stop start LEXUS NX300 2020 Service Manual

365
LEXUS NX300 Owners Manual_USA_M78389_en
7
7
When trouble arises
When trouble arises
7-1. Essential information
Emergency flashers.................. 366
If your vehicle has to be stopped in an emergency .......................... 366
If the vehicle is trapped in rising water............................................ 367
7-2. Steps to take in an emergency If your vehicle needs to be towed........................................................ 369
If you think something is wrong ........................................................ 373
Fuel pump shut off system ..... 374
If a warning light turns on or a warning buzzer sounds ....... 375
If a warning message is displayed ........................................................ 384
If you have a flat tire.................. 387
If the engine wi ll not start .......395
If you lose your keys ................. 396
If the fuel filler door cannot be opened........................................ 397
If the electronic key does not operate properly .................... 397
If the vehicle battery is discharged ........................................................ 400
If your vehicle overheats ........ 403
If the vehicle becomes stuck 406

3747-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
Follow the procedure below to restart
the engine after the system is activated.
1
Turn the engine switch to ACCES-
SORY mode or turn it off.
2
Restart the engine.
Fuel pump shut off system
To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.
Restarting the engine
NOTICE
■Before starting the engine
Inspect the ground under the vehicle.
If you find that fuel has leaked onto the
ground, the fuel system has been dam-
aged and is in need of repair. Do not
restart the engine.

3837-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
7
When trouble arises
●Avoid abrupt maneuvering and brak-
ing. If the vehicle tires deteriorate, you
could lose control of the steering
wheel or the brakes.
■If a blowout or sudden air leakage
should occur
The tire pressure warning system may
not activate immediately.
■Maintenance of the tires
Each tire, including the spare (if pro-
vided), should be checked monthly when
cold and inflated to the inflation pressure
recommended by the vehicle manufac-
turer on the vehicle placard or tire infla-
tion pressure label (tire and load
information label). (If your vehicle has
tires of a different size than the size indi-
cated on the vehicle placard or tire infla-
tion pressure label [tire and load
information label], yo u should determine
the proper tire infl ation pressure for
those tires.)
As an added safety feature, your vehicle
has been equipped with a tire pressure
monitoring system (TPMS-tire pressure
warning system) that illuminates a low
tire pressure telltale (tire pressure warn-
ing light) when one or more of your tires
is significantly under-inflated. Accord-
ingly, when the low tire pressure telltale
(tire pressure warnin g light) illuminates,
you should stop and check your tires as
soon as possible, and inflate them to the
proper pressure. Driving on a signifi-
cantly under-inflated tire causes the tire
to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi-
ciency and tire tread life, and may affect
the vehicle’s handling and stopping abil-
ity.
Please note that the TPMS (tire pressure
warning system) is not a substitute for
proper tire maintenance, and it is the
driver’s responsibility to maintain correct
tire pressure, even if under-inflation has
not reached the level to trigger illumina-
tion of the TPMS low tire pressure telltale
(tire pressure warning light).
Your vehicle has also been equipped with
a TPMS (tire pressure warning system)
malfunction indicator to indicate when
the system is not operating properly. The
TPMS (tire pressure warning system)
malfunction indicator is combined with
the low tire pressure telltale (tire pres-
sure warning light) . When the system
detects a malfunction, the telltale will
flash for approximately one minute and
then remain continuously illuminated.
This sequence will continue upon subse-
quent vehicle start-ups as long as the
malfunction exists. When the malfunction
indicator is illuminated, the system may
not be able to detect or signal low tire
pressure as intended.
TPMS (tire pressure warning system)
malfunctions may occur for a variety of
reasons, including the installation of
replacement or alternate tires or wheels
on the vehicle that prevent the TPMS
(tire pressure warning system) from func-
tioning properly. Always check the
TPMS (tire pressure warning system)
malfunction telltale after replacing one
or more tires or wheels on your vehicle to
ensure that the replacement or alternate
tires and wheels allow the TPMS (tire
pressure warning system) to continue to
function properly.
NOTICE
■To ensure the tire pressure warning
system operates properly
Do not install tires with different specifi-
cations or makers, as the tire pressure
warning system may not operate prop-
erly.

