LEXUS NX200T 2016 Owners Manual

6219-2. Customization
9
Vehicle specifications
NX200t_OM_USA_OM78081U
■Intuitive parking assist* ( P. 2 7 0 )
*:If equipped
■Driving position memory* ( P. 1 4 5 )
*:If equipped
■Outside rear view mirrors ( P. 1 5 5 )
FunctionDefault
settingCustomized setting
Detection distance of the
front center sensorLongShortO–O–
Detection distance of the rear
center sensorLongShortO–O–
Display setting (When intui-
tive parking assist is operat-
ing)
OnOffO–O–
Buzzer volume31 to 5O–O–
1234
FunctionDefault settingCustomized setting
Driver’s seat movement when
exiting the vehicleStandardOffO–O–Pa r t i a l
Selection the door linking
driving position memory with
door unlock operation
Driver’s doorAll doors––O–
1234
FunctionDefault settingCustomized setting
Linked mirror function when
reversingOnOff––O–
1234

6229-2. Customization
NX200t_OM_USA_OM78081U
■LDA (Lane Departure Alert with steering control)* (  P. 2 6 1 )
*:If equipped
■Power back door*1 ( P. 1 2 0 )
*1:If equipped
*2: Configured by operating the switch of the lower back door. ( P. 1 2 3 )
*3: While carrying the electronic key on your person, press the back door opener switch.
FunctionDefault
settingCustomized setting
Steerage assistOnOff–O––
Sensitivity adjustment for the
lane deviation alert buzzerStandardHigh–O––
1234
FunctionDefault settingCustomized setting
Set at the desired Position
(height)
*2
Back Door Automatic
Open and Stop Position
Initial settings
Po s i t i o nStop at the
desired position
(height)
–––O
5 step configuration
Back Door Automatic
Open and Stop Position
51 to 5O–O–
Back door opener switch
operationsWhen the back
door is
locked
*3
When the back
door is
unlocked
––O–
Power back door operationsOnOff–O––
1234

6239-2. Customization
9
Vehicle specifications
NX200t_OM_USA_OM78081U
■Vehicle customization
●When the speed linked door locking function and shift position linked door locking
function are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, all th e doors will be locked.
• If the vehicle is started with all the door s locked, the speed linked door locking func-
tion would not operate.
• If the vehicle is started with any door un locked, the speed linked door locking func-
tion will operate.
●When the smart access system with push-but ton start is off, smart door unlocking can-
not be customized.
●When the doors remain closed after unloc king the doors and the automatic door lock
function is activated, the signals will be generated in accordance with the Operation
signal (buzzer) and the Operation si gnal (emergency flashers) settings.
■In the following situations, customize mo de in which the settings can be changed
through the multi-in formation display will automatically be turned off.
●A warning message appears after the cu stomize mode screen is displayed.
●The engine switch is turned off.
●The vehicle begins to move while the customize mode screen is displayed.
WA R N I N G
■Cautions during customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust
gases including harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

6249-3. Initialization
NX200t_OM_USA_OM78081U
Items to initialize
*:If equipped
The following items must be initialized for normal system operation after such
cases as the battery being reconnecte d, or maintenance being performed on
the vehicle.
ItemWhen to initializeReference
Message indicating mainte-
nance is required (U.S.A. only)• After the maintenance is per- formedP. 4 8 0
Tire pressure warning system
• When rotating the tires on vehi-
cles with differing front and rear
tire inflation pressures
• When changing the tire inflation
pressure by changing traveling
speed or load weight, etc.
• When changing the tire size
P. 5 0 4
Oil maintenance• After the maintenance is per- formedP. 4 9 4
Power back door*
• After reconnecting or changing
the battery
• After changing a fuse
P. 1 2 5
Po w e r w i n d o w• When functioning abnormally normallyP. 1 5 9
Moon roof*P. 1 6 2

625
10For owners
NX200t_OM_USA_OM78081U
Reporting safety defects for U.S. owners ............................................ 626
Seat belt instructions for Canadian owners (in French) .........627
SRS airbag instructions for Canadian owners (in French) ........ 629

