2372-4. Using other driving systems
2
When driving
LX570_OM_OM60L21U_(U) ■ Changing the vehicle-to-vehicle distance
Pressing the button changes the
vehicle-to-vehicle distance as
follows:
Long
Medium
Short The vehicle-to-vehicle distance
is set automatically to long
mode when the “ENGINE
START STOP” switch is turned
to IGNITION ON mode.
If a vehicle is running ahead of
you, the preceding vehicle mark
will also be displayed.
■ Vehicle-to-vehicle distance settings
Select a distance from the tabl e below. Note that the distances
shown correspond to a vehicle sp eed of 50 mph (80 km/h). Vehi-
cle-to-vehicle distance increases/decreases in accordance with
vehicle speed. Preceding vehicle mark
Distance options Vehicle-to-vehicle distance
Long Approximately 220 ft. (65 m)
Medium Approximately 130 ft. (40 m)
Short Approximately 100 ft. (30 m)

2402-4. Using other driving systems
LX570_OM_OM60L21U_(U) Example of follow-up cruising
When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the
speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis-
tance set by the driver.
Example of acceleration
When there are no longer any vehicl es ahead driving slower than the
set speed The system accelerates until the set speed is reached. The system then
returns to constant speed cruising.
Approach warning
When your vehicle is too close to a vehicle ahead, and sufficient auto-
matic deceleration via th e cruise control is not po ssible, the display will
flash and the buzzer will sound to al ert the driver. An example of this
would be if another driver cuts in fron t of you while you are following a
vehicle. Apply the brakes to ensure appropriate vehicle-to-vehicle dis-
tance.
■ Warnings may not occur when
In the following instances, there is a possibility that the warnings will not
occur:
● When the speed of the vehicle ahead matches or exceeds your
vehicle speed
● When the vehicle ahead is traveling at an extremely slow speed
● Immediately after the cruise control speed was set
● At the instant the accelerator is applied

2492-4. Using other driving systems
2
When driving
LX570_OM_OM60L21U_(U) Intuitive parking assist 
 : If equippedThe distance from your vehicle to nearby obstacles when parallel parking
or maneuvering into a garage is measured by the sensors and communi-
cated via the multi-information display, touch screen and a buzzer. Always
check the surrounding area when using this system.
■ Sensor types
Front corner sensors
Rear corner sensors
Rear center sensors
■ Intuitive parking assist switch
Turns the Intuitive parking assist
on/off. When on, the indicator light
comes on and the buzzer
sounds to inform the driver that
the system is operational.
To turn the system off, press the
switch again.

2502-4. Using other driving systems
LX570_OM_OM60L21U_(U) ■ Multi-information display
Front corner sensor detec-
tion
Rear corner sensor detection
Rear center sensor detection
■ Touch screen
When the rear view monitor,
Lexus parking assist monitor
or the wide view front & side
monitor is not displayed A graphic is automatically dis-
played when an obstacle is
detected. The screen can be set
so that the graphic is not dis-
played. ( 
P. 2 5 5 )
When the rear view monitor,
Lexus parking assist monitor
or the wide view front & side
monitor is displayed (insert
display) A simplified image is displayed
on the touch screen when an
obstacle is detected.

2512-4. Using other driving systems
2
When driving
LX570_OM_OM60L21U_(U) Sensor detection display, obstacle distance
■ Corner sensors Approximate
distance to obstacle Multi-
information
display Touch screen
Insert display
Front:
1.6 ft. (50 cm) to
1.2 ft. (37.5 cm)
Rear:
2.0 ft. (60 cm) to
1.5 ft. (45 cm) (continuous) (continuous) (blinking)
Front:
1.2 ft. (37.5 cm) to
0.8 f t. (25 cm)
Rear:
1.5 ft. (45 cm) to
1.0 ft. (30 cm) (continuous) (continuous) (blinking rapidly)
Front:
Less than
0.8 f t. (25 cm)
Rear:
Less than
1.0 ft. (30 cm) (blinking) (continuous) (continuous)

2522-4. Using other driving systems
LX570_OM_OM60L21U_(U) ■ Rear center sensors Approximate distance
to obstacle Multi-information
display To u c h s c r e e n
(insert display)
4.9 ft. (150 cm) to
2.6 ft. (80 cm)
(continuous) (blinking slowly)
2.6 ft. (80 cm) to
2.1 ft. (65 cm)
(continuous) (blinking)
2.1 ft. (65 cm) to
1.6 ft. (50 cm)
(continuous) (blinking rapidly)
Less than
1.6 ft. (50 cm)
(blinking) (continuous)