3997-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
7
When trouble arises
ACCESSORY mode.
3Firmly depress the brake pedal and
check that message shown on the
multi-information display.
4 Press the engine switch.
In the event that the engine still cannot be
operated, contact your Lexus dealer.
■Stopping the engine
Set the parking brake, shift the shift lever to
P and press the engine switch as you nor-
mally do when stopping the engine.
■Electronic key battery
As the above procedure is a temporary
measure, it is recomme nded that the elec-
tronic key battery be replaced immediately
when the battery is depleted.
■Alarm
Using the mechanical key to lock the doors
will not set the alarm system. If a door is
unlocked using the mechanical key when
the alarm system is set, the alarm may be
triggered.
■Changing engine switch modes
Release the brake pedal and press the engine switch in step
3 above.
The engine does not start and modes will be
changed each time the switch is pressed.
(  P.166)

4057-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
7
When trouble arises
6Start the engine and turn the air
conditioning system on to check
that the radiator cooling fans oper-
ate and to check for coolant leaks
from the radiator or hoses.
The fans operate when the air conditioning
system is turned on immediately after a
cold start. Confirm that the fans are oper-
ating by checking the fan sound and air
flow. If it is difficult to check these, turn the
air conditioning system on and off repeat-
edly.
(The fans may not oper ate in freezing tem-
peratures.)
7If the fans are not operating:
Stop the engine immediately and
contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the
nearest Lexus dealer.
8
Check if “Engine Coolant Temp
High” is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the engine and contact your
Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Lexus dealer.
WARNING
■To prevent an accident or injury when
inspecting under the hood of your
vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot.
●Do not touch within the engine com-
partment or get close when the cool-
ing fan is operating. Body parts,
clothes, etc., may get caught and lead
to an accident, resulting in serious
injury. The cooling fan operates auto-
matically at times when the air condi-
tioner is operating and times when the
coolant temperatures are high. Also, it
may operate for several minutes even
after the engine switch is turned off.
●Keep hands and clothing (especially a
tie, a scarf or a muffler) away from the
fans and belts. Failure to do so may
cause the hands or clothing to be
caught, resulting in serious injury.
●Do not loosen the coolant reservoir
cap while the engine and radiator are
hot.
High temperature steam or coolant
could spray out.
NOTICE
■When adding engine coolant
Add coolant slowly after the engine has
cooled down sufficiently. Adding cool
coolant to a hot engine too quickly can
cause damage to the engine.
■To prevent damage to the cooling sys-
tem
Observe the following precautions:
●Avoid contaminating the coolant with
foreign matter (such as sand or dust,
etc.).
●Do not use any coolant additive.

4067-2. Steps to take in an emergency
LEXUS NX300 Owners Manual_USA_M78389_en
1Stop the engine. Shift the shift lever
to P and set the parking brake.
2
Remove the mud, snow or sand
from around the front wheels.
3
Place wood, stones or some other
material under the front wheels to
help provide traction.
4
Restart the engine.
5
Shift the shift lever to D or R,
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal.
■When it is difficult to free the vehicle
Press to turn off TRAC. ( P.261)
If the vehicle becomes stuck
Carry out the following proce-
dures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Recovering procedure
WARNING
■When attempting to free a stuck vehi-
cle
If you choose to push the vehicle back
and forth to free it, make sure the sur-
rounding area is clear to avoid striking
other vehicles, objects or people. The
vehicle may also lunge forward or lunge
back suddenly as it becomes free. Use
extreme caution.
■When shifting the shift lever
Be careful not to shif t the shift lever with
the accelerator pedal depressed.
This may lead to un expected rapid accel-
eration of the vehicle that may cause an
accident resulting in death or serious
injury.
NOTICE
■To avoid damage to the transmission
and other components
●Avoid spinning the front wheels and
depressing the accelerator pedal
more than necessary.
●If the vehicle remains stuck even after
these procedures are performed, the
vehicle may require towing to be freed.

