LEXUS RX350 2012 Repair Manual

Scheduled Maintenance l og
MAINTENANCE
Scheduled Maintenance Log 59108 Months or 90,000 Miles❏ Replace engine oil with 0W-20 oil; replace oil filter
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Replace cabin air filter
❏ Replace brake fluid
❏ Replace engine air filter
❏ Replace Smart Key battery
❏ Reset maintenance reminder light
❏ Inspect the following:
__ Axle shaft boots
__ Ball joints and dust covers
__ Body
__ Brake lines and hoses
__ Brake rotor thickness and runout
__ Drive belt
__ Engine coolant (see page 70)
__ Exhaust pipes and mountings
__ F uel lines and connections, fuel tank band

and fuel tank vapor vent system hoses
I
f you drive primarily under any of these special operating conditions, perform
these additional items:
D riving off-road, on dirt roads or on dusty roads:
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier or heavy vehicle loading:
❏ Replace rear differential oil (AWD)
❏ Replace transfer case oil (AWD)
❏ Tighten nuts and bolts on chassis __ Fuel tank cap gasket
__ Rack-and-pinion assembly
__ Rear differential oil (AWD)
__ Steering linkage and boots
__ Transfer case oil (AWD)
__ Transmission for signs of leakage
__ Wiper blades❏ Rotate tires
❏ Visually inspect brake pads, calipers
and r otors
❏ Check installation of driver’s floor mat
❏ Road-test vehicle
d ate: __________________________ Mileage: __________________________

Scheduled Maintenance l og
MAINTENANCE Scheduled Maintenance Log60 114 Months or 95,000 Miles 120 Months or 100,000 Miles❏ Replace engine oil with 0W-20 oil; replace
oil filter
❏ Replace engine coolant (see page 70)
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
If you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)
d ate: _______ Mileage: ________ d ate: _______ Mileage: ________❏ Inspect and adjust all fluid levels
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
No te: If 0W-20 oil was not used at last oil
change, or if you drive primarily under certain
special operating conditions, you should also
r
eplace the engine oil with 0W-20 oil and
replace the oil filter. See page 44 for conditions
that apply. Some conditions require additional
maintenance. See belo
w.
If you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)

Scheduled Maintenance l og
MAINTENANCE
Scheduled Maintenance Log 61126 Months or 105,000 Miles❏ Inspect and adjust all fluid levels
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Replace Smart Key battery
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❏ Road-test vehicle
❏ Inspect the following:
__ Axle shaft boots
__ Ball joints and dust covers
__ Body
__ Brake lines and hoses
__ Drive belt
__ Exhaust pipes and mountings
Note: If 0W-20 oil was not used at last oil change, or if you drive primarily under certain special operat
-
ing conditions, you should also replace the engine oil with 0W-20 oil and replace the oil filter. See page
44 for conditions that apply
. Some conditions require additional maintenance. See below.
If you drive primarily under any of these special operating conditions, perform
these additional items:
D
riving off-road, on dirt roads or on dusty roads:
❏ Inspect engine air filter
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier or heavy vehicle loading:
❏ Replace rear differential oil (AWD)
❏ Replace transfer case oil (AWD)
❏ Tighten nuts and bolts on chassis __ Rack-and-pinion assembly
__ Rear differential oil (AWD)
__ Steering linkage and boots
__ Transfer case oil (AWD)
__ Wiper blades
d ate: __________________________ Mileage: __________________________

Scheduled Maintenance l og
MAINTENANCE Scheduled Maintenance Log62 132 Months or 110,000 Miles❏ Replace engine oil with 0W-20 oil; replace
oil filter
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
I f you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD) 138 Months or 115,000 Miles
d ate: _______ Mileage: ________ d ate: _______ Mileage: ________❏ Inspect and adjust all fluid levels
❏ Inspect engine coolant (see page 70)
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
Note : If 0W-20 oil was not used at last oil
change, or if you drive primarily under certain
special operating conditions, you should also
r
eplace the engine oil with 0W-20 oil and
replace the oil filter. See page 44 for conditions
that apply. Some conditions require additional
maintenance. See belo
w.
If you drive primarily under any of
these special operating conditions,
perform these additional items:
Driving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)

