LEXUS LX570 2021 Owners Manual

LX570_OM_OM60T33U_(U)
4015-1. Remote Touch screen
5
Interior features
Select: Move the Remote Touch
knob in the desired direction.
Enter: Press the Remote Touch knob
or “ENTER” button.
■Screen display during low temperatures
When the ambient temperature is extremely low, screen response may be delayed even
if the Remote Touch is operated.
Remote Touch operation
1
2
WARNING
■When using the Remote Touch
●Do not allow fingers, fingernails or hair to become caught in the Remote Touch as this
may cause an injury.
●Be careful when selecting the Remote Touch in extreme temperatures as it may
become very hot or cold due to the temperature inside the vehicle.
NOTICE
■To prevent damage to the Remote Touch
●Do not allow the Remote Touch to come into contact with food, liquid, stickers or lit
cigarettes as doing so may cause it to change color, emit a strange odor or stop func-
tioning.
●Do not subject the Remote Touch to excessive pressure or strong impact as the knob
may bend or break off.
●Do not allow coins, contact lenses or ot her such items to become caught in the
Remote Touch as this may cause it to stop functioning.
●Items of clothing may rip if they become caught on the Remote Touch knob.
●If your hand or any object is on the Remote Touch knob when the engine switch is in
ACCESSORY mode, the Remote Touch knob may not operate properly.

4025-1. Remote Touch screen
LX570_OM_OM60T33U_(U)
Press the “MENU” button on the Remote Touch to display the “Menu” screen.
The display may differ depending on the type of the system.
When the split-screen display is selected, the “Menu” screen will be displayed on
the main display. ( P. 403)
“Menu” screen
SwitchFunction
Select to display the “Destination” screen.*
Select to display the radio control screen.*
Select to display the media control screen.*
Select to display the hand s-free operation screen.*
Select to display the “LEXUS App Suite” screen.*
Select to display the “Information” screen.*
Select to display the air conditioning control screen. ( P. 407)
Select to display the “Setup” screen.*

LX570_OM_OM60T33U_(U)
4035-1. Remote Touch screen
5
Interior features
*: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
■Full screen display
The following functions can be displayed full screen:
●Initial screen
●“Menu” screen (P. 402)
●Map screen*
*
: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
“Display”Select to adjust the contrast and brightness of the screens, turn the
screen off, etc.*
12.3-inch display operation
SwitchFunction

4045-1. Remote Touch screen
LX570_OM_OM60T33U_(U)
■Split-screen display
Different information can be displayed on the left and right of the screen. For
example, air conditioning system or au dio screens can be displayed and oper-
ated while the fuel consumption inform ation screen is being displayed. The
large screen on the left of the display is called the main display, and the small
screen to the right is called the side display.

LX570_OM_OM60T33U_(U)
4055-1. Remote Touch screen
5
Interior features
■Main Display
For details about the functions and operation of the main display, refer to the
respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”.
■Side Display
Basic screens
To change the screen displayed on the side display, use the screen buttons on
the right side of the display.
Navigation system
*
Audio*
Phone*
Vehicle information ( P. 110)
Air conditioning system
( P. 407)
Interruption screens
Each of the following screens is displayed automatically in accordance with
conditions. • Intuitive parking assist ( P. 294)
•Phone
*
• Destination Assist
•Driving mode ( P. 291)
*: Refer to the “NAVIGATIO N SYSTEM OWNER’S MANUAL”.
Split-screen display operation
1
2
3
4
5