LEXUS NX300 Owners Manual_USA_M78389_en
453What to do if... (Troubleshooting)
Is the engine switch in IGNITION
ON mode?
If you cannot release the shift lever
by depressing the brake pedal with
the engine switch in IGNITION ON
mode ( P.169)
 It is locked automatically to prevent
theft of the vehicle. ( P.165)
 Is the window lock switch pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the window lock switch
is pressed. ( P.139)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not operating)
for a period of time. ( P.167)
 The seat belt reminder light is flash-
ing Are the driver and the passengers
wearing the seat belts? (
P.379,
380)
 The parking brake indicator is on
Is the parking brake released?
( P.172)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.375, 384)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm
sounds. ( P.70)
To stop the alarm, turn the engine switch to
IGNITION ON mode or start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-
information display. ( P.384)
 When a warning light turns on or a
warning message is displayed, refer
to P.375, 384.
The shift lever cannot be shifted
from P even if you depress the
brake pedal
The steering wheel cannot be
turned after the engine is stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

458Alphabetical Index
LEXUS NX300 Owners Manual_USA_M78389_en
Drive information ........................................... 83
Drive-start control ..............................147, 168
Driver’s seat belt reminder light ............ 379
Driver’s seat position memory .................128
Driving Break-in tips ................................................... 147
Correct posture ............................................ 25
Driving mode select switch ..................258
Procedures .....................................................146
Winter drive tips......................................... 266
Driving position memory............................128 Memory recall function ............................ 129
Dynamic radar cruise control with full- speed rangeFunction .......................................................... 225
Warning message.....................................384
E
Eco Driving Indicator.................................... 78
Eco mode........................................................ 258
EDR (Event data recorder) ............................7
Electric Power Steering (EPS) Function ..........................................................260
Warning light ................................................377
Electronic key Battery-saving function ..............................117
If the electronic key does not operate properly....................................................... 397
Replacing the battery...............................356
Emergency flashers .................................... 366
Emergency, in case of If a warning buzzer sounds .................. 375
If a warning light turns on ...................... 375
If a warning message is displayed.....384
If the battery is discharged ................... 400
If the electronic key does not operate properly....................................................... 397 If the engine will not start....................... 395
If the fuel filler do
or cannot be opened
.......................................................................... 397
If the vehicle is trapped in rising water .......................................................................... 367
If you have a flat tire ..................................387
If you lose your keys ................................ 396
If you think something is wrong.......... 373
If your vehicle becomes stuck ............ 406
If your vehicle has to be stopped in an emergency ................................................ 366
If your vehicle needs to be towed .... 369
If your vehicle overheats ....................... 403
Engine Accessory mode......................................... 166
Compartment..............................................335
Engine switch ................................................ 165
Hood ................................................................333
How to start the engine ........................... 165
Identification number .............................. 409
If your vehicle has to be stopped in an emergency ................................................ 366
Ignition switch (Engine switch) ............ 165
Overheating ................................................ 403
Engine compartment cover .................... 336
Engine coolant Capacity ............................................................ 411
Checking ...................................................... 338
Preparing and checking before winter..........................................................................266
Warning light ............................................... 376
Engine coolant temperature gauge ........79
Engine immobilizer system ........................ 68
Engine oil Capacity .......................................................... 410
Checking .......................................................336
Warning light ...............................................375

