fuel pressure LEXUS RC350 2021 Owners Manual

RC350AWD-RC350-RC300AWD-RC300_U
1
2
3
4
5
6
7
8
9
Pictorial indexSearch by illustration
For safety
and securityMake sure to read through them
(Main topics: Child seat, theft deterrent system)
Vehicle status
information and
indicatorsReading driving-related information
(Main topics: Meters, multi-information display)
Before drivingOpening and closing the doors and windows,
adjustment before driving
(Main topics: Keys, doors, seats)
DrivingOperations and advice which are necessary for driving
(Main topics: Starting engine, refueling)
Interior featuresUsage of the interior features
(Main topics: Air conditioner, storage features)
Maintenance
and careCaring for your vehicle and maintenance procedures
(Main topics: Interior and exterior, light bulbs)
When trouble
arisesWhat to do in case of malfunction and emergency
(Main topics: Battery discharge, flat tire)
Vehicle
specificationsVehicle specifications, customizable features
(Main topics: Fuel, oil, tire inflation pressure)
For ownersReporting safety defects for U.S. owners, and seat belt,
SRS airbag and headlight aim instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically

3TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
4-2. Driving proceduresEngine (ignition) switch .............. 127
Automatic transmission............... 131
Turn signal lever............................. 136
Parking brake ................................. 137
Brake Hold....................................... 139
ASC (Active Sound Control) ... 141
4-3. Operating the lights and wipers Headlight switch ............................ 142
AHB (Automatic High Beam) ............................................................ 144
Windshield wipers and washer ............................................................ 147
4-4. Refueling Opening the fuel tank cap......... 155
4-5. Using the driving support systems Lexus Safety System + ................ 158
PCS (Pre-Collision System)..... 162
LDA (Lane Departure Alert with steering control) ......................... 169
Dynamic radar crui se control with
full-speed range.......................... 176
Intuitive parking assist ................. 185
BSM (Blind Spot Monitor) ......... 191
Driving mode select switch....... 199
Driving assist systems .................. 201
4-6. Driving tips Winter driving tips ....................... 205
5-1. Remote Touch/Display Remote Touch ................................ 210
Center Display ............................... 2125-2. Using the air conditioning system
Automatic air conditioning system............................................................ 215
Heated steering wheel/seat heat- ers/seat ventilators.................... 223
5-3. Using the interior lights Interior lights list ............................ 225
5-4. Using the storage features List of storage features ............... 227
Trunk features ................................ 229
5-5. Using the other interior features Other interior features .............. 230
Garage door opener .................. 232
Compass ......................................... 237
6-1. Maintenance and care Cleaning and protecting the vehi-cle exterior.................................... 242
Cleaning and protecting the vehi- cle interior .................................... 245
6-2. Maintenance Maintenance re quirements .....248
General maintenance................ 249
Emission inspection and mainte- nance (I/M) programs ............. 252
6-3. Do-it-yourself maintenance Do-it-yourself service precautions.......................................................... 253
Hood ................................................. 255
Positioning a floor jack .............. 255
Engine compartment ................. 257
Tires ...

................................................ 265
Tire inflation pressure................. 273
Wheels .............................................. 274
5Interior features
6Maintenance and care

12Pictorial index
Windshield wipers .................................................................................................. P.147
Precautions for winter season .....................................................................................P.205
To prevent freezing (windshield wiper de-icer)
*...................................................P.219
Precautions against car wash ............................. ......................................................... P.243
Fuel filler door .......................................................................................................... P.155
Refueling method .............................................................................................................. P .155
Fuel type/fuel tank capacity ...... ...................................................................................P.330
Tires.......................................................................................................................... ..P.265
Tire size/inflation pressure ........................................................................................... P.334
Winter tires/tire chain ....................................................................................................P.20 5
Checking/rotation/tire pressure warning system.............................................. P.265
Coping with flat tires........................................................................................................ P .307
Hood ..........................................................................................................................P.255
Opening ........................................................................................................................ ....... P.255
Engine oil ..................................................................................................................... .........P.330
Coping with overheating ............................................................................................... P.322
Warning messages ..........................................................................................................P.303
Headlights ................................................................................................................. P.14 2
Parking lights/daytime running lights............................................................... P.142
Turn signal lights ...................................................................................................... P.136
Cornering lights ...................................................................................................... P.142
Side marker lights ................................................................................................... P.142
Tail lights .................................................................................................................... P.142
Stop lights
Back up light
Shifting the shift lever to R ...............................................................................................P.1 32
License plate lights ................................................................................................. P.142
*:If equipped
Light bulbs of the exterior lights for driving
(Replacing method: P. 281, Watts: P.338)
D
E
F
G
H
I
J
K
L
M
N
O

