1712-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) CAUTION ●
When stopped on an inclined surface, use the brake pedal and parking brake to
prevent the vehicle from rolling backward or forward and causing an accident.●
Do not adjust the position of the steering wheel, the seat, or the inside or outside
rear view mirrors while driving.
Doing so may result in a loss of vehicle control that can cause accidents that may
result in death or serious injury. ●
Always check that all passengers’ arms, heads or other parts of their bodies are
not outside the vehicle, as this may result in death or serious injury. ●
Do not drive in excess of the speed limit. Even if the legal speed limit permits it, do
not drive over 85 mph (140 km/h) unless your vehicle has high-speed capability
tires. Driving over 85 mph (140 km/h) may result in tire failure, loss of control
and possible injury. Be sure to consult a tire dealer to determine whether the tires
on your vehicle are high-speed capability tires or not before driving at such
speeds. ●
When crossing rivers, turn off height co ntrol after putting the vehicle height in
high mode, and drive at 18 mph (30 km/h) or less. Otherwise the vehicle height
may change due to the automatic leveling function, resulting in an accident.
(  P. 320)■
When driving on slippery road surfaces ●
Sudden braking, acceleration and steering may cause tire slippage and reduce
your ability to control the vehi cle, resulting in an accident.●
Sudden acceleration, engine braking due to shifting, or changes in engine speed
could cause the vehicle to skid, resulting in an accident. ●
After driving through a puddle, lightly de press the brake pedal to make sure that
the brakes are functioning properly. Wet brake pads may prevent the brakes
from functioning properly. If the brakes on only one side are wet and not func-
tioning properly, steering control may be affected, resulting in an accident.

1722-1. Driving procedures
LX570_OM_OM60L96U_(U) CAUTION■
When shifting the shift lever
Be careful not to shift th e shift lever with the acc elerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an
accident and result in death or serious injury. ■
If you hear a squealing or scraping no ise (brake pad wear limit indicators)
Have your Lexus dealer check and replace the brake pads as soon as possible.
The rotor damage can result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads and/or
that of the brake discs are exceeded. ■
When the vehicle is stopped ●
Do not race the engine.
If the vehicle is in any gear other than “P” or “N”, the vehicle may accelerate sud-
denly and unexpectedly, and may cause an accident. ●
Do not leave the vehicle with the engine running for a long time.
If such a situation cannot be avoided, park the vehicle in an open space and
check that exhaust fumes do no t enter the vehicle interior.●
In order to prevent accidents due to the vehicle rolling away, always keep
depressing the brake pedal while the engi ne is running, and apply the parking
brake as necessary. ●
If the vehicle is stopped on an incline, in order to prevent accidents caused by the
vehicle rolling forward or backward, always depress the brake pedal and
securely apply the parking brake as needed. ●
Avoid revving or racing the engine.
Running the engine at high speed while the vehicle is stopped may cause the
exhaust system to overheat, which could result in a fire if combustible material is
nearby.

1732-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) CAUTION■
When the vehicle is parked ●
Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehi-
cle when it is in the sun.
Failure to do so may result in the following:
• Gas may leak from a cigarette lighter or spray can, and may lead to a fire.
• The temperature inside the vehicle may cause the plastic lenses and plastic
material of eye glasses to deform or crack.
• Soft drink cans may fracture, causing the contents to spray over the interior of
the vehicle, and may also cause a short circuit in the vehicle’s electrical com-
ponents.●
Always apply the parking brake, shift the shift lever to “P”, stop the engine and
lock the vehicle.
Do not leave the vehicle unattend ed while the engine is running.●
If the shift lever is moved before the low speed four-wheel drive indicator turns
on/off, the transfer mode may not be sh ifted completely. The transfer mode dis-
engages both the front and rear driveshafts from the powertrain and allows the
vehicle to move regardless of the shift position. (At this time, the indicator blinks
and the buzzer sounds.)
Therefore, the vehicle is free to roll even if the automatic transmission is in “P”.
You or someone else could be seriously injured. You must complete the shifting
of the transfer mode. (  P. 332)●
Do not touch the exhaust pipe while the engine is running or immediately after
turning the engine off.
Doing so may cause burns. ●
Do not leave the engine running in an ar ea with snow build-up, or where it is
snowing. If snowbanks build up around the vehicle while the engine is running,
exhaust gases may collect and enter the vehicle. This may lead to death or a seri-
ous health hazard.

