TABLE OF CONTENTS4
LX570_OM_OM60R61U_(U)
4-5. Using the driving support systems
Lexus Safety System + ............. 249
PCS (Pre-Collision System) ....................................... 256
LDA (Lane Departure Alert) ............................................ 268
Dynamic radar cruise control with full-speed
range ............................................ 276
Cruise control .............................288
Driving mode select switch .............................................291
Intuitive parking assist.............. 294
4-Wheel AHC (Active Height Control
Suspension)............................... 302
Four-wheel drive system ......... 310
Crawl Control (with Turn Assist function) ..........................314
Multi-terrain Select.....................319
Multi-terrain Monitor............... 323
BSM (Blind Spot Monitor) ..... 370
• BSM function......................... 374
• RCTA function...................... 378
Driving assist systems .............. 384
4-6. Driving tips Winter driving tips ..................... 389
Off-road precau tions............... 393 5-1. Remote Touch screen
Remote Touch/12.3-inch display..........................................400
5-2. Lexus Climate Concierge Lexus Climate Concierge ..... 406
5-3. Using the air conditioning system and defogger
Front automatic air conditioning sy stem ............... 407
Rear air conditioning system........................................... 418
Heated steering wheel/seat heaters/seat ve ntilators ......... 421
5-4. Using the interior lights Interior lights list ......................... 425• Interior lights.......................... 426
• Personal lights........................4275Interior features

8
LX570_OM_OM60R61U_(U)
For your information
Please note that this manual applies to all models and explains all equipment, including
options. Therefore, you may find some expl anations for equipment not installed on your
vehicle.
All specifications provided in this manual are current at the time of printing. However,
because of the Lexus policy of continual pr oduct improvement, we reserve the right to
make changes at any time without notice.
Depending on specifications, th e vehicle shown in the illustrations may differ from your
vehicle in terms of color and equipment.
Approximately five hours after the engine is turned off, you may hear sound coming from
under the vehicle for several minutes. This is the sound of a fuel evaporation leakage
check and, it does not indicate a malfunction.
A wide variety of non-genuine spare parts and accessories for Lexus vehicles are cur-
rently available in the market. You should kn ow that Toyota does not warrant these prod-
ucts and is not responsible fo r their performance, repair, or replacement, or for any
damage they may cause to, or adverse effect they may have on, your Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus products. Modification with
non-genuine Lexus products could affect its performance, safety or durability, and may
even violate governmental regulations. In addition, damage or performance problems
resulting from the modification may not be covered under warranty.
The installation of a mobile two-way radio system in your vehicle could affect electronic
systems such as:
●Multiport fuel injection system/seque ntial multiport fuel injection system
●Lexus Safety System +
●Cruise control system
●Anti-lock brake system
●SRS airbag system
●Seat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special instruc-
tions regarding installation of a mobile two-way radio system.
Main Owner’s Manual
Noise from under vehicle after turning off the engine
Accessories, spare parts and modification of your Lexus
Installation of a mobile two-way radio system

20Pictorial index
LX570_OM_OM60R61U_(U)
Audio remote control switches*1
Talk switch*1
Telephone switches*1
Meter control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 98
Vehicle-to-vehicle distance switch
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 276
LDA (Lane Departure Alert) switch
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 268
Cruise control switch
Cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 288
Dynamic radar cruise control with full-speed range
*2 . . . . . . . . . . . . . . . . . P. 276
Paddle shift switches*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 219
1
2
3
4
5
6
7
8

LX570_OM_OM60R61U_(U)
892. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s various sys-
tems.
Indicators
Turn signal indicator
(  P. 224)
(if equipped)
LDA indicator ( P. 268)
(U.S.A.)
Headlight indicator
( P. 228)*1, 2
Slip indicator ( P. 385)
(Canada)
Tail light indicator
( P. 228) *1VSC OFF indicator
( P. 385)
Headlight high beam
indicator ( P. 229) Multi-terrain Select
indicator (
P. 319)
Automatic High Beam
indicator ( P. 231)
*1Crawl Control indicator
( P. 314)
Fog light indicator
(  P. 236) Automatic transmission
second start indicator
(
 P. 217)
*1Eco Driving Indicator
Light ( P. 91) Low speed four-wheel
drive indicator light
(
 P. 310)
Cruise control indicator
(  P. 288, 276) Center differential lock
indicator (
P. 311)
Cruise control “SET”
indicator ( P. 288, 276)
*1Easy access mode
indicator ( P. 302)
(if equipped)
Dynamic radar cruise
control indicator
( P. 276) Intuitive parking assist
indicator (
P. 294)

