LEXUS RC200T 2017 Owners Manual

691
9
9-2. Customization
Vehicle specifications
RC200t_RC F_EE(OM24728E)
■Smart entry & start system ( P. 164, 170, 175)
■Wireless remote control (P. 164, 170)
■Driving position memory* (P. 214)
*: If equipped
FunctionDefault settingCustomized setting
Smart entry & start systemOnOffO—O
Smart door unlockingBoth side doorsDriver's doorO—O
Number of consecutive doorlock operationsAs many as desired2 times——O
123
FunctionDefault settingCustomized setting
Wireless remote controlOnOff——O
Unlocking operation
Both side doors
unlocked in one step
Driver's door
unlocked in one step, both side doors unlocked in
two steps
O—O
Trunk unlocking operationPress and hold (short)
One short press
——O
Push twice
Press and hold (long)
Off
123
FunctionDefault settingCustomized setting
Selecting the door linking drivingposition memory with door
unlock operation
Driver's doorBoth side doors——O
123

6929-2. Customization
RC200t_RC F_EE(OM24728E)
■Steering wheel ( P. 220)
*: If equipped
■Outside rear view mirrors (P. 224)
*: If equipped
■Power windows (P. 227)
■Moon roof* (P. 231)
*: If equipped
FunctionDefault settingCustomized setting
Auto tilt away function*OnOff——O
123
FunctionDefault settingCustomized setting
Automatic mirror folding and extending operation*
Linked to the locking/unlocking of
the doors
Off
——OLinked to operation of the engine switch
123
FunctionDefault settingCustomized setting
Mechanical key linked operationOffOn——O
Wireless remote control linkedoperationOffOn——O
Wireless remote control linkedoperation signal (buzzer)OnOff——O
123
FunctionDefault settingCustomized setting
Mechanical key linked operationOffOn——O
Wireless remote control linked
operationOffOn——O
Wireless remote control linked operation signal (buzzer)OnOff——O
123

693
9
9-2. Customization
Vehicle specifications
RC200t_RC F_EE(OM24728E)
■Turn signal lever ( P. 260)
*1: After flashing the turn signal lights when turning left or right while this function is off
and the turn signal lever is moved to the fi rst position in the direction of the flashing
light, the turn signal lights can be selected to be flashing or off.
*2: The turn signal lights keep flashing if the turn signal lever is moved to the first position
in the direction of flashing light.
*3: The turn signal lights will be off if the turn signal lever is moved to the first position in
the direction of flashing light.
■Automatic light control system ( P. 264)
■Stop & Start system (Smart Stop)* (P. 285)
*: If equipped
FunctionDefault settingCustomized setting
The number of times the turn sig- nal lights flash automatically
when the turn signal lever is moved to the first position duringa lane change*1
3
5
——O7
Off*2
Off*3
123
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before headlightsautomatically turn off30 seconds
60 seconds
——O90 seconds
120 seconds
123
FunctionDefault settingCustomized setting
Change the Stop & Start systemduration when the A/C is onStandardExtended—O—
123

6949-2. Customization
RC200t_RC F_EE(OM24728E)
■Lexus parking assist-sensor*1 ( P. 320)
*1: If equipped
*2: When Lexus parking assist-sensor is operating.
■Active rear wing* (P. 379)
*:RC F
■Automatic air conditioning system (P. 478)
■Seat heaters (P. 491)
FunctionDefault settingCustomized setting
Detection distance of the front center sensor*1FarNearO—O
Detection distance of the rearcenter sensorFarNearO—O
Buzzer volume31 to 5O—O
Display setting*2All sensors
displayedDisplay offO—O
123
FunctionDefault settingCustomized setting
Operation of the active rear wingOffOn—OO
123
FunctionDefault settingCustomized setting
Switching between outside airand recirculated air mode linked
to “AUTO” switch operation
OnOffO—O
A/C auto switch operationOnOffO—O
Exhaust gas sensor sensitivityStandard-3 to 3O—O
123
FunctionDefault settingCustomized setting
Seat heater timer controlOffOnO—O
123