406
LX570_OM_OM60T33U_(U)5-2. Lexus Climate Concierge
Lexus Climate Concierge
“CLIMATE CONCIERGE” switch
When the switch is
pressed, the indica-
tor above the switch illuminates and all
of the following systems operate in auto-
matic mode.
If any of the system is operated manually,
the indicator turns off. However, all
other functions continue to operate in
automatic mode.
■Automatic air conditioning system ( P. 407, 418)
The temperature can be adjusted individually for the driver seat, passenger seat, and
rear seats.
When a passenger is detected in the second seat, the rear air conditioning operates
in automatic mode.
■Seat heaters and ventilators (if equipped) ( P. 421)
Heating or ventilation is automatically se lected according to the set temperature of
the air conditioning system, the outside temperature, etc.
The seat heaters and ventilators of the front passenger seat and second outboard
seats operate in automatic mode if passengers are detected.
■Heated steering wheel (if equipped) ( P. 421)
Heated steering wheel operates automatically according to the outside temperature
and cabin temperature.
■Front air conditioning system operation
To improve air conditioning performance in th e front seat area, the air outlets on the rear
of the console box may close when there is no passenger in the second seat.
■Rear air conditioning system operation
The rear air conditioning system may stop automatically when there is no passenger in
the second seat.
■Seat heater/ventilator operation
When automatic mode is selected using th e seat heater/ventilator switch, passenger
detection is not performed.
The seat heaters, seat ventilators and heated steering wheel are each auto-
matically controlled according to the set temperature of the air conditioning
system, the outside and cabin temperat ure, etc. Lexus Climate Concierge
allows a comfortable condition to be maintained without adjusting each sys-
tem.

407
LX570_OM_OM60T33U_(U)5-3. Using the air conditio
ning system and defogger
5
Interior features
Front automatic air conditioning system
■Adjusting the temperature setting
Press to increase the temperature and to decrease the tem-
perature.
If the indicator is turned off, the sy stem will blow ambient temperature air
or heated air.
■Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan
speed.
Press to turn the fan off.
Air outlets and fan speed are automati cally adjusted according to the tem-
perature setting.
Select the “MENU” button on the Remo te Touch, then select to display
the air conditioning control screen. ( P. 402)
The air conditioning system can be disp layed and operated on the side display.
(  P. 404)
Control panel

4085-3. Using the air conditioning system and defogger
LX570_OM_OM60T33U_(U)
■Change the airflow mode
To change the air outlets, press .
The air outlets used are switched
each time the button is pressed. Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates
■Other functions
●Switching between outside air and recirculated air modes ( P. 413)
●Defogging the windshield (P. 413)
●Defogging the rear window and outside rear view mirrors ( P. 413)
1
2
3
4

LX570_OM_OM60T33U_(U)
4095-3. Using the air conditioning system and defogger
5
Interior features
■Main display
Left-hand front seat side temperature control
Left-hand front seat side air outlet selector
Air flows to the feet and the windshield defogger operates
Fan speed control
Right-hand front seat side air outlet selector
Option control screen
Right-hand front seat si de temperature control
Rear air conditioning operation screen
Eco mode
Adjust the temperature for driver, passenger and rear seats separately
(“4-ZONE” mode)
Cooling and dehumidification function on/off
Automatic mode
Control screen
1
2
3
4
5
6
7
8
9
10
11
12

4105-3. Using the air conditioning system and defogger
LX570_OM_OM60T33U_(U)
■Changing the air flow mode
To adjust settings, select the screen button.  Air flows to the upper body.
 Air flows to the upper body and feet.
 Air flows to the feet.
 Air flows to the feet and the windshield defogger operates.
■Side displaySelect the left-hand front seat
side air flow mode
Adjust the left-hand side tem-
perature setting
Adjust the fan speed setting
Select the right-hand front seat
side air flow mode
Adjust the right-hand side tem-
perature setting
Adjust the temperature for driver
and passenger seats separately
(“4-ZONE” mode)
Select to set cooling and dehumidification function on/off
Select to set auto mode on
■Option control screen
Select on the main display to display the option contro l screen. The func-
tions can be switched on and off.
Prevent ice from building up on
the windshield and wiper blades
( P. 413)
Micro dust and pollen filter
( P. 413)
1
2
3
4
5
6
7
8
1
2