LX570_OM_OM60R61U_(U)
972. Instrument cluster
2
Instrument cluster
Driving assist system information (if equipped)
Select to display the operational status of the following systems:• Dynamic radar cruise control with full-speed range ( P. 276)
When the vehicle is in constant speed control mode ( P. 284), the menu
icon will change to .
• LDA (Lane Departure Alert) ( P. 268)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected. ( P. 533)
Settings display
Select to change the meter display settings and the operation settings of some
vehicle functions. ( P. 101)

106
LX570_OM_OM60R61U_(U)2. Instrument cluster
Driving assist system status display area (if equipped)
Select to display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range ( P. 276)
• LDA (Lane Departure Alert) ( P. 268)
• Intuitive parking assist ( P. 294)
Displayed content is the same as that disp layed on the multi-information display. For
details, refer to the explanations of each system.
HUD (Head-up display) switch ( P. 106)
◆Enabling/Disabling the head-up display
Press the HUD (head-up display)
switch.
◆Changing settings of the head-up display
Select on the multi-information display ( P. 96), and then select “HUD”
to change the following settings:
■Display brightness/location
Select to adjust the brightness and location of the head-up display.
■Display content
Select to enable/disable the following items:
• Route guidance to destination
• Driving assist system status
•Compass
• Audio system operation status
Using the head-up display
5
6

LX570_OM_OM60R61U_(U)
1072. Instrument cluster
2
Instrument cluster
Displays the following multi-information display linked icons:
: Master warning icon Displayed when a warning message is displayed on the multi-information
display. ( P. 533)
: Information icon Displayed when a suggestion/advice po p-up display is displayed on the
multi-information display. ( P. 96)
Displays the following items in the appropriate situation:
■Warning/Message (if equipped)
Displays the following system warning/messages:
• Pre-collision warning (pre-collision system)
• Notification message (dyn amic radar cruise control with full-speed range)
■Audio system operation status
Displayed when the audio system is operated.
■Outside temperature
Displayed in the following situations:
• When the engine switch is turned to IGNITION ON mode
• When the low outside temperature indicator is flashing
Displayed content is the same as that di splayed on the multi-information display.
(  P. 92)
Displays the following items which ar e linked to the navigation system:
■Route guidance to destination
Displayed when the navigation system is performing route guidance. When
approaching an intersection, an arrow will be displayed to indicate the sug-
gested direction of travel.
■Compass
Displays the direction of travel.
Warning and information icons
Message display area
Navigation system-linked display area

179
LX570_OM_OM60R61U_(U)
4Driving
4-1. Before drivingDriving the vehicle ......................180
Cargo and luggage ....................188
Vehicle load limits ....................... 192
Trailer towing ................................ 193
Dinghy towing .............................. 210
4-2. Driving procedures Engine (ignition) switch ..............211
Automatic transmission............ 217
Turn signal lever.......................... 224
Parking brake ..............................225
4-3. Operating the lights and wipers
Headlight switch .........................228
Automatic High Beam .............. 231
Fog light switch ...........................236
Windshield wipers and washer......................................... 238
Rear window wiper and washer.......................................... 242
Headlight cleaner switch ........245 4-4. Refueling
Opening the fuel tank cap ..... 246
4-5. Using the driving support systems
Lexus Safety System + ............. 249
PCS (Pre-Collision System)........................................ 256
LDA (Lane Departure Alert) ............................................ 268
Dynamic radar cruise control with full-speed
range ............................................ 276
Cruise control ............................ 288
Driving mode select switch ............................................ 291
Intuitive parking assist .............. 294
4-Wheel AHC (Active Height Control
Suspension) ...............................302
Four-wheel drive system ......... 310
Crawl Control (with Turn Assist function).......................... 314
Multi-terrain Select .................... 319
Multi-terrain Monitor ............... 323
BSM (Blind Spot Monitor) ..... 370 • BSM function ......................... 374
• RCTA function...................... 378
Driving assist systems ..............384
4-6. Driving tips Winter driving tips .....................389
Off-road precautions ............... 393