632-1. Instrument cluster
2
Vehicle status information and indicators
Warning lights inform the driver of mal-
functions in the indicated vehicle sys-
tems.
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is
being performed. They will turn off after
the engine is started, or after a few sec-
onds. There may be a malfunction in a
system if a light does not come on, or
turn off. Have the vehicle inspected by
your Lexus dealer.
Warning lights
(U.S.A.)
Brake system warning light*1
(  P.295)
(red)
(Canada)
Brake system warning light*1
(  P.295)
(yellow)
Brake system warning light*1
(  P.295)
High coolant temperature
warning light
*2 (  P.295)
Charging system warning
light
*3 (  P.296)
Low engine oil pressure warn-
ing light
*2 (  P.296)
(U.S.A.)
Malfunction indicator lamp*1
(  P.296)
(Canada)
Malfunction indicator lamp*1
(  P.296)
SRS warning light
*1 (  P.296)
(U.S.A.)
ABS warning light*1 ( P.297)
(Canada)
ABS warning light*1 ( P.297)
(flashes)
(U.S.A.)
Parking brake warning light
(  P.300)
(flashes)
(Canada)
Parking brake warning light
(  P.300)
(flashes) Brake hold operated indicator
*1
(  P.295)
Brake Override System warn-
ing light/Drive-Start Control
warning light
*2 (  P.297)
Electric power steering system
warning light
*1 (  P.297)
(orange)
LDA (Lane Departure Alert)
indicator ( P.298)
(flashes or
illuminates)PCS warning light*1 (  P.298)
Slip indicator
*1 (  P.298)
Open door warning light
(  P.299)
Low fuel level warning light
(  P.299)
Driver’s and front passenger’s
seat belt reminder light
(  P.299)
Rear passenger’s seat belt
reminder lights
*4 (  P.299)
Master warning light
*1
(  P.300)
Tire pressure warning light
*1
(  P.300)

2546-3. Do-it-yourself maintenance
Light bulbs
( P.281)
•Bulb with same num-
ber and wattage rat-
ing as original
• Phillips-head screw- driver
•Flathead screw- driver
•Wrench
Radiator, con-
denser and inter-
cooler radiator
(  P.262)

Tire inflation pres-
sure ( P.273)• Tire pressure gauge
•Compressed air
source
Washer fluid
( P.264)
• Water or washer
fluid containing anti-
freeze (for winter
use)
• Funnel (used only for adding water or
washer fluid)
WARNING
The engine compartment contains many
mechanisms and fluids that may move
suddenly, become hot, or become elec-
trically energized. To avoid death or seri-
ous injury, observe the following
precautions.
■When working on the engine com-
partment
●Keep hands, clothi ng and tools away
from the moving fans and engine drive
belt.
●Be careful not to touch the engine,
radiator, exhaust manifold, etc. right
after driving as they may be hot. Oil
and other fluids may also be hot.
ItemsParts and tools●Do not leave anything that may burn
easily, such as paper and rags, in the
engine compartment.
●Do not smoke, cause sparks or expose
an open flame to fuel or the battery.
Fuel and battery fumes are flammable.
●Be extremely cautious when working
on the battery. It contains poisonous
and corrosive sulfuric acid.
■When working near the electric cool-
ing fans or radiator grille
Be sure the engine switch is off.
With the engine switch in IGNITION
ON mode, the electric cooling fans may
automatically start to run if the air condi-
tioning is on and/or the coolant tempera-
ture is high. ( P.262)
■Safety glasses
Wear safety glasses to prevent flying or
falling material, fluid spray, etc. from get-
ting in your eyes.
NOTICE
■If you remove the air cleaner filter
Driving with the air cleaner filter
removed may cause excessive engine
wear due to dirt in the air.

