1244-1. Before driving
Cargo capacity depends on the total
weight of the occupants.
(Cargo capacity) = (Total load capac-
ity) — (Total weight of occupants)
Steps for Determining Correct Load
Limit —
(1) Locate the statement “The com-
bined weight of occupants and cargo
should never exceed XXX kg or XXX
lbs.” on your vehicle’s placard.
(2) Determine the combined weight of
the driver and passengers that will be
riding in your vehicle.
(3) Subtract the combined weight of
the driver and passengers from XXX
kg or XXX lbs.
(4) The resulting figure equals the
available amount of cargo and luggage
load capacity.
For example, if the “XXX” amount
equals 1400 lbs. and there will be five
150 lb passengers in your vehicle, the
amount of available cargo and luggage
load capacity is 650 lbs. (1400 - 750
(5  150) = 650 lbs.)
(5) Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not safely
exceed the available cargo and lug-
NOTICE
●If the vehicle is invo lved in an accident
that may affect th e suspension or
wheels
●If the brake pads have worn out and
the metal part of the pad is in contact
with the CCB disc surface
Cargo and luggage
Take notice of the following infor-
mation about storage precautions,
cargo capacity and load:
Capacity and distribution

1254-1. Before driving
4
Driving
gage load capacity calculated in Step
4.
(6) If your vehicle will be towing a
trailer, load from your trailer will be
transferred to your vehicle. Consult
this manual to determine how this
reduces the available cargo and lug-
gage load capacity of your vehicle.
( P.126)
Lexus does not recommend towing a
trailer with your vehicle. Your vehicle is not
designed for trailer towing.
Cargo capacity
Total load capacity (vehicle capac-
ity weight) ( P.342)
When 2 people with the combined
weight of A lb. (kg) are riding in your
vehicle, which has a total load capacity
(vehicle capacity weight) of B lb. (kg),
the available amount of cargo and lug-
gage load capacity will be C lb. (kg) as
follows:
B
*2 lb. (kg) - A*1 lb. (kg) = C*3 lb. (kg)
*1: A =Weight of people
*2: B =Total load capacity
*3: C =Available cargo and luggage load
In this condition, if 2 more passengers with
the combined weight of D lb. (kg) get on,
the available cargo and luggage load will
be reduced E lb. (kg) as follows:
C lb. (kg) - D*4 lb. (kg) = E*5 lb. (kg)
*4: D =Additional weight of people
*5: E =Available cargo and luggage load
As shown in the example above, if the
number of occupant s increases, the
cargo and luggage load will be
reduced by an amount that equals the
increased weight due to the additional
occupants. In other words, if an
increase in the number of occupants
causes an excess of the total load
capacity (combined weight of occu-
pants plus cargo and luggage load),
you must reduce the cargo and lug-
gage on your vehicle.
Calculation formula for your
vehicle
A
B
WARNING
■Things that must not be carried in the
trunk
The following things may cause a fire if
loaded in the trunk:
●Receptacles containing gasoline
●Aerosol cans
■Storage precautions
Observe the following precautions.
Failure to do so may prevent the pedals
from being depressed properly, may
block the driver’s vision, or may result in
items hitting the driver or passengers,
possibly causing an accident.
●Stow cargo and luggage in the trunk
whenever possible.

1264-1. Before driving
■Total load capacity and seating capacity
These details are also described on the tire
and loading information label. ( P.279)
WARNING
●Do not place cargo or luggage in or on
the following locations.
• At the feet of the driver
• On the front passenger or rear seats (when stacking items)
• On the package tray
• On the instrument panel
•On the dashboard
• In front of the Center Display
●Secure all items in the occupant com-
partment.
■Capacity and distribution
●Do not exceed the maximum axle
weight rating or the total vehicle
weight rating.
●Even if the total load of occupant’s
weight and the cargo load is less than
the total load capacity, do not apply the
load unevenly. Improper loading may
cause deterioration of steering or
braking control which may cause
death or serious injury.
Vehicle load limits
Vehicle load limits include total
load capacity, seating capacity,
towing capacity and cargo capac-
ity.
 Total load capacity (vehicle
capacity weight): P.342
Total load capacity means the com-
bined weight of occupants, cargo
and luggage.
 Seating capacity: P.342
Seating capacity means the maxi-
mum number of occupants whose
estimated average weight is 150 lb.
(68 kg) per person.
 Towing capacity
Lexus does not recommend towing
a trailer with your vehicle.
 Cargo capacity
Cargo capacity may increase or
decrease depending on the weight
and the number of occupants.
WARNING
■Overloading the vehicle
Do not overload the vehicle.
It may not only cause damage to the tires,
but also degrade steering and braking
ability, resulting in an accident.

