LEXUS RX450H 2019 Owners Manual

6818-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL_U
Chock the tires.
Slightly loosen the wheel nuts (one
turn).
For vehicles with wheel lock nuts, loosen
the wheel lock nut first.
Turn the tire jack portion by hand
until the notch of the jack is in con-
tact with the jack point.
The jack point guides are located under
the rocker panel. They indicate the jack
point positions.
Replacing a flat tire
1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the front left-hand side tire
2
3A

6828-2. Steps to take in an emergency
RX450h_RX450hL_U
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire.
When resting the tire on the ground,
place the tire so that the wheel design
faces up to avoid scratching the wheel
surface.
■If the spare tire cannot be lowered (RX450hL)
If the spare tire cannot be lowered, it may not have been stowed properly. Perform the
following procedure:
If the spare tire still cannot be lowered, the wire cable may be severed. Have the vehicle
inspected by your Lexus dealer.
4
5
Fully tighten the spare tire clamp bolt by turn-
ing the jack handle clockwise until two clicks
are heard and the jack handle skips.
Turn the jack handle counterclockwise to
lower the spare tire.
If the spare tire still cannot be lowered,
attempt to fully tighten the spare tire clamp
bolt again by turning the jack handle clock-
wise. Then turn it counterclockwise at least 2
turns to lower the spare tire.1
2

6838-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL_U
WARNING
■When holding a tire with Selectable Color Trim (if equipped)
■Replacing a flat tire
●Do not touch the disc wheels or the area around the brakes immediately after the
vehicle has been driven.
After the vehicle has been driven the disc wheels and the area around the brakes will
be extremely hot. Touching these areas with hands, feet or other body parts while
changing a tire, etc. may result in burns.
●Failure to follow these precautions could cau se the wheel nuts to loosen and the tire
to fall off, resulting in death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts. Oil and grease may cause the wheel nuts to be excessively tightened, leading to
bolt or disc wheel damage. In addition, the oil or grease can cause the wheel nuts
to loosen and the wheel may fall off, causing a serious accident.
Remove any oil or grease from the wheel bolts or wheel nuts.
• Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m, 10.5 kgf•m) as soon as possible after changing wheels.
• When installing a tire, only use wheel nuts that have been specifically designed for
that wheel.
• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes
of the wheel, have the vehicle inspected by your Lexus dealer.
●Observe the following precautions. (RX450hL)
Failure to do so may result in serious injury:
• Do not try to remove the wheel ornament by hand. Take due care in handling the ornament to avoid unexpected personal injury.
• Lower the spare tire completely to the ground before removing it from under the
vehicle.
■Replacing a flat tire for vehicles with power back door
In cases such as when replacing tires, make sure to turn off the power back door main
switch ( P. 112). Failure to do so may cause the back door to operate unintentionally if
the power back door switch is accidentally touched, re sulting in hands and fingers
being caught and injured.
Do not hold the tire by the Selectable Color
Trim. Otherwise, the Selectable Color Trim
may be damaged or may fall off causing the tire
to drop, possibly causing injury.

6848-2. Steps to take in an emergency
RX450h_RX450hL_U
Remove any dirt or foreign matter
from the wheel contact surface.
If foreign matter is on the wheel contact
surface, the wheel nuts may loosen
while the vehicle is in motion, causing
the tire to come off.
Install the spare tire and loosely
tighten each wheel nut by hand by
approximately the same amount.
Tighten the wheel nuts until the tapered
portion comes into loose contact with
the disc wheel seat.
Lower the vehicle.
Firmly tighten each wheel nut two or
three times in the order shown in the
illustration.
For vehicles with wheel lock nuts,
tighten the wheel lock nut last
Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
RX450h: Stow the flat tire, tire jack and all tools.
RX450hL:  P. 685
Installing the spare tire
1
Disc wheel
seat
Tapered portion2
3
4
5

6858-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL_U
Remove the center wheel ornament by pushing from the reverse side.
Be careful not to lose the wheel ornament.
Stand the tire against the bumper
with the inner surface facing toward
you. Pass the hoist assembly and
holding bracket through the
wheel opening.
Fully depress the secondary latch and install the bracket to the
hoist assembly .
WARNING
■Stowing the flat tire
Failure to follow steps listed under stow ing the tire may result in damage to
the spare tire carrier and loss of the ti re, which could result in serious injury
or death.
Stowing the flat tire, jack and all tools (RX450hL)
1
2
C
B
3
AB
C

6868-2. Steps to take in an emergency
RX450h_RX450hL_U
Lay the tire on the ground with the
outer surface (valve stem) facing up.
Before raising the tire, make sure
that the hoist assembly is perpendic-
ular to the wheel opening. (Try to
place the tire directly beneath the
vehicle, near where the wire cable is
hanging from.)
Using the jack handle and adapter socket, tighten the tire clamp bolt by turn-
ing it clockwise until the tire is in the correct position and two clicks are heard
as the jack handle skips.
Confirm it is not loose after tighten-
ing:
Push and pull the tire
Try rotating
Visually check to ensure tire is not
hung on surrounding parts.
If looseness or misassembly exists,
repeat steps
to .
Repeat step , any time the tire is lowered or disturbed.
Stow the jack and all tools.
4
Valve stem
5
6
7
1
2
27
87
9

