LINCOLN AVIATOR 2004 Quick Reference Guide

Climate Control
Climate
Control Seats
(if equipped)
The controls are
located on the front door trim panels. To
cool the seats, push the icon on the
button; a blue light will illuminate. Push
again to disengage. To heat the seats,
push the icon on the button; a red light
will illuminate. Push again to disengage.
To adjust the heating or cooling levels,
rotate the thumbwheel from 1 (MIN) to 5
(MAX). Allow five minutes for the
temperature to stabilize.
Tire Pressure
Monitoring
System
Using radio-frequencypressure sensors, this systemmonitors
tire pressure on all road tires and
provides the driver with a yellow
warning light when air needs to be
added. Message Center equipped
vehicles provide additional warning
messages. Please note: Outside
temperature affects tire pressure. See
Owner’s Guide for more information.
Remote Entry
System
The remote entry
system allows you
to lock or unlock all vehicle doors, the
liftgate and the liftgate window without
a key. This system operates in any
ignition position.
Unlocking Doors/Liftgate: Press
this control to unlock the driver’s
door; the interior lamps will illuminate
with the ignition OFF. Press the control
a second time within three seconds to
unlock all doors and liftgate.
Locking Doors/Liftgate: Press
this control to lock all doors and
liftgate; the park/turn signal lamps will
flash once. To confirm all doors are
closed and locked, press the control a
second time within three seconds; the
park/turn signal lamps will flash once
and the horn will chirp. If any of the
doors or liftgate are ajar, the horn will
make two quick chirps, reminding you
to properly close all doors.
Audio System Essential Information Additional Features
FUEL TANK CAPACITY/FUEL RECOMMENDATIONS:Your Aviator’s fuel tank can accommodate 22.5
gallons of fuel. Your vehicle is designed to use “Premium” unleaded fuel with an (R+M)/2 octane
rating of 91 or higher for optimum performance. The use of fuel with lower octane ratings may
degrade performance.
FUSES:If electrical components in your vehicle stop working, a fuse may have blown. (You’ll notice a
broken wire within the fuse.) For information on changing fuses, please consult your Owner’s Guide.
TIRE PRESSURE:Your tire pressure is properly set at the dealership according to the
recommended specifications found on the Tire Pressure Label located on the driver door jamb. Please
check your tire pressure during routine maintenance and seasonal changes. If the Tire Pressure
Monitoring System light stays illuminated after starting, immediately check your tire pressure.
Warning: Improperly inflated tires can affect vehicle handling and can fail suddenly, possibly resulting
in loss of vehicle control.
CHANGING THE TIRES:Your spare tire is not equipped with a tire pressure monitoring system
sensor. The tire pressure monitoring system indicator light (if equipped) will illuminate when the
spare is in use. Replace the spare with the road tire as soon as possible. If your vehicle is equipped
with AWD, remember that a spare tire of a different size shall not be used. It can make your vehicle
difficult to control and can result in damage to driveline components. If you get a flat tire while
driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering
wheel firmly and slowly move to a safe place on the side of the road.
•SPARE TIRE:Under the vehicle, just in front of the rear bumper.
•SPARE TIRE WINCH DRIVE NUT:Rear center of the cargo area, under a lid.
•JACK, LUG NUT WRENCH, JACK HANDLE AND WHEEL CHOCK:Behind the rear seat under the
carpeted floor lid in the cargo door.
ROADSIDE EMERGENCIES:To fully assist you if you should have a vehicle concern, Lincoln offers
a complimentary roadside assistance program. This program is separate from the New Vehicle
Limited Warranty. The service is available 24 hours a day, seven days a week for the New Vehicle
Limited Warranty period of four years or 50,000 miles.
Roadside assistance will cover: Country: Phone Number:
•Changing a flat tire United States (800) 521-4140
•Lockout assistance Canada (800) 665-2006
•Jump-starts
•Towing of your vehicle
•Limited fuel delivery
For complete details on any roadside assistance concerns, see the Roadside Emergencies or Customer Assistance
sections of your Owner’s Guide.(If your Aviator is equipped with a different audio
system, please refer to your Owner’s Guide.)
1 SCAN FUNCTION:In radio mode,
press to hear a sampling of all listenable
stations. In CD mode, press to hear a
brief sampling of all selections on the
current CD.
