oil dipstick LINCOLN MARK VIII 1997 Owners Manual

33
DRIVER'S DOOR AJARÐ This warning message
is displayed when the driver's door is not
completely closed and the ignition switch is either
ON or in ACC mode.
RIGHT DOOR AJARÐ This warning message is
displayed when the right (passenger side) door is
not completely closed and the ignition switch is
either ON or in ACC mode.
CHECK ENGINE TEMPÐ This warning message
is displayed when the engine coolant is overheating.
Stop the vehicle as soon as safely possible, turn off
the engine and let it cool. Check the coolant and
level, and add coolant as required following the
instructions in theMaintenance and Carechapter.
If you do not follow these instructions, you or
others could be injured. If this warning stays on or
continues to come on, contact your dealer for
service as soon as safely possible.LOW OIL LEVELÐ This warning message is
displayed when your engine oil level is low. If this
warning message is displayed, check the level of the
engine oil.
To check your oil:
1. Park your vehicle on level ground, turn off the
engine and wait at least 5 minutes for the oil
to drain back into the oil pan.
2. Use the dipstick to check the oil. If the level is
low, add oil, but do not overfill.
If you are parked on a steep incline, the LOW OIL
LEVEL warning may come on when you start your
vehicle, even though the oil is at the correct level.
The oil level is monitored while the engine is off,
so that the oil can drain into the oil pan to be
measured. Some after-market devices such as
remote starters, if improperly installed, can cause
File:03fnis8.ex
Update:Thu Jun 27 10:00:37 1996

223
Checking and Adding Engine OilSince the proper amount of engine oil is important
for safe engine operation, check the oil using the
dipstick each time you put fuel in your vehicle.
Remember the engine must be off, the oil must be
warm and the vehicle must be parked on level
ground.
Checking the engine oil level:
1. Turn the engine off after it has warmed up and
allow a few minutes for the engine oil to drain
back into the oil pan.
2. Set the parking brake, making sure the gearshift
is securely latched in P (Park).
3. Open the hood. Protect yourself from engine
heat.
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the engine.5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
Engine oil dipstick
6. Carefully, pull the dipstick out again and read
it. If the oil level is below the MIN line, add a
half quart of engine oil as necessary. If the oil
level is above the MAX line, engine damage or
high oil consumption may occur and some oil
must be removed from the engine.
7. Put the dipstick back in and make sure it is
fully seated.
File:11fnmc8.ex
Update:Thu Jun 20 14:28:32 1996

299
Climate control system
air conditioning........... 69
electronic automatic temperature
control.............. 69
heating............... 69
Clock................. 82
Clutch
fluid reservoir............ 225
specifications............ 265
Combination lap and shoulder belts.... 138
Console, description.......... 115
Controls, mirrors............ 99
Convenience kit in cargo area...... 202
Coolant (see Engine coolant)....... 228
checking and adding......... 228
preparing for storage......... 267
refill capacities............ 264specifications............ 265
temperature gauge.......... 17
warnings.............. 228
Cooling fan.............. 217
Crankcase emission filter........ 263
Cruise control indicator light....... 13
Customer Assistance Centre,
Ford of Canada............ 276
D
Daytime running light system...... 78
Defects, reporting............ 269
Dipstick................ 223
automatic transmission fluid...... 234
engine oil.............. 223
power steering fluid......... 233
Disabled vehicle (see Towing)...... 213
Dispute Settlement Board........ 272
Doors................. 106
lubricant specifications........ 265
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996

301
proper solution........... 235
recovery reservoir.......... 228
refill capacities............ 264
specifications............ 265
temperature gauge.......... 17
Engine coolant temperature gauge..... 17
Engine fan............... 217
Engine knocking............ 246
Engine oil............... 222
ªbreak-inº oils............. 5
changing oil and oil filter....... 224
checking and adding......... 223
check oil warning light........ 11
dipstick............... 223
disposal............... 216engine oil pressure warning light.... 11
filter, specifications.......... 263
refill capacities............ 264
specifications.........222, 265
synthetic oil............. 222
viscosity.............. 222
Exhaust fumes............. 169
Extended Service Plan, Ford........ 4
F
Fan.................. 217
engine fan, avoiding injury...... 217
Flashers, hazard............ 89
Flashing the lights........... 86
Flat tire................ 201
Fluid refill capacities.......... 264
Ford Dispute Settlement Board...... 272
Ford Extended Service Plan........ 4
Ford Motor Company of Canada..... 276
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996

307
O
Octane rating............. 246
Odometer............... 16
Oil filter............224, 263
Oil (see Engine oil)........... 222
Oil viscosity.............. 222
On-board diagnostic (OBD II) system . . . 253
Overdrive............... 181
Overseas offices............ 278
P
Panic alarm feature, remote entry system . 123
Parking brake, warning light....... 10
Parking brake and auto-release...... 10
Parts (see Motorcraft Parts)....... 263
PCV valve, specifications........ 263
Phone, cellular............. 114
Power features
antenna............... 65
doors................ 106
mirrors............... 99
moon roof.............. 97seats................ 134
windows.............. 108
Power steering
dipstick............... 233
driving with power steering...... 177
fluid, checking and adding....... 233
fluid, refill capacity.......... 264
fluid, specifications.......... 265
servicing.............. 177
Prop rod, hood............. 219
R
Radio (see Electronic sound systems) . . . 49
Rear axle
lubricant specification......... 265
refill capacity............ 264
Rear window defroster......... 77
Rearview mirror............ 99
Redundant electronic gearshift indicator . . 15
Refill capacities for fluids........ 264
Regulations, National Highway Traffic Safety
Administration............ 269
File:fnix8.ex
Update:Thu Jun 27 10:02:38 1996
