bluetooth LEXUS NX300h 2015 User Guide

382 5-7. Connecting Bluetooth ®
NX300h_U_OM78007USteps for using Bluetooth ®
devicesThe following can be performed using Bluetooth ®
wireless communication:■
A portable audio player can be operated and listened to via the Lexus
Display Audio system ■
Hands-free phone calls can be made via a cellular phone
In order to use wireless communication, register and connect a Bluetooth ®
device by performing the following procedures.
Device registration/connection flow 1. Register the Bluetooth ®
device to be used with Lexus Display
Audio system (  P. 3 8 4 )
2. Select the Bluetooth ®
device to be used
(  P. 3 8 5 )
Audio Hands-free phone
3. Start Bluetooth ®
connec-
tion (  P. 386) 3. Start Bluetooth ®
connec-
tion (  P. 3 8 7 )
4. Check connection status
(  P. 3 9 0 ) 4. Check connection status
(  P. 393)
5. Use Bluetooth ®
audio
(  P. 3 9 0 ) 5. Use Bluetooth ®
phone
(  P. 3 9 4 )

3835-7. Connecting Bluetooth ®
5
Lexus Display Audio system
NX300h_U_OM78007U Go to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc. ■
When displaying “Bluetooth
* Setup” screen from the “Bluetooth
* Audio” screen
Display the “Bluetooth
* Audio” screen. (  P. 3 9 0 )
Move the controller to the left and select “Connect”.■
When displaying “Bluetooth
* Setup” screen from the phone top screen
Display the phone top screen. (  P. 3 9 2 )
Move the controller to the left and select “Connect Phone”.
* : Bluetooth is a registered trad emark of Bluetooth SIG, Inc.“Bluetooth
* Setup” screen 1
2
1
2

384 5-7. Connecting Bluetooth ®
NX300h_U_OM78007URegistering a Bluetooth ®
deviceTurn the Bluetooth ®
connection setting of your device set to on.
Go to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Move the controller to the left and then select “Add Device”
When this screen is displayed, input
the passcode displayed on the
screen into your Bluetooth ®
device. For operation of the Bluetooth ®
device,
see the manual that comes with your
Bluetooth ®
device.
Register the Bluetooth ®
device
using your Bluetooth ®
device.A PIN code are not required for SSP
(Secure Simple Pairing) compatible
Bluetooth ®
devices. Depending on the
device, you may need to select Yes to
register, or No to cancel on the device.
If an error message is displayed, follow the guidance on the screen to try again.
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Go to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Move the controller to the left and then select “Remove Device”.
Select the device to remove.
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.Bluetooth ®
compatible phones (HFP) and portable audio players (AVP) can
be registered simultaneously. You can register up to 5 Bluetooth ®
devices.
How to register a Bluetooth ®
device1
2
3
4
5
Removing a Bluetooth ®
device 1
2
3

3855-7. Connecting Bluetooth ®
5
Lexus Display Audio system
NX300h_U_OM78007USelecting a Bluetooth ®
deviceGo to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Select the device to connect.
Select “Connect All”, “Connect as a Ph one” or “Connect as an Audio Player”.
“Connect All” means connect both the telephone and audio functions of one
device.
If the desired Bluetooth ®
device is not displayed, register the device.
(  P. 3 8 4 )
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.If multiple Bluetooth ®
devices are registered, follow the procedure below to
select the Bluetooth ®
device to be used. You ma y only use one device at a
time.
How to select a Bluetooth ®
device1
2
3

386 5-7. Connecting Bluetooth ®
NX300h_U_OM78007UConnecting a Bluetooth ®
audio playerWhen the portable audio player is in st andby for a connection, it will be automat-
ically connected whenever the power switch is in either ACCESSORY or ON
mode.
Operate the portable player and connect it to the Bluetooth ®
audio system.
Go to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Select the device to connect.
Select “Connect All” or “Connect as an Audio player”.
If the desired Bluetooth ®
device is not displayed, register the device.
(  P. 3 8 4 )
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.There are 2 portable audio player connection settings available: connecting
from the vehicle and connecting from the portable player.
Connecting method is set to “Vehicle”
Connecting method is set to “Device” 1
2
3