2736-3. Do-it-yourself maintenance
6
Maintenance and care
The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
( P.334)
Tire valve
Tire pressure gauge 1
Remove the tire valve cap.
2 Press the tip of the tire pressure
gauge onto the tire valve.
3 Read the pressure using the gauge
gradations.
4 If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.
5 After completing the tire inflation
pressure measurement and adjust-
ment, apply soapy water to the
valve and check for leakage.
6 Put the tire valve cap back on.
■Tire inflation pressure check interval
You should check tire inflation pressure
every two weeks, or at least once a month.
Do not forget to check the spare.
■Effects of incorrect tire inflation pres-
sure
Driving with incorrect ti re inflation pressure
may result in the following:
●Reduced fuel economy
●Reduced driving comfort and poor han-
dling
●Reduced tire life due to wear
●Reduced safety
●Damage to the drivetrain
If a tire needs frequent inflating, have it
checked by your Lexus dealer.
■Instructions for checking tire inflation
pressure
When checking tire inflation pressure,
observe the following:
●Check only when the tires are cold.
If your vehicle has been parked for at
least 3 hours or has not been driven for
more than 1 mile or 1.5 km, you will get an
accurate cold tire inflation pressure read-
Tire inflation pressure
Checking the specified tire infla-
tion pressure
Inspection and adjustment pro-
cedure
A
B

3017-2. Steps to take in an emergency
7
When trouble arises
■Brake hold operated indicator (warning buzzer)
■SRS warning light
This warning light system monitors the air-
bag sensor assembly, fr ont impact sensors,
side impact sensors (door), side impact
sensors (front), side impact sensors (rear),
driver’s seat position sensor, driver’s seat
belt buckle switch, front passenger occu-
pant classification system, “AIR BAG ON”
indicator light, “AIR BAG OFF” indicator
light, front passenger’s seat belt buckle
switch, seat belt pret ensioners, airbags,
interconnecting wiring and power sources.
(  P.29)
■Front passenger detection sensor, seat
belt reminder and warning buzzer
●If luggage is placed on the front passen-
ger seat, the front passenger detection
sensor may cause th e warning light to
flash and the warning buzzer to sound
even if a passenger is not sitting in the
seat.
●If a cushion is placed on the seat, the sen-
sor may not detect a passenger, and the
warning light may not operate properly.
■If the malfunction indicator lamp comes
on while driving
First check the following:
●Is the fuel tank empty?
If it is, fill the fuel tank immediately.
●Is the fuel tank cap loose?
If it is, tighten it securely.
The light will go off after several driving
trips.
If the light does not go off even after several
trips, contact your Lexus dealer as soon as
possible.
■Electric power steering system warning
light (warning buzzer)
When the battery charge becomes insuffi- cient or the voltage temporarily drops, the
electric power steering system warning
light may come on and the warning buzzer
may sound.
■When the tire pressure warning light
comes on
Check the tire inflatio n pressure and adjust
to the appropriate leve l. Pushing the tire
pressure warning reset switch will not turn
off the tire pressure warning light.
■The tire pressure warning light may
come on due to natural causes
The tire pressure wa rning light may come
on due to natural causes such as natural air
leaks and tire inflation pressure changes
caused by temperature. In this case, adjust-
ing the tire inflation pressure will turn off the
warning light (after a few minutes).
■When a tire is replaced with the spare
tire
The spare tire is not equipped with a tire
pressure warning valve and transmitter. If a
tire goes flat, the tire pressure warning light
will not turn off even though the flat tire has
been replaced with the spare tire.
■Conditions that the tire pressure warn-
ing system may not function properly
 P.268
■If the tire pressure warning light fre-
quently comes on after blinking for 1
minute
If the tire pressure wa rning light frequently
comes on after blinking for 1 minute when
the engine switch is turned to IGNITION
ON mode, have it checked by your Lexus
dealer.
■Warning buzzer
In some cases, the buzzer may not be heard
due to being in a noisy location or audio
sound.
Warning lightDetails/Actions
(flashes)
Indicates a malfunction in the brake hold system
 Have the vehicle inspected by your Lexus dealer immediately.

