4187-2. Steps to take in an emergency
LEXUS NX300h Owners Manual_USA_M78578_en
■“Engine Coolant Temp High” is
shown on the multi-information dis-
play
1 Stop the vehicle in a safe place and
turn off the air conditioning system,
and then stop the hybrid system.
2 If you see steam:
Carefully lift the hood after the
steam subsides.
If you do not see steam:
Carefully lift the hood.
3 After the hybrid system has cooled
down sufficiently, inspect the hoses
WARNING
●Do not allow children near the 12-volt
battery.
■After recharging the 12-volt battery
Have the 12-volt battery inspected at
your Lexus dealer as soon as possible.
If the 12-volt battery is deteriorating, con-
tinued use may cause the 12-volt battery
to emit a malodorous gas, which may be
detrimental to the health of passengers.
■When exchanging the 12-volt battery
After exchanging, securely attach the
exhaust hose and exhaust hole plug to
the exhaust hole of the exchanged 12-
volt battery. If not properly installed,
gases (hydrogen) may leak into the vehi-
cle interior, and there is the possible dan-
ger of the gas igniting and exploding.
NOTICE
■When handling jumper cables
When connecting the jumper cables,
ensure that they do not become entan-
gled in the cooling fans or belt.
■To prevent damaging the vehicle
The exclusive jump starting terminal is to
be used when charging the 12-volt bat-
tery from another ve hicle in an emer-
gency. It cannot be used to jump start
another vehicle.
If your vehicle overheats
The following may indicate that
your vehicle is overheating.
 The needle of the engine coolant
temperature gauge ( P.84)
enters the red zone, or a loss of
hybrid system power is experi-
enced. (For example, the vehicle
speed does not increase.)
 “Engine Coolant Temp High” or
“Hybrid System Overheated” is
shown on the multi-information
display.
 Steam comes out from under the
hood.
Correction procedures

4197-2. Steps to take in an emergency
LEXUS NX300h Owners Manual_USA_M78578_en
7
When trouble arises
and radiator core (radiator) for any
leaks.
Radiator
Cooling fans
If a large amount of coolant leaks, immedi-
ately contact your Lexus dealer.
4The coolant level is satisfactory if it
is between the “FULL” and “LOW”
lines on the reservoir.
Reservoir
“FULL” line
“LOW” line
5 Add coolant if necessary.
Water can be used in an emergency if coolant is unavailable.
6
Start the hybrid system and turn the
air conditioning system on to check
that the radiator cooling fans oper-
ate and to check for coolant leaks
from the radiator or hoses.
The fans operate when the air conditioning
system is turned on immediately after a
cold start. Confirm that the fans are oper-
ating by checking the fan sound and air
flow. If it is difficult to check these, turn the
air conditioning system on and off repeat-
edly.
(The fans may not oper ate in freezing tem-
peratures.)
7 If the fans are not operating:
Stop the hybrid system immediately
and contact your Lexus dealer.
If the fans are operating:
Have the vehicle inspected at the
nearest Lexus dealer.
8 Check if “Engine Coolant Temp
High” is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact
your Lexus dealer.
If the message is not displayed:
Have the vehicle inspected at the
nearest Lexus dealer.
A
B
A
B
C

4207-2. Steps to take in an emergency
LEXUS NX300h Owners Manual_USA_M78578_en
■If “Hybrid System Overheated” is
shown on the multi-information dis-
play
1 Stop the vehicle in a safe place.
2 Stop the hybrid system and care-
fully lift the hood.
3 After the hybrid system has cooled
down, inspect the hoses and radia-
tor core (radiator) for any leaks.
Radiator
Cooling fans
If a large amount of coolant leaks, immedi-
ately contact your Lexus dealer.
4The coolant level is satisfactory if it
is between the “FULL” and “LOW”
lines on the reservoir.
Reservoir
“FULL” line
“LOW” line 5
Add coolant if necessary.
Water can be used in an emergency if
coolant is unavailable.
6After stopping the hybrid system
and waiting for 5 minutes or more,
start the hybrid system again and
check if “Hybrid System Over-
heated” is shown on the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact your
Lexus dealer.
If the message is not displayed:
The hybrid system temperature has
dropped and the vehicle may be driven
normally.
However, if the message appears again fre-
quently, contact your Lexus dealer.
A
B
A
B
C
WARNING
■To prevent an accident or injury when
inspecting under the hood of your
vehicle
Observe the following precautions.
Failure to do so may result in serious
injury such as burns.
●If steam is seen coming from under the
hood, do not open the hood until the
steam has subsided. The engine com-
partment may be very hot.