695
9
9-2. Customization
Vehicle specifications
RC200t_RC F_EE(OM24728E)
■Illumination ( P. 492)
*: If equipped
FunctionDefault settingCustomized setting
Time elapsed before the interior lights turn off15 seconds
Off
O—O7.5 seconds
30 seconds
Operation after the engineswitch is turned offOnOff——O
Operation when the doors areunlockedOnOff——O
Operation when you approach
the vehicle with the electronic key on your personOnOff——O
Ambient lights and RemoteTouch pad light*OnOff——O
Time elapsed before the outerfoot lights turn off15 seconds
Off
O—O7.5 seconds
30 seconds
Operation of the outer foot lights
when you approach the vehicle with the electronic key on yourperson
OnOff——O
Operation of the outer foot lights
when the doors are unlocked with the power door lock switchOnOff——O
Operation of the outer foot lightswhen a door is openedOnOff——O
Fading out of the outer foot lights
when they turn offLongShort——O
123

6969-2. Customization
RC200t_RC F_EE(OM24728E)
■Vehicle customization
●When the speed-detecting automatic door lock and shift-linked automatic door lock are both on, the door lock operates as follows.
• When shifting the shift lever to any position other than P, both side the doors will be
locked. • If the vehicle is started with both side doors locked, the speed-detecting automaticdoor lock will not operate.
• If the vehicle is started with any door unlocked, the speed-detecting automatic door lock will operate.
●When the smart entry & start system is off, the entry unlock function cannot be custom-ized.
●When the doors remain closed after unlocking the doors and the timer activated auto-
matic door lock function activates, signals will be generated in accordance with the operational signal (Emergency flashers) function setting.
●Some settings can be changed using a switch or the audio system screen. If a setting is
changed using a switch, the changed setting will not be reflected on the audio system screen until the engine switch is turn ed off and then to IGNITION ON mode.
■When customizing using the Remote Touch or Lexus Display Audio controller
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also, to prevent battery discharge, leave the engine running while customizing the features.
WARNING
■During customization
As the engine needs to be running during customization, ensure that the vehicle is
parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle. Thismay lead to death or a serious health hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while customizing fea-
tures.

697
RC200t_RC F_EE(OM24728E)
9
Vehicle specifications
9-3. Items to initialize
*: If equipped
Items to initialize
The following item must be initialized for normal system operation after such
cases as the battery being reconnected, or maintenance being performed on
the vehicle:
ItemWhen to initializeReference
Engine oil maintenance data*After changing the engine oilP. 526
Tire pressure warning system
• When rotating the tires • When changing the tire inflation
pressure by changing traveling speed or load weight, etc.
P. 538

6989-3. Items to initialize
RC200t_RC F_EE(OM24728E)

699
Index
RC200t_RC F_EE(OM24728E)
What to do if...
(Troubleshooting)...................700
Alphabetical index .................... 704
For vehicles with a navigation or multimedia system, refer to the
“NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S
MANUAL” for information regardin g the equipment listed below.
• Navigation system
• Audio/video system
• Lexus parking assist-sensor
• Lexus parking assist monitor

700
RC200t_RC F_EE(OM24728E)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be made
by any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional. ( P. 160)
●If you lose your electronic keys, the risk of vehicle theft increases significantly.
Contact any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional immediately. ( P. 163)
●Is the electronic key battery weak or depleted? (P. 563)
●Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 248)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on your
person.
●The function may not operate properly due to the condition of the radio wave.
( P. 177)
●The function to prevent the electronic key from being left inside the trunk will
operate and you can open the trunk as us ual. Take the key out from the trunk.
( P. 172)
If you have a problem, check the following before contacting any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The trunk lid is closed with the electronic key left inside