626
NX200t_OM_USA_OM78081U
Reporting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying the Lexus
Division of Toyota Motor Sales, U.S. A., Inc. (Toll-free: 1-800-25-LEXUS).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a gr oup of vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual
problems between you, your dealer, or Lexus Division of Toyota Motor Sales,
U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to
http://www.safercar.gov; or
write to: Administrator, NHTSA, 1200 New Jersey Ave, S.E., Washington, DC
20590. You can also obtain other information about motor vehicle safety from
http://www.safercar.gov.

627
10
For owners
NX200t_OM_USA_OM78081U
Seat belt instructions for Canadian owners (in French)
●Déroulez la sangle diagonale de
telle sorte qu’elle passe bien sur
l’épaule, sans pour autant être en
contact avec le cou ou glisser de
l’épaule.
●Placez la sangle abdominale le plus
bas possible sur les hanches.
●Réglez la position du dossier de
siège. Asseyez-vous le dos le plus
droit possible et calez-vous bien
dans le siège.
●Ne pas vriller la ceinture de sécurité.
■Ceintures de sécurité
Nettoyez avec un chiffon ou une éponge humectée d’eau savonneuse tiède.
Par ailleurs, vérifiez régulièrement que les ceintures ne sont pas effilochées,
entaillées, ou ne paraissent pas exagérément usées.
The following is a French explanation of seat belt instructions extracted from
the seat belt section in this manual.
See the seat belt section for more deta iled seat belt instructions in English.
Utilisation correcte des ceintures de sécurité
Entretien et soin

628
NX200t_OM_USA_OM78081U
AVERTISSEMENT
Respectez les précautions suivantes afin de réduire le risque de blessure en cas de
freinage brusque, d’embardée ou d’accident.
À défaut, des blessures graves, voire mortelles, pourraient s’ensuivre.
■Port de la ceinture de sécurité
●Ne pas passer la sangle diagonale sous le bras.
●Faites toujours passer votre ceinture de sé curité au plus bas sur vos hanches et bien
dans l’axe.
■État et usure des ceintures de sécurité
Inspectez les ceintures de sécurité périod iquement. Contrôlez qu’elles ne sont pas
entaillées, effilochées, et que leurs ancrages ne sont pas desserrés. Ne pas utiliser une
ceinture de sécurité défectueuse avant qu’elle ne soit remplacée. Une ceinture de
sécurité défectueuse n’apport e aucune garantie de protection de l’occupant contre
des blessures graves, voire mortelles.
■Lorsque vous utilisez la ceinture de sécurité du siège central arrière
Ne pas utiliser la ceinture de sécurité du siège
central arrière avec une de ses deux boucles
déverrouillée. Si une seule des boucles est
verrouillée, tout freinage brusque ou collision
peut entraîner des blessures graves, voire
mortelles.

629
10
For owners
NX200t_OM_USA_OM78081U
SRS airbag instructions for Canadian owners (in French)
◆Coussins gonflables SRS frontaux
Coussins gonflables SRS conducteur/passager avant
Participent à la protection de la tête et du thorax du conducteur et du
passager avant contre les chocs avec les éléments de l’habitacle
Coussin gonflable SRS de genoux
Participe à la protection du conducteur
Coussin gonflable SRS d’assise de siège
Participe à la retenue du passager avant
The following is a French explanation of SRS airbag instructions extracted
from the seat belt section in this manual.See the SRS airbag section for more deta iled seat belt instructions in English.
1
2
3

630
NX200t_OM_USA_OM78081U
◆Coussins gonflables SRS latéraux et rideauCoussins gonflables SRS latéraux
Participent à la protection du haut du corps des occupants des sièges avant
Coussins gonflables SRS rideau
●Participent principalement à la protection de la tête des occupants assis
dans les sièges des places extérieures
●Peuvent empêcher les occupants d’être éjectés du véhicule en cas de
retournement de celui-ci
4
5
