3367-2. Steps to take in an emergency
Once the engine starts, have the vehi-
cle inspected at your Lexus dealer as
soon as possible.
■Starting the engine when the battery is
discharged
The engine cannot be started by push-start-
ing.
■To prevent battery discharge
●Turn off the headlights and the audio sys-
tem while the engine is off.
●Turn off any unnecessary electrical com-
ponents when the vehicle is running at a
low speed for an extended period, such
as in heavy traffic.
■Charging the battery
The electricity stored in the battery will dis-
charge gradually even when the vehicle is
not in use, due to natural discharge and the
draining effects of certain electrical appli-
ances. If the vehicle is left for a long time,
the battery may discharge, and the engine
may be unable to start. (The battery
recharges automatically during driving.)
■When recharging or replacing the bat-
tery
●In some cases, it may not be possible to
unlock the doors using the smart access
system with push-button start when the
battery is discharged. Use the wireless
remote control or the mechanical key to
lock or unlock the doors.
●The engine may not start on the first
attempt after the battery has recharged
but will start normally after the second
attempt. This is not a malfunction.
●The engine switch mode is memorized by
the vehicle. When the battery is recon-
nected, the system will return to the
mode it was in before the battery was dis-
charged. Before di sconnecting the bat-
tery, turn the engine switch off.
If you are unsure what mode the engine
switch was in befo re the battery dis-
charged, be especially careful when
reconnecting the battery.
■When replacing the battery
●Use a battery that conforms to European
regulations.
●Use a battery that tha case size is same as
the previous one (LN3), 20 hour rate
capacity (20HR) is equivalent (70Ah) or
greater, and performance rating (CCA)
is equivalent (592A) or greater.
• If the sizes differ, the battery cannot be properly secured.
• If the 20 hour rate capacity is low, even if the time period where the vehicle is not
used is a short time, battery may dis-
charge and the engine may not be able to
start.
●For details, consult your Lexus dealer.
WARNING
■Avoiding battery fires or explosions
Observe the following precautions to
prevent accidentally igniting the flamma-
ble gas that may be emitted from the bat-
tery:
●Make sure each jumper cable is con-
nected to the correct terminal and that
it is not unintentionally in contact with
any other than the intended terminal.
●Do not allow the other end of the
jumper cable connected to the “+” ter-
minal to come into contact with any
other parts or meta l surfaces in the
area, such as brackets or unpainted
metal.
●Do not allow the + and - clamps of the
jumper cables to come into contact
with each other.
●Do not smoke, use matches, cigarette
lighters or allow open flame near the
battery.
■Battery precautions
The battery contains poisonous and cor-
rosive acidic electrol yte, while related
parts contain lead and lead compounds.
Observe the following precautions when
handling the battery:

3628-2. Customization
*1: For details about each function: P.81
*2: The default setting varies according to country.
*3: Some status screens cannot be registered (i ndicated on the multi-information display)
*4: Always observe the legal speed limit when driving on public roads.
*5: On multi-information display
■Door lock (P.92, 95, 332)
Speed indicator settings75 mph (120 km/h)
30 mph to 100 mph
(50 km/h to 160
km/h)
*4—O—
Eco Driving Indicator LightOnOff—O—
Clock*512-hour display24-hour display—O—
Function*1Default settingCustomized settingABC
FunctionDefault settingCustomized setting
Unlocking using a mechani-
cal key
Driver’s door
unlocked in one
step, both side doors unlocked in two steps
Both side doors
unlocked in one step——O
Automatic door lock
Shifting the shift
lever to position other than P
Off
O—OVehicle speed is
approximately 12
mph (20 km/h) or higher
Automatic door unlockShifting the shift lever to POff
O—ODriver’s door is opened
Locking/unlocking of the
trunk when both side doors
are locked/unlocked
OnOff——O
ABC

3648-2. Customization
■Driving position memory* ( P.105)
*:If equipped
■Power easy access system ( P.105)
*:If equipped
■Power windows ( P.112)
Trunk unlocking operationPress and hold
(short)
One short press
——O
Push twice
Press and hold (long)
Off
Alarm (panic mode)OnOff——O
FunctionDefault settingCustomized settingABC
FunctionDefault settingCustomized setting
Selecting the door linking
driving position memory with
door unlock operation
Driver’s doorBoth side doors——O
ABC
FunctionDefault settingCustomized setting
Driver’s seat movement when
exiting the vehicleFullOffO—OPartial
Steering wheel movement*OnOff——O
ABC
FunctionDefault settingCustomized setting
Mechanical key linked opera-
tionOffOn——O
Wireless remote control
linked operationOffOn (Open only)——O
Wireless remote control
linked operation signal
(buzzer)
OnOff——O
ABC