2 CD/AUX: Press to select CD/AUX
modes. No CD will display if there is not
a CD present in the audio system. If a
disc is loaded, there will be a number
(1-6) inside the circle on the display.
3 LOADING CD:Press to open the CD
door, then load a CD into the player. Press
LOAD and then a preset number to select
a slot. Press and hold LOAD to activate
autoload.
4 VOLUME/POWER CONTROL:Press the
control to turn the audio system on or off.
Turn the control to raise or lower volume.
The speed sensitive volume feature
automatically adjusts radio volume in
accordance with vehicle speed to
compensate for road and wind noise. To
engage, press and hold the volume
control for five seconds (with the radio
on), then simultaneously press SEL to
choose the compensation level.
5 AM/FM SELECT:In radio mode, press
AM/FM to select AM or FM frequency
bands. In CD mode, press AM/FM to stop
play and begin radio play. 6 SATELLITE:Your Audiophile radio
comes equipped with satellite-ready
capability. The kit to enable satellite
reception is available through your Ford
dealer. Detailed satellite instructions are
included with the dealer-installed kit.
7 DISC/TUNE CAT: In radio mode, press
to move to the next frequency up or down
the band. In CD mode, press to select a
disc in the CD player. CAT is only
available when equipped with satellite
radio. The kit to enable satellite reception
is available through your Ford dealer.
Detailed satellite instructions are
included with the dealer-installed kit.
8 DIGITAL SIGNAL PROCESSING:Press
DSP and then SEL to choose the desired
signal mode (DSP OFF, NEWS, JAZZ
CLUB, HALL, CHURCH, STADIUM).
9 SEEK FUNCTION:In radio mode, press
to move to the next listenable station up
or down the band. In CD mode, press to
select the next/previous track on the
current disc.
10 SETTING THE CLOCK:Press MENU
until SELECT HOUR or SELECT MINUTE
is displayed. Press SEL to set the
time. Press MENU again to disengage
the clock mode.
11 SETTING MEMORY PRESET STATIONS:
Select AM, FM1, or FM2 band, then
select a station. Next, press and
hold a numbered control until the
sound returns.
1AUTO:Press AUTO and select the
temperature you find most comfortable.
The system will automatically determine
fan speed, airflow location and whether
outside or recirculated air is required.
2AUTO OFF:Press OFF to disengage
automatic temperature control.
3DIRECT AIRFLOW:You can personally
determine where you’d like air to go by
choosing one of these manual override
controls.
4DEFROST:To clear thin ice and fog from
the windshield, choose DEFROST; this
control will distribute outside air through
the windshield defroster ducts and the
side window demisters. To return to
automatic operation, press AUTO.
5DEFROST REAR WINDOW:Press this
control to manually enable or disable the
rear window defroster in all modes. After
approximately 10 minutes of operation,
the climate control system will
automatically disable the rear defrost
operation. If more defrosting is needed,
press the control again.
6DRIVER TEMPERATURE CONTROL:Press
the up arrow of the driver temperature
control for a warmer temperature, the
down arrow for a cooler temperature.
7FAN SPEED:When your climate control
system is in automatic mode, the fan
speed will automatically adjust toachieve the selected temperature. To
adjust fan speed manually, press the up
arrow to increase the speed, the down
arrow to decrease the speed. To return to
automatic fan operation, press AUTO.
8EXTERIOR TEMPERATURE DISPLAY:
Press EXT to display the outside
temperature; press again to end exterior
temperature display.
9FAHRENHEIT/CELSIUS:Press the °F °C
control to switch between Fahrenheit and
Celsius.
10A/C:You may override automatic
operation at any time by pressing the A/C
control. To return to automatic air
conditioning operation, press AUTO.
11RECIRCULATED AIR:Press this button
to manually control recirculated air; to
return to automatic recirculated air,
press AUTO.
12PASSENGER TEMPERATURE CONTROL:
Press the up arrow of the passenger
temperature control for a warmer
temperature, the down arrow for a cooler
temperature.
13DUAL TEMPERATURE ZONE:Press
DUAL to enable or disable the dual zone
temperature feature that allows driver and
front passenger to select a temperature
based on personal preference. Press
DUAL again to disable this feature.