6878-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL_U
■The compact spare tire
●The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the
tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.
●Make sure to check the tire inflation pressure of the compact spare tire. (P. 717)
■When using the compact spare tire
As the compact spare tire is not equipped wi th a tire pressure warning valve and trans-
mitter, low inflation pressure of the spare tire will not be indicated by the tire pressure
warning system. Also, if you replace the compact spare tire after the tire pressure warn-
ing light comes on, the light remains on.
■When the compact spare tire is equipped
When driving with the compact spare tire inst alled, the vehicle height will be different
than when driving with standard tires.
■If you have a flat front tire on a road covered with snow or ice
Install the compact spare tire on one of the rear wheels of the vehicle. Perform the follow-
ing steps and fit tire chains to the front tires: Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of the vehicle.
Fit tire chains to the front tires.
1
2
3

6888-2. Steps to take in an emergency
RX450h_RX450hL_U
WARNING
■When using the compact spare tire
●Remember that the compact spare tire provided is specifically designed for use with
your vehicle. Do not use your comp act spare tire on another vehicle.
●Do not use more than one compact spare tire simultaneously.
●Replace the compact spare tire with a standard tire as soon as possible.
●Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking.
■When the compact spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:
Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:
•E-Four
■Speed limit when using the compact spare tire
Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is
installed on the vehicle.
The compact spare tire is not designed for driving at high speeds. Failure to observe
this precaution may lead to an accident causing death or serious injury.
■After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their storage
location to reduce the possibilit y of personal injury during a collision or sudden brak-
ing.
• ABS & Brake assist
•VSC
•TRAC
•EPS
• Trailer Sway Control
•VDIM
• Adaptive Variable Suspension System (if equipped)
• Dynamic radar cruise control with full- speed range
• PCS (Pre-Collision System)
• LKA (Lane-Keeping Assist) • Automatic High Beam
• AFS (Adaptive Front-lighting System)
(if equipped)
• Tire pressure warning system
• Intuitive parking assist (if equipped)
• Intelligent Clearance Sonar (ICS) (if equipped)
• Lexus parking assist monitor (if equipped)
• Panoramic view monitor (if equipped)
• BSM (Blind Spot Monitor) (if
equipped)
• Navigation system (if equipped)

6898-2. Steps to take in an emergency
8
When trouble arises
RX450h_RX450hL_U
NOTICE
■Be careful when driving over bumps with the compact spare tire installed on the vehi-
cle
When driving with the compact spare tire installed, the vehicle height will be different
than when driving with standard tires. Be careful when driving over uneven road sur-
faces, etc.
■Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.
■When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly.
■When stowing the flat tire (RX450hL)
●Ensure that there is no object caught between the tire and the vehicle underbody.
●Securely tighten the spare tire clamp bolt to hold the spare wheel carrier by the hook.
●Stow the flat tire in the spare tire location. Failure to do so may cause damage to the
spare tire carrier. Proper storage reduces the possibilit y of injury in a collision or
during sudden braking.
●Have the flat tire repaired and the spare tire replaced with it as soon as possible.
■Proper storage of the spare tire (RX450hL)
●If the spare tire clamp bolt is turned withou t a tire on the hoist assembly, the wire cable
may not be able to be lowered. If the wire cable cannot be lowered, contact your
Lexus dealer.
●If the hoist assembly is slanted when stowing a
tire, the hoist assembly may become stuck in
the wheel opening and the tire may not be
raised properly, causing damage to the wheel
or the wire cable.

6908-2. Steps to take in an emergency
RX450h_RX450hL_U
One of the following may be the cause of the problem:
●The electronic key may not be functioning properly. ( P. 692)
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
●There may be a malfunction in the immobilizer system. ( P. 83)
●There may be a malfunction in the steering lock system.
●The hybrid system may be malfunctioni ng due to an electrical problem such
as electronic key battery depletion or a blown fuse. However, depending on
the type of malfunction, an interim meas ure is available to start the hybrid sys-
tem. ( P. 691)
One of the following may be the cause of the problem:
●The 12-volt battery may be discharged. ( P. 695)
●The 12-volt battery terminal connections may be loose or corroded.
( P. 691)
If the hybrid system will not start
Reasons for the hybrid system not star ting vary depending on the situation.
Check the following and perform the appropriate procedure:
The hybrid system will not start even though the correct starting proce-
dure is being followed. ( P. 239)
The interior lights and headlights are d im, or the horn does not sound or
sounds at a low volume.
