MASERATI LEVANTE 2019 Owners Manual

Allowed tires size Levante TROFEO Levante GTS
Light alloy rims 20" x 9J (front)
20” x 10,5J (rear)
- Front tires (Standard tire)
- Rear tires (Standard tire)
- Front tires - All season 265/45 R20 104W
- Rear tires - All season 295/40 R20 106W
Light alloy rims 21” x 9J (front)
21” x 10,5J (rear) 21” x 9J (front)
21” x 10,5J (rear)
- Front tires (Standard tire) 265/40 R21 101Y
- Rear tires (Standard tire) 295/35 R21 103Y
- Front tires - All season 265/40 R21 105W 265/45 R21 105W
- Rear tires - All season 295/35 R21 107W 295/35 R21 107W
Light alloy rims 22” x 9J (front)
22” x 10,5J (rear) 22” x 9J (front)
22” x 10,5J (rear)
- Front tires 265/35 R22 265/35 R22
- Rear tires 295/30 R22 295/30 R22
- Front tires - All season 265/35 R22 265/35 R22
- Rear tires - All season 295/30 R22 295/30 R22Features and Specifications
8
417

Performance NOTE:
The specifications described can change without prior notification.
Levante TROFEO Levante GTS Levante S Levante
Maximum speed 190 mph (305 km/h) 183 mph (294 km/h) 164 mph (264 km/h) 156 mph (251 km/h)
Accelerations from 0 to
60 mph 3.8 seconds 4.1 seconds 5.0 seconds 5.8 seconds
(*) Values obtained with 94 AKI (98 RON) unleaded gasoline.
Weights NOTE:
The specifications described can change without prior notification.
Levante TROFEO - GTS Levante S - Levante
Unladen vehicle weight with tank and reservoirs
filled, tools and accessories (*) 5070 lb / 2300 kg
(2624 lb / 1190 kg front axle -
2447 lb / 1110 kg rear axle) 4994 lb / 2265 kg
(2540 lb/1152 kg front axle -
2454 lb/1113 kg rear axle)
Approved Gross Vehicle Weight Rating (GVWR) 6228 lb / 2825 kg
(2932 lb / 1330 kg front axle -
3296 lb / 1495 kg rear axle) 6116 lb / 2780 kg
(2827 lb/1285 kg front axle -
3289 lb/1495 kg rear axle)
Maximum load on the roof rails 176 lb / 80 kg
(*) Base configuration without options.Features and Specifications
8
418

Trailer Towing Weights
NOTE:
• On the TROFEO version you can not install the trailer tongue.
• Follow trailer manufacturer recommendations, never exceed trailer tow weights provided.
Towable loads: trailer with brakes 5952 lb/2700 kg (GTS: 3306 lb/1500 kg)
Towable loads: trailer without brakes 1500 lb (680 kg )
Maximum load on tow hitch 474 lb (215 kg)
Dimensions Wheel base 118.2 in (3004 mm )
Overall length 197 in (5003 mm)
Overall width without mirrors 77.5 in (1968 mm)
Overall width with mirrors 85 in (2158 mm)
Front track 63.9 in (1624 mm)
Rear track 65.9 in (1676 mm)
Front overhang 38 in (966 mm)
Rear overhang 40.6 in (1033 mm)
Overall height (*) 66.1 in (1679 mm)
Ground clearance (*) 8 in (205 mm)
Trunk compartment volume 14.9 cu.ft. (422 l )
Cargo area length 41 in (1040 mm)
Cargo area length with rear seatbacks folded down 79.8-71 in (2027-1803 mm)
Cargo area width 46.7-39.5 in (1186-1002 mm)
(*) In “Normal” ride height and with standard rims and tires. Features and Specifications
8
419

