hood release LINCOLN CONTINENTAL 1996 Customer Assistance Guide
[x] Cancel search | Manufacturer: LINCOLN, Model Year: 1996, Model line: CONTINENTAL, Model: LINCOLN CONTINENTAL 1996Pages: 320, PDF Size: 1.8 MB
Page 73 of 320
Light
Instrument panel
70ClusterHood release handleRear window def roster/heated
Page 236 of 320
3.Block the wheels. This will prevent your
vehicle from moving unexpectedly.
Working with the engine on:
1. Set the parking brake fully and make sure that
the gearshift is securely latched in P (Park).
2.Block the wheels. This will prevent your
vehicle from moving unexpectedly./! WARNINGDo not start your engine with the aircleaner removed and do not remove it whilethe engine is running./! WARNINGThe cooling fan is automatic and may comeon at any time. Always disconnect thenegative terminal of the battery beforeworking near the fan.234If the battery is disconnected' the computer must
releam its idle control. See Battery in the Index.
NOTE: The engine compartment light may be
switched on or off at the light assembly. The light
assembly is located on the hood on the driver's side.
To turn the light on, pull the switch toward you; to
turn it off, push it away from you. The switch may
remain in the on position at all times, as the light will
turn off when the hood is closed.
Opening the Hood
1. Inside the vehicle, pull the hood release handle
located under the bottom left comer of the
instrument panel.
Page 237 of 320
The hood release under the instrument panel2.Go to the front of the vehicle and release the
auxiliary latch that is located under the hood at the
center of the vehicle.
Auxiliary hood releaseThe auxiliary latch under the front edge of the
hood
3.Lift the hood until the lift cylinders hold it open.
235
Page 239 of 320
Engine coolant reservoir Power steering fluid reservoir Windshield washer fluid reservoir Engine oil filler cap Hood safety release High current fuse box Engine oil
dipstick Air filterEngine compartment service points
237
Page 281 of 320
1.Make sure that the headlamp switch is in the
OFF position.
2.Lift the hood and remove the plastic sight
shield covering the back of the headlamps by
lifting up on the rear corners to release the
velcro attachments. Lift the shield and pull
towards the windshield.
3.At the back of the headlamp, pull up on the
two right angle brackets to release the
headlamp assembly from the vehicle.
4.Carefully pull the headlamp assembly away
from the vehicle to expose the back of the
bulb and wiring connector.
5.Remove the electrical connector from the bulb
by grasping the wire with a quick pull
rearward.6.Remove the retaining ring by turning it 1/8 of
a turn to free it from the socket. Then slide
the ring off the plastic base of the bad bulb.
Keep the ring. You must use it again to hold
the new bulb in place.
7.Carefully remove the bulb assembly from its
socket by gently pulling it rearward without
turning.
Installing the headlamp bulb
1.With the flat side of the bulb's plastic base
facing upward, insert the glass end of the bulb
into the socket. You may need to turn the
bulb left or right to line up the grooves in the
plastic base with the tabs in the socket. When
the grooves are aligned, push the bulb into the
socket until the plastic base contacts the rear
of the socket.
279
Page 299 of 320
Turn signals Windshield wiper Fuse panel Hood release Parking brake Gearshift- Automatic transmission Seats Speed control Head restraints301
Page 304 of 320
Engine coolant reservoir Power steering fluid reservoir Windshield washer fluid reservoir Automatic transaxlefluid dipstick Brake master cylinderEngine oil filler cap Hood safety release Engine oil dipstick High current fuse box Battery
306
Page 312 of 320
Headlamps (continued).................................I.............................
cleaning...............................................83Idle.............................................................
daytime running lights..........................81relearning.........................................253
flashing................................................90speed.................................................45
high beam............................................90Ignition......................................................
replacing bulbs...................................277chime.................................................42
turning on and off................................82positions of the ignition......................41
warning chime.....................................58removing the key...............................42
Head restraints.......................................114Infant seats (see Safety seats).................27
Heated mirrors.......................................127Instrument panel, location of components .70
Heating........................................................Interval wipers........................................91
electronic automatic temperature...............................................................................
control system...................................71J.............................
High beams, indicator light.......................58Jack, operation.....................................207
Hood............................................................Jump-starting your vehicle..........................
latch location...............................234,235attaching cables................................201
lubrication specifications....................289disconnecting cables.........................203
release lever.......................................234K...............................
working under the hood.....................233Keyless entry system...................................
Horn........................................................93locking and unlocking doors............102
....................................................................programming entry code..................103
314
Page 320 of 320
Service Station InformationEngine4.6 Liter 4 Valve SFI (Sequential Fuel Injection) 8 Cylinder
FuelPREMIUM FUEL ONLY- Octane 91 or higher
Fuel Tank Capacity17.8 gallons (68.1 Liters)
Tire SizeRefer to the Tire Pressure Decal
Tire PressureFront- 30 PSI, Rear- 28 PSI (measured cold)- Tire pressure decal on the front
face of the passenger’s door jamb.
Hood ReleasePull handle under left side of dash.
Engine OilUse only engine oil displaying the American Petroleum Institute Certification
Mark- 5W30 preferred
Engine Oil Capacity6.0 quarts (5.7 Liters).
Automatic
TransmissionMotorcraft MERCONÒ (ATF),
Transaxle Capacity13.7 quarts (13.0 Liters).
Power Steering FluidUse only power steering fluid that meets Ford Specification Motorcraft
MERCONÒ ATF
Engine Coolant
Capacity14.25 quarts (13.5 Liters).
322
