LEXUS LX570 2016 Owners Manual

LX570_OM_OM60N01U_(U)
4215-4. Using the interior lights
5
Interior features
■Illuminated entry system
The lights automatically turn on/off according to engine switch mode, the presence of the
electronic key, whether the doors are locked/unlocked, and whether the doors are
open/closed.
■To prevent battery discharge
If the interior lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes:
■Customization
Settings (e.g. adjust the time elapsed before the interior light s automatically turn off) can
be changed. (Customizable features: P. 5 8 5 )
Personal lights
Front Rear
Turns the lights on/off (touch the lights) Turns the lights on/off
NOTICE
To prevent battery discharge, do not leave the lights on longer than necessary when the
engine is not running.

422
LX570_OM_OM60N01U_(U)5-5. Using the storage features
List of storage features
Auxiliary boxes (
P. 4 2 7 )
Card holder ( P. 4 2 6 )
Overhead console ( P. 4 2 4 )
Glove box ( P. 4 2 3 )
Bottle holders ( P. 4 2 6 )
Door pockets
Cup holders ( P. 4 2 5 ) Console box (if equipped)
(
 P. 4 2 3 )
Cool box (if equipped) ( P. 4 3 1 )
Auxiliary box (if equipped)
(  P. 4 2 7 )
Wireless charger (if equipped)
(  P. 4 3 6 )
WA R N I N G
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the
following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with other
stored items.
●Lighters or spray cans may explode. If they come into contact with other stored items,
the lighter may catch fire or the spray can may release gas, causing a fire hazard.
1
2
3
4
5
6
7
8
9

LX570_OM_OM60N01U_(U)
4235-5. Using the storage features
5
Interior features
Open (push button)
Unlock with the mechanical key
Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail lights are on.
■Removing the separate tray
Your vehicle is equipped with either a console box or cool box.
For vehicles with the cool box, refer to page 431.Press the button to open the lid.
Glove box
1
2
3
Pull out the separate tr ay while releasing the
clips.
WA R N I N G
Keep the glove box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an accident.
Console box (if equipped)
1

424
LX570_OM_OM60N01U_(U)5-5. Using the storage features
Remove the tray.
Press the button.2
WA R N I N G
Keep the console box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an accident.
Overhead console
WA R N I N G
■Items unsuitable for storing
Do not store items heavier than 0.4 lb (0.2 kg).
Doing so may cause the overhead console to open and the items inside may fall out,
resulting in an accident.
■While driving
Do not leave the overhead console open.
Items may fall out and cause injury.

LX570_OM_OM60N01U_(U)
4255-5. Using the storage features
5
Interior features
Front
Press down and release the lid.
Rear
To open, pull down the armrest, press
the button and release the rear cup
holder on the armrest.
Cup holders
WA R N I N G
■Items unsuitable for the cup holders
Do not place anything other than cups or be verage cans in the cup holders. Even with
the lid is closed, items must not be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, and cause injury. If possible , cover hot drinks to prevent burns.
■When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.
NOTICE
■To prevent damage to the cup holders
Stow the cup holders before stowing the rear armrest.

426
LX570_OM_OM60N01U_(U)5-5. Using the storage features
Bottle holders
Front seatsSecond seats
Third seats
NOTICE
■Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bottle holders,
or glasses and paper cups containing liquid. The contents may spill and glasses may
break.
Card holder

LX570_OM_OM60N01U_(U)
4275-5. Using the storage features
5
Interior features
Your vehicle is equipped with either a front auxiliary box type B or wireless
charger.
For vehicles with wireless charger, refer to page 436.
■Front seats
Ty p e A
Press and release the lid.
Type B (if equipped)
Press the lid to open.
■Second seats
Pull down the armrest.
Auxiliary boxes
1

428
LX570_OM_OM60N01U_(U)5-5. Using the storage features
Press the button to release the
lock.
■Third seats
2
WA R N I N G
■While driving
Except for the third seats: Do not leav
e the auxiliary box open while driving.
Items stored in it may fall out and cause death or serious injury in case of an accident or
sudden stop.

429
LX570_OM_OM60N01U_(U)5-5. Using the storage features
5
Interior features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
To hang the cargo net, use the cargo
net hooks and rear tie-down hooks.
The cargo net itself is not included as an
original equipment.
Remove the cover.
Cargo hooks
Cargo net hooks
Storage compartment (if equipped)

430
LX570_OM_OM60N01U_(U)5-5. Using the storage features
Remove the cover. Hold the warning
reflector with the bands.
The warning reflector itself is not
included as an original equipment.
Remove the cover. Hold the first-aid kit
with a band.
The first-aid kit itself
is not included as an
original equipment.
Warning reflector holder
First-aid kit holder
WA R N I N G
●To avoid injury, always return the cargo hooks to their positions when not in use.
●Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant bein g struck by an open auxiliary box or the
items stored inside.
NOTICE
■To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.
