5317-2. Steps to take in an emergency
LX570_OM_OM60Q78U_(U) 7
When trouble arises ■
If a following message is shown, take appr opriate action and confirm that the message
has disappeared. ( → P. 307)●
“Crawl Not Available Select L4 an d Shift to [D] or [R] Position”●
“Crawl Not Available Check System Operation Conditions” ●
“Turn Assist Function Not Available Check System Operation Conditions”●
“Turn Assist Function Not Available Activate Crawl Control”■
If “Maintenance Required Soon” is shown (U.S.A. only)
Indicates that all maintenance according to the driven distance on the maintenance
schedule
* should be performed soon.
Comes on approximately 4500 miles (7200 k m) after the message has been reset.
If necessary, perform maintenance.
* : Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.■
If “Maintenance Required Visit Your Dealer” is shown (U.S.A. only)
Indicates that all maintenance is required to correspond to the driven distance on the
maintenance schedule
* .
Comes on approximately 5000 miles (8000 km) after the message has been reset.
(The indicator will not work properly unless the message has been reset.)
Perform the necessary maintenance. Please reset the message after the maintenance is
performed ( → P. 465)
* : Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual Supple-
ment” for the maintenance interval applicable to your vehicle.■
If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed. (The indicator will not work
properly unless the message has been reset.)
Check the engine oil, and change if necessary. After changing the engine oil, the mes-
sage should be reset. ( → P. 475)■
If “Oil Maintenance Required Visit Your Dealer” is shown
Indicates that the engine oil should be ch anged. (The indicator will not work properly
unless the message has been reset.)
Check and change the engine o il, and oil filter by your Lexus dealer. After changing the
engine oil, the messag e should be reset. ( → P. 475)■
If “Visit Your Dealer” is shown
The system or part shown on the multi-info rmation display is malfunctioning. Have the
vehicle inspected by your Lexus dealer immediately. ■
Warning buzzer
In some cases, the buzzer ma y not be heard due to being in a noisy location or audio
sound.
NOTICE ■
While the engine oil level warning is displayed
Continued engine operation with low engine oil will damage the engine.

5337-2. Steps to take in an emergency
LX570_OM_OM60Q78U_(U) 7
When trouble arises WARNING ■
Using the tire jack
Improper use of the tire jack may lead to death or serious injuries due to the vehicle
suddenly falling off the jack. ●
Do not use the tire jack for any purpose ot her than replacing tires or installing and
removing tire chains. ●
Only use the tire jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, and do no t use other tire jacks for replacing tires on
this vehicle. ●
Always check that the tire jack is securely set to the jack point.●
Be sure to turn off the 4-Wh eel AHC and stop the engine.●
Do not put any part of your body under the vehicle supported by a jack. ●
Do not start or run the engine while yo ur vehicle is supported by the jack.●
Do not raise the vehicle while someone is in it. ●
When raising the vehicle, do not pu t an object on or under the jack.●
Do not raise the vehicle to a height greater than that required to replace the tire. ●
Use a jack stand if it is necessary to get under the vehicle.
Take particular care when lowering the ve hicle to ensure that no one working on or
near the vehicle will be injured. ■
Using the jack handle
Tighten all the jack handle bo lts securely using a Phillips-he ad screwdriver, to prevent
the extension parts from co ming apart unexpectedly.

5477-2. Steps to take in an emergency
LX570_OM_OM60Q78U_(U) 7
When trouble arises Ensure that the shift lever is in P and depress the brake pedal.
Touch the Lexus emblem side of the
electronic key to the engine switch. When the electronic key is detected, a
buzzer sounds and the engine switch
will turn to IGNITION ON mode.
When the smart access system with
push-button start is deactivated in cus-
tomization setting, the engine switch will
turn to ACCESSORY mode.
Firmly depress the brake pedal and check that is shown on the
multi-information display.
Press the engine switch. In the event that the engine still cannot be started, contact your Lexus dealer.■
Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when stopping
the engine. ■
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the electronic
key battery be replaced immediately when the battery is depleted. ( → P. 503)■
Changing engine switch modes
Release the brake pedal and press the engine switch in step above. The engine does
not start and modes will be changed e ach time the switch is pressed. ( → P. 206)■
Alarm
Using the mechanical key to lock th e doors will not set the alarm system.
If a door is unlocked using the mechanical ke y when the alarm system is set, the alarm
may be triggered. ( → P. 77)■
When the electronic key does not work properly ●
Make sure that the smart access system wi th push-button start has not been deacti-
vated in the customization setting. If it is off, turn the function on.
(Customizable features: → P. 580)●
Check if battery-saving mode is set. If it is set, cancel the function. ( → P. 134)Starting the engine 1
2
3
4
3

