LINCOLN NAVIGATOR 2009 Scheduled Maintenance Guide

Batteries
The technicians at your Ford or Lincoln Mercury dealership can determine the health of your vehicle’s
battery during any service visit. The Motorcraft Tested Tough Max Series with its “long-life” design
outlasted other long-life batteries by up to 200%. That’s one reason why we stand behind this battery with
a national, 3-year, free replacement warranty and prorated-cost replacement thereafter for up to
100 months and unlimited mileage. Should your battery need to be replaced, please consider a Motorcraft
brand battery that meets your vehicle’s Ford Motor Company specifications.
Brakes
Your Ford or Lincoln Mercury Dealership has the right brake parts for your vehicle and their factory-trained
technicians know exactly how to install them. Ford Original Equipment and Motorcraft replacement
brake pads, shoes, rotors and drums meet the stringent standards of Ford Motor Company engineers, and
they’re also Federal Motor Vehicle Safety Standard (FMVSS) compliant. In addition, all Ford Original
Equipment replacement brake pads, shoes, rotors, and drums are vehicle tested for durability and noise
suppression. The right brake parts and installation are essential to proper brake system operation.
KEEPITGENUINE
Scheduled Maintenance11
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Keep It Genuine

Oil & Lubricants
It is important to follow a regular maintenance schedule for changing your vehicle’s oil and lubricants.
Motorcraft Oils and Lubricants meet the stringent standards set by Ford Motor Company. Motorcraft Oils are
formulated to reduce engine friction, improve fuel economy, and protect against deposits and wear. The
American Petroleum Industry certifies them, so you know Motorcraft oil stands up to the tests of both Ford
and independent engineers.
Collision
An accident is an upsetting experience and collision repair is often complicated and confusing. Here are a
few pointers to help you better understand the collision repair process and make sure your vehicle is
properly repaired with the right parts. Properly repairing your vehicle will help maintain its value.
Your rights as a consumer
As a consumer, you are within your rights to insist on original equipment replacement parts. These genuine
parts are made by the manufacturer to meet stringent criteria for fit, finish, structural integrity,
corrosion protection and dent resistance, just like the parts that were originally on your vehicle. Insist on
genuine Ford replacement parts.
The collision shop
Many Ford and Lincoln Mercury Dealerships offer collision repair services. Ask your selling dealership about
their capabilities to help with collision repair.
KEEPITGENUINE
12Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

Parts
Genuine Ford Collision Parts are designed, engineered, and warranted by Ford Motor Company. See your
dealer for limited warranty details. They are manufactured to the same specifications as those on your vehicle
when it was built. The right replacement parts will help maintain the value of your vehicle.
Ford recommended scheduled maintenance – In order to keep your vehicle running right, it is important to
have the systems on your vehicle checked regularly. This can help identify potential issues and prevent
major problems. Ford Motor Company recommends the following multi-point inspection be performed at every
scheduled maintenance interval to help ensure your vehicle keeps running great.
MULTI-POINT INSPECTION - Recommended at every visit
❑Check and top up fluid levels: brake, coolant recovery reservoir, manual and automatic transmission (if equipped
with an underhood dipstick), power steering and window washer
❑Inspect tires for wear and check air pressure, including spare.
❑Check exhaust system for leaks, damage, loose parts and foreign material.
❑Check battery performance.
❑Check operation of horn, exterior lamps, turn signals and hazard warning lights.
❑Check radiator, coolers, heater and air conditioning hoses.
❑Inspect windshield washer spray and wiper operation.
❑Check windshield for cracks, chips and pitting.
❑Inspect for oil and fluid leaks.
❑Inspect engine air filter.
❑Inspect half shaft dust boots, if equipped.
❑Check shocks and struts and other suspension components for leaks and damage.
❑Inspect steering and linkage.
❑Inspect accessory drive belt(s).
❑Inspect clutch operation, if equipped.
MULTI-POINTINSPECTION
Scheduled Maintenance13
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Keep It Genuine

Be sure to ask your Ford or Lincoln Mercury Dealership Service Advisor or Technician about the multi-point
vehicle inspection. It’s a comprehensive way to perform a thorough inspection of your vehicle. It’s
your checklist that gives you immediate feedback on the overall condition of your vehicle. You’ll know
what’s been checked, what’s okay, as well as those things that may require future or immediate attention.
The multi-point vehicle inspection is one more way to keep your vehicle running great!
MULTI-POINTINSPECTION
14Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