Audiophile Satellite-Ready In Dash Six CD Radio (if equipped) Automatic Temperature Control
Ford Motor Company Customer Relationship Center
16800 Executive Plaza Drive, P.O. Box 6248, Dearborn, MI 48121
1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952)
This Quick Reference Guide is not intended to replace the vehicle Owner
Guide that contains more detailed information concerning the features of
your vehicle and important safety warnings to help reduce the risk of injury
to you and your occupants. Always carefully read your entire owner guide
when first learning about your vehicle and consult the appropriate section
when questions arise.
4C5J-19G217-AA
*F4C5J19G217AA*
June 2003
First Printing
Quick Reference GuideLincoln Aviator
Litho in U.S.A.
Opening
the Liftgate
& Liftgate
Window
To prevent injury or damage to your
vehicle, always make sure the liftgate
window is closed before opening
the liftgate.
The liftgate on your Aviator is designed
to be opened from outside the vehicle.
You can unlock the liftgate with the
power door locks, the remote entry,
keyless entry pad. Push the center
control button under the license plate
lamp shield while pulling the liftgate. To
open the liftgate window, press the
control on the remote entry key fob or,
with the liftgate unlocked, push the
right control button under the license
plate lamp shield.
12
3
4
56
789
1110
101112
12345
678
913
2004aviatorQUICK REFERENCE GUIDE
2004
aviator
QUICK REFERENCE GUIDE
2004aviatorQUICK REFERENCE GUIDE
*CDs with adhesive labels and irregularly shaped CDs may get stuck in the CD player.
Homemade CDs should be identified with permanent felt tip marker rather than adhesive labels.CAUTION: DO NOT USE CD WITH ADHESIVE LABEL*
21271_AviatorQRG 7/9/03 6:43 PM Page 1

2Headlamps
Rotate the headlamp control clockwise to the second position to
turn on the headlamps. Pull the headlamp control towards you to
turn on the foglamps. Rotate the control counterclockwise to
initiate the auto lamps. (This light-sensitive system turns your
exterior lamps on and off automatically. It also keeps the lights on
for approximately 20 seconds after the ignition switch is turned to
the OFF position.) To turn the system off, rotate the control
clockwise to the OFF position.
3 ABS Light
Your anti-lock braking system (ABS) detects the onset of wheel lockup
during brake applications and helps prevent wheels from locking
during extreme braking situations. The ABS warning light will
illuminate when you start your engine; however, if it stays on,
continues to flash or fails to illuminate, see your dealership's service
department immediately.
5Speed Control
You must be traveling at or above 30 miles per hour to use the
speed control system. Press ON to enable speed control. Press
SET + to set a speed. To set a higher speed, accelerate to the
desired speed, press and release SET +. To establish a lower
speed, depress the brake pedal; when the desired vehicle speed
is reached, press SET + /SET -. To return to a previously set speed,
press RES. To disengage speed control and erase the previously
programmed set speed, press OFF.
12Parking Brake Release
Pull the release lever to release the parking brake. Driving with the
parking brake on will cause the brakes to wear out quickly and
reduce fuel economy. The parking brake is not recommended to
stop a moving vehicle. However, if the normal brakes fail, the
parking brake can be used to stop your vehicle in an emergency.
Since the parking brake applies only the rear brakes, the vehicle’s
stopping distance will increase greatly and the handling of your
vehicle will be adversely affected.
11Advance Trac™ (if equipped)
By monitoring vehicle speed, yaw, lateral acceleration, and
intended direction, the AdvanceTrac™ system provides enhanced
traction and stability on slippery surfaces, or in emergency
maneuvers. The system defaults to on. If your vehicle should
become stuck, try switching the system off by pressing the
AdvanceTrac™ button on the center console. When the system is
functioning, a yellow icon will flash.
10Defrost Windshield
To clear thin ice and fog from the windshield, choose defroster
mode from the manual override controls; this control will
distribute outside or recirculated air through the windshield
defroster ducts and the side window demisters. To return to
automatic operation, press AUTO.
8Turn Signal/Wiper Washer Controls
For a single swipe with no wash, tap the end of the stalk briefly.
The bars of varying length are for intermittent wiper operation.
When in this position rotate the control upward for fast intervals
and downward for slow intervals. For three swipes with wash,
push and hold the end of the stalk. For a longer wash, push and
hold the end of the stalk for up to ten seconds.
