1664-1. Before driving
LEXUS NX300h Owners Manual_USA_M78578_en
■Break-in schedule
If your vehicle is new or equipped with any
new power train components (such as an
engine, transmission, differential or wheel
bearing), Lexus recommends that you do
not tow a trailer until the vehicle has been
driven for over 500 miles (800 km).
After the vehicle has been driven for over
500 miles (800 km), you can start towing.
However, for the next 500 miles (800 km),
drive the vehicle at a speed of less than 50
mph (80 km/h) when towing a trailer, and
avoid full throttle acceleration.
■Maintenance
●If you tow a trailer, your vehicle will
require more frequent maintenance due
to the additional load. (See “Warranty
and Services Guide”, “Owner’s Manual
Supplement” or “Scheduled Mainte-
nance”.)
●Retighten the fixing bolts of the towing
ball and bracket after approximately 600
miles (1000 km) of trailer towing.
■If trailer sway occurs
One or more factors (crosswinds, passing
vehicles, rough roads, etc.) can adversely
affect handling of your vehicle and trailer,
causing instability.
●If trailer swaying occurs:
• Firmly grip the steering wheel. Steer
straight ahead.
Do not try to control trailer swaying by
turning the steering wheel.
• Begin releasing the accelerator pedal immediately but very gradually to reduce
speed.
Do not increase sp eed. Do not apply
vehicle brakes.
If you make no extreme correction with the
steering or brakes, your vehicle and trailer
should stabilize.
●After the trailer swaying has stopped:
• Stop in a safe place. Get all occupants out of the vehicle.
• Check the tires of the vehicle and the trailer.
• Check the load in the trailer.
Make sure the load has not shifted.
Make sure the tongue weight is appropri-
ate, if possible. • Check the load in the vehicle.
Make sure the vehicle is not overloaded
after occupants get in.
If you cannot find any problems, the speed
at which trailer swayin g occurred is beyond
the limit of your part icular vehicle-trailer
combination. Drive at a lower speed to pre-
vent instability. Reme mber that swaying of
the towing vehicle-trailer increases as
speed increases.
WARNING
■Trailer towing precautions
To tow a trailer safely, use extreme care
and drive the vehicle in accordance with
the trailer’s characteristics and operating
conditions. Failure to do so could cause
an accident resulting in death or serious
injury. Vehicle stability and braking per-
formance are affected by trailer stability,
brake setting and performance, and the
hitch. Your vehicle will handle differently
when towing a trailer.
■To avoid accident or injury
●Do not exceed the TWR, unbraked
TWR, GCWR, GVWR or GAWR.
●Adjust the tongue weight within the
appropriate range. Place heavier loads
as close to the trailer axle as possible.
●Do not exceed 65 mph (104 km/h),
the posted towing speed limit or the
speed limit for your trailer as set forth
in your trailer owner’s manual, which-
ever is lowest. Slow down sufficiently
before making a turn, in cross winds,
on wet or slippery surface, etc. to help
avoid an accident. If you experience a
vehicle-trailer instability from reduc-
ing a certain speed, slow down and
make sure you keep your vehicle
speed under the speed of which you
experience the instability.
●Do not make jerky, abrupt or sharp
turns.

4298-1. Specifications
LEXUS NX300h Owners Manual_USA_M78578_en
8
Vehicle specifications
*: The fluid capacity is the quantity of reference.
If replacement is necessary, contact your Lexus dealer.
*: Minimum pedal clearance when depressed with a force of 110 lbf (490 N, 50.0 kgf)
while the hybrid system is operating.
NOTICE
■Transmission fluid type
Using transmission fluid other than the above type may cause abnormal noise or vibra-
tion, or ultimately damage the transmission of your vehicle.
Rear differential (Rear electric motor)
Fluid capacity*1.9 qt. (1.8 L, 1.6 Imp.qt.)
Fluid typeToyota Genuine ATF WS
NOTICE
■Transmission fluid type
Using transmission fluid other than the above type may cause abnormal noise or vibra-
tion, or ultimately damage the transmission of your vehicle.
Brakes
Pedal clearance*4.13 in. (105 mm) Min.
Brake pad wear limit0.04 in. (1.0 mm)
Pedal free play0.04 — 0.24 in. (1.0 — 6.0 mm)
Fluid type• FMVSS No. 116 DOT 3 or SAE J1703
• FMVSS No. 116 DOT 4 or SAE J1704
Steering
Free playLess than 1.2 in. (30 mm)

