technical data LUCID AIR 2022 Owners Manual

Floor Mats 166Parts and Accessories 167
Parts, Accessories, and Modifications167
Body Repairs 167
Vehicle Lifting Points 168
Lifting the Vehicle 168Tire & WheelsTire Information 170
Understanding Tire Markings 170 International Tire Approval Marks 173
Uniform Tire Quality Grading 173
Tire and Loading Information Label 174
Tire Care and Maintenance 176
Inspecting and Maintaining Tires 176
Maintaining Tire Pressures 177
Replacing Tires and Wheels 179
Seasonal Tire Types 179 Driving in Low Temperatures 180
Tire Traction Devices 180
Tire Pressure Monitoring System 181 Tire Pressure Monitoring System (TPMS) 181
Vehicle Loading 183
Loading the Vehicle 183
Steps for Determining Correct Load Limit 183Technical DataVehicle Dimensions and Weights 186
Exterior Dimensions 186
Vehicle Weights 187
Wheels and Tires 188
Wheel and Tire Specifications 188
Tire Pressures 189
Vehicle Sub-Systems 190
Steering 190
Brakes 191
Front Suspension 192
Rear Suspension 193
Motors 194
Transmission 194
12V Batteries 194
High-Voltage Battery 194

11
Technical Data
Technical Data185

Vehicle WeightsCurb Weight* (19"/ 21")5203 lbs (2360 kg) / 5236 lbs (2375 kg)Gross Vehicle Weight Rating (GVWR)6283 lbs (2850 kg)Gross Axle Weight Rating (GAWR) - Front3153 lbs (1430 kg)Gross Axle Weight Rating (GAWR) - Rear3197 lbs (1450 kg)Trailer towingNot permissible
*Curb Weight = Weight of vehicle with correct fluid levels, no occupants, and no cargo
Technical Data187

Vehicle Sub-Systems
SteeringTypeRack and pinion with electronic power steering and speed sensitive assist.Number of turns lock to lock2.3 turnsTurning circle (curb to curb)39 ft (11.9 m)Technical Data190

MotorsFrontPermanent Magnet AC MotorRearPermanent Magnet AC Motor
Transmission
Drive Ratio7.06:1 single speed
12V Batteries
TypeDeep CycleQuantity2Rating18 AhVoltage and polarity12V Negative (-) ground
High-Voltage Battery
TypeLithium ion (Li-ion)CoolingLiquid-cooledTechnical Data194
