LINCOLN TOWN CAR 1998 Workshop Manual

The memory seat positions are also
recalled when you press your
remote entry transmitter UNLOCK
control.
To program the memory seat to
remote entry transmitter, refer to
Remote entry systemin the
Controls and features chapter.
CENTER CONSOLE
Your vehicle may be equipped with
a variety of console features. These
include:
²cassette storage
²coin holder slots
²cellular phone (if equipped)
Use only soft cups in the
cupholder. Hard objects
can injure you in a collision.
Auxiliary power point
The auxiliary power point is
located on the instrument panel.
This outlet should be used in place
of the cigarette lighter for optional
electrical accessories.
Controls and features
52

POSITIVE RETENTION FLOOR
MAT
Position the floor mat so that the
eyelet is over the pointed end of
the retention post and rotate
forward to lock in. Make sure that
the mat does not interfere with the
operation of the accelerator or the
brake pedal. To remove the floor
mat, reverse the installation
procedure.
REMOTE ENTRY SYSTEM
The remote entry system allows
you to lock or unlock all vehicle
doors without a key.
The remote entry features only
operate with the ignition in the
OFF position.
Unlocking the doors
Press this control to unlock the
driver door. The interior lamps will
illuminate.
Press the control a second time
within five seconds to unlock all
doors.
Controls and features
53

Locking the doors
Press this control to lock all doors.
The horn will chirp and the
parklamps/taillamps will flash to
confirm that the control was
pressed. This feature can be
turned on/off through the following
procedure:
You must complete steps 1-5
within 30 seconds or the
procedure will have to be
repeated. If procedure needs to be
repeated, you must wait 30
seconds.
1. Turn ignition key to ON.
2. Press power door unlock control
3 times.
3. Turn ignition key from ON to
OFF.
4. Press power door unlock control
3 times.
5. Turn ignition key back to ON.
The doors will lock and unlock.
6. Press unlock control twice
within 5 seconds. The horn will
chirp twice upon successful
toggling of the horn chirp feature.
7. Turn ignition to OFF.
Controls and features
54

Opening the trunk
Press the control once to open the
trunk.
Be certain the trunk is closed
before driving your vehicle. The
trunk may appear closed, but it
may not be latched. Failure to do
so may cause objects to fall out of
the trunk or block rear view vision.
Sounding a panic alarm
Press this control to activate the
alarm.
To deactivate the alarm, press the
control again or turn the ignition
to ACC or ON.
This device complies with part 15
of the FCC rules and with RS-210
of Industry Canada. Operation is
subject to the following two
conditions: (1) This device may
not cause harmful interference,
and (2) This device must accept
any interference received,
including interference that may
cause undesired operation.
Changes or modifications not
expressly approved by the
party responsible for
compliance could void the
user's authority to operate the
equipment.
Replacing the batteries
The transmitter is powered by one
coin type three-volt lithium battery
CR2032 or equivalent. Typical
Controls and features
55

operating range will allow you to
be up to 10 meters (33 feet) away
from your vehicle. A decrease in
operating range can be caused by:
²battery weakness due to time
and use
²weather conditions
²nearby radio towers
²structures around the vehicle
²other vehicles parked next to
the vehicle
To replace the battery:
1. Twist a thin coin between the
two halves of the transmitter near
the key ring. DO NOT TAKE THE
FRONT PART OF THE
TRANSMITTER APART.
2. Place the positive (+) side of
new battery in the same
orientation. Refer to the diagram
inside the transmitter unit.
3. Snap the two halves back
together.
Replacing lost transmitters
Take all your vehicle's transmitters
to your dealer for reprogramming
if:
²a transmitter is lost or
²you want to purchase additional
transmitters (up to four may be
programmed).
To reprogram the transmitters,
place the key in the ignition and
switch from OFF to ON four times
in rapid succession within 3
seconds. After doors lock/unlock,
Controls and features
56

press any button on all
transmitters (up to four). When
completed, switch the ignition to
OFF.
All transmitters must be
programmed at the same time.
Illuminated entry
The interior lamps illuminate when
the remote entry system is used to
unlock the door(s) or sound the
personal alarm.
The system automatically turns off
after 25 seconds or when the
ignition is turned to the START or
ACC position. The dome lamp
switch (if equipped) mustnotbe
set to the OFF position for the
illuminated entry system to
operate.
The inside lights will not turn off
if:
²they have been turned on with
the dimmer control or
²any door is open.
Battery saver will shut off the
interior lamps 30 minutes after the
last door is closed.
Autolock
The autolock feature will lock all of
the doors when:
²all vehicle doors are fully closed
²the ignition key is turned to the
ON position
²the vehicle is in a forward gear
and
Controls and features
57

