display LEXUS RC350 2021 Owners Manual

3528-2. Customization
Definition of symbols: O = Available, — = Not available
■Gauges, meters and multi-information display (P.62, 66, 71)
Function*1Default settingCustomized setting
LanguageEnglishFrenchOO—Spanish
Units*2miles (MPG US)
km (km/L)
OO—km (L/100 km)
miles (MPG Impe-
rial)
Switch settings*3Drive information 1Desired status
screen
*4—O—
Drive information 1
Current fuel con- sumption
Customizable items: P.73—O—
Average fuel econ-
omy (after reset)
Drive information 2
Distance (driving range)
Average vehicle
speed (after reset)
Drive information 3
Average fuel con- sumption (after refuel)
Elapsed time (after start)
Pop-up displayOnOff—O—
Accent color*3Color 1Color 2OO—
Needle*5Color 1Color 2—O—Color 3
ABC

3538-2. Customization
8
Vehicle specifications
*1: For details about each function: P.76
*2: The default setting varies according to country.
*3:Except F SPORT models
*4: Some status screens cannot be registered (i ndicated on the multi-information display)
*5:F SPORT models
*6: Always observe the legal speed limit when driving on public roads.
*7: On multi-information display
■Door lock (P.88, 91, 317)
Rev indicator*55000 r/min.
Select to set the
desired engine
speed at which the Rev indicator will begin to be dis- played.
—O—
Off
Rev peak*5OnOff—O—
Speed indicator*5OffOn—O—
Speed indicator settings*575 mph (120 km/h)
30 mph to 100 mph (50 km/h to
160km/h)
*6—O—
Eco Driving Indicator LightOnOff—O—
Clock*712-hour display24-hour display—O—
Function*1Default settingCustomized settingABC
FunctionDefault settingCustomized setting
Unlocking using a mechani-
cal key
Driver’s door
unlocked in one
step, both side doors unlocked in two steps
Both side doors
unlocked in one step——O
Automatic door lock
Shifting the shift
lever to position other than P
Off
O—OVehicle speed is
approximately 12
mph (20 km/h) or higher
ABC

3608-2. Customization
function cannot be customized.
●When the doors remain closed after
unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.
●Some settings can be changed using a
switch or the Center Display. If a setting is
changed using a switch, the changed set-
ting will not be reflected on the Center
Display screen until the engine switch is
turned off and then to IGNITION ON
mode.

383What to do if... (Troubleshooting)
ON mode?
If you cannot release the shift lever by
depressing the brake pedal with the engine
switch in IGNITION ON mode. (P.132)
 It is locked automatically to prevent
theft of the vehicle. ( P.127)
 Is the window lock switch pressed?
The power window except for the one at
the driver’s seat cannot be operated if the
window lock switch is pressed. ( P.113)
 The auto power off function will be
operated if the vehicle is left in
ACCESSORY or IGNITION ON
mode (the engine is not running) for
a period of time. ( P.130)
 The seat belt reminder light is flash-
ing
Are the driver and the front passenger
wearing the seat belts? ( P.299)
 The parking brake indicator is on
Is the parking brake released? ( P.137)
Depending on the situation, other types of warning buzzer may also
sound. (
P.295, 303)
 Did anyone inside the vehicle open
a door during setting the alarm?
The sensor detects it and the alarm sounds.
( P.57)
Do one of the following to deactivate
or stop the alarm:
 Unlock the doors.
 Open the trunk using the entry
function or wireless remote control.
 Turn the engine switch to ACCES-
SORY or IGNITION ON mode, or
start the engine.
 Is the message displayed on the
multi-information display?
Check the message on the multi-informa-
tion display. ( P.303)
 When a warning light turns on or a
warning message is displayed, refer
to P.295, 303.
The steering wheel cannot be
turned after the engine is
stopped
The windows do not open or
close by operating the power
window switches
The engine switch is turned off
automatically
A warning buzzer sounds during
driving
An alarm is activated and the
horn sounds
A warning buzzer sounds when
leaving the vehicle
A warning light turns on or a
warning message is displayed

385Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ............................... 275
Automatic air conditioning system .....215
Micro dust and pollen filter..................... 219
ABS (Anti-lock Brake System)................201 Warning light ............................................... 297
Active Sound Control (ASC) ................... 141
Adaptive Variable Suspension System 201
Air conditioning filter ................................. 275
Air conditioning system Air conditioning filter ............................... 275
Automatic air conditioning system .....215
Micro dust and pollen filter..................... 219
Airbags Airbag operating conditions................... 30
Airbag precautions for your child .........32
Correct driving posture .............................23
Curtain shield airbag operating condi-tions .................................................................. 30
Curtain shield airbag precautions ........32
Front passenger occupant classification system ............................................................. 36
General airbag precautions ....................32
Locations of airbags.................................... 28
Modification and disposal of airbags . 35
Side airbag operating conditions ......... 30
Side airbag precautions .............................32
Side and curtain shield airbags operating conditions...................................................... 30
Side and curtain shield airbags precau- tions ...................................................................32
SRS airbags ..................................................... 28
SRS warning light ...................................... 296
Alarm ....................................................................57 Warning buzzer ......................................... 295
Anchor brackets .......................................41, 49
Antennas (smart access system with push-button start)........................................ 95
Anti-lock Brake System (ABS)................201 Warning light ............................................... 297 Approach warning......................................... 181
ASC (Active Sound Control) ................... 141
Assist grips ..................................................... 230
Audio system-linked display .......................76
Automatic air conditioning system ........215
Automatic headlight leveling system ....143
Automatic High Beam ................................144
Automatic light control system................ 142
Automatic transmission ............................... 131
M mode ............................................................134
Paddle shift switches ....................... 133, 134
Snow mode.................................................... 133
Average fuel economy..................................73
Average vehicle speed .................................73
B
Back-up light Replacing light bulbs ................................282
Wattage ......................................................... 338
Battery Battery checking ........................................263
If the battery is discharged ..................... 319
Preparing and checking before winter......................................................................... 205
Warning light ...............................................296
Blind Spot Monitor (BSM).......................... 191
Boost gauge.......................................................74
Brake Brake hold ...................................................... 139
Fluid...................................................................334
Parking brake ................................................137
Warning light ...............................................295
Brake assist ......................................................201
Break-in tips...................................................... 119
Brightness control Instrument panel light control................... 71
BSM (Blind Spot Monitor).......................... 191
C
Card key ............................................................ 84

386Alphabetical Index
CareExterior ........................................................... 242
Interior ............................................................. 245
Seat belts........................................................ 245
Wheels and wheel ornaments............ 242
Cargo capacity...............................................125
Cargo hooks ................................................. 229
Center Display ............................................... 212
Chains .............................................................. 206
Child restraint system Child seats definition................................... 40
Child seats installation........................ 44, 47
Front passenger occupant classification system ............................................................. 36
Installing a CRS to the front passenger seat ....................................................................42
Installing CRS with LATCH anchors . 48
Installing CRS with top tether strap.....50
Riding with children ..................................... 40
Types of child restraint system installation method ............................................................. 41
Using an anchor bracket .......................... 49
Child safety Airbag precautions.......................................32
Battery precautions ........................ 264, 321
Child restraint system.......................... 40, 41
Heated steering wheel or seat heater precautions................................................ 223
How your child should wear the seat belt ............................................................................ 25
Installing child restraints ............................ 40
Moon roof precautions ............................. 116
Power window lock switch...................... 113
Seat belt extender precautions ............. 25
Seat belt precautions .................................. 40
Trunk precautions .......................................... 91
Cleaning Exterior ........................................................... 242
Interior ............................................................. 245
Radar sensor................................................. 158
Seat belts........................................................ 245
Wheels and wheel ornaments............ 242 Clock ........................................................66, 230
Clock settings ............................................... 230
Coat hooks..................................................... 230
Compass ......................................................... 237
Condenser ..................................................... 262
Console box .................................................. 228
Consumption screen .....................................79
Cooling system............................................. 260
Engine overheating................................... 322
Cornering lights .............................................143 Replacing light bulbs ................................282
Cruise control Dynamic radar cruise control with full-speed range ........................................176
Cup holders ................................................... 228
Current fuel consumption ...........................73
Curtain shield airbags .................................. 28
Customizable features ................................351
D
Daytime running light system ................... 142
Daytime running lights Replacing light bulbs ................................282
Defogger Outside rear view mirrors.......................219
Rear window ..................................................219
Windshield ......................................................219
Differential Front differential oil............. .......................333
Rear differential oil......... ..................... .......333
Dimension ...................................................... 328
Dinghy towing.................................................126
Display Center Display .............................................. 212
Drive information .......................................... 73
LDA (Lane Departure Alert with steering control) ........................................................... 171
Multi-information display ............................ 71
Warning messages.................................. 305
Distance until next engine oil change .... 70
Do-it-yourself maintenance .................... 249
Door courtesy lights ................................... 225