2552-4. Using other driving systems
2
When driving
LX570_OM_OM60L21U_(U) Setting up intuitive parking assist
You can change the warning beep volume and touch screen operating
conditions.
Press the “SETUP” button.
Touch “Vehicle” on the “Setup” screen.
Touch “Lexus Park Assist” on the “Vehicle Settings” screen.
Alert volume setting
Display on/off
Alert distance setting
Make sure to save after changing
settings.
■ Alert volume setting
The alert volume can be adjusted.
Touch “1” to “5” on the “L EXUS Park Assist settings”.
Touch “Save”. STEP 1
STEP 2
STEP 3
STEP 1
STEP 2

2562-4. Using other driving systems
LX570_OM_OM60L21U_(U) ■ Display on/off setting
On or off can be selected for intuitive parking assist display.
Touch “Display Off”. When the “Display Off” indicator is turned on, the disp lay of intuitive
parking assist will be off. Touch “Display Off” again to turn the display of
intuitive parking assist on.
Touch “Save”.
■ Alert distance setting
Front or rear center sensors display and tone indication can be set.
Touch “Rear”. Long distance or short di stance can be selected.
Touch “Save”.■
The intuitive parking assist can be operated when ●
Front corner sensors:
• The “ENGINE START STOP” switch is in IGNITION ON mode.
• The shift lever is in a position other than “P”.
• The vehicle speed is less than approximately 6 mph (10 km/h). ●
Rear corner and rear center sensors:
• The “ENGINE START STOP” switch is in IGNITION ON mode.
• The shift lever is in “R”.■
Intuitive parking assist display
When an obstacle is detected while the rear view monitor system, Lexus parking
assist monitor or wide view front & side monitor is in use, the warning indicator will
appear in the top right of the screen even if the display setting has been set to off.STEP 1
STEP 2
STEP 1
STEP 2

2572-4. Using other driving systems
2
When driving
LX570_OM_OM60L21U_(U) ■
Sensor detection information ●
The sensor’s detection areas are limited to the areas around the vehicle’s front
corner and rear bumpers. ●
Certain vehicle conditions and the su rrounding environment may affect the
ability of the sensor to correctly detect obstacles. Particular instances where this
may occur are listed below.
• There is dirt, snow or ice on the sensor. (Wiping the sensors will resolve this
problem.)
• The sensor is frozen. (Thawing the area will resolve this problem.)
In especially cold weather, if a sensor is frozen the screen may show an abnor-
mal display, or obstacles may not be detected.
• The sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle engines,
air brakes of large vehicles, or other loud noises producing ultrasonic waves.
• There is another vehicle equipped with parking assist sensor s in the vicinity.
• The sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or wireless antenna.
• Towing eyelets are installed.
• The bumper or sensor receives a strong impact.
• The vehicle is approaching a tall or curved curb.
• In harsh sunlight or intense cold weather
•The area directly under th e bumpers is not detected.
• If obstacles draw too close to the sensor.
• A non-genuine Lexus suspension (low ered suspension etc.) is installed.
• People may not be detected if they are wearing certain types of clothing.
In addition to the examples above, there are instances in which, because of their
shape, signs and other object s may be judged by the sensor to be closer than they
are.

2582-4. Using other driving systems
LX570_OM_OM60L21U_(U) ●
The shape of the obstacle may prevent th e sensor from detecting it. Pay particu-
lar attention to the following obstacles:
• Wires, fences, ropes, etc.
• Cotton, snow and other materi als that absorb sound waves
• Sharply-angled objects
•Low obstacles
• Tall obstacles with upper sections projec ting outwards in the direction of your
vehicle●
The following situations may occur during use.
• Depending on the shape of the obstacle and other factors, the detection dis-
tance may shorten, or dete ction may be impossible.
• Obstacles may not be detected if they are too close to the sensor
• There will be a short delay between obstacle detection and display. Even at
slow speeds, there is a possibility that the obstacle will come within the sen-
sor’s detection areas before the display is shown and the warning beep
sounds.
• Thin posts or objects lower than the sensor may not be detected for collision
when approached, even if they have been detected once.
• It might be difficult to hear beeps due to the volume of audio system or air
flow noise of air conditioning system.■
If a message is displayed on the multi-information display
 P. 8 3 2■
Certification (Canada only)
This ISM device complies with Canadian ICES-001.
