LEXUS RX450h 2016 Owners Manual

4015-1. Basic operation of the Remote Touch screen
5
Interior features
RX450h_U_OM0E013U Press the “MENU” button on the Remote Touch to display the “Menu” screen.
The display may differ depending on the type of the system. Vehicles with 12.3-inch display: When the split-screen display is selected, the “Menu”
screen will be displayed on the main display. (  P. 4 0 2 )
* : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.“Menu” screen 
Vehicles with 8-inch display 
Vehicles with 12.3-inch display
Switch Function
Select to display the map screen (Vehicles with 8-inch display).
*Select to display the radio control screen.
*Select to display the media control screen.
*Select to display the hands-free operation screen.
*Select to display the “LEXUS App Suite” screen.
*Select to display the “Information” screen.
*Select to display the air conditioning control screen. (  P. 4 0 5 )
Select to display the “Setup” screen.
*Select to display the “Destination” screen (Vehicles with 12.3-inch
display).
*“Display” Select to adjust the contrast and br ightness of the screens, turn the
screen off, etc.
*

402 5-1. Basic operation of the Remote Touch screen
RX450h_U_OM0E013U ■
Full screen display
The following functions can be displayed full screen:
• Initial screen
•“Menu” screen (  P. 4 0 1 )
• Map screen
**: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.■
Split-screen display
Different information can be displayed on the left and right of the screen. For
example, audio screen can be displayed and operated while the fuel con-
sumption information screen is being disp layed. The large screen on the left of
the display is called the main display, an d the small screen to the right is called
the side display.12.3-inch display 
 : If equipped12.3-inch display overview

4035-1. Basic operation of the Remote Touch screen
5
Interior features
RX450h_U_OM0E013U ■
Selecting the operation screen
When selecting the main display, move the Remote Touch knob to the left.
When selecting the side display, move the Remote Touch knob to the right. ■
Main display
For details about the functions and operat ion of the main display, refer to the
respective section and “NAVIGATION SYSTEM OWNER’S MANUAL”. ■
Side display 
Basic screens
To change the screen displayed on the side display, use the screen buttons on
the right side of the display.
Navigation system
*Audio
* Phone
* Vehicle information (  P. 1 2 9 )
Air conditioning system
(  P. 4 0 8 ) 
Interruption screens
Each of the following screens is displayed automatically in accordance with
conditions.
• Intuitive parking assist (  P. 3 4 0 )
•Phone
*• Destination Assist
*•Driving mode (  P. 3 7 7 )
* : Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.Split-screen display operation
1
2
3
4
5

404
RX450h_U_OM0E013U 5-2. Using the air conditio ning system and defogger
Automatic air conditioning system (  P. 4 0 8 )
Set the air conditioning system to automatic mode. The temperature for the driver’s seat and front passenger’s seat can be adjusted indi-
vidually.
Seat heaters and ventilators (  P. 4 1 5 , 4 1 6 )
Select “AUTO” mode on each seat. Seat heater or ventilation is automatically selected according to the set temperature
of the air conditioning system, outside temperature, etc.Lexus Climate Concierge The climate control seats are automati cally controlled according to the set
temperature of the air conditioning system, outside temperature, cabin tem-
perature, etc. Lexus Climate Concierge allows a comfortable condition to be
maintained without adjusting each system.
1
2

4055-2. Using the air conditio ning system and defogger
5
Interior features
RX450h_U_OM0E013U ■
Adjusting the temperature setting
Press to increase the temperature and to decrease the temper-
ature. ■
Adjusting the fan speed setting
Press to increase the fan speed and to decrease the fan speed.
Press the “OFF” button to turn the fan off.Automatic air conditioning system Air outlets and fan speed are automatica lly adjusted according to the temper-
ature setting.
Press the “MENU” button on the Remote Touch, then select to display
the air conditioning control screen.
Vehicles with 12.3-inch display: The ai r conditioning system can be displayed
and operated on the side display. (  P. 4 0 3 )
For details on the Remote Touch, refer to the “NAVIGATION SYSTEM
OWNER’S MANUAL”.
Control panel