387Alphabetical Index
Door lockDoors..................................................................88
Smart access system with push-button start ................................................................... 95
Wireless remote control........................... 86
Doors Automatic door lock ing and unlocking
system ............................................................. 90
Door glasses ....................................................112
Door lock..........................................................88
Open door warning buzzer .........89, 90, 299
Open door warning light ...................... 299
Outside rear view mirrors ....................... 110
Drive distance ...................................................73
Drive info 1/Drive info 2/Drive info 3.....73
Drive information ............................................73
Driver’s seat position memory Driving position memory.........................102
Memory recall function ........................... 104
Power easy access system .....................102
Drive-start control ......................................... 119
Driving Break-in tips .................................................... 119
Correct driving posture .............................23
Driving mode select switch ....................199
Procedures ...................................................... 118
Winter drive tips.........................................205
Driving assist system information display ..............................................................................76
Driving information display .........................73
Driving position memory............................102 Memory recall function ........................... 104
Power easy access system .....................102
Driving range ....................................................73
DRS (Dynamic Rear Steering) ................201
Dynamic radar cruise control Warning message.....................................303
Dynamic radar cruise control with full-speed range .......................................... 176Warning message...................................... 183
Dynamic Rear Steering (DRS) ................201E
Eco Driving Indicator.....................................74
Eco Driving Indicator Light .........................74
EDR (Event data recorder) ............................6
Elapsed time ......................................................73
Electric Power Steering (EPS) ................201 Warning light ............................................... 297
Electronic key .................................................. 84 Battery-saving function..............................96
If the electronic key does not operate properly .........................................................317
Replacing the battery ............................... 277
Emergency flashers .................................... 286
Emergency, in case of If a warning buzzer sounds...................295
If a warning light turns on.......................295
If a warning message is displayed .... 303
If the battery is discharged ..................... 319
If the electronic key does not operate properly .........................................................317
If the engine will not start..........................314
If the fuel filler do or cannot be opened
........................................................................... 316
If the vehicle is trapped in rising water .......................................................................... 287
If you have a flat tire ..................................307
If you lose your keys .................................. 316
If you think something is wrong..........293
If your vehicle becomes stuck .............326
If your vehicle has to be stopped in an emergency ................................................ 286
If your vehicle needs to be towed .... 289
If your vehicle overheats ........................ 322
Engine ACCESSORY mode................................129
Compartment.............................................. 257
Engine switch ................................................. 127
Fuel pump shut off system..................... 294
Hood ................................................................255
How to start the engine ............................ 127
Identification number ...............................329

390Alphabetical Index
Keyless entry ..........................................88, 95
Mechanical key.............................................. 84
Replacing the battery................................277
Warning buzzer ............................................ 95
Wireless remote control........................... 86
Knee airbags .................................................... 28
L
Lane Departure Alert wi th steering control
(LDA) Operation........................................................169
Warning messages .................................... 174
Language (multi-information display) ....76
LDA (Lane Departure Alert with steering control)Operation........................................................169
Warning messages .................................... 174
LDA (Lane Departure Alert with steering control) switch .............................................. 171
LDH (Lexus Dynamic Handling system) .......................................................................... 202
Lever Auxiliary catch lever ................................. 255
Hood lock release lever......................... 255
Shift lever........................................................... 131
Turn signal lever ...........................................136
Wiper lever..................................................... 147
Lexus Dynamic Handling system (LDH) .......................................................................... 202
Lexus Enform Safety Connect.................. 52
Lexus Safety System + Automatic High Beam .............................. 144
LDA (Lane Departure Alert with steering control) ..........................................................169
PCS (Pre-Collision System).................. 162
License plate lights Light switch ..................................................... 142
Replacing light bulbs................................ 282
Light Wattage..........................................................338
Light bulbs Replacing .........................................................281 Lights
Automatic High Beam system ..............144
Front interior lights .................................... 225
Headlight switch...........................................142
Interior lights ................................................. 225
Interior lights list .......................................... 225
Personal lights ............................................. 226
Rear interior lights ..................................... 225
Replacing light bulbs ................................282
Trunk light ......................................................... 93
Turn signal lever .......................................... 136
Vanity lights ....................................................231
Wattage ......................................................... 338
Lock steering column .................................. 127
M
Maintenance Do-it-yourself maintenance .................253
General maintenance ............................. 249
Maintenance date ......................................328
Maintenance requirements ..................248
Malfunction indicator la mp ..................... 296
Master warning light ..................................300
Menu icons.........................................................72
Meter Changing the main meter location......69
Clock...................................................................66
Indicators........................................................... 64
Instrument panel light control................... 71
Meters................................................................. 66
Multi-information display ............................ 71
Settings............................................................... 76
Units..................................................................... 75
Warning lights .............................................295
Warning messages.................................. 303
Micro dust and pollen filter .......................219
Mirrors Inside rear view mirror ............................. 109
Outside rear view mirror defoggers .219
Outside rear view mirrors........................ 110
Vanity mirrors ................................................231