2024-5. Using the driving support systems
●When driving over roads with potholes
or uneven surfaces
■TRAC may not operate effectively
when
Directional control and power may not
be achievable while driving on slippery
road surfaces, even if the TRAC system is
operating. Drive the vehicle carefully in
conditions where stability and power
may be lost.
■Hill-start assist control does not oper-
ate effectively when
●Do not overly rely on hill-start assist
control. Hill-start assist control may
not operate effectively on steep
inclines and roads covered with ice.
●Unlike the parking brake, hill-start
assist control is not intended to hold
the vehicle stationary for an extended
period of time. Do not attempt to use
hill-start assist control to hold the vehi-
cle on an incline, as doing so may lead
to an accident.
■When the TRAC/VSC is activated
The slip indicator light flashes. Always
drive carefully. Re ckless driving may
cause an accident. Exercise particular
care when the indicator light flashes.
■When the TRAC/VSC systems are
turned off
Be especially careful and drive at a speed
appropriate to the road conditions. As
these are the system s to help ensure
vehicle stability and driving force, do not
turn the TRAC/VSC systems off unless
necessary.
■Expert mode precautions
●Do not use on public roads.
●Use only when the road conditions and
safety of the surrounding area can be
ensured.
WARNING
●Proper use of expert mode requires a
professional level of driving skill. When
using expert mode, always check the
road conditions and surrounding area
and drive more carefully than usual.
■Replacing tires
Make sure that all ti res are of the speci-
fied size, brand, tread pattern and total
load capacity. In addition, make sure that
the tires are inflated to the recom-
mended tire inflation pressure level.
The ABS, TRAC and VSC systems will
not function correctly if different tires are
installed on the vehicle.
Contact your Lexus dealer for further
information when replacing tires or
wheels.
■Handling of tires and the suspension
Using tires with any kind of problem or
modifying the suspensi on will affect the
driving assist systems, and may cause a
system to malfunction.

2746-4. Do-it-yourself maintenance
■When to replace your vehicle’s tires
Tires should be replaced if:
●The treadwear indicators are showing on
a tire.
●You have tire damage such as cuts, splits,
cracks deep enough to expose the fabric,
and bulges indicating internal damage
●A tire goes flat repeatedly or cannot be
properly repaired due to the size or loca-
tion of a cut or other damage
If you are not sure, consult your Lexus
dealer.
■Tire life
Any tire over 6 years old must be checked
by a qualified technician even if it has sel-
dom or never been used or damage is not
obvious.
■Low profile tires
Compared to normal tires, the grip perfor-
mance of these tires will be lower on snow
covered or icy roads. Be sure to use snow
tires when driving on snowy and/or icy
roads and drive carefully at a speed appro-
priate for the road conditions.
■Maximum load of tire
Check that the maximum load of the
replacement tire is greater than 1/2 of the
Gross Axle Weight Ratings (GAWR) of
either the front axle or the rear axle, which-
ever is greater.
For the GAWR, see the Certification Label.
For the maximum load of the tire, see the
load limit at maximum cold tire inflation
pressure mentioned on the sidewall of the
tire. ( P.351)
■Tire types
●Summer tires
Summer tires are high-speed performance tires best suited to
highway driving under
dry conditions. Since summer tires do not
have the same traction performance as
snow tires, summer ti res are inadequate for
driving on snow-covered or icy roads. For
driving on snow-covered roads or icy
roads, the use of snow tires is recom-
mended. When installing snow tires, be
sure to replace all four tires.
●All season tires
All season tires are designed to provide
better traction in snow and to be adequate
for driving in most winter conditions as well
as for use year-round. All season tires,
however, do not have adequate traction
performance compared with snow tires in
heavy or loose snow. Also, all season tires
fall short in accelerati on and handling per-
formance compared with summer tires in
highway driving.
●Snow tires
For driving on snow-covered roads or icy
roads, we recommend using snow tires. If
you need snow tires, select tires of the
same size, construction and load capacity
as the originally instal led tires. Since your
vehicle has radial tires as original equip-
ment, make sure your snow tires also have
radial construction. Do not install studded
tires without first checking local regula-
tions for possible restrictions. Snow tires
should be installed on all wheels.
(  P.204)
■If the tread on snow tires wears down
below 0.16 in. (4 mm)
The effectiveness of the tires as snow tires is
lost.