Scheduled Maintenance l og
MAINTENANCE
Scheduled Maintenance Log 63144 Months or 120,000 Miles❏ Replace engine oil with 0W-20 oil; replace oil filter
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Replace cabin air filter
❏ Replace brake fluid
❏ Replace engine air filter
❏ Replace Smart Key battery
❏ Replace spark plugs (use Denso FK20HR11 plugs
or equivalent) 1

❏ Inspect the following:
__ Axle shaft boots
__ Ball joints and dust covers
__ Body
__ Brake lines and hoses
__ Brake rotor thickness and runout
__ Drive belt
__ Exhaust pipes and mountings
__ F uel lines and connections, fuel tank band

and fuel tank vapor vent system hoses
I
f you drive primarily under any of these special operating conditions, perform
these additional items:
D riving off-road, on dirt roads or on dusty roads:
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier or heavy vehicle loading:
❏ Replace rear differential oil (AWD)
❏ Replace transfer case oil (AWD)
❏ Replace transmission fluid
❏ Tighten nuts and bolts on chassis __ Fuel tank cap gasket
__ Rack-and-pinion assembly
__ Rear differential oil (AWD)
__ Steering linkage and boots
__ Transfer case oil (AWD)
__ Transmission for signs of leakage
__ Wiper blades❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers
and rotors
❏ Check installation of driver’s floor mat
❏ Road-test vehicle
1
Required under the terms of the Emission Control Warranty.d ate: __________________________ Mileage: __________________________

Scheduled Maintenance l og
MAINTENANCE Scheduled Maintenance Log64 150 Months or 125,000 Miles 156 Months or 130,000 Miles❏ Replace engine oil with 0W-20 oil; replace
oil filter
❏ Inspect engine coolant (see page 70)
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
If you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)
d ate: _______ Mileage: ________ d ate: _______ Mileage: ________❏ Inspect and adjust all fluid levels
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
Note: If 0W -20 oil was not used at last oil
change, or if you drive primarily under certain
special operating conditions, you should also
r
eplace the engine oil with 0W-20 oil and
replace the oil filter. See page 44 for conditions
that apply. Some conditions require additional
maintenance. See belo
w.
If you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)

Scheduled Maintenance l og
MAINTENANCE
Scheduled Maintenance Log 65162 Months or 135,000 Miles❏ Inspect and adjust all fluid levels
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Replace Smart Key battery
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❏ Road-test vehicle
❏ Inspect the following:
__ Axle shaft boots
__ Ball joints and dust covers
__ Body
__ Brake lines and hoses
__ Drive belt
__ Exhaust pipes and mountings
Note: If 0W-20 oil was not used at last oil change, or if you drive primarily under certain special operat
-
ing conditions, you should also replace the engine oil with 0W-20 oil and replace the oil filter. See page
44 for conditions that apply
. Some conditions require additional maintenance. See below.
If you drive primarily under any of these special operating conditions, perform
these additional items:
D
riving off-road, on dirt roads or on dusty roads:
❏ Inspect engine air filter
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier or heavy vehicle loading:
❏ Replace rear differential oil (AWD)
❏ Replace transfer case oil (AWD)
❏ Tighten nuts and bolts on chassis __ Rack-and-pinion assembly
__ Rear differential oil (AWD)
__ Steering linkage and boots
__ Transfer case oil (AWD)
__ Wiper blades
d ate: __________________________ Mileage: __________________________