LEXUS NX300h Owners Manual_USA_M78578_en
Alphabetical Index473
rideau ...........................................................460
Précautions générales avec les coussins gonflables ...................................................460
Cruise control Dynamic radar cruise control with full-speed range .............................................. 237
Cup holders ................................................... 306
Curtain shield airbags .................................. 32
Customizable features .............................. 443
D
Daytime running light system .................... 191
Deck board .................................................... 309
Deck under tray ........................................... 309
Defogger Outside rear view mirrors .................... 292
Rear window ................................................ 292
Windshield .................................................... 292
Differential ...................................................... 429
Dimension ...................................................... 424
Dinghy towing................................................. 173
Display BSM (Blind Spot Monitor) ................... 262
Drive information .......................................... 90
Dynamic radar cruise control with full-speed range .............................................. 237
Energy monitor.............................................. 99
Head-up display ........................................... 95
Intuitive parking assist.............................. 248
LDA (Lane Departure Alert with steering control) .........................................................227
LTA (Lane Tracing Assist)......................218
Multi-information display .......................... 89
Warning messages ..................................398
Do-it-yourself maintenance .................... 344
Door lock Back door......................................................... 115
Side doors ........................................................ 110
Smart access system with push-button start .................................................................. 126
Wireless remote control..........................107 Doors
Automatic door lock ing and unlocking
system.............................................................. 113
Back door ......................................................... 114
Door glasses ................................................. 148
Door lock .......................................................... 110
Outside rear view mirrors...................... 146
Rear door child-protectors ..................... 113
Side doors ........................................................ 110
Drive information ........................................... 90
Drive-start control ............................. 157, 180
Driver’s seat belt remi nder light ............ 393
Driver’s seat position memory ................ 138
Driving Break-in tips ...................................................157
Correct posture............................................. 25
Driving mode select switch .................. 270
Hybrid vehicle driving tips .................... 277
Procedures .................................................... 156
Winter drive tips ......................................... 279
Driving position memory........................... 138 Memory recall function............................ 139
Dynamic radar cruise control with full- speed rangeFunction .......................................................... 237
E
E-Four .............................................................. 273
ECB (Electronically Controlled Brake Sys-
tem) .................................................................272
Eco mode........................................................ 270
EDR (Event data recorder) ........................... 8
Electric motor Location ............................................................. 67
Specification ................................................. 426
Electric Power Steering (EPS) Function .......................................................... 272
Warning light .............................................. 390
Electronic key Battery-saving function............................. 127
If the electronic key does not operate properly .........................................................412

LEXUS NX300h Owners Manual_USA_M78578_en
Alphabetical Index477
Vanity lights .................................................... 312
Wattage............................................................ 431
Welcome light illumination control ....... 111
Light bulbs Replacing ........................................... 375, 376
Wattage............................................................ 431
LTA (Lane Tracing Assist) .........................218
Luggage cover .............................................. 310
M
Maintenance Do-it-yourself maintenance ................. 344
General maintenance .............................340
Maintenance data...................................... 424
Maintenance requirements .................. 339
Malfunction indicator lamp ..................... 389
Meter Head-up display ........................................... 95
Indicators ..........................................................80
Instrument panel light control ................88
Meters ................................................................ 84
Multi-information display .......................... 89
Warning lights ............................................ 388
Warning messages ..................................398
Micro dust and pollen filter ..................... 297
Mirrors Inside rear view mirror.............................. 144
Outside rear view mirror defoggers 292
Outside rear view mirrors ......................146
Vanity mirrors................................................ 312
Moon roof Jam protection function............................. 151
Operation....................................................... 150
Warning message.......................... 152, 398
Multi-information display Clock .................................................................. 84
Drive information .......................................... 90
Dynamic radar cruise control with full-speed range .............................................. 237
Energy monitor.............................................. 99
Language....................................................... 446
LDA (Lane Departure Alert with steering control) ........................................................ 227
LTA (Lane Tracing Assist) ..................... 218
Warning messages.................................. 398
N
Noise from under vehicle ...............................6
O
Odometer ......................................................... 84
Oil Engine oil........................................................ 426
Rear differential oil......... ..................... ....... 429
Opener Back door ......................................................... 117
Fuel filler door ..............................................203
Hood ................................................................346
Outside rear view mirrors .........................146 Adjusting and folding................................ 146
Blind Spot Monitor (BSM).................... 262
Linked mirror functi on when reversing
............................................................................147
Mirror position memory .......................... 138
Outside rear view mirror defoggers 292
Outside temperature display .................... 84
Overheating ................................................... 418
P
Paddle shift switches ....................................182
Panic mode ..................................................... 108
Parking brake Operation ....................................................... 184
Parking brake engaged warning buzzer/message ....................................................... 185
Warning light ...............................................392
Parking lights Light switch .................................................... 190
Replacing light bulb ..................................375
Parking Support Brake fu nction (for static
objects) ......................................................... 253 Enabled/disabled on the system .......254
