LEXUS RX450h 2016 Owners Manual

421
RX450h_U_OM0E013U 5
Interior features 5-4. Using the storage features
List of storage features
Glove box (  P. 422)
Auxiliary boxes (  P. 4 2 6 )
Door pockets (  P. 4 2 4 )
Bottle holders (  P. 4 2 5 ) Console box (  P. 422)
Cup holders (  P. 4 2 3 )
Coin box (  P. 4 2 5 )
WA R N I N G ●
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact with other
stored items.
• Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard. ●
When driving or when the storage compartments are not in use, keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur due to an
occupant being struck by an open lid or the items stored inside. 1
2
3
4 5
6
7

422 5-4. Using the storage features
RX450h_U_OM0E013U Open (press the button)
Unlock with the mechanical key
Lock with the mechanical key
The glove box light turns on when the tail lights are on.
Push the knob. Lift by hand to fully open the console
box.
●
The console box light turns on when the tail lights are on.Glove box 1
2
3
Console box
●
A pen can be stored in the pen holder on the
underside of the lid.
●
Remove the tray to access a storage space
under the tray.

4235-4. Using the storage features
5
Interior features
RX450h_U_OM0E013U The depth of the front cup holder can be changed.Cup holders 
Front 
Rear
Pull down the armrest and then press
down the button.To store a water bottle, push down the bottom
of the cup holder.
To return the bottom to its original position,
press the button.
WA R N I N G ●
Do not place anything other than cups, aluminum cans, or water bottles in the cup
holders. Other items may be thrown out of the holders in the event of an accident or
sudden braking, possibly caus ing injury. If possible, cover hot drinks to prevent burns.●
Rear cup holder: When not in use, keep the cup holders are closed. Injuries may
result in the event of an accident or sudden braking. 1
2

424 5-4. Using the storage features
RX450h_U_OM0E013U The door pockets can be opened and
closed. NOTICE
To prevent damage to the rear cup holder, stow the cup holder before stowing the arm-
rest.
Door pockets 
Front 
Rear
WA R N I N G
Front door pockets: Keep the door pockets closed while driving.Injuries may result in
the event of an accident or sudden braking.

4255-4. Using the storage features
5
Interior features
RX450h_U_OM0E013U ●
When storing a bottle, close the cap. ●
The bottle may not be stored depending on its size or shape.
Press in the button.Bottle holders
NOTICE
Do not place open bottle, glass or paper cu ps containing liquid in the bottle holders.
Otherwise, contained liquid may be spilled. Gl ass cups may break if used in the bottle
holders.
Coin box
WA R N I N G
Keep the coin box
closed while driving.
Injuries may result in the event of an accident or sudden braking.

426 5-4. Using the storage features
RX450h_U_OM0E013U Auxiliary boxes 
Ty p e A 
Ty p e B
Press in the lid. Lift the lid. 
Ty p e C
Pull up the lever to release the lock, and
lift the lid. WA R N I N G
Type A: Do not store items heavier than 0.44 lb. (200 g).
Doing so may cause the auxiliary box to open and the items inside may fall out, result-
ing in an accident.

4275-4. Using the storage features
5
Interior features
RX450h_U_OM0E013U Pull down the hook to use. The cargo hooks are provided for
securing loose items.
To hang the cargo net, use the cargo
net hooks and rear cargo hooks.Luggage compartment features Cargo hooks
WA R N I N G
To avoid injury, always return the hooks to their stowed positions when not in use.
Cargo net hooks

428 5-4. Using the storage features
RX450h_U_OM0E013U To use the grocery bag hook, push it in.
■
Using the luggage cover
Insert either end of the luggage
cover into the recess, then com-
press the other end of the lug-
gage cover and insert it into the
recess.
Pull out the luggage cover and
hook it onto the anchors.Grocery bag hooks
NOTICE
Do not hang any object heavier than 8. 8 lb. (4 kg) on the grocery bag hooks.
Luggage cover 1
2

4295-4. Using the storage features
5
Interior features
RX450h_U_OM0E013U ■
Removing the luggage cover
Release the cover from the left
and right anchors and allow it to
retract.
Compress the end of the luggage
cover and lift the luggage cover
up. After removing the luggage cover,
place it somewhere other than the
passenger compartment. 1
2
WA R N I N G ●
Do not place anything on the luggage cover.
In the event of sudden braking or turn-
ing, the item may go flying and strike an occupant. This could lead to an unexpected
accident, resulting in death or serious injury. ●
Do not allow children to climb on the lugg age cover. Climbing on the luggage cover
could result in damage to the luggage cover, possibly causing death or serious injury
to the child.

430 5-4. Using the storage features
RX450h_U_OM0E013U Pull the lever up and fold the flap of
the deck board.
Lift the deck board and disengage
the hook on the underside of the
deck board.
Attach the hook to the upper edge
of the back door opening as shown.Auxiliary boxes 1
2
3

Deck floor box 
Deck side box
