LEXUS NX300H 2016 Owners Manual

4416-1. Using the air conditioning system and defogger
6
Interior features
NX300h_OM_USA_OM78082U
Turns the heated steering wheel on/off
The indicator light comes on when the
heated steering wheel is operating.
■Operation condition
●The heated steering wheel can be used when the power switch is in ON mode.
■Timer
●The heated steering wheel will automati cally turn off after about 30 minutes.
Vehicles without seat ventilators
Each time the switch is pressed, the
operation condition changes as follows.
Hi (3 segments lit)  Mid (2 segments
lit)  Lo (1 segment lit)  Off
The level indicator (amber) light up dur-
ing operation.
Vehicles with seat ventilators
Each time the switch is pressed, the
operation condition changes as follows.
Hi (3 segments lit)  Mid (2 segments
lit)  Lo (1 segment lit)  Off
The indicator (amber) and level indica-
tor (green) light up during operation.
■Operation condition
The seat heaters can be used when the power switch is in ON mode.
Heated steering wheel
Seat heaters
Level
indicator
Level
indicator

4426-1. Using the air conditioning system and defogger
NX300h_OM_USA_OM78082U
Each time the switch is pressed, the
operation condition changes as follows.
Hi (3 segments lit)  Mid (2 segments
lit)  Lo (1 segment lit)  Off
The indicator (green) and level indicator
(green) light up during operation.
■Operation condition
The seat ventilators can be used when the power switch is in ON mode.
Seat ventilators
Level
indicator

4436-2. Using the interior lights
6
Interior features
NX300h_OM_USA_OM78082U
Interior lights list
Outer foot lights
Personal lights (P. 444)
Front interior light ( P. 444)
Rear interior light ( P. 4 4 5 )
Footwell lights
• When the power switch is in ON mode, th e footwell lights will turn on. However, if
the instrument panel light cont rol switch is turned to minimum, the footwell lights will
turn off. ( P. 9 9 )
• When shifting the shift lever is in a position other than P, the brightness of the foot-
well light will reduce intensity.
1
2
3
4
5

4446-2. Using the interior lights
NX300h_OM_USA_OM78082U
Turns the light on/off (touch the light)
The rear interior light also turns on/off.
However, when the rear interior light
has already been turned on, it will not be
controlled by front interior light opera-
tions.
Turns the door position on/off On
The front and rear interior lights turn on/
off when a door is opened/closed.
Off
Turns the lights on/off (touch the lights)
Front interior light
1
2
Personal lights

4456-2. Using the interior lights
6
Interior features
NX300h_OM_USA_OM78082U
Tu r n s t h e l i g h t o n /o f f
The rear interior light is also turned on/
off by the front interior light operations.
If the light is turned on by front interior
light operation, the rear interior light
cannot turn off by pressing the switch.
●Illuminated entry system: The lights automatically turn on/off according to power switch
mode, the presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are opened/closed.
●If the interior lights remain on when the power switch is turned off, the lights will go off
automatically after 20 minutes.
●In the following cases, the front interior li ghts and personal lights may not respond as
normal.
• When water, dirt, etc., have adhered to the lens surface
• When operated with a wet hand
• When wearing gloves, etc.
●Settings (e.g. the time elapsed before the lights turn off) can be changed.
(Customizable features: P. 6 3 5 )
Rear interior light
NOTICE
●Never remove the lens for the front interior light and personal lights. Otherwise, the
lights will be damaged. If the lens need to remove, contact your Lexus dealer.
●To prevent 12-volt battery discharge, do not leave the lights on longer than necessary
when the hybrid system is off.

4466-3. Using the storage features
NX300h_OM_USA_OM78082U
List of storage features
Glove box ( P. 4 4 7 )
Bottle holders ( P. 4 4 8 )
Console box ( P. 4 4 7 ) Cup holders (
P. 4 4 8 )
Sunglass holder ( P. 4 4 9 )
WA R N I N G
●Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other stored items.
• Lighters or spray cans may explode. If they come into contact with other stored items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
●When driving or when the glove box and the console box are not in use, keep it
closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside.
1
2
3
4
5

4476-3. Using the storage features
6
Interior features
NX300h_OM_USA_OM78082U
Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the tail lights are on.
Lift the lid while pushing the button
to release the lock.
Vehicles with the wireless charger:
Lift the wireless charger.
●The console box light turns on when the tail lights are on.
Glove box
1
2
3
Console box
1
2
●Vehicles without the wireless charger:
The tray slides forward/backward and can be
removed.

4486-3. Using the storage features
NX300h_OM_USA_OM78082U
■Cup holders
■Bottle holders
●When storing a bottle, close the cap.
●The bottle may not be stored depending on its size or shape.
Cup holders/bottle holders
FrontRear
Fold down the armrest and release
the button.
FrontRear
WA R N I N G
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or sudden
braking, causing injury. If possible , cover hot drinks to prevent burns.

4496-3. Using the storage features
6
Interior features
NX300h_OM_USA_OM78082U
Remove the lid using the strap.
●The back side of the lid for the sunglass holder can be used as a vanity mirror.
(  P. 4 5 5 )
NOTICE
●To prevent damage to the rear cup holder, stow the cup holder before stowing the
armrest.
●Do not place open bottles or glass and paper cups containing liquid in the bottle hold-
ers. The contents may spill and glasses may break.
Sunglass holder
Strap
●The removed the lid of the sunglass holder can
be stored on the tray in the console box.

4506-3. Using the storage features
NX300h_OM_USA_OM78082U
Luggage compartment features
Raise the hook to use.
The cargo hooks are provided for
securing loose items.
Raise the hook to use.
The cargo net can be hanged, using the
hook.
Cargo hooks
WA R N I N G
To avoid injury, always return the hooks to their stowed positions when not in use.
Cargo net hooks
WA R N I N G
To avoid injury, always return the hooks to their stowed positions when not in use.