Tire Inflation Pressure Cold tire inflation pressure value under the following loading conditions listed in the table below:
• PLC (Partial Loading Condition): considering 2 passengers + luggage.
• FLC (Full Loading Condition): considering 4 or 5 passengers + luggage.
• CC (Comfort Condition) : not more than 80 mph (130 km/h).
NOTE:
• For more information about the pressure check methods, see “Tires – General Information” in section “Driving”.
• Tire inflation pressure values are also indicated on the information label applied to the driver's side rear door pillar.
WARNING!
• Improperly inflated tires are dangerous.
• Under-inflation increases tire flexing and can result in tire overheating and failure.
• Over-inflation reduces a tire's ability to cushion shock. Objects on the road and potholes can cause damage that results
in tire failure.
• Over-inflated or under-inflated tires can affect vehicle handling and can fail suddenly, resulting in loss of vehicle control.
• Unequal tire pressures can cause steering problems.
• Unequal tire pressures from one side of the vehicle to the other can cause the vehicle to drift to the right or left.
• Always drive with each tire inflated to the recommended cold tire inflation pressure.Features and Specifications
8
420

Wheel Pressure
Tire Type Rim PLC CC FLC/High speed
Front Rear Front Rear Front Rear
Summer 18” - 19” -
20”
230 kPa -
2.3 bar - 33
psi 250 kPa -
2.5 bar - 36
psi 200 kPa -
2.0 bar - 29
psi 220 kPa -
2.2 bar - 32
psi 250 kPa - 36 psi
(2.5 bar) 270 kPa - 39 psi
(2.7 bar)
21” 270 kPa - 39 psi
(2.7 bar) 310 kPa - 45 psi
(3.1 bar)
22” 320 kPa - 46 psi
(3.2 bar) 340 kPa - 49 psi
(3.4 bar)
All Season 18” 250 kPa - 36 psi
(2.5 bar) 290 kPa - 42 psi
(2.9 bar)
19” 250 kPa - 36 psi
(2.5 bar) (265/50)
290 kPa - 42 psi
(2.9 bar)
(295/45)
270 kPa - 39 psi
(2.7 bar)
20” - 21” 270 kPa - 39 psi
(2.7 bar) (265/45)
310 kPa - 45 psi
(3.1 bar)
(295/40)
290 kPa - 42 psi
(2.9 bar)
22” 310 kPa - 45 psi
(3.1 bar) 340 kPa - 49 psi
(3.4 bar)
Spare 18” 350 kPa - 51 psi (3.5 bar) (Max 50 mph - 80 km/h) Features and Specifications
8
421

