LEXUS LS600H 2015 Owners Manual

4696-3. Do-it-yourself maintenance
6
Maintenance and care
LS600hL_U(OM50E41U)
■Front air conditioning filterSet the air conditioning system to recirculated air mode. ( P. 3 4 2 )
The air conditioning filter case cannot be removed with the system in outside
air mode.
Turn the power switch off.
Open the glove box. Remove the partition. ( P. 366)
Remove the filter cover.
Remove the filter case.
Air conditioning filter
The air conditioning filter must be changed regularly to maintain air
conditioning efficiency.
Removal method
1
2
3
34
5

4706-3. Do-it-yourself maintenance
LS600hL_U(OM50E41U)
Remove the air conditioning
filter from the filter case and
replace it with a new one.
The “UP” marks shown on the fil-
ter and the filter case should be
pointing up.
Reset the air conditioning filter maintenance data. ( P. 471)
■Rear air conditioning filter
Turn the power switch off.
Open the trunk lid. Remove
the filter cover.
Remove the air conditioning
filter and replace it with a new
one.
The “ UP” mark shown on the filter
should be pointing up.
6
7
1
2
33

4716-3. Do-it-yourself maintenance
6
Maintenance and care
LS600hL_U(OM50E41U)
■Checking interval
Front air conditioning filter
Inspect and replace the air conditioning fil ter when a message is appeared on the
multi-information display. In dusty areas or areas with heavy traffic flow, early
replacement may be required. (For sche duled maintenance information, please
refer to the “Owner’s Manual Supplement” or “Scheduled Maintenance”.)
Rear air conditioning filter
Replace every 9000 miles (15000 km).
■If air flow from the vents decreases dramatically
The filter may be clogged. Check the filter and replace if necessary.
■After changing the front air conditioning filter
The front air conditioning filter maintenanc e data should be reset. Perform the fol-
lowing procedures:
Turn the power switch to ON mode.
Press and hold (on the air conditioning panel) for 4 seconds or more.
A buzzer will sound to indicate that the maintenance data has been successfully
reset.
■Rear air conditioning filter
If it is necessary to clean or replace the filter, contact your Lexus dealer.
■Climate control seat filter
Filters are installed in the seats. When it is necessary to clean or replace the filters,
contact your Lexus dealer.
1
2
NOTICE
■When using the air conditioning system
Make sure that a filter is always installed.
Using the air conditioning system without a filter may cause damage to the system.

4726-3. Do-it-yourself maintenance
LS600hL_U(OM50E41U)●
Flathead screwdriver
●Small flathead screwdriver
●Lithium battery CR1632
Take out the mechanical key.
Remove the cover.
To prevent damage to the key, cover
the tip of the screwdriver with a rag.
Remove the depleted battery.
Insert a new battery with the “+” termi-
nal facing up.
Electronic key battery
Replace the battery with a new one if it is depleted.
You will need the following items:
Replacing the battery
1
2
3

4736-3. Do-it-yourself maintenance
6
Maintenance and care
LS600hL_U(OM50E41U)
■Use a CR1632 lithium battery
●Batteries can be purchased at your Lexus dealer, local electrical appliance shops
or camera stores.
●Replace only with the same or equivalent type recommended by the manufacturer.
●Dispose of used batteries according to local laws.
■When the card key battery needs to be replaced (if equipped)
The battery for the card key is available only at Lexus dealers. Your Lexus dealer can
replace the battery for you.
■If the electronic key battery is depleted
The following symptoms may occur:
●The smart access system with push-button start and wireless remote control will
not function properly.
●The operational range will be reduced.
CAUTION
■Removed battery and other parts
These parts are small and if swallowed by a child, they can cause choking. Keep
away from children. Failure to do so could result in death or serious injury.
NOTICE
■For normal operation after replacing the battery
Observe the following precautions to prevent accidents:
●Always work with dry hands.
Moisture may cause the battery to rust.
●Do not touch or move any other co mponent inside the remote control.
●Do not bend either of the battery terminals.

4746-3. Do-it-yourself maintenance
LS600hL_U(OM50E41U)
Turn the power switch off.
Open the fuse box cover.
Engine compartment (type A fuse box)
Remove the engine compartment
cover ( P. 440) and push the tab
in and lift the lid off.
Engine compartment (type B fuse box)
Remove the engine compartment
cover ( P. 440) and push the tab
in and lift the lid off.
Engine compartment (type C fuse box)
Remove the engine compartment
cover ( P. 440) and push the tab
in and lift the lid off.
Checking and replacing fuses
If any of the electrical components do not operate, a fuse may have
blown. If this happens, check and replace the fuses as necessary.
1
2

4756-3. Do-it-yourself maintenance
6
Maintenance and care
LS600hL_U(OM50E41U)
Engine compartment (fuse box near the power control unit)
There are high voltage parts and
wiring near the fuse box. For inspec-
tion and replacement of the fuses,
contact your Lexus dealer.
Driver’s side instrument panel
Remove the lid.
Passenger’s side instrument panel
Remove the lid.

4766-3. Do-it-yourself maintenance
LS600hL_U(OM50E41U)
Trunk (type A fuse box)
Remove the 12-volt battery cover
( P. 450) and then remove the lid.
Trunk (type B fuse box)
Remove the cover.
Trunk (type C fuse box)
Remove the 12-volt battery cover
( P. 450) and then remove the
terminal cover.
Remove the fuse with the pullout
tool.
Only type A fuse can be removed
using the pullout tool.
3

4776-3. Do-it-yourself maintenance
6
Maintenance and care
LS600hL_U(OM50E41U)
Check if the fuse is blown.Normal fuse
Blown fuse
Type A and B:
Replace the blown fuse with a new fuse of an appropriate amperage rating. The
amperage rating can be found on the fuse box lid.
Type C and D:
Contact your Lexus dealer.
4
1
2
Ty p e AType B
Ty p e CType D

4786-3. Do-it-yourself maintenance
LS600hL_U(OM50E41U)
■After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb may need
replacement. (P. 4 8 1 )
●If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer.
■If there is an overload in a circuit
The fuses are designed to blow, protecting the wiring harness from damage.
CAUTION
■To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failure to do so may cause damage to the vehicle, and possibly a fire or injury.
●Never use a fuse of a higher amperage rating than that indicated, or use any
other object in place of a fuse.
●Always use a genuine Lexus fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
●Do not modify the fuses or fuse boxes.
■Fuse box near the power control unit
Never check or replace the fuses as there are high voltage parts and wiring near
the fuse box.
Doing so may cause electric shock, resulting in death or serious injury.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your Lexus
dealer as soon as possible.
