MAZDA CX3 2023 Owners Manual

If the switch is pressed again, the parking sensor becomes operational and the
indicator light turns off.
1. Indicator light
Sound and viewing distance display
Informs the driver of the ap proximate distance from the vehicle to the obstruction
using warning beeps depending on the distance. If multiple obstructions are
detected at the same time, warning beeps are activated according to the distance to
the nearest obstruction.
Front
*､ Rear
Distance between vehicle and ob-
struction Display
Beeper sound
Front Rear Without 360° view
monitor With 360° view
monitor
Approx. 100― 60.0
cm (39.3 ―23.6 in)
Approx.
150― 60.0 cm
(59.0― 23.6 in)
Green
Slow intermittent
sound
When Driving
Pa r k i n g S e n s o r Sys te m
4-234*Some models.
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Distance between vehicle and ob-struction Display
Beeper sound
Front Rear Without 360° view
monitor With 360° view
monitor
Approx.
60.0 ―45.0 cm
(23.6― 17.7 in)
Approx.
60.0― 45.0 cm
(23.6 ―17.7 in)
Yellow
Medium intermit-
tent sound
Approx.
45.0 ―35.0 cm
(17.7― 13.7 in)
Approx.
45.0― 35.0 cm
(17.7 ―13.7 in)
Amber
Fast intermittent
sound
Within approx.
35.0 cm (13.7 in)
Within approx.
35.0 cm (13.7 in)
Red
Continuous sound
When Driving
Pa r k i n g S e n s o r Sys te m
4-235
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Corner
Distance between vehi-cle and obstruction Display
Beeper sound
Without 360° view mon-
itor With 360° view monitor
Approx. 55.0 ―38.0 cm
(21.6― 14.9 in)
Yellow
Medium intermittent
sound
Approx. 38.0 ―25 cm
(14.9 ―9.8 in)
Amber
Fast intermittent
sound
Within approx. 25 cm (9.8 in)
Red
Continuous sound
When Driving
Pa r k i n g S e n s o r Sys te m
4-236
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

NOTE
The detection indicator can be switched between display and non-display and the
buzzer volume can be changed.
Refer to the Settings section in the Mazda Connect Owner's Manual.
(Vehicles with 360° View Monitor)
When the detection indicator is set to “Display”, even with the 360° view monitor
not displayed, if a front sensor or a front corner sensor detects an obstruction, the
360° view monitor switches automatically to display. When an obstruction is no
longer detected, the display switches to the display before the obstruction was
detected.
However, while the 360° view monitor is displayed, it continues to display no
matter if an obstruction is detected or not.
If an obstruction in the same area excluding the close area is detected
continuously for 6 seconds or longer, on ly the warning beeps stop activating.
(Detection is indicated) If the detection area changes to the close side, the
warning beeps resumes. (If the detection area changes to the far side, the warning
beeps remain off)
System Problem Indication
If any of the problems indicated in the
table occurs, the driver is notified of
the problem depending on the type of
system as shown.
Detection Indicator
Solution
Without
360° view monitor With 360°
view mon- itor
Sys-
tem
mal-
func- tion
The system may
have a mal-
function. Have
the vehicle in-
spected at an
Authorized
Mazda Dealer
as soon as pos-
sible.
The driver is notified of a problem
with the following indications.
Indicator/Beep How to check
A message indi-
cating a system
malfunction or
sensor malfunc-
tion is displayed. There may be a problem
with the system. Have your
vehicle inspected by an Au-
thorized Mazda Dealer as
soon as possible.
A message indi-
cating that the
sensor is dirty is
displayed. Remove any foreign matter
from the sensor area. If the
system does not recover,
have the vehicle inspected
by an Authorized Mazda
Dealer.
A certain ob-
struction detec-
tion indication is
continuously dis-
played. Foreign matter may have
gotten on the sensor area
corresponding to the detec-
tion indicator. If the system
does not recover, have the
vehicle inspected by an Au-
thorized Mazda Dealer.
When Driving
Pa r k i n g S e n s o r Sys te m
4-237
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

MEMO
4-238
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

5Interior Features
Use of various features for ride comfort, including air-
conditioning system and audio system.
Climate Control System............. 5-2 Operating Tips....................... 5-2
Vent Operation......................5-3
Manual Type..........................5-6
Fully Automatic Type............ 5-10
Mazda Connect...................... 5-15 What is Mazda Connect ?.....5-15
Mazda Connect Basic
Operations.......................... 5-19
Connected Service (If
applicable).......................... 5-37
Interior Equipment.................. 5-39Sunvisors............................. 5-39
Interior Lights...................... 5-40
Accessory Socket................. 5-42
Cup Holder......................... 5-43
Bottle Holder.......................5-44
Assist Grips......................... 5-45
Rear Coat Hooks................. 5-45
Storage Compartments........ 5-46
5-1
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Operating Tips
▼Operating Tips
Operate the climate control system
with the engine running.
To prevent the battery from being
discharged, do not leave the fan
control switch on for a long period of
time with the ignition switched ON
when the engine is not running.
Clear all obstructions such as leaves,
snow and ice from the hood and the
air inlet in the cowl grille to improve
the system efficiency.
Use the climate control system to
defog the windows and dehumidify
the air.
The recirculate mode should be used
when driving through tunnels or
while in a
traffic jam, or when you
would like to shut off outside air for
quick cooling of the interior.
Use the outside air position for
ventilation or windshield defrosting.
If the vehicle has been parked in
direct sunlight during hot weather,
open the windows to let warm air
escape, then run the climate control
system.
Run the air conditioner about 10
minutes at least once a month to
keep internal parts lubricated.
Have the air conditioner checked
before the weather gets hot. Lack of
refrigerant may make the air
conditioner less efficient.
The refrigerant specifications are
indicated on a label attached to the
inside of the engine compartment. If
the wrong type of refrigerant is used,
it could result in a serious
malfunction of the air conditioner.
Consult a professional, government certified repairer for the inspection
or repair because a special device is
required for the air conditioner
maintenance.
For details, consult an Authorized
Mazda Dealer.
1. Label
Interior Features
Climate Control System
5-2
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Ve n t O p e ra t i o n
▼Adjusting the Vents
Directing airflow
To adjust the direction of
airflow, move
the adjustment knob.
NOTE
When using the air conditioner
under humid ambient temperature
conditions, the system may blow fog
from the vents. This is not a sign of
trouble but a result of humid air
being suddenly cooled.
The air vents can be fully opened and
closed by operating the knob/dial.
Driver's Side Vents
Air vent open/close
1. Knob
2. Open
3. Close
NOTE
The figure indicates the air vent on the
left side of the instrument cluster. The
operation direction for the air vent on
the right side of the instrument cluster
is symmetrical with the air vent on the
left side.

Airflow direction adjustment
1. Knob

Passenger's Side Vents
Air vent open/close
1. Knob
2. Open
3. Close

Airflow direction adjustment
1. Knob

Interior Features
Climate Control System
5-3
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Rear Vents*
Air vent open/close
1. Dial
2. Open
3. Close

Airflow direction adjustment
1. Knob
▼Selecting the Airflow Mode
Dashboard Vents
1. With rear vents

Dashboard and Floor Vents
1. With rear vents

Interior Features
Climate Control System
5-4*Some models.
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

Floor Vents
1. With rear vents

Defroster and Floor Vents
1. With rear vents

Defroster Vents
NOTE
The location airflow exits the air vents
and the airflow amount may change
depending on the open or close status
of the air vents.
Interior Features
Climate Control System
5-5