4217-2. Steps to take in an emergency
LEXUS NX300h Owners Manual_USA_M78578_en
7
When trouble arises
1Stop the hybrid system. Shift the
shift lever to P and set the parking
brake.
2 Remove the mud, snow or sand
from around the front wheels.
3 Place wood, stones or some other
material under the front wheels to
help provide traction.
4 Restart the hybrid system.
5 Shift the shift lever to D or R,
release the parking brake. Then,
while exercising caution, depress
the accelerator pedal.
■When it is difficult to free the vehicle
Press to turn off TRAC. ( P.273)
WARNING
●After the hybrid system has been
turned off, check that the “READY”
indicator is off. When the hybrid sys-
tem is operating, the gasoline engine
may automatically start, or the cooling
fan may suddenly operate even if the
gasoline engine stops. Do not touch or
approach rotating parts such as the
fan, which may lead to fingers or cloth-
ing (especially a tie, a scarf or a muf-
fler) getting caught, resulting in serious
injury.
●Do not loosen the coolant reservoir
cap while the hybrid system and radia-
tor are hot.
High temperature steam or coolant
could spray out.
NOTICE
■When adding engine/power control
unit coolant
Add coolant slowly after the hybrid sys-
tem has cooled down sufficiently. Adding
cool coolant to a hot hybrid system too
quickly can cause damage to the hybrid
system.
■To prevent damage to the cooling sys-
tem
Observe the following precautions:
●Avoid contaminating the coolant with
foreign matter (such as sand or dust
etc.).
●Do not use any coolant additive.
If the vehicle becomes stuck
Carry out the following proce-
dures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
Recovering procedure

LEXUS NX300h Owners Manual_USA_M78578_en
469What to do if... (Troubleshooting)
Is the power switch in ON mode?
If you cannot release the shift lever
by depressing the brake pedal with
the power switch in ON mode
( P.181)
 It is locked automatically to prevent
theft of the vehicle. ( P.175)
 Is the window lock switch pressed?
The power window except for the
one at the driver’s seat cannot be
operated if the window lock switch
is pressed. ( P.149)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or ON mode (the
hybrid system is not operating) for a
period of time. ( P.177)
 The seat belt reminder light is flash-
ing
Are the driver and the passengers wearing the seat belts? (
P.393)
 The parking brake indicator is on
Is the parking brake released?
( P.184)
Depending on the situation, other
types of warning buzzer may also
sound. ( P.388, 398)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm
sounds. ( P.77)
To stop the alarm, turn the power
switch to ON mode or start the hybrid
system.
 Is the message displayed on the
multi-information display?
Check the message on the multi-
information display. ( P.398)
 When a warning light turns on or a
warning message is displayed, refer
to P.388, 398.
The shift lever cannot be shifted
from P even if you depress the
brake pedal
The steering wheel cannot be
turned after the hybrid system is
stopped
The windows do not open or
close by operating the power
window switches
The power switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

474Alphabetical Index
LEXUS NX300h Owners Manual_USA_M78578_en
Replacing the battery...............................369
Electronically Controlled Brake System (ECB) .............................................................272
Emergency flashers ....................................380
Emergency, in case of If a warning buzzer sounds ................. 388
If a warning light turns on ..................... 388
If a warning message is displayed.....398
If the 12-volt battery is discharged ...... 414
If the electronic key does not operate properly......................................................... 412
If the fuel filler door cannot be opened .............................................................................411
If the hybrid system will not start ........409
If the vehicle is trapped in rising water .......................................................................... 381
If you have a flat tire .................................. 402
If you lose your keys.....................................411
If you think something is wrong .........386
If your vehicle becomes stuck............... 421
If your vehicle has to be stopped in an
emergency ............................................... 380
If your vehicle needs to be towed .....383
If your vehicle overheats ......................... 418
Energy monitor ............................................... 99
Engine .............................................................. 425 Accessory mode ......................................... 177
Compartment .............................................348
Engine switch................................................. 174
Hood................................................................ 346
How to start the hybrid system ............ 174
Identification number ............................... 425
If your vehicle has to be stopped in an
emergency ............................................... 380
Ignition switch (power switch) .............. 174
Overheating.................................................. 418
Power switch ................................................. 174
Engine compartment cover .................... 349
Engine coolant Capacity ......................................................... 427
Checking .........................................................351
Preparing and checking before winter .......................................................................... 279
Warning light .............................................. 389
Engine coolant temperature gauge ....... 84
Engine oil Capacity ......................................................... 426
Checking .......................................................349
Warning light .............................................. 389
Engine switch .................................................. 174
EPS (Electronic Power Steering) Function .......................................................... 272
Warning light .............................................. 390
EV drive mode................................................178
EV indicator ...................................................... 68
Event data recorder (E DR) ........................... 8
F
Flat tire ............................................................. 402
Tire pressure warning system ............ 359
Floor mats .......................................................... 24
Fluid Brake ................................................................ 429
Transmission.................................................428
Washer ...........................................................353
Fog lights Replacing light bulbs ................................375
Switch................................................................ 196
Front passenger occupant classification system ................................................................ 41
Front passenger’s seat belt reminder light .......................................................................... 393
Front seat heaters........................................300
Front seats ........................................................132 Adjustment ......................................................132
Cleaning .........................................................335
Correct driving posture ............................ 25
Driving position memory ........................ 138
Head restraints............................................... 141
Power easy access system .................... 138
Seat heaters ................................................. 300
Seat position memory .............................. 138
Front side marker lights Light switch .................................................... 190

