240
LX570_OM_OM60N01U_(U)4-4. Refueling
Pull the lever.
Turn the fuel tank cap slowly and
remove it, then put it into the holder
on the fuel filler door.
After refueling, turn the fuel tank cap
until you hear a click. Once the cap is
released, it will turn slightly in the oppo-
site direction.
NOTICE
■Refueling
Do not spill fuel during refueling.
Doing so may damage the vehicle, such as causing the emission control systems to
operate abnormally or damaging fuel system components or the vehicle’s painted sur-
face.
Opening the fuel tank cap
1
2
Closing the fuel tank cap

632
LX570_OM_OM60N01U_(U)GAS STATION INFORMATION
Fuel filler doorAuxiliary catch lever
P. 2 4 0 P. 4 7 2
Tire inflation pressureFuel filler door openerHood lock release lever
P. 5 6 9 P. 2 4 0 P. 4 7 2
Fuel tank capacity
(Reference) 24.5 gal. (93 L, 20.4 Imp.gal.)
Fuel type
Unleaded gasoline only
P. 5 6 4
Cold tire inflation
pressure P. 5 6 9
Engine oil capacity
(Drain and refill —
reference)With filter
Without filter 7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.5 qt. (7.1 L, 6.2 Imp.qt.)
Engine oil type
“Toyota Genuine Motor Oil” or equivalent
P. 5 6 4