3448-1. Specifications
your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil”
or equivalent to satisfy the following
grade and viscosity.
Oil grade: ILSAC GF-5 multigrade
engine oil
Recommended viscosity: SAE 5W-30
SAE 5W-30 is the best choice for
good fuel economy and good starting
in cold weather.
If SAE 5W-30 is not available, SAE
10W-30 oil may be used. However, it
should be replaced with SAE 5W- 30
at the next oil change.Outside temperature
Oil viscosity (5W-30 is explained here
as an example):
• The 5W in 5W-30 indicates the characteristic of the oil which allows
cold startability. Oils with a lower
value before the W allow for easier
starting of the engine in cold
weather.
• The 30 in 5W-30 indicates the vis- cosity characteristic of the oil when
the oil is at high temperature. An oil
with a higher viscosity (one with a
higher value) may be better suited if
the vehicle is operated at high
speeds, or under extreme load con-
ditions.
How to read oil container label:
The International Lubricant Specifica-
tion Advisory Committee (ILSAC)
Certification Mark is added to some oil
containers to help you select the oil you
should use.
*: The fluid capacity is a reference quantity.
A
Cooling system
Capacity*12.2 qt. (11.5 L, 10.1 Imp. qt.)
Coolant type
Use either of the following:
 “Toyota Super Long Life Coolant”
 Similar high-quality ethylene glycol-based non-silicate,
non-amine, non-nitrite, and non-borate coolant with
long-life hybrid orga nic acid technology
Do not use plain water alone.

3558-1. Specifications
8
Vehicle specifications
Curb weight
The weight of a motor vehicle with standard equip-
ment, including the maximum capacity of fuel, oil
and coolant, and if so equipped, air conditioning
and additional weight optional engine
Maximum loaded vehicle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant weight
150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that fol-
lows
Occupant distributionDistribution of occupants in a vehicle as specified in
the third column of Table 1
* below
Production options weight
The combined weight of installed regular produc-
tion options weighing over 5 lb. (2.3 kg) in excess of
the standard items which they replace, not previ-
ously considered in curb weight or accessory
weight, including heavy duty brakes, ride levelers,
roof rack, heavy duty battery, and special trim
RimA metal support for a tire or a tire and tube assem-
bly upon which the tire beads are seated
Rim diameter (Wheel diameter)Nominal diameter of the bead seat
Rim size designationRim diameter and width
Rim type designationThe industry manufacturer’s designation for a rim
by style or code
Rim widthNominal distance between rim flanges
Vehicle capacity weight (Total load
capacity)The rated cargo and luggage load plus 150 lb. (68
kg) times the vehicle’s designated seating capacity
Vehicle maximum load on the tire
The load on an individual ti re that is determined by
distributing to each axle its share of the maximum
loaded vehicle weight, and dividing by two
Tire related termMeaning

