LOTUS ELISE 2005 Owner's Manual

To use the belt, sit erect and fully back in the seat before
taking the buckle tongue in the outer hand, and drawing the belt through the top slide, pass the belt across the body and
push the tongue into the buckle lock at the inboard side of the
seat, until a positive ‘click’ is heard. Pull on the belt to check for correct latching and ensure that the belt fits snugly against the body with all the slack taken up by the reel. The belt should be
worn low across the front of the pelvis, and across the chest and shoulder. The belts are released by pressing the red button on the
buckle lock, and will retract automatically for tidy storage and
to permit easy access to the passenger compartment.
Seat Belt Precautions
WARNING:
• Be sure you and your passenger always wear seat belts and wear them properly. Not wearing a seat belt

correctly, increases the chance of serious injury or death
in a crash, even with airbags.
• On fastening the seat belt, ensure that no part of the belt is twisted, or is entangled in the door or seat

mechanism.
• Seat belts are designed to bear upon the bone structure
of the body and should be worn low across the front of
the pelvis, and across the chest and shoulder. Wearing
the lap section of the belt across the abdominal area must be avoided.
• Improperly positioning the seat belts can cause serious injury or death in a crash. Ensure the seat belts are

correctly positioned before driving.
• Pregnant women should always wear seat belts to protect
both themselves and the unborn child. The lap belt por
-
tion of the belt should be kept as low as possible across the hips. Consult your doctor regularly to check if you
should drive.
• The shoulder portion of the belt must never be worn beneath the arm, or behind the back.
• Each seat belt assembly is designed for use by one

occupant of adult build, and should not be used by

children unable to meet the requirements set forth
herein.
Seating & Safety Restraints
19

oh_croft_InD.indd 1920/05/2004 07:58:43ProCarManuals.com

WARNING:
• Lotus strongly recommends that you do not carry children
as passengers in your Elise.
• Because the Elise is fitted with a non-switchable pas
-
senger airbag, a rear facing child seat must never be
used.
• Never use one belt around two people, or allow a child to be carried on a driver’s or passenger’s lap.
• Refer to Child Restraints section of handbook.
WARNING:
• No modifications or additions should be made to the inertia reel assemblies or seat belts. Do not attempt to
adjust the seat belt tension by altering the mechanism.
• The seat belt should be replaced if webbing becomes frayed, contaminated, or damaged. Inspect regularly.
• It is essential to replace the entire seat belt assembly
if it has been used in a severe impact, even if damage
to the assembly is not obvious. In situations where the airbags have been deployed, the belt tensioner systems must also be replaced. Seat belt anchorage points must
also be rigorously checked.
• Not checking or maintaining seat belts can result in serious injury or death if the seat belts do not work

properly when needed. Check the belts regularly and have any problem corrected immediately.
• No one should sit in a seat with an in-operative seat belt.
Care should be taken to avoid contamination of the webbing
with polishes, oils or chemicals and particularly battery acid. Use
only a mild detergent to clean the webbing, never use bleach or
dye, and allow the belt to dry fully before using the car. Ensure
that the buckle mechanism is kept free of dirt contamination as disassembly for cleaning is not possible.Seating & Safety Restraints
20

oh_croft_InD.indd 2020/05/2004 07:58:44ProCarManuals.com

Airbag Safety SystemYour car has airbags. One airbag for the driver, and
another for the passenger.
The car is also equipped with shoulder and lap belts. Airbags
are supplementary restraints to the seat belts. In the event of a moderate to severe frontal collision, airbags
provide occupant protection additional to that provided by the lap
and diagonal seat belts. Both driver and passenger must wear
the seat belts at all times, whether or not an air bag is provided, in order to minimise the risk of severe injury or death, no matter how short the journey. An occupant who is properly restrained by a seat belt, will be in the best position for full effectiveness
of the airbag in the event of airbag deployment. The airbag system is designed to inflate when the car is
involved in a frontal, or near frontal collision, and the force of
impact is sufficient to warrant additional occupant protection.
The driver's airbag is housed in the centre of the steering wheel, and that for the passenger in the dashboard. When triggered by
an electronic crash sensor, each air bag inflates in a fraction of
a second to provide protection for the occupant’s upper body,
and then deflates very rapidly to minimise any obstruction to
the driver. Some parts of the system are designed to operate only once,
and need replacing after air bag inflation with new components, before being ready for another deployment.
Remember that the seat belts, when correctly worn, provide
Seating & Safety Restraints
21
w53b
AIRBAG INFLATED
ON IMPACT

