LEXUS LS600H 2015 Owners Manual

589
9
For owners
LS600hL_U(OM50E41U)
Assurez-vous que le véhicule est doté d’un réservoir d’essence com-
plet et que la zone située autour des feux avant n’est pas déformée.
Garez le véhicule sur un sol de niveau.
Installez-vous dans le siège conducteur.
Donnez plusieurs impu lsions au véhicule.
À l’aide d’un tournevis cruci-
forme, tournez la vis A dans
n’importe quel sens.
Mémorisez le sens dans lequel vous
avez tourné et le nombre de tours.
Tournez la vis B du même nom-
bre de tours dans le même sens
qu’à l’étape .
Si vous n’arrivez pas à régler les feux
avant en procédant de la sorte, con-
fiez votre véhicule à votre concession-
naire Lexus pour qu’il règle le faisceau
des feux avant.
Avant de vérifier le régl age du faisceau des phares
Réglage du faisceau des phares
1
2
3
4
1
2
1

590
LS600hL_U(OM50E41U)

591
Index
LS600hL_U(OM50E41U)What to do if...
(Troubleshooting)............................... 592
Alphabetical index.................................598
For information regarding the equipment listed below, refer to “NAVIGATION
AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
• Navigation system
• Audio/visual system
• Rear seat entertainment system • Intuitive parking assist
• Lexus parking
assist monitor

592
LS600hL_U(OM50E41U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys
can be made by your Lexus dealer. ( P. 122)
●If you lose your electronic keys, the risk of vehicle theft
increases significantly. Contact your Lexus dealer immediately.
( P. 1 2 4 )
●Is the electronic key battery weak or depleted? ( P. 4 7 2 )
●Is the power switch in ON mode?
When locking the doors, turn the power switch off. ( P. 217)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the elec-
tronic key on your person.
●The function may not operate pr operly due to the condition of
the radio wave. ( P. 1 3 4 )
If you have a problem, check the following before contacting your
Lexus dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked

593What to do if... (Troubleshooting)
LS600hL_U(OM50E41U)●
Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when
the lock is set. Open the re
ar door from outside and then
unlock the child-protector lock. ( P. 1 4 6 )
●The function to prevent the electronic key from being left inside
the trunk will operate and you ca n open the trunk as usual. Take
the key out from the trunk. ( P. 127)
The rear door cannot be opened
The trunk lid is closed with the electronic key left inside

594What to do if... (Troubleshooting)
LS600hL_U(OM50E41U)●
Did you press the power switch
while firmly depressing the
brake pedal? ( P. 2 1 6 )
●Is the shift lever in P? ( P. 2 1 6 )
●Is the electronic key anywhere detectable inside the vehicle?
( P. 1 2 9 )
●Is the steering wheel unlocked? ( P. 2 1 8 )
●Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary
way. ( P. 5 2 6 )
●Is the 12-volt battery discharged? ( P. 5 2 7 )
●Is the power switch in ON mode?
If you cannot release the shift lever by depressing the brake
pedal with the power switch in ON mode ( P. 5 1 9 )
●It is locked automatically to prevent theft of the vehicle.
( P. 218)
If you think something is wrong
The hybrid system does not start
The shift lever cannot be shifted from P even if you depress the
brake pedal
The steering wheel cannot be turn ed after the hybrid system is
stopped

595What to do if... (Troubleshooting)
LS600hL_U(OM50E41U)●
Is the window lock switch pressed?
The power window except for the one at the driver’s seat can-
not be operated if the window
lock switch is pressed. (P. 1 8 9 )
●The auto power off function will be operated if the vehicle is left
in ACCESSORY mode for a period of time. ( P. 218)
●The seat belt remind er light is flashing
Are the driver and the front passenger wearing the seat belts?
( P. 4 9 6 )
●The parking brake indicator is on
Is the parking brake released? ( P. 2 2 8 )
Depending on the situation, ot her types of warning buzzer may
also sound. ( P. 493, 503)
The windows do not open or close by operating the power win-
dow switches
The power switch is turned off automatically
A warning buzzer sounds during driving

596What to do if... (Troubleshooting)
LS600hL_U(OM50E41U)●
Did anyone inside the vehicle op
en a door during setting the
alarm?
The sensor detects it and the alarm sounds. ( P. 9 0 )
Do one of the following to stop the alarms:
• Unlock the doors or open the trunk.
• Turn the power switch to ACCESSORY or ON mode, or start the hybrid system.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display.
( P. 503)
●When a warning light turns on or a warning message is dis-
played, refer to P. 493, 503.
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
A warning light turns on or a warning message is displayed

597What to do if... (Troubleshooting)
LS600hL_U(OM50E41U)●
Vehicles with a spare tire
Stop the vehicle in a safe place an
d replace the flat tire with the
spare tire. ( P. 506)
●Vehicles with run-flat tires
Slow down and drive with extra ca ution. Take your vehicle to the
nearest Lexus dealer or authorized tire dealer to have the flat
tire replaced. ( P. 515)
●Try the procedure for when th e vehicle becomes stuck in mud,
dirt, or snow. ( P. 535)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

598
LS600hL_U(OM50E41U)
Alphabetical index
Alphabetical index
A/CAir conditioning filter....................... 469
Front automatic air conditioning system ......................336
Rear air conditioning system......... 351
ABS (Anti-lock Brake System)....... 289 Function ................................................. 289
Warning light .......................................494
Adaptive Front-lighting System (AFS) ...................................................... 235
AFS (Adaptive Front-lighting System) .................................................. 235
Air conditioning filter .......................... 469
Air conditioning system Air conditioning filter....................... 469
Front automatic air conditioning system ..................................................336
Rear air conditioning system......... 351 Airbags ......................................................... 42
Airbag operating conditions .......... 50
Airbag precautions for your child ....................................... 45
Airbag warning light ........................ 494
Correct driving posture .................... 34
Curtain shield airbag operating conditions ......................... 51
Curtain shield airbag precautions .......................................... 45
Front passenger occupant classification system......................... 55
General airbag precautions ........... 45
Locations of airbags.............................42
Modification and disposal of airbags............................................... 49
Side airbag operating conditions ............................................... 51
Side airbag precautions .................... 45
Side and curtain shield airbags operating conditions ......................... 51
Side and curtain shield airbags precautions .......................................... 45
SRS airbags ..............................................42
Alarm Alarm .......................................................... 90
Warning buzzer.................... 493, 503
Anchor brackets...............................66, 67
Antennas (smart access system with push-button start) ..................... 128
Anti-lock Brake System (ABS) ...... 289 Function .................................................. 289
Warning light ....................................... 494
A