402Alphabetical Index
Tilt and telescopic steering control switch.......................................................................... 108
Tire pressure warning reset switch .. 278
Trunk opener main switch ....................... 98
Trunk opener switch ................................... 96
TVD (Toruqe Vector ing Differential)
switch............................................................. 198
VSC OFF switch .......................................200
Window lock switch ................................... 113
Windshield wiper and washer switch143
Windshield wiper de-icer switch ........ 217
T
Tachometer....................................................... 66 Rev indicator ................................................... 70
Rev peak ............................................................. 71
Tail lights Light switch .................................................... 138
Replacing light bulbs................................289
Theft deterrent system Alarm ..................................................................58
Engine immobilizer system ..................... 57
Theft prevention labels............................... 60
Tire inflation pressure Maintenance data...................................... 347
Tire inflation pressu re display function
......................................................................... 275
Tire pressure warning light ................... 307
Tire information ..............................................351 Glossary......................................................... 354
Size.................................................................... 352
Tire identification number ..................... 352
Uniform Tire Quality Grading............353
Tire infration pressure ...................................76
Tire pressure display .................................. 275
Tire pressure warning system Function .......................................................... 275
Initializing ........................................................277
Installing tire pressure warning valves and transmitters .......................................277
Registering ID codes ............................... 278
Tire pressure warning light ................... 307 Tires
Chains ............................................................ 205
Checking ....................................................... 273
Emergency tire puncture repair kit.... 319
If you have a flat tire ......................... 313, 319
Inflation pressure ........................................ 279
Information ..................................................... 351
Replacing ........................................................ 313
Rotating tires ................................................ 275
Size .................................................................... 347
Snow tires ......................................................204
Spare tire ......................................................... 313
Tire inflation pressure display function.......................................................................... 275
Tire pressure warning light ...................307
Tire pressure warning system ............. 275
Tools........................................................ 314, 320
Top tether strap........................................ 43, 51
Toruqe Vectoring Differential (TVD) .. 198
Total load capacity ...................................... 342
Towing Dinghy towing ............................................... 127
Emergency towing.................................... 297
Towing eyelet...............................................299
Trailer towing ................................................. 127
TRAC (Traction Control) ........................200
Traction Control (TRAC) ........................200
Trailer towing .................................................. 127
Transmission Automatic transmission ............................132
Driving mode select switch ....................192
M mode ........................................................... 135
Paddle shift switches ....................... 134, 135
Trip meters .........................................................72
Trunk .................................................................... 95 Smart access system with push-button start ...................................................................96
Trunk features .............................................. 227
Trunk grip ......................................................... 97
Trunk light ......................................................... 97
Trunk opener main switch........................98
Trunk opener switch ................................... 96

403Alphabetical Index
Trunk storage extension ........................ 228
Wireless remote control........................... 97
Turn signal lights Replacing light bulbs................................289
Turn signal lever ...........................................136
TVD (Toruqe Vectorin g Differential) .. 198
V
Vanity lights.................................................... 230
Vanity mirrors ............................................... 230
VDIM (Vehicle Dynami cs Integrated Man-
agement)......................................................200
Vehicle data recording . ...................................6
Vehicle Dynamics Integrated Manage- ment (VDIM)..............................................200
Vehicle identification number ................ 342
Vehicle Stability Control (VSC) .............199
Vehicle sway warning display ....................76
Ventilators (seat ventilators)..................... 221
VSC (Vehicle Stabilit y Control) .............199
W
Warning buzzer
Open door....................................................306
Warning buzzers Approach warning...................................... 176
Brake Override System .........................304
Downshifting ..................................................135
Driver’s and front passenger’s seat belt.........................................................................306
Drive-Start Control ..................................304
Electric power steering ..........................304
High coolant temperature .................... 302
LDA (Lane Departure Alert with steering control) ..........................................................164
Low engine oil pressure.........................303
Open door.............................................. 93, 94
Open window ................................................ 113
Parking brake ..............................................304
Pre-collision braking................................. 158
Rear passengers’ seat belt .................... 307 Warning lights............................................... 302
ABS .................................................................. 303
Automatic headlight leveling system306
Brake Override System ........................ 304
Brake system................................................302
Charging system........................................302
Driver’s and front passenger’s seat belt reminder light .......................................... 306
Drive-Start Control.................................. 304
Electric power steering.......................... 304
High coolant temperature.....................302
LDA indicator ............................................. 305
Low engine oil pressure........................ 303
Low fuel level .............................................. 306
Malfunction indicator lamp .................. 303
Master warning light.................................307
Open door warning ................................ 306
Parking brake indicator ......................... 304
Pre-collision system................................. 305
Rear passengers’ seat belt reminder lights ..............................................................307
Slip indicator ................................................ 305
SRS ................................................................... 303
Tire pressure ................................................307
Warning message ........................................ 310
Warning message display.............................81
Washer Checking ....................................................... 272
Preparing and checking before winter..........................................................................204
Switch.................................................................143
Washing and waxing.................................. 240
Weight Cargo capacity .............................................126
Load limits .......................................................126
Weight............................................................. 342
Wheels ...............................................................281 Size .................................................................... 347
Window lock switch ...................................... 113
Windows Power windows ............................................. 112
Rear window defogger............................. 217