²you exceed 5 km/h (3 mph).
The autolock feature repeats when:
²the ignition key remains in the
ON position
²a door is opened and then
closed
²the vehicle is in a forward gear,
and
²you exceed 5 km/h (3 mph).
Autolock can also be activated or
deactivated using the following
procedure:
You must complete steps 1 through
5 within 30 seconds or the
procedure will have to be
repeated. If the procedure needs
to be repeated, you must wait 30
seconds.
1. Turn the ignition key to ON.
2. Press the power door unlock
control three times.
3. Turn the ignition key from ON
to OFF.
4. Press the power door unlock
control three times.
5. Turn the ignition key back to
ON. The doors will lock and
unlock.
6. Press the power door unlock
switch. The horn will chirp once
upon successful toggling of the
Autolock feature.
7. Turn ignition to OFF. The horn
will chirp to confirm procedure is
complete.
Controls and features
58

Memory seat/mirrors feature
(if equipped)
The remote keyless entry system
can also control the memory
seats/mirrors feature. With this
feature, the first two programmed
transmitters will recall a different
memory position.
Press the control once to unlock
the driver's door and move the
memory features to the
corresponding memory position,
just as if you had pressed the
memory control in the vehicle.
²transmitter #1 will recall
memory feature position one.
²transmitter #2 will recall
memory feature position two.
²If a third or fourth transmitter is
added, it will not recall a
memory position.
Memory seat positions can be
changed at any time. Transmitter
#1 will always move the memory
features to position #1.
Reactivating the memory
seat/mirrors feature
The remote memory seat/mirrors
feature comes disabled from the
factory. The following sequence
will reactivate the transmitter:
1. Press the SET control.
2. Press any button on the remote
entry transmitter.
3. Within five seconds, press
control one or two.
SET
12
Controls and features
59

Deactivating the memory
seat/mirrors feature
1. Press the SET control.
2. Press any button on the remote
entry transmitter.
3. Within five seconds, press the
SET control again.
Manually moving any seat or
mirror during these steps will
cancel the programming
procedure.
SECURILOCKYANTI-THEFT
SYSTEM
The SecuriLockyanti-theft system
provides an advanced level of
vehicle theft protection. Your
vehicle's engine can only be started
with the two special SecuriLocky
electronically coded keys provided
with your vehicle. Each time you
start your vehicle, the
SecuriLockykey is read by the
SecuriLockyanti-theft system. If
the SecuriLockykey identification
code matches the code stored in
the SecuriLockyanti-theft system,
the vehicle's engine is allowed to
start. If the SecuriLockykey
identification code does not match
the code stored in the system or if
a SecuriLockykey is not detected
(vehicle theft situation), the
vehicle's engine will not operate.
Spare SecuriLockykeys can be
purchased from your dealership
and programmed to your
SecuriLockyanti-theft system.
Refer toProgramming spareSET
12
Controls and features
60

SecuriLockykeysfor more
information.
If one or both of your SecuriLocky
keys are lost or stolen and you
want to ensure the lost or stolen
key will not operate your vehicle,
bring your vehicle and all available
SecuriLockykeys to your
dealership for reinitialization.
Theft indicator
The theft indicator on top of the
instrument panel will operate as
follows:
²When the ignition is OFF, the
theft indicator will flash briefly
every 2 seconds to indicate the
SecuriLockysystem is
protecting your vehicle.
²When the ignition is turned to
RUN or START, the theft
indicator will light for 3 seconds
and then go out. If the theft
indicator stays on for an
extended period of time or
flashes rapidly, have the system
serviced by your dealership or a
qualified technician.
Programming spare
SecuriLockYkeys
Spare SecuriLockykeys can be
purchased from your dealership
and programmed to your
SecuriLockyanti-theft system (up
to a total of 8 keys). Your
dealership can program your new
SecuriLockykey(s) to your
vehicle or you can do it yourself
using the following simple
Controls and features
61