oh_croft_InD.indd 2120/05/2004 07:58:44ProCarManuals.com

the primary crash protection to the occupants, especially in collisions below the actuation threshold of the airbag system, and during types of accident which do not cause airbag deploy
-
ment. Therefore, both driver and passenger must always wear
seat belts (in most states, and all Canadian provinces, the law
requires the use of seat belts). See the earlier pages on ‘Seat
Belts’.
WARNING:
• You can be killed or seriously injured in a crash if you aren’t wearing your seat belt - even with airbags. Wearing
your seat belt during a crash helps reduce your chance of hitting things inside the car or being ejected from it.
Airbags are designed to work with seat belts, but don’t replace them. Airbags are designed to deploy only in
moderate to severe frontal and near frontal crashes.
They aren’t designed to inflate at all in rollover, rear or low-speed frontal crashes, or in many types of side im
-
pacts. Both driver and passenger should wear a seat belt properly to minimise the risk of severe injury or death in
the event of a crash.
• Airbags inflate with great force, in a fraction of a second. If you’re too close to an inflating airbag, as you would
be if you were leaning forward, you could be killed or seriously injured. Seat belts help keep you in the correct
position before and during a crash. Always wear your seat
Seating & Safety Restraints
22
w53b
AIRBAG DEFLATED
AFTER DEPLOYMENT

oh_croft_InD.indd 2220/05/2004 07:58:44ProCarManuals.com

belt, even with airbags. Sit as far back from the steering
wheel as is comfortable, whilst ensuring that full control can be maintained.
• Airbags plus lap-shoulder seat belts offer the best protection for adults, but not for young children and

infants. Neither the car ’s seat belt system nor its

airbag system is designed for them. Young children and

infants need the protection that a child restraint system can

provide. See later section on ‘Child Restraints’.
• If an object is between a person and an airbag, the bag
might not inflate properly or it might force the object into
that person causing death or serious injury. The path of an inflating airbag must be kept clear. Don’t put anything between an occupant and an airbag, and don’t attach or
put anything on the steering wheel hub or on or near any
passenger dashboard air bag covering.
• Do not lean against the inside of the doors; always hold the steering wheel by the outer rim; never rest your hands
on the airbag panel.
• Never transport heavy objects on or in front of the pas
-
senger seat.
• Give your passenger all of the information in this sec
-
tion.
• Do not attempt to de-activate the airbags, or make any other changes to the wiring or components of the airbag
system. Do not undertake any wiring for electrical ac
-
cessory equipment in the vicinity of the airbag wiring harnesses. Doing so may disable the airbag system, or
cause its unintended deployment.
• Adjust the driver’s seat to ensure that your chest is at
least 10 inches (250mm) from the steering wheel.
• If the airbag trim cover on the passenger side of the dash
-
board is accidently knocked off, the passenger airbag will
not operate correctly. Improper protection could result
in death or serious injury to a passenger in a crash. Do
not attempt to refit or repair the trim cover, but have the
fault rectified immediately by your dealer.
Airbag Tell Tale There is an airbag warning light (‘tell tale’) on the instrument
panel which shows the airbag symbol. The system checks the
following airbag electrical circuits for malfunction:
Seating & Safety Restraints
23

oh_croft_InD.indd 2320/05/2004 07:58:45ProCarManuals.com

• Drivers airbag circuit;
• Passenger airbag circuit;
• Seatbelts pre-tensioner circuit;
• Internal componentry of the sensor and diagnostic module.
As a bulb and circuit check, the tell tale will light briefly when
the ignition is switched on, and then go out. If the lamp lights at any other time, a fault in the airbag system is indicated, which
should be rectified without delay by your Lotus dealer.
WARNING: If the airbag tell tale does not light up as the ignition is
turned on, or remains lit for more than a few seconds, have
the fault rectified immediately by your dealer. Ignoring the
tell tale can result in serious injury or death if the airbags do not inflate when needed.
Airbag Deployment If a crash or collision causes the airbags to inflate, you may
see what looks like smoke, but is actually powder from the airbag
surface used to aid smooth deployment. Although the powder is not harmful, people with respiratory problems may experience
some temporary discomfort. If this occurs, get out of the car if possible as soon as it is safe to do so. After airbag deployment, the airbags, seat belt tensioners
and electronic control unit must be replaced by a Lotus dealer
or other suitably qualified organisation. Component parts of the airbag system are located in various
sites around the car. Any technician working on the car should be advised that the car is fitted with airbags to allow suitable
precautions to be taken.
WARNING:
• For up to 20 seconds after the ignition has been turned off and the battery disconnected, an airbag can still