For rear wiper operation, rotate the rear window wiper and
washer control to the desired position. Select INT 2 for normal
speed operation, INT 1 for intermittent operation, or OFF to turn
the rear wiper/washer off. For rear wash cycle, rotate (and hold
as desired) the rear wiper/washer control to either position. The
control will automatically return to the INT 2 or OFF position.
9Clock
Your clock is mounted on your instrument panel. Press the right
control to increase the time displayed, the left control to decrease the
time displayed.
Instrument Panel
Congratulations on your new Lincoln Aviator. This exciting vehicle comes equipped
with many sophisticated features – some will require no explanation, others may be
new to you. This Quick Reference Guide was designed to acquaint you with many of
the features you’ll use most.
Take a few minutes to use this Quick Reference Guide with the accompanying CD-
ROM. Insert the CD into any audio CD player; find the numbered call-outs on the
instrument panel portion of this guide, then select the corresponding number on the
CD audio track for a fast, convenient introduction to Aviator’s most-used features.
When you have more time, place the CD into your computer for an enjoyable
interactive introduction to your new vehicle. (The CD jacket will tell you if your
computer meets the minimum configuration requirements.)
For detailed information, please consult your Owner’s Guide.
This vehicle handles differently from an ordinary
passenger car in driving conditions which may
occur on streets and highways and off-road.
DRIVE
WITH CARE AND WEAR A SAFETY BELT AT ALL
TIMES.Ford urges you to read the Owner’s Guide
and Driving Your SUV or Truck Supplement for
further information on safe driving precautions and instructions.
Your Message Center is located on your
instrument cluster. With the ignition in the ON
position, it displays important vehicle
information while constantly monitoring
vehicle systems. The Message Center will
also notify you of potential vehicle problems
by displaying system warnings followed by a
long indicator chime.
Reset
Press this control to select and
reset functions shown in the
INFO menu and SETUP menu.
Info Menu
This control displays the
following:
•Odometer/Compass
•Trip Odometer/Odometer/Compass
•Distance to Empty
•Average Fuel Economy
•Trip Elapsed Drive Time
Setup Menu
Press this control for the
following displays:
Selecting the system check function from the
SETUP menu causes the message center to
cycle through each of the systems being
monitored. Each system will indicate either
an OK message or a warning message for
three seconds.
Pressing the RESET control cycles the
message center through each of the systems
being monitored.
The sequence of the systems check report
and how it appears in the message center is
as follows:
System Warnings
System warnings alert you to possible
problems or malfunctions in your vehicle’s
operating systems. In the event of a multiple
warning situation, the message center will
cycle the display to show all warnings by
displaying each one for 4 seconds.
The message center will display the last selected
feature if there are no more warning messages.
This allows you to use the full functionality of the
message center after you acknowledge the
warning by pressing the RESET control and
clearing the warning message.
Warning messages that have been reset are
divided into three categories that: :
•Will reappear on the display every minute
from the reset.
•Will reappear on the display ten minutes
from the reset.
•Will not reappear until an ignition OFF-ON
cycle has been completed.
Message Center
6Audio System
Please see Audio System on the reverse side of this card.
7Climate Control
Please see Climate Control on the reverse side of this card.
1 FUEL LEVEL
2 WASHER FLUID
LEVEL
3OIL LIFE IN XX%
4PARK ASSIST
5ENGINE TEMP
6OIL PRESSURE7TIRE PRESSURE
SYSTEM
8BRAKE FLUID
LEVEL
9CHARGING
SYSTEM
•System Check
•Units
(English/Metric)
•Autolock
•Easy Entry/Exit
•Reverse Mirrors
•Autolamp Delay•Oil Change
•Language
•Rear Park Assist
(in reverse)
•AWD locked
(if equipped)
2004aviatorQUICK REFERENCE GUIDE
4Service Engine Soon
This light will illuminate briefly when you start your vehicle to ensure
that the engine warning system is functional. If it comes on after the
engine is started, one of your engine’s emission control systems
may be malfunctioning. Or, it may stay on because your vehicle is out
of fuel, existing fuel quality is poor, or the fuel cap hasn’t been
properly tightened. If you have added high quality fuel or tightened
the fuel cap and the light continues to stay on, remember that it can
take three driving cycles for the light to turn off. (A driving cycle
consists of a cold engine startup followed by mixed city/highway
driving.) No additional vehicle service would be required.
25678910111234
1
21271_AviatorQRG 7/9/03 6:48 PM Page 7
