98 2. Instrument cluster
NX300h_U_OM78007U Background color of drive mode Background color changes according to the drive mode. (  P. 303)
• Sport mode: Red
• Eco drive mode: Blue
When in Normal mode, the background color is Black.
Outside temperature Displays the outside temperature within the range of -40  F (-40  C) to 122  F
(50  C). Low outside temperature indicator comes on when the ambient temperature
is 37  F (3  C) or lower.
Displays the vehicle speed
Shift position and shift range Displays the selected shift posi tion or selected shift range (  P. 2 0 8 )
Speedometer Displays the vehicle speed
Fuel gauge Displays the quantity of fuel remaining in the tank
Multi-information display Presents the driver with a variety of vehicle data (  P. 1 0 2 )
Displays warning messages in case of a malfunction (  P. 5 7 2 )
Odometer, trip meter and maintena nce required information displayOdometer:
Displays the total distance the vehicle has been driven
Tr i p m e t e r :
Displays the distance the vehicle has been driven since the meter was last reset.
Trip meters “A” and “B” can be used to record and display different distances indepen-
dently.
Maintenance required information:
Displays the remaining distance until the engine oil should be changed.
• Displays the maintenance required information when the power switch is ON
mode.
• It can be reset from the “settings display” of the multi-information display.
(  P. 1 0 2 )
Tachometer Displays the engine speed in revolutions per minute 3
4
5
6
7
8
9
10

506 7-3. Do-it-yourself maintenance
NX300h_U_OM78007U ■
After changing the engine oil
The engine oil maintenance da ta should be reset. Perform the following procedures:
Press of the meter control switch.
Press or of the meter control switch,
select , and then press .
Press or of the meter control switch,
select the “Oil Mainte nance” screen and then
press and hold the .
Select the “Yes” and push .
A message is displayed on the multi-informa-
tion display. 1
2
3
4
5

574 8-2. Steps to take in an emergency
NX300h_U_OM78007U ■
If “Depress Brake When Vehicle Is Stopped Hybrid System May Overheat” is shown
Message is displayed when the accelerator pedal is depressed to maintain the vehicle
position when stopped on a upward slope, etc.
If this continues, the hybrid system may overheat.
Release the accelerator pedal and depress the brake pedal. ■
If “Oil Maintenance Required Soon” is shown
Indicates that the engine oil is scheduled to be changed. (The indicator will not work
properly unless the oil maintenance data has been reset.)
Check the engine oil, and change if necessar y. After changing the engine oil, the oil
change system should be reset. (  P. 5 0 6 )■
If “Oil Maintenance Required” is shown
Indicates that the engine oil should be changed. (After the engine oil is changed and the
oil maintenance data has been reset.)
Check and change the engine oil, and oil filt er by your Lexus dealer. After changing the
engine oil, the oil change system should be reset. (  P. 5 0 6 )■
If “See Owner’s Manual” is shown ●
If the following messages are shown, following the instru ctions, accordingly.
• “Engine Coolant Temp High” (  P. 6 0 0 )●
If the following messages are sh own, there may be a malfunction.
Immediately have the vehicle inspected by your Lexus dealer.
• “Hybrid System Malfunction”
•“Check Engine”
• “Hybrid Battery System Malfunction”
• “Accelerator System Malfunction”
• “Braking Power Low”
• “Smart Access System Malfunction” ●
If the following messages are sh own, there may be a malfunction.
Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing
to drive the vehicle may be dangerous.
•“Low Oil Pressure”
• “Charging System Malfunction” ■
Warning buzzer
 P. 5 6 9
NOTICE ■
“High Power Consumption Partial Limit On AC/Heater Operation” is frequently
shown
There is a possible malfunction relating to the charging system or the 12-volt battery
may be deteriorating. Have the vehicle inspected by your Lexus dealer.