inflate if improper servicing occurs. You can be injured
if you are close to an airbag when it inflates.
• Airbag system components should be serviced only by an authorised Lotus dealer. Do not work on the airbag
system yourself.
• The disposal of used airbag units is subject to stringent
Seating & Safety Restraints
24

oh_croft_InD.indd 2420/05/2004 07:58:45ProCarManuals.com

regulations, and should be handled only by your dealer.
• If you sell your Lotus, notify the purchaser that the car is equipped with airbags, and refer them to ‘Airbag Safety
System’ in this handbook (safety and disposal rules).
• Further information on the airbag system can be found
on stickers on the sun visors.
• For important recommendations on the use of child restraints, please refer to ‘Child Restraints’ in this hand
-
book. Never use a rear facing child seat in your Elise.
• A crash can damage the restraint systems in your car. A damaged restraint system may not properly protect the
person using it, resulting in serious injury or even death
in a crash. To help make sure your restraint systems are
working properly after a crash, have them inspected and
any necessary replacements made as soon as possible.
Seating & Safety Restraints
25

oh_croft_InD.indd 2520/05/2004 07:58:45ProCarManuals.com

Child Restraints
WARNING:
Lotus strongly recommends that children are not car
-
ried in the Elise due to the risk of death or serious injury if the child is too close to the dashboard when the airbag
inflates.

Accident statistics show that children are safer when properly
restrained in the back seats of cars, an option unavailable on
this model. In addition, your car is equipped with a passenger’s airbag which poses serious risks to children - particularly infants
and small children. If, nevertheless, a child is to be carried in the
car, the following notes are provided for guidance:
When a child is of a physical size whereby the standard
fitment lap and diagonal seat belt will fit satisfactorily, with the belt positioned over the collar bone and against the centre of
the chest, the standard seat and seat belt should be used. If the
belt touches or crosses the child’s neck, the child should NOT
be carried in the Elise.
WARNING:
• Children should not be carried in the Elise unless they are large enough to be able properly to use the standard
seat belt without any child seat or booster seat.
• Child restraint systems (other than belt positioning booster seats) are designed to be secured in the car seat
by the lap belt portion of the lap/shoulder belt. READ
ALL INSTRUCTIONS THAT ACCOMPANY THE CHILD RESTRAINT OR BOOSTER SEAT.
• I n f a n t s w h o a r e u n a b l e t o s i t u p b y t h e m s e l v e s ,

unsupported, should NOT be carried in the Elise.
• Never put a rear-facing child seat in the passenger seat
of the Elise. If the airbag inflates, it can hit the child or
the back of the child seat with enough force to kill or very seriously injure an infant.
• There is no provision on the Elise to switch off or disable
the passenger airbag.
WARNING: Children who are not properly restrained can be killed
or seriously injured in an accident.
Seating & Safety Restraints
26

oh_croft_InD.indd 2620/05/2004 07:58:45ProCarManuals.com

Behaviour: It is essential that the behaviour of any child trav-
elling in the car is such that they remain correctly seated and belted, and it is the responsibility of the driver to ensure that
this occurs.
The following wording has been included to comply with
National Highway Traffic Safety Authority requirements,
however;
WARNING: Lotus str ongly recommen ds that you do not fit any type
of child seat into the Elise due to the risk of death or seri
-
ous injury if the c hild is too close to the dashboard when
the airbag inflates.
Procedure for Proper Fitment of For ward- Facing Child
Seat
A utomatic Locking Retractor: The safety belt for the passen-
ger’s seat is equipped with an automatic locking retractor that
must be used for securing a forward-facing child restraint sy
s-
tem. When activated , this retractor allows you to securely fas
-
ten the child restraint system.
Activating the Automatic Retracto r:
1. Pull the passenger seat safety belt completely
out . At this
point, the locking mechanism is activated.
2.
P lace the forward-facing child seat in the passenger seat,
using the safety belt to secure the child seat,
fo llowing the
instructions that come with the child seat
.
3. Insert the safety tongu e into the buckle and make sure that
it is properl y latched.
4. Allow the safety belt to retract until it is tight on the child seat.
You may further tighten the belt by pulling on it to allow more of
it to retract. Check to make sure the child seat is secured, and
that the belt is snug and will not pull out.
Releasing the safety bel t and child seat:
1. Unbuckle the safety belt. 2. Remove the child seat.
3. Make sure that the belt has fully retracted. At this point the
automatic locking feature is disengaged.
Seating & Safety Restraints
27

oh_croft_InD.indd 2720/05/2004 07:58:46ProCarManuals.com

Seating & Safety Restraints
28

oh_croft_InD.indd 2820/05/2004 07:58:46ProCarManuals.com