7,500 miles
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
15,000 miles
❑Change engine oil and replace oil filter❑Replace cabin air filter (if equipped)❑Inspect steering linkage, ball joints, suspension,
tie rod ends, driveshaft, and U-joints (lubricate if
equipped with Zerk fittings)
❑Inspect engine cooling system and hoses❑Inspect brake pads, shoes, rotors, drums, brake
lines and hoses and parking brake system.
❑Inspect half shaft boots (if equipped)❑Inspect exhaust system and heat shields❑Inspect automatic transmission fluid level (if
equipped with an underhood dipstick)
❑Inspect and lubricate 4x4 front axle U-joints❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
Scheduled Maintenance15
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Normal Schedule
Trucks, Fullsize
Vans & SUVs

Tires
When your tires need to be replaced, consider visiting your Ford or Lincoln Mercury dealership for
name-brand tires and people who know your vehicle. And if your Ford or Lincoln Mercury dealership sells
the name-brand tire, they can also honor the tire manufacturer’s warranty.
22,500 miles
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
16Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

30,000 miles
❑Change engine oil and replace oil filter❑Inspect automatic transmission/transaxle fluid
level on vehicles if equipped with dipstick.
Consult your dealer for particular requirements.
❑Replace cabin air filter (if equipped)❑Replace climate-controlled seat filter (if equipped)❑Replace engine air filter❑Replace fuel filter (except Escape, Mariner,
F-Series [non Super Duty],
Expedition/Navigator [short wheel base only],
E-Series)
❑Inspect steering linkage, ball joints, suspension,
tie rod ends, driveshaft, and U-joints (lubricate if
equipped with Zerk fittings)
❑Inspect engine cooling system and hoses❑Inspect brake pads, shoes, rotors, drums, brake
lines and hoses and parking brake system.
❑Inspect half shaft boots (if equipped)❑Inspect exhaust system and heat shields❑Inspect and lubricate 4x4 front axle U-joints❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
37,500 miles
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
Scheduled Maintenance17
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Normal Schedule
Trucks, Fullsize
Vans & SUVs

Oil & Lubricants
It is important to stick to a regular maintenance schedule for changing your vehicle’s oil and lubricants.
Motorcraft Oils and Lubricants meet the stringent standards set by Ford Motor Company. Motorcraft Oils are
formulated to reduce engine friction, improve fuel economy, and protect against deposits and wear. The
American Petroleum Industry certifies them, so you know Motorcraft oil stands up to the tests of both Ford
and independent engineers.
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
18Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

Batteries
The technicians at your Ford and Lincoln Mercury dealership can determine the health of your vehicle’s
battery during any service visit. The Motorcraft Tested Tough Max Series with its “long-life” design outlasted
other long-life batteries by up to 200%. That’s one reason why we stand behind this battery with a
national 3 year, free-replacement and prorated-cost thereafter up to 100 months with unlimited mileage.
Should your battery need to be replaced, consider any one of the batteries that bear the Motorcraft name.
45,000 miles
❑Change engine oil and replace oil filter❑Replace cabin air filter (if equipped)❑Inspect steering linkage, ball joints, suspension,
tie rod ends, driveshaft, and U-joints (lubricate if
equipped with Zerk fittings)
❑Inspect engine cooling system and hoses❑Inspect brake pads, shoes, rotors, drums, brake
lines and hoses and parking brake system.
❑Inspect half shaft boots (if equipped)❑Inspect exhaust system and heat shields❑Inspect automatic transmission fluid level (if
equipped with an underhood dipstick)
❑Inspect and lubricate 4x4 front axle U-joints❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
Scheduled Maintenance19
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Normal Schedule
Trucks, Fullsize
Vans & SUVs

52,500 miles
❑Change engine oil and replace oil filter❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
60,000 miles
❑Change engine oil and replace oil filter❑Change automatic transmission fluid on all
vehicles equipped with the TorqShift
transmission. Consult your dealer for your
particular requirements.
❑Replace cabin air filter (if equipped)❑Replace climate-controlled seat filter (if equipped)❑Replace engine air filter❑Replace fuel filter (except Escape, Mariner,
F-Series [non Super Duty],
Expedition/Navigator [short wheel base only],
E-Series)
❑Replace wheel bearing grease and grease seals
on 4x2 front wheel bearings (if non-sealed
bearings)
❑Inspect steering linkage, ball joints, suspension,
tie rod ends, driveshaft, and U-joints (lubricate if
equipped with Zerk fittings)
❑Inspect engine cooling system and hoses❑Inspect brake pads, shoes, rotors, drums, brake
lines and hoses and parking brake system.
❑Inspect half shaft boots (if equipped)❑Inspect exhaust system and heat shields❑Inspect and lubricate 4x4 front axle U-joints❑Rotate tires, inspect tires for wear and measure
tread depth (vehicles with dual rear wheels
should only rotate if unusual wear is noted)
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULETRUCKS,FULLSIZEVANS& SUVS