Features and Specifications
422

9 – Index
423

Abbreviations .................9
Accessories
Aftermarket Parts and Accessories
Statement .................13
Active Blind Spot Assist - ABSA . . . .310
Adaptive Cruise Control (ACC) . . . .286
Activation/Deactivation ...... .289
Display Warnings and
Maintenance ............. .294
Precautions while Driving with
ACC ................... .295
Setting the Following Distance . .291
Setting the Speed .......... .290
Airbag.....................65
Advanced Front Air Bag
Properties .................66
Air Bag Deployment Result .....71
Air Bag Deployment Sensors and
Controls ..................15
Air Bag System Components .....66
Front Air Bag Inflator Units .....70
Passenger Air bag Labels .......20
Supplemental Restraint System
(SRS) .....................65
Supplemental Seat-mounted Side
Air Bags (SAB) ..............68
Supplemental Side Air Bag Inflatable
Curtain (SABIC) ..............68
Transport of persons with
disability ..................72
Air Conditioning (A/C) System . . . .214
A/C Distribution ........... .154
Dual-zone Climate Controls . . . .214 Four-zone Climate Controls . . . .221
Alarm, Vehicle Security ..........27
ALR (Automatic Locking Retractor) . .63
Anti-Lock Braking System (ABS) and
Electronic Brake-force Distribution
(EBD) ................... .274
Assistance ...................11
Assistance, if you need ..........11
ATC (Automatic Temperature
Control) ................. .220
Audio Controls .............. .192
Audio Controls on Central
Console ................. .192
Steering Wheel Audio Controls . .192
Audio, setting .............. .207
Audio System ............... .193
Automatic Transmission
Manual Release of Transmission .360
AUX, USB and SD Memory Card
Ports .................... .135
AWD, All-Wheel Drive ......... .243
BAS (Brake Assist System) ...... .275
Battery ................... .381
Battery Recharge .......... .384
Battery Remote Posts Position. . .358
Maintaining Battery Charge . . . .403
To Disconnect the Battery .... .382
To Reconnect the Battery
..... .383
Blind
Spot Alert ............. .305
Blind
Spot Alert (BSA)
BSA System .............. .305
RCP - Rear Cross Path ........ .308 Bluetooth, Customer settings .... .208
Bodywork Maintenance and Care . .397
Pre-Short Drop Function ..... .400
Protection from Atmospheric
Agents ................. .397
Useful Advice to Keep the Bodywork
in Good Condition ......... .398
Brakes
Brake and Stability Control System
(ESC) ................... .273
Brake Overheating ......... .280
Brake System ............. .273
Manual Release of Parking
Brake .................. .356
Parking Brake ............. .268
Using the Brakes ........... .280
Capacity/Refillings ........... .406
Cargo Area ................ .139
Accessories Compartment .... .142
Cargo Area Extension ....... .143
Installing the Cargo Net ...... .144
Loading with Rear Seatbacks Folded
Down .................. .141
Luggage Fasteners and
Retainers ................ .140
Ski and Snowboard Bag
Compartment ............. .141
Trunk Compartment Cover .... .142
Vehicle Load Carrying Capacity . .139
Child Restraint Systems ..........74
Children too large for Booster
Seats .....................75Index
9 424

Infants and Child Restraints .....74
Installing Child Restraint Systems
using the Vehicle Seat Belt
equipped with ALR ...........76
Lower Anchors and Tether for
Children (LATCH) ............76
Older Children and Child
Restraints .................75
Tips on getting the most out of your
child restraint ..............76
Climate Control ............. .214
Clock, analog .............. .201
Console
Central Console Components ....95
Front Dome Console
Components ...............96
Controls Screen ............. .195
Cruise Control
Cruise Control Adaptive (ACC) . .286
Electronic Cruise Control (CC) . . .282
Cupholders ................ .134
Front Passengers Cupholders . . .134
Rear Passengers Cupholders . . . .135
Dashboard Compartment ...... .210
Dashboard Components .........94
Defroster ...................91
Doors
Child Protection Door Lock
System ...................41
Doors Locking ..............39
Doors Manual Lock ...........39
Front Doors Components ......96 Lock/Unlock Door Flashlight ....34
Power Doors Locking/Unlocking . .40
Rear Doors Components .......97
Soft Door Close System ........41
Unlock Driver Door/All Doors with
Key fob 1st Press ............34
Unlock the Vehicle with Key fob. .33
DPF System
DPF Filter Replacement ...... .377
“Drive Away Inhibit” strategy . . . .272
Drive Mode, controls ......... .244
Setting Ride Height ........ .258
Setting the Drive Mode ...... .245
Driving Conditions ........... .338
Before the Trip ............ .338
Driving at Night ........... .339
Driving in Fog ............ .340
Driving in Snow and Wet Grass . .266
Driving in the Mountains ..... .340
Driving in the Rain ......... .339
Driving on Snow or Ice ...... .340
Safe Driving .............. .339
DRL (Daytime Running Light) . . . .116
EDR (Event Data Recorder) .......73
Electronic Cruise Control .......
.282
Emergency ...................
5
Hazard W arning
Lights ...... .128
In the Event of an Accident . . . .350
Jump Starting ............ .357
Use the Vehicle Tow Hook .... .360
Engine
Engine Coolant Level Check . . . .374 Engine Oil Level Check ...... .377
Hood ....................56
Normal Starting of the Engine . .228
Use of the Engine .......... .281
Entry/Exit, lights on ............30
EPB (Electric Parking Brake) ..... .268
ESC (Electronic Stability Control) . .273
Filters
A/C System Air Filter
Replacement ............. .379
Engine Air Filter Replacement . .379
Forward Collision Warning (FCW) . .297
Fuel
Carbon Monoxide Warning . . . .335
Emergency Fuel Filler Door
Release ................. .338
Emissions Inspection and
Maintenance Programs ...... .369
Fuel Consumption ......... .410
Fuel Filter Service .......... .377
Fuel Requirements ......... .334
Fuel System Warnings ....... .335
Gasoline/Oxygenate Blends . . . .334
Low Fuel Indicator ......... .181
Materials Added to Fuel ..... .335
MMT in Gasoline .......... .335
Reformulated Gasoline ...... .334
Fuses .................... .386
Fuses Position ............ .386
Fuses Replacement ......... .386
Glove Box Lock Feature ....... .211Index
9 425