550 7-2. Steps to take in an emergency
LX570_OM_OM60Q78U_(U) Start the engine of the second vehicle. Increase the engine speed slightly and
maintain at that level for approximatel y 5 minutes to recharge the battery of
your vehicle.
Open and close any of the doors with the engine switch off.
Maintain the engine speed of the second vehicle and turn the engine switch to
IGNITION ON mode, then start the vehicle’s engine.
Once the vehicle’s engine has started, remove the jumper cables in the exact
reverse order in which they were connected.
Once the engine starts, have the vehicl e checked at your Lexus dealer, as soon
as possible. ■
Starting the engine when the battery is discharged
The engine cannot be started by push-starting. ■
Avoiding a discharged battery ●
Turn off the headlights and the audio system while the engine is off. ●
Turn off any unnecessary electrical componen ts when the vehicle is running at a low
speed for an extended period, such as in heavy traffic, etc. ■
Charging the battery
The electricity stored in the battery will disc harge gradually even when the vehicle is not
in use, due to natural discharge and the draini ng effects of certain electrical appliances. If
the vehicle is left for a long time, the battery may discharge, and the engine may be
unable to start. (The battery recharges automatically during driving.) ■
When the battery is removed or discharged
The power back door mu st be initialized. ( → P. 126)4
5
6
7

5537-2. Steps to take in an emergency
LX570_OM_OM60Q78U_(U) 7
When trouble arises The coolant level is satisfactory if it is between the “F” and “L” lines on the res-
ervoir.
Reservoir
“F” line
“L” line
Radiator cap
Add coolant if necessary. Water can be used in an emergency if
coolant is unavailable.
Start the engine and turn the air conditioning system on to check that the air
conditioning condenser cooling fans op erate and to check for coolant leaks
from the radiator or hoses. The fans operate when the air conditioning system is turned on immediately after a
cold start. Confirm that the fans are operating by checking the fan sound and air flow.
If it is difficult to check these, turn the air conditioning system on and off repeatedly.
(The fans may not operate in freezing temperatures.)
If the fans are not operating:
Stop the engine immediately an d contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the nearest Lexus dealer. 4
1
2
3
4
5
6
7

560
LX570_OM_OM60Q78U_(U) 8-1. Specifications
* : The engine oil capacity is a reference quantity to be used when changing the engine
oil. Warm up and turn off the engine, wait more than 5 minutes, and check the oil level
on the dipstick.Engine Model 5.7L V8 (3UR-FE)
Type 8-cylinder V type, 4-cycle, gasoline
Bore and stroke 3.70 × 4.02 in. (94.0 × 102.0 mm)
Displacement 345.6 cu.in. (5663 cm 3
)
Valve clearance
Automatic adjustment
Drive belt tension
Fuel Fuel type Unleaded gasoline only
Octane rating 91 (Research Octane Number 96) or higher
Fuel tank capacity
(Reference) 24.5 gal. (93 L, 20.4 Imp.gal.)
Lubrication system Oil capacity
(Drain and refill — reference
* )
With filter
Without filter 7.9 qt. (7.5 L, 6.6 Imp.qt.)
7.5 qt. (7.1 L, 6.2 Imp.qt.)

562
LX570_OM_OM60Q78U_(U) 8-1. Specifications
Cooling system Capacity (Reference) 17.1 qt. (16.2 L, 14.3 Imp.qt.)
Coolant type Use either of the following.
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based
non-silicate, non-amine, non-nitrite, and non-
borate coolant with long-life hybrid organic
acid technology
Do not use plain water alone.
Ignition system Spark plug
Make
Gap DENSO SK20HR11
0.043 in. (1.1 mm)
NOTICE ■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Electrical system Battery
Open voltage at 68 ° F
(20 ° C): 12.6 ⎯ 12.8 V Fully charged
12.2 ⎯ 12.4 V Half charged
11.8 ⎯ 12.0 V Discharged
(Voltage is checked 20 minutes after the engine
and all lights are turned off.)
Charging rates 5 A max.