3658-2. Customization
8
Vehicle specifications
■Moon roof*( P.114)
*:If equipped
■Turn signal lever ( P.136)
*1: After flashing the turn signal lights when turnin g left or right while this function is off and
the turn signal lever is moved to the first positi on in the direction of the flashing light, the
turn signal lights can be sele cted to be flashing or off.
*2: The turn signal lights keep flashing if the turn signal lever is moved to the first position in
the direction of flashing light.
*3: The turn signal lights will be off if the turn si gnal lever is moved to the first position in the
direction of flashing light.
■Automatic light control system ( P.138)
FunctionDefault settingCustomized setting
Mechanical key linked opera-
tionOffOn——O
Wireless remote control
linked operationOffOn (Open only)——O
Wireless remote control
linked operation signal
(buzzer)
OnOff——O
ABC
FunctionDefault settingCustomized setting
The number of times the turn
signal lights flash automati-
cally when the turn signal
lever is moved to the first
position during a lane
change
*1
3
5
——O
7
Off*2
Off*3
ABC
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard-2 to 2O—O
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
O—O60 seconds
90 seconds
ABC

3688-2. Customization
■Seat belt reminder (P.306)
■Vehicle customization
●When the smart access system with
push-button start is off, the entry unlock
function cannot be customized.
●When the doors remain closed after
unlocking the doors and the timer acti-
vated automatic door lock function acti-
vates, signals will be generated in
accordance with the operation buzzer
volume and operational signal (Emer-
gency flashers) function settings.
●Some settings can be changed using a
switch or the Center Di splay. If a setting is
changed using a switch, the changed set-
ting will not be reflected on the Center
Display screen until the engine switch is
turned off and then to IGNITION ON
mode.
Operation when the doors
are unlockedOnOff——O
Operation when you
approach the vehicle with the
electronic key on your person
OnOff——O
Remote Touch pad lightOnOff——O
Time elapsed before the outer
foot lights turn off15 seconds
Off
O—O7.5 seconds
30 seconds
Operation of the outer foot
lights when you approach the
vehicle with the electronic
key on your person
OnOff——O
Operation of the outer foot
lights when the doors are
unlocked with the power
door lock switch
OnOff——O
Operation of the outer foot
lights when a door is openedOnOff——O
Fading out of the outer foot
lights when they turn offLongShort——O
FunctionDefault settingCustomized settingABC
FunctionDefault settingCustomized setting
Vehicle speed linked seat belt
reminder buzzerOnOff——O
ABC

390What to do if... (Troubleshooting)
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
If you lose your mechanical keys,
new genuine mechanical keys can
be made by your Lexus dealer.
( P.331)
 If you lose your electronic keys, the
risk of vehicle theft increases signifi-
cantly. Contact your Lexus dealer
immediately. ( P.331)
 Is the electronic key battery weak or
depleted? ( P.283)
 Is the engine switch in IGNITION
ON mode?
When locking the doors, turn the engine
switch off. ( P.130)
 Is the electronic key left inside the
vehicle?
When locking the doors, make sure that
you have the electronic key on your per-
son.
The function may not operate prop-
erly due to the condition of the radio
wave. ( P.100)
 The function to prevent the elec-
tronic key from being left inside the
trunk will operate and you can open
the trunk as usual. Take the key out
from the trunk. ( P.97)
 Did you press the engine switch
while firmly depressing the brake
pedal? ( P.128)
 Is the shift lever in P? ( P.128)
 Is the electronic key anywhere
detectable inside the vehicle?
( P.99)
 Is the steering wheel unlocked?
( P.128)
 Is the electronic key battery weak or
depleted?
In this case, the engine can be started in a
temporary way. ( P.333)
 Is the battery discharged?
( P.334)
If you have a problem, check the
following before contacting your
Lexus dealer.
The doors cannot be locked,
unlocked, opened or closed
You lose your keys
The electronic key does not
operate properly
The doors cannot be locked or
unlocked
The trunk lid is closed with the
electronic key left inside
If you think something is wrong
The engine does not start
The shift lever cannot be shifted
from P even if you depress the
brake pedal