1742-1. Driving procedures
LX570_OM_OM60L96U_(U) CAUTION■
Exhaust gases
Exhaust gases include harmful carbon monoxide (CO) that is colorless and odor-
less. Inhaling exhaust gases may lead to death or a serious health hazard.●
If the vehicle is in a poorly ventilated ar ea, stop the engine. In a closed area, such
as a garage, exhaust gases may collect and enter the vehicle. This may lead to
death or a serious health hazard. ●
The exhaust should be checked occasionally. If there is a hole or crack caused by
corrosion, damage to a joint or abnormal ex haust noise, be sure to have the vehi-
cle inspected and repaired by your Lexus dealer. Failure to do so may allow
exhaust gases to enter the vehicle, result ing in death or a serious health hazard.■
When taking a nap in the vehicle
Always turn the engine off.
Otherwise, you may accidentally move the shift lever or depress the accelerator
pedal, which could cause an accident or fire due to abnormal engine overheating.
Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may
collect and enter the vehicle, leading to death or a serious health hazard. ■
When braking the vehicle ●
When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and may cause one side of
the vehicle to brake differently than the other side. Also the parking brake may
not securely hold the vehicle. ●
If the power brake assist function does not operate, do not follow other vehicles
closely and avoid hills or shar p turns that require braking.
In this case, braking is still possible, but the brake pedal should be depressed
more firmly than usual. Also, th e braking distance will increase.
Have your brakes fixed immediately. ●
Do not pump the brake peda l if the engine stalls.
Each push on the pedal uses up the reserve for the power-assisted brakes. ●
The brake system consists of 2 individual hydraulic systems: If one of the systems
fails, the other will still operate. In this case, the brake pedal should be depressed
more firmly than usual and the braking distance will increase.
Have your brakes fixed immediately.

1752-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) NOTICE■
When driving the vehicle ●
Do not depress the accelerator and brake pe dals at the same time during driving,
as this may restrain driving torque. ●
Do not use the accelerator pedal or depress accelerator and brake pedals
together to hold the vehicle on a hill.■
When parking the vehicle
Always put the shift lever in “P”. Failure to do so may cause the vehicle to move or
the vehicle may accelerate suddenly if the accelerator pedal is accidentally
depressed. ■
Avoiding damage to vehicle parts ●
Do not turn the steering wheel fully in either direction and hold it there for a long
time.
Doing so may damage the power steering pump. ●
When driving over bumps in the road, driv e as slowly as possible to avoid damag-
ing the wheels, underside of the vehicle, etc.

1762-1. Driving procedures
LX570_OM_OM60L96U_(U) NOTICE■
If you get a flat tire while driving
A flat or damaged tire may cause the following situations. Hold the steering wheel
firmly and gradually press the brak e pedal to slow down the vehicle.●
It may be difficult to control your vehicle. ●
The vehicle will make abnormal sounds.●
The vehicle will behave abnormally.
Replace a flat tire with a new one. (  P. 859)■
When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may cause
the following serious damage to the vehicle. ●
Engine stalling ●
Short in electrical components ●
Engine damage caused by water immersion
In the event that you drive on a flooded ro ad and the vehicle is flooded, be sure to
have your Lexus dealer check the following. ●
Brake function ●
Changes in quantity and quality of oil an d fluid used for the engine, transmission,
transfer, differentials, etc. ●
Lubricant condition for the propeller shaft, bearings and suspension joints (where
possible) and the function of all joints, bearings, etc.