Scheduled Maintenance l og
MAINTENANCE Scheduled Maintenance Log66 168 Months or 140,000 Miles❏ Replace engine oil with 0W-20 oil; replace
oil filter
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
I f you drive primarily under any of
these special operating conditions,
perform these additional items:
Driving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD) 174 Months or 145,000 Miles
d ate: _______ Mileage: ________ d ate: _______ Mileage: ________❏ Inspect and adjust all fluid levels
❏ Inspect engine coolant (see page 70)
❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers and rotors
❏ Check installation of driver’s floor mat
❑ Inspect wiper blades
❏ Road-test vehicle
Note: If 0W-20 oil was not used at last oil
change, or if you drive primarily under certain
special operating conditions, you should also
r
eplace the engine oil with 0W-20 oil and
replace the oil filter. See page 44 for conditions
that apply. Some conditions require additional
maintenance. See belo
w.
If you drive primarily under any of
these special operating conditions,
perform these additional items:
D
riving off-road, on dirt roads or on
dusty roads:
❏ Inspect axle shaft boots
❏ Inspect ball joints and dust covers
❏ Inspect engine air filter
❏ Inspect steering linkage and boots
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier
or heavy vehicle loading:
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Tighten nuts and bolts on chassis
Driving on roads on which road salt has
been applied:
❏ Re-torque nuts and bolts of drive shaft (AWD)

Scheduled Maintenance l og
MAINTENANCE
Scheduled Maintenance Log 67180 Months or 150,000 Miles❏ Replace engine oil with 0W-20 oil; replace oil filter
❏ Re-torque nuts and bolts of drive shaft (AWD)
❏ Replace cabin air filter
❏ Replace brake fluid
❏ Replace engine air filter
❏ Replace engine coolant (see page 70)
❏ Replace Smart Key battery
❏ Inspect the following:
__ Axle shaft boots
__ Ball joints and dust covers
__ Body
__ Brake lines and hoses
__ Brake rotor thickness and runout
__ Drive belt
__ Exhaust pipes and mountings
__ F uel lines and connections, fuel tank band

and fuel tank vapor vent system hoses
I
f you drive primarily under any of these special operating conditions, perform
these additional items:
D riving off-road, on dirt roads or on dusty roads:
❏ Tighten nuts and bolts on chassis
Towing a trailer, using a car-top carrier or heavy vehicle loading:
❏ Replace rear differential oil (AWD)
❏ Replace transfer case oil (AWD)
❏ Tighten nuts and bolts on chassis __ Fuel tank cap gasket
__ Rack-and-pinion assembly
__ Rear differential oil (AWD)
__ Steering linkage and boots
__ Transfer case oil (AWD)
__ Transmission for signs of leakage
__ Wiper blades❏ Reset maintenance reminder light
❏ Rotate tires
❏ Visually inspect brake pads, calipers
and r otors
❏ Check installation of driver’s floor mat
❏ Road-test vehicle
d ate: __________________________ Mileage: __________________________

e xplanation of Maintenance i te MS
MAINTENANCE Scheduled Maintenance Log68 The following descriptions are
provided to give you a better under -
standing of the maintenance services
that should be performed on your
vehicle. The scheduled maintenance
log indicates at which time/mileage
intervals each service should be
performed. Please note that many
maintenance services should be per -
formed only by a qualified technician.
Axle Shaft Boots
Check the axle shaft boots and
clamps for cracks, deterioration and
damage. Replace any damaged parts
and, if necessary, repack the grease.
A qualified technician should perform
these operations.
Ball Joints and Dust Covers
Check the suspension and steering
linkage ball joints for looseness and
damage. Check all dust covers for
deterioration and damage. A quali -
fied technician should perform
these inspections. Body Inspection
Visually check for corrosion,
scratches and other damage. Check
outer body panels, inner panels of
the hood and doors, and underneath
the vehicle. Apply touch-up paint to
any chips and scratches or have them
repaired by a qualified technician.
Brake Fluid
Replace using fluid type specified in
your Owner’s Manual . A qualified tech -
nician should perform this operation.
Brake Lines and Hoses
Visually inspect for proper instal -
lation. Check for chafing, cracks,
deterioration and signs of leakage.
Replace any deteriorated or dam -
aged parts. A qualified technician
should perform these operations.
Brake Pads, Calipers and Rotors
Check brake pads and rotors for
excessive wear; check brake rotors
for runout. Check brake calipers for
fluid leakage. A qualified technician
should perform these inspections.
For further information on
maintenance services that you
can perform yourself, see the
maintenance sections of your
Owner’s Manual .
