LINCOLN NAVIGATOR 2009 Scheduled Maintenance Guide

150,000 miles
❑Change engine oil and replace oil filter❑Change Motorcraft Premium Gold Engine Coolant
(see Exceptions on page 47 and Premium Gold
Coolant Change Record on page 48)
❑Change automatic transmission fluid❑Replace automatic transmission fluid filter (except
6F50, AWF-21 and FNR5 transaxles)
❑Change manual transmission fluid❑Replace rear axle lubricant on all rear wheel
drive (RWD) vehicles (see pages 42 and
47).
❑Replace climate-controlled seat filter (if equipped)❑Replace engine air filter (except Focus with
PZEV engine)
❑Replace cabin air filter (if equipped)❑Replace fuel filter (Crown Victoria, Grand
Marquis, Town Car and Mustang)
❑Replace drive belt(s) if not replaced in the last
100,000 miles (160,000 km)
❑Inspect and lubricate steering linkage, ball joints,
suspension, tie rod ends, driveshaft and U-joints
(lubricate if equipped with Zerk fittings)
❑Inspect engine cooling system and hoses❑Inspect brake pads, shoes, rotors, drums, brake
lines and hoses and parking brake system.
❑Inspect half shaft boots (if equipped)❑Inspect exhaust system and heat shields❑Rotate tires, inspect tires for wear and measure
tread depth
❑Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
❑Perform multi-point inspection (recommended)
DEALERVALIDATION:
RO#: P&A C
ODE:
D
ATE:MILEAGE:
NORMALSCHEDULECARS& CUVS
Scheduled Maintenance41
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Normal Schedule
Cars & CUVs

Items Needing Special Attention
If you operate your Ford/Lincoln/Mercuryprimarilyin one of the more demandingSpecial Operating
Conditionslisted below, you will need to have some items maintained more frequently. If you only
occasionallyoperate your vehicle under these conditions, it is not necessary to perform the additional
maintenance. For specific recommendations, see your Ford or Lincoln Mercury Dealership Service
Advisor or Technician.
Towing a trailer or using a camper or car-top carrier
Every 5,000 milesRotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
Inspect and lubricate U-joints
Every 30,000 milesChange automatic transmission/transaxle fluid (not
required on 6R60/6R75/TorqShift transmissions)
Replace wheel bearing grease and grease seals on
4x2 front wheel bearings (if non-sealed bearings)
Every 60,000 milesChange transfer case fluid
Change manual transmission fluid
As requiredInspect and lubricate U-joints
See Rear Axle Towing under
Exceptions.
SPECIALOPERATINGCONDITIONS
42Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

Extensive idling and/or low-speed driving for long distances as in
heavy commercial use such as delivery, taxi, patrol car or livery
Every 5,000 milesInspect brake system
Rotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Lubricate control arm and steering ball joints (if
equipped with zerk fittings)
Every 5,000 miles or 6 monthsInspect and lubricate U-joints
Every 5,000 miles, 6 months or
200 hours of engine operationChange engine oil and replace oil filter
Every 15,000 milesReplace fuel filter (Crown Vic, Grand Marquis, Town
Car, Mustang, Ranger, F-Super Duty, Expedition EL
and Navigator EL)
Every 30,000 milesChange automatic transmission/transaxle fluid (not
required on 6R60/6R75/TorqShift transmissions)
Replace wheel bearing grease and grease seals on
4x2 front wheel bearings (if non-sealed bearings)
Every 60,000 milesReplace spark plugs
Change transfer case fluid
As requiredReplace cabin air filter
SPECIALOPERATINGCONDITIONS
Scheduled Maintenance43
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Special Operating
Conditions &
Exceptions

Operating in dusty conditions such as unpaved or dusty roads
Every 5,000 milesRotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
Inspect and lubricate U-joints
Every 15,000 milesReplace fuel filter (Crown Vic, Grand Marquis, Town
Car, Mustang, Ranger, F-Super Duty, Expedition EL
and Navigator EL)
Every 30,000 milesChange automatic transmission/transaxle fluid (not
required on 6R60/6R75/TorqShift transmissions)
Replace wheel bearing grease and grease seals on
4x2 front wheel bearings (if non-sealed bearings)
Every 50,000 milesChange manual transmission fluid
Change rear axle lubricant (E–450 and F–450/550
only)
Every 60,000 milesChange transfer case fluid
As requiredReplace engine air filter
Replace cabin air filter (if equipped)
SPECIALOPERATINGCONDITIONS
44Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