1772-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) Engine (ignition) switch Performing the following operations when carrying the electronic key on
your person starts the engine or changes “ENGINE START STOP” switch
modes.
■ Starting the engine
Check that the parking brake is set.
Check that the shift lever is set in “P”.
Sit in the driver’s seat and firmly depress the brake pedal. The “ENGINE START STOP” switch indicator turns green.
Press the “ENGINE START
STOP” switch. The engine can be started from
any “ENGINE START STOP”
switch mode.
Continue depressing the brake
pedal until the engine is com-
pletely started. The engine will
crank until it starts or for up to
30 seconds, whichever is less.STEP 1
STEP 2
STEP 3
STEP 4

1782-1. Driving procedures
LX570_OM_OM60L96U_(U) ■ Changing “ENGINE START STOP” switch mode
Modes can be changed by pres sing the “ENGINE START STOP”
switch with the brake pedal release d. (The mode changes each time
the switch is pressed.)
OFF
* Emergency flashers can be
used.
ACCESSORY mode Some electrical components
such as the audio system can be
used.
The “ENGINE START STOP”
switch indicator turns amber.
IGNITION ON mode All electrical components can
be used.
The “ENGINE START STOP”
switch indicator turns amber.
* : If the shift lever is in a position othe r than “P” when turn ing off the engine,
the “ENGINE START STOP” switch will be turned to ACCESSORY
mode, not to OFF.

1792-1. Driving procedures
2
When driving
LX570_OM_OM60L96U_(U) ■
Operation of the “ENG INE START STOP” switch
When operating the “ENGINE START STOP ” switch, one short, firm press is
enough. If the switch is pressed improp erly, the engine may not start or the
“ENGINE START STOP” switch mode may not change. It is not necessary to press
and hold the switch. ■
When the steering lock cannot be released
■
If the engine does not start
The engine immobilizer system may not have been deactivated. (  P. 119)
Contact your Lexus dealer. ■
When the “ENGINE START STOP” switch indicator flashes in amber
The system may be malfunctioning. Have the vehicle inspected by your Lexus
dealer immediately. ■
Auto power off function
If the vehicle is left in ACCESSORY mode for more than 20 minutes with the shift
lever in P, the “ENGINE START STOP” switch will automatically turn off. However,
this function cannot entirely prevent battery discharge. Do not leave the vehicle
with the “ENGINE START STOP” switch in ACCESSORY mode for long periods
of time when the engine is not running. ■
Electronic key battery depletion
 P. 42■
When the electronic key battery is discharged
 P. 872■
Conditions affecting operation
 P. 40 The green indicator light on the “ENGINE
START STOP” switch will flash and a mes-
sage will be shown on the multi-information
display. Press the “ENGINE START STOP”
switch again while turning the steering wheel
left and right.

1802-1. Driving procedures
LX570_OM_OM60L96U_(U) ■
Note for the entry function
 P. 43
CAUTION■
When starting the engine
Always start the engine while sitting in th e driver’s seat. Do not depress the acceler-
ator while starting the engi ne under any circumstances.
Doing so may cause an accident resulting in death or serious injury. ■
Stopping the engine in an emergency
If you want to stop the engine in an emergency while driving the vehicle, press and
hold the “ENGINE START STOP” switch fo r more than 2 seconds, or press it
briefly 3 times or more in succession. (  P. 883)
However, do not touch the “ENGINE START STOP” switch while driving except in
an emergency. Turning the engine off while driving will not cause loss of steering or
braking control, but the power assist to these systems will be lost. This will make it
more difficult to steer and brake, so you should pull over and stop the vehicle as
soon as it is safe to do so.
NOTICE■
To prevent battery discharge
Do not leave the “ENGINE START STOP ” switch in ACCESSORY or IGNITION
ON mode for long periods of ti me without the engine running.■
When starting the engine ●
Do not race a cold engine. ●
If the engine becomes difficult to start or stalls frequently, have your vehicle
checked by your Lexus dealer immediately.■
Symptoms indicating a malfunction with the “ENGINE START STOP” switch
If the “ENGINE START STOP” switch seem s to be operating somewhat differently
than usual, such as the swit ch sticking slightly, there may be a malfunction. Contact
your Lexus dealer immediately.