406 5-2. Using the air conditio ning system and defogger
RX450h_U_OM0E013U ■
Change the airflow mode
To change the air outlets, press .
The air outlets used are switched
each time the button is pressed.
Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger operates■
S-FLOW mode
In S-FLOW mode, priority for the airflow is given to the front seats, reducing
the airflow and air conditioning effect on the rear seats.
If a passenger is not detected in the front passenger seat, priority for the air-
flow will be given to the driver's seat only. In this case, the temperature indicator fo r the front passenger side will turn off.
S-FLOW mode will be activated automatically according to the set tempera-
ture, outside temperature, etc. (  P. 411)The indicator comes on when S-FLOW mode is on.■
Other functions ●
Switching between outside air and recirculated air modes (  P. 4 0 9 )●
Defogging the windshield (  P. 4 0 9 )●
Defogging the rear window and outside rear view mirrors (  P. 4 0 9 )1
2
3
4

4075-2. Using the air conditio ning system and defogger
5
Interior features
RX450h_U_OM0E013U Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tem-
perature setting
Display the option control screen
(  P. 4 0 7 )
Select to set automatic mode on/off
Select to set cooling and de humidification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (  P. 4 0 8 )
Select to set eco mode on/off (  P. 4 1 2 )■
Option control screen
Select on the air conditioning control screen to display the option
control screen. The functions can be switched on and off.
Prevent ice from building up on
the windshield and wiper blades
(if equipped) (  P. 4 0 9 )Control screen 1
2
3
4
5
6
7
8
9
1

408 5-2. Using the air conditio ning system and defogger
RX450h_U_OM0E013U ■
Side display operation screen (Vehicles with 12.3-inch display)
Select the air flow mode
Adjust the left-hand side temper-
ature setting
Adjust the fan speed setting
Adjust the right-hand side tem-
perature setting
Select to set auto mode on/off
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (  P. 4 0 8 )■
Using the automatic mode
Press the “AUTO” button or select “AUTO” on the air conditioning control
screen.
Press to switch to automatic air intake mode. (if equipped)
The air conditioning system automati cally switches between outside air
and recirculated air modes.
Adjust the temperature setting.
To stop the operation, press the “OFF” button.■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automati c mode for functions other than that
operated is maintained. ■
Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)
To turn on the “DUAL” mode, perform any of the following procedures: ●
Select “DUAL” on the air co nditioning control screen.●
Select “DUAL” on the side display operation screen. (Vehicles with 12.3-
inch display) ●
Adjust the temperature setting of the passenger side with the passenger
side temperature adjustment button. The indicator comes on when the “DUAL” mode is on. 1
2
3
4
5
6
Air conditioning controls 7
1
2
3
4

4095-2. Using the air conditio ning system and defogger
5
Interior features
RX450h_U_OM0E013U ■
Switching between outside air and recirculated air modes
Press . The mode switches between (recirculated air mode), automatic and
(outside air mode) modes each time the button is pressed.
When the system is switched to automatic mode, the air conditioning system oper-
ates automatically.■
Defogging the windshield
Defoggers are used to defog the windshield and front side windows.
Press . Set the outside/recirculated air mode button to outside air mode if the recirculated
air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press again when the windshield is
defogged.■
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.
Press . The defoggers will automatically turn off after a period of time.■
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice fr om building up on the windshield and
wiper blades.
Select on the option control screen. When the windshield wiper de-icer is on , is displayed on the air condition-
ing control screen.
The windshield wiper de-icer will automati cally turn off after a period of time.Other functions

410 5-2. Using the air conditio ning system and defogger
RX450h_U_OM0E013U ■
Location of air outlets
The air outlets and air volume
changes according to the selected
air flow mode.
■
Adjusting the position of and opening and closing the air outlets
Direct air flow to the left or right, up or down
Turn the knob to open or close the ventAir outlets 
Front side 
Front center
Rear
1
2