393Alphabetical Index
Alphabetical Index
A
A/CAir conditioning filter ............................... 282
Automatic air conditioning system ..... 213
Micro dust and pollen filter..................... 217
ABS (Anti-lock Brake System)................199 ABS warning light .....................................303
Active rear wing.............................................195
Adaptive Variable Suspension System200
Air conditioning filter ................................. 282
Air conditioning system Air conditioning filter ............................... 282
Automatic air conditioning system ..... 213
Micro dust and pollen filter..................... 217
Airbags Airbag operating conditions................... 30
Airbag precautions for your child .........32
Correct driving posture .............................23
Curtain shield airbag operating condi-tions .................................................................. 30
Curtain shield airbag precautions ........32
Front passenger occupant classification system ............................................................. 36
General airbag precautions ....................32
Locations of airbags.................................... 28
Modification and disposal of airbags . 35
Side airbag operating conditions ......... 30
Side airbag precautions .............................32
Side and curtain shield airbags operating conditions...................................................... 30
Side and curtain shield airbags precau- tions ...................................................................32
SRS airbags ..................................................... 28
SRS warning light ......................................303
Alarm ................................................................... 58 Warning buzzer ......................................... 302
Anchor brackets ...................................... 43, 51
Antennas (smart access system with push-button start)........................................ 98
Anti-lock Brake System (ABS)................199 ABS warning light .....................................303 Approach warning........................................ 176
Armrest............................................................ 228
Assist grips ..................................................... 229
Audio system-linked display ........................81
Automatic air conditioning system ........213
Automatic headlight leveling system ....139
Automatic headlight leveling system warning light............................................. 306
Automatic High Beam ............................... 140
Automatic light control system............... 138
Automatic transmission ..............................132 M mode ........................................................... 135
Paddle shift switches ....................... 134, 135
Average fuel economy................................. 75
Average vehicle speed ................................ 75
B
Back-up light Replacing light bulbs ............................... 289
Battery Battery checking .......................................... 271
Charging system warning light...........302
If the battery is discharged ....................334
Preparing and checking before winter..........................................................................204
Blind Spot Monitor (BSM)......................... 179
Brake Brake system warning light ..................302
Fluid...................................................................346
Parking brake ................................................137
Brake assist ......................................................199
Break-in tips...................................................... 119
Brightness control Instrument panel light control................. 73
BSM (Blind Spot Monitor)......................... 179
C
Card key ............................................................ 88
Care Exterior................................... 240, 248, 252
Interior .............................................................245

395Alphabetical Index
Door glasses ....................................................112
Door lock.......................................................... 92
Open door warning buzzer93, 94, 306
Open door warning light ......................306
Outside rear view mirrors ....................... 110
Drive distance ...................................................75
Drive info 1/Drive info 2/Drive info 3.....75
Drive information ............................................75
Driver’s and front passenger’s seat belt reminder light............................................. 306
Driver’s seat position memory Driving position memory........................ 105
Memory recall function ........................... 106
Power easy access system .................... 105
Drive-start control ......................................... 119
Driving Break-in tips .................................................... 119
Correct driving posture .............................23
Driving mode select switch .................... 192
Procedures ...................................................... 118
Winter drive tips......................................... 204
Driving information display .........................75
Driving position memory........................... 105 Memory recall function ........................... 106
Power easy access system .................... 105
Driving range ....................................................75
Driving support system information display ...............................................................................81
Dynamic radar cruise control ................... 171 Warning message.......................................178
E
Eco Driving Indicator.....................................76
Eco Driving Indicator Light .........................76
EDR (Event data recorder) ............................7
Elapsed time ......................................................75
Electric Power Steering (EPS) ..............200Electric power steer ing system warning
light ................................................................304
Electronic key .................................................. 88 Battery-saving function ............................. 99 If the electronic key does not operate
properly ....................................................... 332
Replacing the battery ...............................283
Emergency flashers .................................... 294
Emergency tire puncture ...........................319
Emergency, in case of If a warning buzzer sounds...................302
If a warning light turns on.......................302
If a warning message is displayed ...... 310
If the battery is discharged ....................334
If the electronic key does not operate properly ....................................................... 332
If the engine will not start........................329
If the fuel filler do or cannot be opened
........................................................................... 331
If the vehicle is trapped in rising water ..........................................................................295
If you have a flat tire ......................... 313, 319
If you lose your keys .................................. 331
If you think something is wrong......... 300
If your vehicle becomes stuck .............339
If your vehicle has to be stopped in an emergency ................................................. 294
If your vehicle needs to be towed ..... 297
If your vehicle overheats ........................ 337
Engine ACCESSORY mode............................... 130
Compartment.............................................. 267
Engine switch ................................................ 128
Fuel pump shut off system...................... 301
Hood ................................................................ 264
Identification number ...............................343
If the engine will not start........................329
If your vehicle has to be stopped in an emergency ................................................. 294
Ignition switch (engine switch)............. 128
Overheating ................................................. 337
Tachometer ..................................................... 66
Engine coolant Capacity .........................................................344
Checking .......................................................269