208
LX570_OM_OM60R61U_(U)4-1. Before driving
WARNING
■Trailer towing precautions
●To tow a trailer safely, use extreme care an
d drive the vehicle in accordance with the
trailer’s characteristics and operating condit ions. Failure to do so could cause an acci-
dent resulting in death or serious injury. Vehicle stability and braking performance are
affected by trailer st ability, brake setting and performanc e, and the hitch. Your vehicle
will handle differently when towing a trailer.
●Set the vehicle height to the “LO” mode and turn off the 4-Wheel AHC when you
connect a trailer, otherwise the vehicle height may change due to the automatic level-
ing function, and you may catch part of your body in the vehicle, resulting in an acci-
dent. ( P. 302)
■To avoid accident or injury
●Do not exceed the TWR, unbraked TWR, GCWR, GVWR or GAWR.
●If the gross trailer weight is over 2000 lb. (907 kg), a sway control device with suffi-
cient capacity is required.
●If the gross trailer weight is over 5000 lb. (2268 kg), a weight distributing hitch with
sufficient capacity is required.
●Adjust the tongue weight within the approp riate range. Place heavier loads as close
to the trailer axle as possible.
●Do not exceed 65 mph (104 km/h), the posted towing speed limit or the speed limit
for your trailer as set forth in your trai ler owner’s manual, whichever is lowest. Slow
down sufficiently before making a turn, in crosswinds, on wet or slippery surface, etc.
to help avoid an accident. If you experien ce a vehicle-trailer instability from reducing
a certain speed, slow down and make sure you keep your vehicle speed under the
speed of which you experience the instability.
●Do not make jerky, abrupt or sharp turns.
●Do not apply the brakes suddenly as you ma y skid, resulting in jackknifing and loss of
vehicle control. This is especially true on wet or slippery surfaces.
●Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle
weight and trailer tongue weight capacities.
●Do not use cruise control (if equipped) or dynamic radar cruise control with full-
speed range (if equipped) when trailer towing.
●Slow down and downshift before descending steep or long downhill grades. Do not
make sudden downshifts while descending steep or long downhill grades.
●Vehicle-trailer instability is more likely on steep long down hills. Before descending
steep or long downhill grades, slow down and downshift. Do not make sudden down-
shifts when descending steep or long do wnhill grades. Avoid holding the brake pedal
down too long or applying the brakes too frequently. This could cause the brakes to
overheat and result in reduced braking efficiency.

LX570_OM_OM60R61U_(U)
2214-2. Driving procedures
4
Driving
■Paddle shift switches (if equipped)
●When the “-” paddle shift switch is operated in the D position, a shift range will be auto-
matically selected. The highest gear of the first shift rang e will be one gear lower than
the gear in use during normal D position driving.
●Automatic deactivation of shift range selection in the D position
Shift range selection in the D position will be deactivated in the following situations:
• When the vehicle comes to a stop
• If the accelerator pedal is depressed for long er than a certain period of time in one
shift range
■Driving on a downhill
On declines, there may be case where the ve hicle shifts down automatically to obtain
engine braking. As a result of the down shifting, the engine speed may increase.
■Second start mode automatic deactivation
Second start mode is automatically deactivated if the engine is turned off after driving in
second start mode.
■S mode
When the shift range is 7 or lower, holding th e shift lever toward “+” sets the shift range to
8.
■AI-SHIFT
AI-SHIFT automatically selects the suitable gear according to driver performance and
driving conditions.
AI-SHIFT automatically operates when the shift lever is in the D position. (Shifting the
shift lever to the S position cancels the function.)
■When driving with cruise control or dynamic radar cruise control with full-speed range
activated
Even when performing the following actions with the intent of enabling engine braking,
engine braking will not activate because crui se control or dynamic radar cruise control
with full-speed range will not be canceled.
●While driving in D position (vehicles with paddle shift switches) or S mode, downshift-
ing to 7, 6, 5 or 4. ( P. 276, 288)
●When switching the driving mode to spor t mode while driving in D position. (P. 291)
■Shift lock system
The shift lock system is a system to prevent ac cidental operation of the shift lever in start-
ing.
The shift lever can be shifted from P only when the engine switch is in IGNITION ON
mode and the brake pedal is being depressed.