608 What to do if... (Troubleshooting)
LX570_OM_OM60Q78U_(U)What to do if... (Troubleshooting) ●
If you lose your mechanical keys, ne w genuine mechanical keys can be made
by your Lexus dealer. ( → P. 112)●
If you lose your electronic keys, the risk of vehicle theft increases significantly.
Contact your Lexus dealer immediately. ( → P. 114)●
Is the electronic key battery weak or depleted? ( → P. 503)●
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( → P. 206)●
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on your
person. ●
The function may not operate properly du e to the condition of the radio wave.
( → P. 134)
●
Is the child-protector lock set?
The rear door cannot be opened from in side the vehicle when the lock is set.
Open the rear door from outside and then unlock the child-protector lock.
( → P. 118)If you have a problem, check the foll owing before contacting your Lexus
dealer.
The doors cannot be locked, unlocked, opened or closed You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

615Alphabetical index
LX570_OM_OM60Q78U_(U) Coolant..................................................... 562
Capacity .................................................562
Checking................................................478
Preparing and checking
before winter ................................... 382
Cooling system
Engine overheating.......................... 552
Crawl Control ....................................... 307
Cruise control
Cruise control....................................... 281
Dynamic radar cruise control
with full-speed range ....................269
Cup holders ............................................ 423
Curtain shield airbags ........................... 38
Customizable features .......................580
Daytime running light system .......... 222
Defogger
Outside rear view mirrors ............ 405
Rear window ....................................... 405
Windshield ........................................... 405
Differential ............................................... 563
Dimension ...............................................558
Dinghy towing........................................ 204 Display
Crawl Control..................................... 307
Drive information.................................. 94
Dynamic radar cruise control
with full-speed range ................... 269
Fuel consumption information ..... 106
Head-up display ................................. 100
Intuitive parking assist......................288
LDA (Lane Departure Alert)....... 264
Multi-information display.................... 91
Multi-terrain Monitor .........................316
Multi-terrain Select ............................. 312
Warning messages ..........................528
Do-it-yourself maintenance..............470
Door courtesy lights
Location ................................................... 417
Doors
Automatic door locking and
unlocking system............................... 119
Back door................................................ 122
Door glasses ..........................................165
Door lock.................................................. 115
Open door warning buzzer ........ 522
Open door warning light .............. 522
Outside rear view mirrors .............. 162
Rear door child-protectors ............. 118
Side doors ................................................ 115D
* : Refer to
the “NAVIGATION SYSTEM OWNER’S MANUAL”.

617Alphabetical index
LX570_OM_OM60Q78U_(U) Engine
Accessory mode............................... 206
Air cleaner ...............................................471
Compartment...................................... 473
Engine switch ...................................... 205
Exhaust gas precautions ................... 74
Hood ........................................................ 472
How to start the engine ................. 205
Identification number ...................... 559
If the engine will not start................544
If your vehicle has to be
stopped in an emergency ............. 511
Ignition switch (engine
switch) ................................................. 205
Overheating ........................................ 552
Engine compartment cover ............. 474
Engine coolant....................................... 478
Capacity .................................................562
Checking................................................478
Preparing and checking
before winter ................................... 382
Engine coolant temperature
gauge ........................................................ 88
Engine immobilizer system ................. 75
Engine oil ................................................. 475
Capacity ................................................ 560
Checking................................................475
Preparing and checking
before winter ................................... 382 Engine switch (ignition switch) ....... 205
Engine switch light
(ignition switch light)......................... 417
Event data recorder (EDR)................... 10
Exhaust gas precautions ....................... 74
First-aid kit holder ................................ 428
Flat tire ...................................................... 532
Floor mats....................................................26
Fluid
Automatic transmission ..................563
Brake........................................................ 564
Steering .................................................. 564
Washer ...................................................485
Fog lights...................................................229
Replacing light bulbs ...................... 508
Switch ...................................................... 229
Footwell lights .......................................... 417
Four-wheel AHC (Active Height
Control Suspension) ....................... 295
Easy access mode ............................ 297
Disabling the height control ......... 298
Selecting vehicle height.................. 295
Four-wheel drive system
Center differential
lock/unlock .......................................304
Four-wheel drive control
switch ...................................................303
Warning light ....................................... 522
Front automatic air conditioning
system .................................................... 399
Front doors ................................................ 115 F
* : Refer to
the “NAVIGATION SYSTEM OWNER’S MANUAL”.