3027-2. Steps to take in an emergency
WARNING
■If both the ABS and the brake system
warning lights remain on
Stop your vehicle in a safe place immedi-
ately and contact your Lexus dealer. The
vehicle will become extremely unstable
during braking, and the ABS system may
fail, which could cause an accident
resulting in death or serious injury.
■When the electric power steering
system warning light comes on
The steering wheel may become
extremely heavy.
When steering wheel operations are
heavier than usual, grip the steering
wheel firmly and operate it using more
force than usual.
■If the tire pressure warning light
comes on
Be sure to observe the following precau-
tions. Failure to do so could cause a loss
of vehicle control and result in death or
serious injury.
●Stop your vehicle in a safe place as
soon as possible. Adjust the tire infla-
tion pressure immediately.
●If the tire pressure warning light comes
on even after tire inflation pressure
adjustment, it is probable that you have
a flat tire. Check the tires. If a tire is flat,
change it with the spare tire and have
the flat tire repaired by the nearest
Lexus dealer.
●Avoid abrupt maneuvering and brak-
ing. If the vehicle tires deteriorate, you
could lose control of the steering
wheel or the brakes.
■If a blowout or sudden air leakage
should occur
The tire pressure warning system may
not activate immediately.
■Maintenance of the tires
Each tire, including the spare (if pro-
vided), should be checked monthly when
cold and inflated to the inflation pressure
recommended by the vehicle manufac-
turer on the vehicle pl acard or tire infla-
tion pressure label (tire and load
information label). (If your vehicle has
tires of a different size than the size indi-
cated on the vehicle placard or tire infla-
tion pressure label [tire and load
information label], you should determine
the proper tire inflation pressure for
those tires.)
As an added safety fe ature, your vehicle
has been equipped with a tire pressure
monitoring system (TPMS-tire pressure
warning system) that illuminates a low
tire pressure telltale (tire pressure warn-
ing light) when one or more of your tires
is significantly under-inflated. Accord-
ingly, when the low ti re pressure telltale
(tire pressure warning light) illuminates,
you should stop and check your tires as
soon as possible, and inflate them to the
proper pressure. Driving on a signifi-
cantly under-inflated tire causes the tire
to overheat and can lead to tire failure.
Under-inflation also reduces fuel effi-
ciency and tire tread life, and may affect
the vehicle’s handling and stopping abil-
ity.
Please note that the TPMS (tire pressure
warning system) is not a substitute for
proper tire maintenance, and it is the
driver’s responsibility to maintain correct
tire pressure, even if under-inflation has
not reached the level to trigger illumina-
tion of the TPMS low tire pressure telltale
(tire pressure warning light).

3147-2. Steps to take in an emergency
One of the following may be the cause
of the problem:
There may not be sufficient fuel in
the vehicle’s tank.
Refuel the vehicle.
 The engine may be flooded.
Try to restart the engine again fol-
lowing correct starting procedures.
( P.127)
 There may be a malfunction in the
engine immobilizer system.
( P.56)
One of the following may be the cause
of the problem:
 The battery may be discharged.
( P.319)
 The battery terminal connections
may be loose or corroded.
( P.263)
NOTICE
■Driving with tire chains and the spare
tire
Do not fit tire chains to the spare tire.
Tire chains may damage the vehicle body
and adversely affect driving perfor-
mance.
■When replacing the tires
When removing or fitting the wheels,
tires or the tire pressure warning valve
and transmitter, contact your Lexus
dealer as the tire pr essure warning valve
and transmitter may be damaged if not
handled correctly.
If the engine will not start
If the engine will not start even
though correct starting procedures
are being followed ( P.127), con-
sider each of the following points:
The engine will not start even
though the starter motor oper-
ates normally.
The starter motor turns over
slowly, the interior lights and
headlights are dim, or the horn
does not sound or sounds at a low
volume.

3458-1. Specifications
8
Vehicle specifications
cornering (turning) traction.
■Temperature A, B, C
The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudden tire failure. Grade C corresponds to
a level of perfor-
mance which all passenger car tires must
meet under the Fede ral Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, unde rinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pressure
Tire pressure when the vehicle has been parked for
three hours or more, or has not been driven more
than 1 mile or 1.5 km under that condition
Maximum inflation pressureThe maximum cold inflated pressure to which a tire
may be inflated, shown on the sidewall of the tire
Recommended inflation pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those standard
items which may be replaced) of automatic trans-
mission, power steering, power brakes, power win-
dows, power seats, radio and heater, to the extent
that these items are available as factory-installed
equipment (whether installed or not)
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning
and additional weight optional engine