391Alphabetical Index
Moon roofDoor lock linked moon roof operation............................................................................ 115
Jam protection function............................. 115
Operation..........................................................114
Multi-information display .............................. 71 Audio system-linked display................... 76
Boost gauge.....................................................74
Drive information ...........................................73
Drive information 1/Drive information 2/Drive information 3..............................73
Driving assist system information display ............................................................................ 76
Dynamic radar cruise control ............... 176
Eco Driving Indicator ..................................74
Engine oil pressure gauge ........................74
Engine oil temperature gauge ................74
Gear Position ................................................. 75
G-force...............................................................74
LDA (Lane Departure Alert with steering control) ............................................................171
Menu icons .......................................................72
Meter control switches ...............................72
Navigation system-linked display ........ 76
Settings .............................................................. 76
Tire pressure ....................................... 75, 268
Units .................................................................... 75
Vehicle sway warning ................................ 75
Warning message display ....................... 76
Warning messages ..................................303
N
Navigation system-linked display.............76
Noise from under vehicle .............................. 5
O
“ODO TRIP” switch ...................................... 70
Odometer ......................................................... 70
Odometer and trip meter display “ODO TRIP” switch .................................... 70 Oil
Engine oil....................................................... 330
Front differential oil............. .......................333
Rear differential oil......... ..................... .......333
Opener Fuel filler door ............................................... 155
Hood ................................................................255
Trunk ................................................................... 92
Outer foot lights Location .......................................................... 225
Outside rear view mirrors Adjustment ....................................................... 110
BSM (Blind Spot Monitor)....................... 191
Folding.................................................................. 111
Linked mirror functi on when reversing111
Mirror position memory .......................... 102
Outside rear view mirror defoggers .219
RCTA function ............................................... 191
Outside temperature.................................... 66
Overheating .................................................. 322
P
Paddle shift switches ..........................133, 134
Panic mode ....................................................... 86
Parking brake Operation ........................................................137
Parking brake engaged warning buzzer........................................................................... 138
Warning light .............................................. 300
Warning message ...................................... 138
Parking lights Light switch .....................................................142
Replacing light bulbs ................................282
PCS (Pre-Collision System) Function ............................................................162
PCS OFF switch ......................................... 164
Warning light .............................................. 298
Warning message .................................... 303
Personal lights............................................... 225
Power control unit coolant Preparing and checking before winter......................................................................... 205

394Alphabetical Index
Outside rear view mirror switches ...... 110
Paddle shift switches ....................... 133, 134
Parking brake switch ................................. 137
PCS OFF switch ..........................................164
Power door lock switch ............................ 90
Power window switches ............................112
Rear window and outside rear view mir-ror defoggers switch ..............................215
Seat heater switches ................................ 223
Seat ventilator switches .......................... 223
Snow mode switch .....................................133
“SOS” button .................................................. 52
Tilt and telescopic steering control switch .......................................................................... 108
Tire pressure warning reset switch .. 270
Trunk opener main switch ....................... 94
Trunk opener switch ................................... 92
VSC OFF switch ....................................... 202
Window lock switch ................................... 113
Windshield wiper and washer switch147
Windshield wiper de-icer switch ........ 219
T
Tachometer....................................................... 66 Rev indicator ................................................... 69
Rev peak ........................................................... 69
Tail lights Light switch ..................................................... 142
Replacing light bulbs................................ 282
Wattage..........................................................338
Theft deterrent system Alarm .................................................................. 57
Engine immobilizer system ..................... 56
Theft prevention labels............................... 59
Tire inflation pressure Maintenance data...................................... 334
Tire inflation pressu re display function
.........................................................................268
Warning light .............................................. 300
Tire information ..............................................341 Glossary......................................................... 345
Size.................................................................... 343 Tire identification number...................... 342
Uniform Tire Quality Grading ............344
Tire infration pressure .................................. 75
Tire pressure display ... ............................... 268
Tire pressure warning system Function ......................................................... 268
Initializing........................................................269
Installing tire pres sure warning valves
and transmitters.......................................269
Registering ID codes ................................. 271
Warning light .............................................. 300
Tires Chains ............................................................ 206
Checking .......................................................265
If you have a flat tire ..................................307
Inflation pressure ........................................ 273
Information ......................................................341
Replacing .......................................................307
Rotating tires ................................................ 267
Size ....................................................................334
Snow tires ..................................................... 205
Spare tire ........................................................307
Tire inflation pressure display function......................................................................... 268
Tire pressure warning system ............ 268
Warning light .............................................. 300
Tools.................................................................. 307
Top tether strap.........................................41, 49
Total load capacity ...................................... 328
Towing Dinghy towing ...............................................126
Emergency towing................................... 289
Towing eyelet.................................................291
Trailer towing .................................................126
TRAC (Traction Control) ..........................201
Traction Control (TRAC) ..........................201
Trailer towing ..................................................126
Transmission Automatic transmission ............................. 131
Driving mode select switch ................... 199
M mode ............................................................134
Paddle shift switches ....................... 133, 134
