Page 3 of 320
Table of ContentsINTRODUCTORY INFORMATIONSAFETY RESTRAINTS
STARTING YOUR CONTINENTALWARNING LIGHTS AND GAUGESINSTRUMENT PANEL CONTROLS
STEERING COLUMN CONTROLSFEATURESELECTRONIC SOUND SYSTEMS1
9
41
51
69
89
99
159
i
Page 13 of 320
Safety RestraintsImportant Safety Belt Information
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
Safety belts provide best restraint when: the seatback is upright the occupant is sitting upright (not slouched) the lap belt is snug and low on the hips the shoulder belt is snug against the chest the knees are straight forward
To help you remember to fasten your safety belt, a
warning light may come on and a chime may sound.
See Safety Belt Warning Light and Chime in the
Warning Lights and Gauges chapter.See the following sections in this chapter for
directions on how to properly use these safety belts.
Also see Safety Restraints for Children in this
chapter for special instructions about using safety
belts for children./! WARNINGMake sure that you and your passengers wearsafety belts. Always drive and ride with yourseatback upright and the lap belt snug and lowacross the hips.9
Page 45 of 320
OFF allows you to shut off the engine and all
accessories without locking the steering wheel, or the
gearshift lever.
ON allows You to test your vehicle's warning lights
(except the brake system warning light) to make sure
they work before you start the engine. The key returns
to the ON position once the engine is started and
remains in this position while the
engine runs.
START cranks the engine. Release the key once the
engine starts so that you do not damage the starter. The
key should return to ON when You release it. The
START position also allows You to test the Brake
Warning Light.
42Removing the Key From the Ignition
1.Put the gearshift in P (Park)-
2.Set the parking brake fully.
3.Turn the ignition key to LOCK.
4.Remove the key.
If the key is stuck in the LOCK position, move the
steering wheel left or right until the key turns freely.
If the driver's door is open while the key is still in the
ignition, a warning chime sounds./! WARNINGAlways set the parking brake fully andmake sure that the gearshift is securelylatched in P (Park).
Page 47 of 320
3.Make sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
Before you start your vehicle, you should test the
warning lights on the instrument panel to make sure that
they work. Refer to the Warning Lights and Gauges
chapter.
Starting Your Engine
To start your engine:
1.Follow the steps under Preparing to Start Your
Vehicle at the beginning of this section.
2.Turn the ignition key to the ON position.
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the accelerator
while the vehicle is parked.
444. Turn the key to the START position (cranking)
until the engine starts. Allow the key to return to
the ON position after the engine has started.
If you have difficulty in turning the key, rotate the
steering wheel slightly because it may be binding.
For a cold engine: At temperatures 10° °F (-12° °C) and below: If the
engine does not start in fifteen (15) seconds on the
first try, turn the key to OFF, wait approximately
ten (10) seconds so you do not flood the engine,
then try again. At temperatures above 10° °F (-12° °C): If the
engine does not start in five (5) seconds on the
first try, turn the key to OFF, wait approximately
ten (10) seconds so you do not flood the engine,
then try again.
Page 51 of 320
The left side of the trunk/! WARNINGIf you see or smell fuel, do not reset theswitch or try to start your vehicle. Haveall the passengers get out of the vehicleand call the local fire department or atowing service.48If your engine cranks but does not start after a
collision or substantial jolt:
1 . Turn the ignition key to the OFF position.
2.Check under the vehicle for leaking fuel.
3.if you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
4.Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
5.Check under the vehicle again for leaking
fuel. If you see or smell fuel, do not start
your vehicle again. If you do not see or
smell fuel, you can try to start your vehicle
again.
6. Check all vehicle warning lights before
driving the vehicle.
Page 54 of 320
Warning Lights and GaugesInstrument cluster
51
Page 55 of 320
The following warning lights and gauges are on
the instrument cluster. AD of the warning
lights and gauges alert you to possible
problems with your vehicle.
Indicator Lights and Chimes
Safety Belt Warning Light and Chime
This warning light and chime remind you to
fasten your safety belt. The following
conditions will take place: If the safety belt is not buckled when the
ignition is turned to the ON position, the
chime will turn on for four (4) to eight (8)
seconds and the light will come on for one
to two minutes. If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime will turn off.
52 If the safety belt is buckled before the
ignition is turned to the ON position,
neither the light nor the chime will come
on.Brake System Waming Light
The warning light for the brakes can show two
things - that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level
is low, the brake system should be checked by
your dealer or a qualified service technician.
Page 59 of 320
This light comes on every time you turn the
ignition to the ON or START position (engine
offl. The light should go off when the engine
starts and the alternator begins to charge.
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
Turn Signal Indicator Lights
When you push the turn signal lever up before
making a right turn, the right side arrow on the
instrument panel flashes.
When you push the turn signal lever down
before making a left turn, the left side arrow on
the instrument panel flashes.
Usually, the turn signals turn off automatically
after you turn your car. If the turn signal
continues to flash after you have made the turn,
push the lever back to the OFF position.
56If one or both of your turn indicators do not flash
or stay on continuously, have them serviced as
soon as possible. In the meantime, be sure to use
the accepted hand signals.
Service Engine Soon Warning Light
The Powertrain On-Board Diagnostic 11
(OBD 11) system consists of the hardware
and software necessary to monitor the
operation of the powertrain. The OBD 11
system is designed to check the function
of the vehicle's powertrain control system
during normal operation. If an emission
problem is detected, the Service Engine
Soon light (in the cluster) is turned on.
Page 61 of 320
condition occurring. A warm up cycle consists
of engine start from a cold condition (engine at
ambient temperature) and running until the
engine reaches normal operating temperature.
On the fourth engine start up, the Service
Engine Soon light will turn off as soon as the
engine begins to crank. It is not necessary to
have the engine serviced.
Under certain conditions, the Service Engine
Soon Light may come on if the fuel cap is not
properly installed. If the Service Engine Soon
Light comes on and you suspect that the fuel
cap is not properly installed, pull off the road as
soon as it is safely possible and turn off the
engine. Remove and replace the cap, making
sure it is properly seated.
After completing the three consecutive warm
up cycles and on the fourth engine start up, the
Service Engine Soon Warning Light should
turn off. If the light does not go off after the
fourth engine re-start, have your vehicle
serviced by your dealer or a qualified
technician.
58High Beam LightThis light comes on when the headlamps are turned
to high beam or when you flash the lights.
Chime for Headlamps On
This chime sounds if the driver or any passenger
door is open when the parking lamps or headlamps
are on. The chime sounds until you close the door,
turn off the lamps or turn the ignition to the ON
position.
Page 63 of 320
The Instrument Cluster
In addition to warning lights, the instrument
cluster has a message center/odometer, a
speedometer, tachometer, fuel and coolant
temperature gauges.
The Electronic Message Center (M/C)
The Electronic Message Center only works
when the ignition is in the ON position.
Each time the WC is powered the display goes
through a self test by displaying the PLEASE
FASTEN SEATBELT message. This self test
is used to stabilize the systems before reporting
the status to you.
60The message center tells you about the
condition of your vehicle by two methods: operator selectable features continuous warning reporting of
monitored systems
You can select different features for the M/C to
display by using the message center control
buttons located to the right of the instrument
cluster. You will hear a tone when you press one
of these buttons. However, if the M/C detects a
warning from any of the monitored systems, then
the M/C will display the appropriate warning
message.