3875-7. Connecting Bluetooth ®
5
Lexus Display Audio system
NX300h_U_OM78007UConnecting a Bluetooth ®
phoneWhen you register a phone, auto conn ection will be activated. It is recom-
mended to have the system set to this mode and leave the Bluetooth ®
phone in a
place where a good connection can be established.
When the power switch is turned to ACCESSORY or ON mode, the system will
search for a nearby cellular phone you have registered.
Next, the system automatically connects with the most recent phone that was
connected. The connected result is displayed.
When auto connection has failed or “Bluetooth
* Power” is turned off, you must
connect the Bluetooth ®
device manually.
Go to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Select the device to connect.
Select “Connect All”, “Connect as a Ph one” or “Connect as an Audio player”.
If the desired Bluetooth ®
device is not displayed, register the device.
(  P. 3 8 4 )
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc. ■
Reconnecting a Bluetooth ®
phone
If the system cannot connect due to poor signal strength with the power switch in
ACCESSORY or ON mode, the system will automatically attempt to reconnect.
If the phone is turned off, the system will not attempt to reconnect. In this case, the con-
nection must be made manually, or the phone must be reselected.■
Connecting a phone while Bluetooth ®
audio is playing●
Bluetooth ®
audio will stop temporarily.●
It may take time to connect.There are two connecting methods av ailable: automatic and manual.
Auto connection
Manual connection 1
2
3

388 5-7. Connecting Bluetooth ®
NX300h_U_OM78007UDisplaying a Bluetooth ®
device detailsGo to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Select the desired device and then select “Device Info”.
Change the name of the device
Change the connection method “Vehicle”: Connect the audio system
to the portable audio player.
“Device”: Connect the portable
audio player to the audio system
Device address
Device telephone number Depending on the model of phone, the number may not be displayed.
Compatibility profile of the device
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.■
Restoring the default settings
Move the controller to the left and select “Default” on the “Device Information” screen.You can confirm and change th e registered device details.
Bluetooth ®
device registration status 1
2
1
2
3
4
5

3895-7. Connecting Bluetooth ®
5
Lexus Display Audio system
NX300h_U_OM78007UDetailed Bluetooth ®
settingsGo to “Bluetooth
* Setup”: “MENU” button  “Setup”  “Bluetooth
* ”
Move the controller to the left and then select “System Settings”.
Select to set the Bluetooth ®
func-
tion on/off.
Change the name of the device.
Change the PIN-code. You can change the PIN-code that is
used to register your Bluetooth ®
devices in the system.
Device address
Select to set the display of the
telephone status on/off You can set the system to show the
status confirmation display when
connecting a telephone.
Select to set the display of the audio player status on/off You can set the system to show the status confirmation display when connecting an
audio player.
Compatibility profile of the system
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.■
Restoring the default settings
Move the controller to the left and select “Default” on the “System Settings” screen.You can confirm and change the detailed Bluetooth ®
settings.
How to check and change detailed Bluetooth ®
settings1
2
1
2
3
4
5
6
7

390 5-8. Bluetooth ®
Audio
NX300h_U_OM78007UListening to Bluetooth ®
AudioWhen a Bluetooth ®
device cannot be connected, check the connection status
on the “Bluetooth
* Audio” screen. If the device is not connected, either register
or reconnect the device. (  P. 3 8 4 , 3 8 6 )
* : Bluetooth is a registered trademark of Bluetooth SIG, Inc.
You can check indicators, such as, signal strength and battery charge on the
screen.
Connection status
Battery charge
Depending on the type of portable
audio player used, some titles may not
be displayed.The Bluetooth ®
audio system enables the user to enjoy music played on a por-
table player from the vehicle speakers via wireless communication.
Status display 1
2
Indicators Conditions
Connection status Good Not connected
Battery charge Full Empty

3915-8. Bluetooth ®
Audio
5
Lexus Display Audio system
NX300h_U_OM78007U Pressing the “MEDIA” button displays the Bluetooth ®
audio top screen from any
screen of the selected source. ■
Menu screen
 P. 3 5 8■
Selecting a song
Press the “  ” or “  ” on the “PRST•TRACK” button or turn the
“TUNE•SCROLL” knob to select the desired song number.
To fast-forward or reverse, press and hold the “  ” or “  ” on the
“PRST•TRACK” button. ■
Selecting a play mode
Move the controller to the right and then select “Browse”.
Select the desired play mode, and then select a song to begin using the
selected play mode.■
Displaying the now playing list
Move the controller to the right and then select “Now Playing List”.Bluetooth ®
audio top screen
1
2