LEXUS NX300h Owners Manual_USA_M78578_en
Alphabetical Index475
Replacing light bulbs................................ 376
Wattage............................................................ 431
Front turn signal lights Replacing light bulbs.................... 375, 376
Turn signal lever .......................................... 183
Wattage............................................................ 431
Fuel Capacity ......................................................... 425
Fuel gauge ....................................................... 84
Gas station information..........................484
Information .................................................... 432
Refueling ........................................................ 203
Type.................................................................. 425
Warning light ............................................... 393
Fuel filler door ............................................... 203 Refueling ........................................................ 203
When the fuel filler door cannot be opened ............................................................411
Fuses ................................................................... 371
G
Garage door opener ................................. 322
Gas station information ............................ 484
Gauges ............................................................... 84
Glove box ....................................................... 306
Glove box light ............................................. 306
Grocery bag hooks .................................... 309
H
Head restraints ................................................ 141
Head-up display.............................................. 95
Headlights ....................................................... 190 Automatic headlight leveling .................. 191
Automatic High Beam ..............................193
Light switch .................................................... 190
Replacing light bulbs................................ 375
Heated steering wheel ..............................300
Heaters Automatic air conditioning system ..... 291
Heated steering wheel............................ 299
Outside rear view mirrors .................... 292 Seat heaters ................................................. 300
High mounted stoplight Replacing light bulb ..................................375
Hill-start assist control ............................... 273
Hood ................................................................. 346 Open................................................................346
Hooks Cargo hooks............................................... 308
Retaining hooks (floor mat) ..................... 24
Horn ....................................................................144
Hybrid battery (traction battery) Location ............................................................. 70
Specification ................................................. 426
Hybrid battery air vent ..................................72
Hybrid system ...................................................67 Acoustic vehicle alerting system...........69
Emergency shut off system...................... 73
Energy monitor/consumption screen99
EV drive mode............................................. 178
High voltage components ....................... 70
Hybrid System Indicator ........................... 87
Hybrid system precautions...................... 70
Hybrid vehicle driving tips .................... 277
If the hybrid system will not start ....... 409
Overheating .................................................. 418
Power switch..................................................174
Regenerative braking .................................68
Starting the hybrid system .......................174
Warning lights ............................................ 388
Hybrid System Indicator......................84, 87
Hybrid transmission..................................... 180
I
I/M test ............................................................ 342
Identification Engine..............................................................425
Vehicle ............................................................ 424
Ignition switch (Power switch) ................. 174
Illuminated entry system ........................... 302
Immobilizer system........................................ 75
Indicators ........................................................... 82

LEXUS NX300h Owners Manual_USA_M78578_en
Alphabetical Index479
How to wear your seat belt ......................27
How your child should wear the seat belt
.............................................................................27
Pregnant women, proper seat belt use ............................................................................ 26
Reminder light and buzzer ................... 393
Seat belt extender .........................................27
Seat belt instructions for Canadian own- ers...................................................................456
Seat belt pretensioners .............................. 30
SRS warning light ......................................390
Seat heaters ................................................... 299
Seat position memory................................. 138
Seat ventilators .............................................. 301
Seating capacity................................. 164, 424
Seats Adjustment............................................132, 133
Adjustment precautions .................132, 134
Child seats/child restraint system installa-tion .....................................................................47
Cleaning......................................................... 335
Driving position memory........................ 138
Folding down the rear seatbacks........134
Front seat heaters ..................................... 300
Head restraint..................................................141
Power easy access system .................... 138
Properly sitting in the seat ........................ 25
Rear seat heaters ...................................... 300
Seat position memory .............................. 138
Seat ventilators............................................. 301
Sécurité de l’enfant Précautions avec les coussins gonflables.........................................................................460
Sensor Automatic High Beam system..............193
BSM (Blind Spot Monitor) ................... 265
Inside rear view mirror..............................145
Intuitive parking assist.............................. 248
Kick sensor....................................................... 118
Radar sensor................................................205
Rain-sensing windshield wipers.........200
Service plug ...................................................... 70 Service reminder message ..................... 339
Shift lever ......................................................... 180
Shift lock system.............................................. 181
Side airbags ...................................................... 32
Side doors.......................................................... 110
Side marker lights
Light switch .................................................... 190
Replacing light bulbs ....................375, 376
Wattage ............................................................431
Side mirrors .....................................................146 Adjusting and folding................................ 146
Blind Spot Monitor (BSM).................... 262
Heaters............................................................ 292
Side turn signal lights Replacing light bulbs ................................375
Turn signal lever .......................................... 183
Smart access system with push-button start...................................................................126Antenna location ..........................................126
Entry functions ....................................... 110, 115
Starting the hybrid system .......................174
Warning message .................................... 398
Snow tires ....................................................... 279
Spare tire Inflation pressure ....................................... 430
Storage location .........................................402
Spark plug ...................................................... 428
Specifications ................................................ 424
Speedometer ................................................... 84
Sport mode .................................................... 270
Steering wheel Adjustment ......................................................143
Heated steering wheel ............................299
Power easy access system .................... 138
Stop lights Replacing light bulbs ................................375
Storage feature ............................................305
Storage precautions...................................305
Stuck If the vehicle becomes stuck ..................421
Sun visors ..........................................................312