397Alphabetical Index
Heated steering wheel ................................ 221
HeatersAutomatic air conditioning system ..... 213
Heated steering wheel.............................. 221
Outside rear view mirrors ...................... 217
Rear window .................................................. 217
Seat heaters .................................................... 221
High mounted stoplight Replacing light bulbs................................289
Hill-start assist control ...............................200
Hood Open ............................................................... 264
Hooks Cargo hooks.................................................227
Coat hooks ................................................... 229
Retaining hooks (floor mat)......................22
Horn ................................................................... 109
I
I/M test .............................................................. 261
Identification Engine ............................................................. 343
Vehicle ............................................................ 342
Ignition switch (engine switch).................128 Auto power off function ............................ 131
Changing the engine switch modes. 130
If your vehicle has to be stopped in an
emergency ................................................ 294
Illuminated entry system ........................... 224
Indicators ........................................................... 63
Initialization Items to initialize .........................................369
Maintenance ................................................ 257
Power windows..............................................112
Tire pressure warning system ..............277
Inside rear view mirror ............................... 109
Instrument panel light control ....................73
Interior lights.................................................. 223 Front interior light ...................................... 223
Rear interior light ....................................... 223
Intuitive parking assist Function ............................................................187 Warning message ...................................... 189
J
Jack
Positioning a floor jack ............................265
Vehicle-equipped jack ................ 314, 320
Jack handle .......................................... 314, 320
Jam protection function Moon roof ........................................................ 115
Power windows ............................................. 112
K
Keyless entrySmart access system with push-button start ...................................................................98
Wireless remote control ...........................90
Keys Battery-saving function..............................99
Electronic key ................................................ 88
Engine switch ................................................ 128
If the electronic key does not operate properly ....................................................... 332
If you lose your keys .................................. 331
Key number plate ........................................ 88
Keyless entry ..........................................92, 98
Mechanical key ............................................. 88
Replacing the battery ...............................283
Warning buzzer ............................................ 99
Wireless remote control ...........................90
Knee airbags .................................................... 28
L
Lane Departure Alert LDA indicator ............................................. 305
Lane Departure Alert with steering control (LDA)Operation ....................................................... 164
Warning message ...................................... 169
Language (multi-information display) .....81
LATCH anchors ............................................. 49

400Alphabetical Index
PCS warning light .................................... 305
R
Radar cruise control (dynamic radar cruise control) ............................................................ 171
Radiator ........................................................... 270
RCTA Function ............................................................ 179
Rear Cross Traffic Alert (RCTA) ........... 179
Rear passengers’ seat belt reminder lights .......................................................................... 307
Rear seats Seat heaters .................................................... 221
Seat ventilators.............................................. 221
Rear side marker lights Light switch .................................................... 138
Rear turn signal lights Replacing light bulbs................................289
Turn signal lever ...........................................136
Wattage..........................................................348
Rear view mirror Inside rear view mirror............................. 109
Outside rear view mirrors ....................... 110
Rear window defogger ............................... 217
Refueling Capacity ......................................................... 343
Fuel types....................................................... 343
If the fuel filler door cannot be opened...........................................................................331
Opening the fuel tank cap ..................... 150
Remote Touch ..............................................208
Replacing Electronic key battery.............................. 283
Fuses ................................................................285
Light bulbs.....................................................288
Tires ....................................................................313
Resetting the message indicating mainte- nance is required ...................................... 257
Rev indicator .................................................... 70
Rev peak............................................................... 71
S
Seat belt reminder light................. 306, 307
Seat belts............................................................ 24 Automatic Locking Retractor................. 26
Child restraint system installation ......... 43
Cleaning and maintaining the seat belt..........................................................................245
Driver’s and front passenger’s seat belt reminder light and buzzer ................ 306
Emergency Locking Retractor .............. 26
How to wear your seat belt ..................... 25
How your child should wear the seat belt ............................................................................. 25
Pregnant women, proper seat belt use ............................................................................. 24
Rear passengers’ seat belt reminder lights and buzzer ....................................307
Seat belt extender......................................... 25
Seat belt pretensioners .............................. 27
SRS warning light...................................... 303
Seat heaters ..................................................... 221
Seat position memory................................. 105
Seat ventilators ............................................... 221
Seating capacity.............................................126
Seats Adjustment ..................................................... 103
Child seats/child restraint system installa-tion .................................................................... 42
Cleaning .........................................................245
Driving position memory ........................ 105
Power easy access system .................... 105
Properly sitting in the seat ........................ 23
Seat heaters .................................................... 221
Seat position memory .............................. 105
Seat ventilators .............................................. 221
Sensor Automatic headlight system .................. 138
Automatic High Beam system ............. 140
Inside rear view mirror ............................... 110
LDA (Lane Departure Alert with steering control) ......................................................... 164