Off-road operation
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
Rotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 30,000 milesChange automatic transmission/transaxle fluid (not
required on 6R60/6R75/TorqShift transmissions)
Replace wheel bearing grease and grease seals on
4x2 front wheel bearings (if non-sealed bearings)
Every 50,000 milesChange manual transmission fluid
Change rear axle lubricant (E–450 and F–450/550
only)
Every 60,000 milesChange transfer case fluid
As requiredReplace cabin air filter (if equipped)
Inspect and lubricate steering linkage ball joints and
U-joints (if equipped with zerk fittings)
Use of E85 50% of the time or greater (flex fuel vehicles only)
Every 5,000 milesRotate tires, inspect tires for wear and measure tread
depth
Inspect the wheels and related components for
abnormal noise, wear, looseness, or drag
Every 3,000 milesFill fuel tank with a full tank of regular unleaded fuel
Every 5,000 miles or 6 monthsChange engine oil and replace oil filter
SPECIALOPERATINGCONDITIONS
Scheduled Maintenance45
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Special Operating
Conditions &
Exceptions

Special Operating Conditions Log
DEALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:D
EALERVALIDATION:
RO#: P&A C
ODE:
DATE:MILEAGE:
SPECIALOPERATINGCONDITIONS
46Scheduled Maintenance
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)

In addition, there are several exceptions to the Normal Schedule. They are listed below:
Normal Vehicle Axle Maintenance
❑Rear axles and power take off (PTO) units containing synthetic lubricant and light duty trucks equipped with
Ford-design axles are lubricated for life. These lubricants are not to be checked or changed unless a leak is suspected,
service is required or the axle assembly has been submerged in water. The axle and PTO lubricant should be
changed anytime the axle and PTO have been submerged in water. During extended trailer tow operation above 70°F
ambient and wide open throttle for extended periods above 45 mph, non-synthetic rear axle lubricants
should be replaced every 3,000 miles or 3 months, whichever occurs first. The 3,000 mile lube change interval
may be waived if the axle was filled with 75W140 synthetic gear lubricant meeting Ford specification
WSL-M2C192-A, part number F1TZ-19580-B or equivalent. Add friction modifier C8AZ-19B546-A (EST-M2C118-A)
or equivalent for complete refill of Traction-Lok rear axles (see
Owner’s Guidefor quantity). The axle
lubricant should be changed anytime an axle has been submerged in water.
Police/Taxi/Livery Vehicle Axle Maintenance
❑Replace rear axle lubricant every 100,000 miles. Rear axle lubricant change may be waived if the axle was
filled with 75W140 synthetic gear lubricant meeting Ford specification WSL-M2C192-A, part number FITZ-19580-B
or equivalent. Add four ounces of additive friction modifier C8AZ-19B546-A (EST-M2C118-A) or equivalent for
complete refill of Traction-Lok rear axles. The axle lubricant should be changed anytime the axle has been submerged
in water.
E–450 and F–450/550 Axle Maintenance
❑Replace rear axle lubricant every 100,000 miles under normal driving conditions on all E–450 and
F–450/550 applications. For E–450 and F–450/550 vehicles operated at or near maximum Gross Vehicle
Weights, the rear axle lubricant should be replaced every 50,000 miles. In addition, this 50,000 mile schedule
should be observed when the vehicles are operated under the Special Operating Conditions, where noted, on
page 42.
California Fuel Filter Replacement
❑If vehicle is registered in California, the California Air Resources Board has determined that the failure to
perform this maintenance item will not nullify the emission warranty or limit recall liability prior to the completion
of the vehicle’s useful life. Ford Motor Company, however, urges you to have all recommended maintenance
services performed at the specified intervals and to record all vehicle service.
Class A Motorhome
❑Every two years - Change brake fluid❑Every 60,000 miles - Change automatic transmission fluid
EXCEPTIONS
Scheduled Maintenance47
2009 Scheduled Maintenance Guide(smg)
Scheduled Maintenance Guide
USA(fus)
Special Operating
Conditions &
Exceptions

Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
Current mileage goes here =>
Add 45,000 miles to the current miles + 45,000
Next change due at this mileage =>
Or
Today’s date goes here =>
Add 3 years + 00 / 00 / 03
Date of next change =>
whichever comes firstDealer Stamp
P & A CODE
R.O.#
PREMIUMGOLDCOOLANTCHANGERECORD