Handholds and Cloth Hooks . . . .138
Hazard Warning Flashers ....... .350
Head Restraints ...............98
Highway Assist - HAS ......... .313
Hill Descend Control (HDC) ..... .277
HomeLink ................. .150
Security ................. .153
Troubleshooting Tips ........ .153
Using HomeLink ........... .153
Hood
Open and Close the Hood ......56
Hood Operation ..............56
HSA (Hill Start Assist) ......... .276
Identification Labels ............19
Illuminated Entry/Exit ...........30
Immobilizer (Sentry Key) .........26
Indicator Lights/Warning Lights
Air Bag Warning Light .........90
TFT Display: Menus and Settings .165
TFT Display: Warning/Indicator
Lights of Set Modes/Functions. . .178
Warning and Indicator Lights on
Analog Instrument ......... .161
Infotainment System .......... .185
Main Menu Bar on MTC+
Display ................. .187
Manual Controls and Devices . . .186
Personalized the Main Menu Bar.188
Instrument Cluster ........... .160
Interior Components ...........94
Interior Maintenance and Care. . . .400 Interiors Features ............ .133
iPad Holder ................ .139
iPod Connection ............. .136
Jump Start Procedure ......... .358
KeyFob ....................25
Key fob Battery Replacement ....35
Preventing Inadvertent Locking of
key fob RKE Transmitter Inside the
Vehicle ...................43
Replacement ...............27
Requiring and setting Additional
Key Fobs ..................34
Unlock the Vehicle with Key fob . .33
Keys .......................24
Lane Departure Warning (LDW) . . .301
Level Checks ............... .374
Brake Fluid Level Check ...... .375
Engine Coolant Level Check . . . .374
Engine Oil Level Check ....... .374
Fluid Level Check for Coolant
Transmission System ........ .379
Transmission Oil Check ....... .378
Washer/Headlight Fluid, adding .376
Liftgate
Automatic
Opening and Closing
Movement
of the Power Liftgate .51
Liftgate and Hood Ajar
Indicators ................ .180
Power Liftgate Emergency
Release ...................55 Power Liftgate Operation ......50
Unlatch the Liftgate ..........34
Lights .................... .113
Automatic Headlights ....... .115
Automatic Headlights Leveling . .126
Automatic High Beam ....... .120
Bi-Xenon Headlight ......... .117
Bulb Replacement .......... .393
Cargo Lamps ............. .127
Dome Lights .............. .126
DRL, Daytime Running Lights . . .116
Fog Lights ............... .123
Headlight Time Delay ....... .115
Headlight with AFS ......... .117
High Beam and Flashing ..... .124
Interior Lights ............. .125
Light Switch .............. .113
Multifunction Lever ......... .124
SmartBeam System ......... .116
Turn Signals .............. .124
Loading the Vehicle
Loading with Rear Seatbacks
Down .................. .141
Vehicle Load Carrying Capacity . .139
Main- and Submenu .......... .166
Maintenance ..................5
A/C System Maintenance ..... .395
Air Bag System Maintenance ....72
Bodywork Maintenance and
Care ................... .397
Emissions Inspection and
Maintenance Programs ...... .369Index
9 426
