LEXUS LX570 2021 Owners Manual

LX570_OM_OM60T33U_(U)
4315-5. Using the storage features
5
Interior features
Cup holders
Front seatsSecond seats
Press down and release the lid. To op en, pull down the armrest, press
the button and release the rear cup
holder on the armrest.
Third seats (if equipped)Luggage compartment (if
equipped)
WARNING
■Items unsuitable for the cup holders
Do not place anything other than cups or be verage cans in the cup holders. Even when
the lid is closed, items must no t be stored in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, and cause injury. If possible, cover hot drinks to prevent burns.
■When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an accident.

432
LX570_OM_OM60T33U_(U)5-5. Using the storage features
NOTICE
■To prevent damage to the cup holders
Stow the cup holders before stowing the rear armrest.
Bottle holders
Front seatsSecond seats
NOTICE
■Items that should not be stowed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bottle holders,
or glasses and paper cups containing liqui
d. The contents may spill and glasses may
break.
Card holder

LX570_OM_OM60T33U_(U)
4335-5. Using the storage features
5
Interior features
Your vehicle is equipped with either a front auxiliary box type B or wireless char-
ger.
For vehicles with wireless charger, refer to page 443.
■Front seats
Type A
Press the button to open.
Type B (if equipped)
Press the lid to open.
■Second seats
Pull down the armrest.
Auxiliary boxes
1

434
LX570_OM_OM60T33U_(U)5-5. Using the storage features
Press the button to release the
lock.
■Third seats /luggage compartment
2
WARNING
■While driving
For the front seats and the second seats: Do not leave the au
xiliary box open while driv-
ing.
Items stored in it may fall out and cause death or serious injury in case of an accident or
sudden stop.

435
LX570_OM_OM60T33U_(U)5-5. Using the storage features
5
Interior features
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
To hang the cargo net, use the cargo
net hooks and rear tie-down hooks.
The cargo net itself is not included as an
original equipment.
Remove the cover.
Cargo hooks
Cargo net hooks
Storage compartment (if equipped)

436
LX570_OM_OM60T33U_(U)5-5. Using the storage features
Remove the cover. Hold the warning
reflector with the bands.
The warning reflector itself is not
included as an original equipment.
Remove the cover. Hold the first-aid kit
with a band.
The first-aid kit itself is not included as an
original equipment.
■Using the luggage cover
Pull out the luggage cover and hook
it on the anchors.
Warning reflector holder
First-aid kit holder
Luggage cover (if equipped)

LX570_OM_OM60T33U_(U)
4375-5. Using the storage features
5
Interior features
■Removing the luggage cover
Retract the cover and release both
ends, then lift it out.
After removing the luggage cover,
place it somewhere other than the
passenger compartment.
■When installing the luggage cover (if equipped)
Keep the “TOP” mark on the luggage cover
ends upward.
WARNING
●To avoid injury, always return the cargo hooks to their positions when not in use.
●Keep the auxiliary box closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant bein g struck by an open auxiliary box or the
items stored inside.
●Vehicles with luggage cover: Do not allo w children to climb on the luggage cover.
Climbing on the luggage cove r could result in damage to the luggage cover, possibly
causing death or serious injury to the child.
NOTICE
■To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on it.

438
LX570_OM_OM60T33U_(U)5-6. Using the other interior features
Other interior features
While the engine is running, the cool box, which is cooled by the air conditioning,
can be used.
Press the button to open the lid.
Turns the cool box on/off
When on, the indicator light comes on.
■While the cool box is on
The front air conditioning sy stem cannot be turned off.
■When the outside temperature is 32 F (0 C) or below
The cool box may not operate.
Cool box (if equipped)
1
2
WARNING
Keep the cool box closed while driving.
Injuries may result in the event of sudden braking, sudden swerving or an accident.
NOTICE
To prevent battery discharge, do not leave the cool box on longer than necessary when
the engine is not running.

LX570_OM_OM60T33U_(U)
4395-6. Using the other interior features
5
Interior features
Main sun visor
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
Sub sun visor
Flip down with the main sun visor in
position or .
Slide the cover to open.
The light turns on when the cover is
opened.
If the vanity lights remain on when the engine switch is turned off, the lights will go off
automatically after 20 minutes.
Sun visors
1
2
3
23
Vanity mirrors
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended periods
when the engine is not running.

440
LX570_OM_OM60T33U_(U)5-6. Using the other interior features
The GPS clock’s time is automatically
adjusted by utilizing GPS time informa-
tion. For details, refer to “NAVIGA-
TION SYSTEM OWNER’S
MANUAL”.
The power outlet can be used
for the following components:
12 V DC: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W
■Center of console
Front (12 V DC)
Press the lid to open.
Clock
Power outlets