460Alphabetical Index
LEXUS NX300 Owners Manual_USA_M78389_en
Heated steering wheel .............................. 287
Heaters
Automatic air conditioning system ... 279
Heated steering wheel............................ 287
Outside rear view mirrors ......................136
Seat heaters .................................................. 287
High mounted stoplight Replacing light bulb.................................. 362
Hill-start assist control ............................... 260
Hood ................................................................. 333 Open ............................................................... 333
Hooks Cargo hooks................................................ 295
Retaining hooks (floor mat)......................24
Horn ....................................................................134
I
I/M test ............................................................ 330
Identification Engine .............................................................409
Vehicle ........................................................... 408
Ignition switch (Engine switch) ................165
Illuminated entry system ........................... 289
Immobilizer system ........................................ 68
Indicators ............................................................74
Initialization Items to initialize .........................................438
Inside rear view mirror ................................134
Instrument panel light control .....................81
Interior lights.................................................. 289
Intuitive parking assist Function .......................................................... 236
Warning message..................................... 238
J
JackPositioning a floor jack............................ 333
Vehicle-equipped jack .......................... 388 Jack handle ....................................................388
Jam protection function
Moon roof ........................................................ 141
Power back door closer ............................. 111
Power windows ........................................... 138
Rear seats ........................................................ 127
K
Keyless entrySmart access system with push-button start ................................................................... 116
Wireless remote control ........................... 97
Keys...................................................................... 96 Battery-saving function.............................. 117
Electronic key .................................................96
Engine switch ................................................ 165
If the electronic key does not operate properly ....................................................... 397
If you lose your keys ................................ 396
Key number plate .........................................96
Keyless entry ........................................ 100, 116
Mechanical key .............................................. 96
Replacing the battery .............................. 356
Warning buzzer ............................................ 117
Wireless remote control key .................. 97
Knee airbags .................................................... 32
L
Lane Departure Alert with steering control (LDA) ..............................................................215
Lane Tracing Assist (LTA) ....................... 206
Language (multi-information display) 430
LATCH anchors ............................................. 57
LDA (Lane Departure Alert with steering control) ...........................................................215

464Alphabetical Index
LEXUS NX300 Owners Manual_USA_M78389_en
Sensor
Automatic High Beam system............... 181
BSM (Blind Spot Monitor) ................... 252
Inside rear view mirror..............................135
Intuitive parking assist.............................. 236
Kick sensor..................................................... 108
Radar sensor..................................................193
Rain-sensing windshield wipers.......... 188
Service reminder message ..................... 326
Shift lever ......................................................... 168
Shift lock system.............................................169
Side airbags ...................................................... 32
Side doors........................................................ 100
Side marker lights Light switch .....................................................178
Replacing light bulbs................................ 362
Side mirrors .....................................................136 Adjusting and folding ................................136
BSM (Blind Spot Monitor) ...................250
Side turn signal lights Replacing light bulbs................................ 362
Turn signal lever ........................................... 172
Smart access system with push-button start.................................................................... 116Antenna location........................................... 116
Entry functions................................... 100, 105
Starting the engine ..................................... 165
Warning message.....................................384
Snow tires ....................................................... 266
Spare tire Inflation pressure..........................................413
Storage location ........................................ 388
Spark plug ......................................................... 411
Specifications ................................................408
Speedometer ....................................................79 Sport mode .................................................... 258
Steering wheel
Adjustment ..................................................... 133
Heated steering wheel ............................ 287
Power easy access system .................... 128
Stop lights Replacing light bulbs ................................362
Storage feature ............................................ 292
Storage precautions................................... 292
Stuck If the vehicle becomes stuck ............... 406
Sun visors ........................................................ 299
Switch ASC (Active Sound Control) dial....... 177
Automatic High Beam switch ................ 181
Brake hold switch ........................................175
BSM (Blind Spot Monitor) main switch......................................................................... 250
Cruise control switch............................... 225
Door lock switch ......................................... 102
Driving mode select switch ................. 258
Driving position memory switches .... 128
Emergency flashers switch .................. 366
Engine switch ................................................ 165
Fog light switch ............................................ 184
Garage door opener switches.......... 309
Heated steering wheel ............................ 287
HUD (Head-up display) switches ...... 88
Ignition switch ............................................... 165
Intuitive parking assist switch ...............236
LDA switch .....................................................219
Light switches ............................................... 178
LTA switch ....................................................... 211
Meter control switches .............................. 82
Moon roof switches................................... 140
