This light comes on every time you turn the
ignition to the ON or START position (engine
offl. The light should go off when the engine
starts and the alternator begins to charge.
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
Turn Signal Indicator Lights
When you push the turn signal lever up before
making a right turn, the right side arrow on the
instrument panel flashes.
When you push the turn signal lever down
before making a left turn, the left side arrow on
the instrument panel flashes.
Usually, the turn signals turn off automatically
after you turn your car. If the turn signal
continues to flash after you have made the turn,
push the lever back to the OFF position.
56If one or both of your turn indicators do not flash
or stay on continuously, have them serviced as
soon as possible. In the meantime, be sure to use
the accepted hand signals.
Service Engine Soon Warning Light
The Powertrain On-Board Diagnostic 11
(OBD 11) system consists of the hardware
and software necessary to monitor the
operation of the powertrain. The OBD 11
system is designed to check the function
of the vehicle's powertrain control system
during normal operation. If an emission
problem is detected, the Service Engine
Soon light (in the cluster) is turned on.

Alternator mounting brace stud jumper cable
The engine with jumper cables
202 Booster battery

Fuse
LocationMaxi-Fuse
Amp
RatingDescriptionFuse
LocationMaxi-Fuse
Amp RatingDescription1
2
340A
60A
60A· EATC blower motor
· Engine cooling fans
· Air suspension compressor relay1330A
· DSM
· Heated seats
· Driver 4-way power
lumbar seats460A
· ABS module
· EVAC and fill14 30A
· Passenger power seat
· Passenger 4-way power560A
· Fuse panel to LCM
· OBD 111530A
· Luxury radio
· Sub woofer amplifier
· CD player660A
· Fuse panel to LCM CD player1620A
· HI beam730A
· VDM1720A
· Horn840A
· Heated mirrors
· Heated backlight1810A
· Air bags940A
· DDM
· LH power windows
· Door locks19Not used1040A
· RH power windows2010A
· PCM KAPWR1140A
· Ignition switch to fuse panel2110A
· Alternator sensor
· Alternator field supply1240A
· Ignition switch to fuse panel
