LINCOLN NAVIGATOR 2012 Rear Seat Entertainment System Supplement Manual
Manufacturer: LINCOLN, Model Year: 2012, Model line: NAVIGATOR, Model: LINCOLN NAVIGATOR 2012Pages: 32, PDF Size: 3.87 MB
Page 21 of 32
21Playing an Audio CD
EN
Playing an Audio CD
When playing an audio CD, the DISPLAY ban-
ner appears automatically. It displays the cur-
rent track and the amount of time the track has
been playing, the total amount of time on the
disc and the current time running on the disc.
Press the DISPLAY button on the remote con-
trol to display the DISPLAY banner.
The options below show you what happens
when you press the DISPLAY button.
Press DISPLAY (1x)
“Single Elapsed” appears along with the
current track playing and the time of that
track.
Press DISPLAY (2x)
“Single Remain” appears along with the
current track playing and the amount of time
left.
Press DISPLAY (3x)
“Total Elapsed” appears along with the current
track playing and the total time playing on CD.
Press DISPLAY (4x)
“Total Remain” appears along with the current
track playing and the amount of time left on CD. Using the REPEAT Feature
The default mode for the
REPEAT feature is
OFF. Pressing REPEAT button on the remote
control consecutively changes the REPEAT
options as follows:
- repeat the track that is playing.
- repeat the disc that is playing.
As you toggle through the options, the REPEAT
option changes. The track repeats once that
track has ended. The selected repeat option
loops repeatedly until you turn it of.
Page 22 of 32
22Playing a MP3 Disc
EN
Playing a MP3 Disc
MP3 is a format for storing digital audio. An
audio CD-quality song can be compressed into
the MP3 format with very little loss of quality,
while taking up much less space. CD-R discs
that have been encoded in MP3 format can be
played on your DVD player.
Selecting Folders and Songs
When an MP3 disc is inserted in the player, the
navigation screen appears automatically. You
can change folders and songs by navigating
the fle system. The DVD player plays the songs
in the order they were burned to the disc.
1. If a disc is playing, press the DISPLAY
button on the remote control, and then
press the UP or DOWN arrow buttons to
go through the folder list on the left side
of the navigation screen.
2. Once the folder you want is highlighted,
press the ENTER button on the remote
control
3. Press the UP or DOWN arrow button on
the remote control to go through the
song list and highlight the song you
want. Press the ENTER button to begin
the playback of the highlighted song. Skipping Songs
Use the
(NEXT ) button on the remote
control to move to the next song. Use the
(PREV ) button to move to the beginning of
the currently playing song. Press the (PREV )
button 2 times to move to the previous song.
Selecting a Play Mode
You can choose what order the songs will play
on a disc temporarily. The FOLDER play mode
is the default. To access the play mode opera-
tions, press the REPEAT button on the remote
control. The play mode options are as follows:
Single: Play a selected song.
Repeat One: Repeat the song that is playing.
Folder: Play the folder in the order the songs
were recorded.
Folder Repeat: Repeat the folder that is playing.
Random: Play the songs in the random order.
Shufe: Play the songs in random order (with-
in the selected folder).
Page 23 of 32
23Connecting a USB Device
You can connect a USB mass storage device
such as a USB memory stick, digital audio
player (USB mass storage class device) etc. to
the USB port of the REV LT unit.
The REV LT unit can play many popular formats
stored in a USB device, including but not
limited to the following fle types: JPEG, JPG,
M2V, MP3, MPE, MPEG Formats (MPEG-1,
MPEG-2, MGEP-4), MPG, OGG, WMA and MWV.
Turn on the REV LT unit to watch the playback
picture if you playback a fle. You can also con-
trol playback by refering to the REV LT unit
screen.
Order of Tracks
The Rev LT unit plays the fles in the order that
they were written to the USB drive. Therefore,
the playing order may not be the same as the
order shown on your device or as expected.
To access the fle structure/menus, for the USB
device, you will need the remote control, set to
the appropriate systems (A or B).
Upon insertion, the USB device may begin
playing fles automatically, returning to the
previous position, if it was unplugged during
a previous playback. To return to the menus,
press MENU or LEFT ARROW, depending on
the type of fle being played. The current
directory will appear, listing all fle types. Controls:
MENU – Return to the menu structure.
UP / DOWN – Moves the select bar up/down
within the selected menu/fle list.
LEFT – Moves menu up one level / Returns to
the menu structure for some functions.
RIGHT – Selects menu item.
ENTER – Makes a selection or begins playback
of fles.
PLAY – Press this button to play fle
STOP – Stops playing the movie/song
PAUSE – While item is playing, press this but-
ton to temporarily stop the playback
FR (Fast Rewind) – Press to move backwards
(2x, 4x, 8x, 16x, 32x) within a fle.
FF (Fast Forward) – Press to move forwards (2x,
4x, 8x, 16x, 32x) within a fle.
PREV – Moves to previous fle.
NEXT – Moves to next fle.
Sample of Root Directory:
File Structure:
Music Playback: Screen will display: Folder
Location, Elapsed Time, and if available: Song
Title, Artist, and Album.
EN
Connecting a USB Device
Page 24 of 32
24Connecting a MP3 Device
Connecting a MP3 Device
Connecting a MP3 Device to your REV LT
Unit via USB
Plug the MP3 Dock Connector to USB cable
into a high-power USB port on your REV LT
unit, and then connect the other end to the
player.
See the documentation that came with your
device for more information.
Charging the MP3 Player Battery
Connect the device to the USB port on your
REV LT unit. The REV LT unit must be turned on.
Depending on the device, it may or may not
charge when connected to the USB port.
Note: Not all devices are able to charge when
connected to the USB port.
Connecting a MP3 Device to your
REV LT Unit via AV cable
t Connect the device using an AV cable to
the headphones port . Note: Use the AV
cable made specifcally for the device.
Other similar RCA-type cables might not
work.
t Connect the video and audio connectors
to the AV-IN ports on your REV LT unit, as
shown. EN
