Daytime running light system ................... 179
Defogger
Outside rear view mirrors.......................314
Rear window ..................................................314
Windshield ......................................................314
Differential
Front differential oi l............. ...................... 450
Rear differential oil. .................... ........... ...... 451
Dimension ...................................................... 446
Dinghy towing.................................................163

4991-1. What to do if... (Troubleshooting)
LS500_OM_(U)_1810 499Alphabetical Index
Display
Center Display............................................306
Dynamic radar cruise control with
full-speed range ...................................... 237
Head-up display ........................................... 87
Intuitive parking assist.............................. 257
LTA (Lane Tracing Assist)...................... 231
Multi-information display ..........................80
Parking Support Brake function (rear
pedestrians) ..............................................286
RCD (Rear Camera Detection) ........ 267
RCTA .............................................................. 263
Warning message..................................... 425
Distance until next engine oil
change ......................................................74, 79
Do-it-yourself maintenance .................... 365
Door courtesy lights .....................................331
Door lock
Doors................................................................ 100
Smart access system with push-button
start ..................................................................... 111
Wireless remote control........................... 98
Doors
Automatic door lock ing and unlocking
system ........................................................... 104
Door closer ................................................... 103
Door glasses .................................................. 142
Door lock........................................................ 100
Open door warning bu zzer ........ 101, 103
Outside rear view mirrors ..................... 140
Rear door child-protectors ................... 103
Drive distance .................................................. 82
Drive info 1/Drive info 2 .............................. 82
Driver’s seat position memory
Driving position memory........................ 130
Memory recall function ............................133
Power easy access system .................... 130
Drive-start control ....................................... 155
Driving
Break-in tips .................................................. 155
Correct driving posture .............................23
Driving mode select switch ..................289 Procedures .................................................... 154
Winter drive tips ........................................ 300
Driving information disp lay ........................ 82
Driving position memory........................... 130
Memory recall function............................ 133
Power easy access system .................... 130
Driving range ................................................... 82
Driving support system information display
............................................................................. 85
DRS (Dynamic Rear Steering) .............. 295
Dynamic radar cruise control with
full-speed range ............................. 237, 247
Warning message .....................................245
Dynamic Rear Steering (DRS) .............. 295
E
ECB (Electronically Controlled Brake Sys-
tem) ................................................................ 294
Eco Driving Indicator............................. 83, 91
Eco Driving Indicator Light ........................ 83
EDR (Event data recorder) ............................7
Elapsed time ..................................................... 82
Electric Power Steering (EPS) .............. 295
Warning light ................................................ 418
Electronic key .................................................. 96
Battery-saving function.............................. 112
If the electronic key does not operate
properly .......................................................433
Replacing the battery .............................. 399
Electronic roof sunshade
Jam protection function ........................... 149
Operation ........................................................147
Electronically Controlled Brake System
(ECB) ............................................................ 294
Electronically modulated air suspension
............................................................................291
Emergency flashers .................................... 406
Emergency, in case of
If a warning buzzer sounds.................... 415
If a warning light turns on........................ 415
If a warning message is displayed .....425
If the battery is discharged ....................435

500 Alphabetical Index
LS500_OM_(U)_1810 If the electronic key does not operate
properly....................................................... 433
If the engine will not start .......................430
If the fuel filler door cannot be opened
......................................................................... 432
If the vehicle is trapped in rising water
......................................................................... 407
If you have a flat tire .................................. 429
If you lose your keys................................. 432
If you think something is wrong ........... 413
If your vehicle becomes stuck............. 443
If your vehicle has to be stopped in an
emergency ................................................406
If your vehicle needs to be towed .....409
If your vehicle overheats ........................440
Engine
ACCESSORY mode ...............................166
Compartment ............................................. 373
Engine compartment cover ................. 374
Engine switch.................................................164
Fuel pump shut off system ...................... 414
Hood.................................................................. 371
How to start the engine............................164
Identification number ............................... 447
If the engine will not start .......................430
If your vehicle has to be stopped in an
emergency ................................................406
Ignition switch (engine switch) .............164
Overheating.................................................440
Tachometer ............................................. 73, 76
Engine compartment cover .................... 374
Engine coolant
Capacity ......................................................... 449
Checking ........................................................377
Preparing and checking before winter
........................................................................ 300
Engine coolant temperature gauge 73, 76
Engine immobilizer system ........................ 63
Engine oil
Capacity .........................................................448
Checking ....................................................... 375 Preparing and checking before winter
......................................................................... 300
Warning light ................................................ 416
Engine oil maintenance data ...................377
Engine switch ..................................................164
Auto power off function........................... 166
Changing the engine switch modes . 166
If your vehicle has to be stopped in an
emergency ................................................ 406
EPS (Electric Power Steering) .............. 295
Warning light ................................................ 418
Event data recorder (E DR) ............................7 F
FCTA (Front Cross Traffic Alert) ......... 222
First-aid kit storage belt ..............................341
Flat tire
Tire pressure warning system ............ 384
Floor mats ...........................................................22
Fluid
Automatic transmission ......................... 450
Brake ................................................................. 451
Washer ........................................................... 379
Footwell light ...................................................331
Front automatic air conditioning system
............................................................................313
Front Cross Traffic Alert (FCTA) ......... 222
Front passenger occupant classification
system .............................................................. 40
Front seats
Adjustment ....................................................... 119
Cleaning .......................................................... 361
Correct driving posture ............................ 23
Driving position memory ........................ 130
Head restraints............................................. 135
Memory recall function............................ 133
Power easy access system .................... 130
Refresh system ..............................................124
Seat heaters ..................................................326
Seat position memory .............................. 130
Seat ventilators ............................................326
