MAZDA CX3 2023 Owners Manual

▼Dimensions
Item
Vehicle specification
Overall length 4,395 mm (173.0 in)
Overall width U.S.A. and Canada
1,795 mm (70.7 in)
Mexico 1,797 mm (70.8 in)
Overall height
*1U.S.A. and Canada Type A 1,579 mm (62.2 in)
Type B
1,567 mm (61.7 in)
Mexico 1,562 mm (61.5 in)
Front tread 1,563 mm (61.5 in)
Rear tread 1,563 mm (61.5 in)
Wheelbase 2,653 mm (104.4 in)
*1 The overall height is categorized according to the antenna type as follows:
Ty p e A
1. Antenna
Ty p e B
Except above.
▼ Weights
U.S.A. and Canada
SKYACTIV-G 2.0
Item Weight
FWD AWD
GVWR (Gross Vehicle Weight Rat-
ing) 1,902 kg (4,193 lbs) 1,972 kg (4,347 lbs)
GAWR (Gross Axle
Weight Rating) Front 1010 kg (2,227 lbs) 1,030 kg (2,271 lbs)
Rear 895 kg (1,973 lbs) 945 kg (2,083 lbs)
Specifications
Specifications
9-6
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

SKYACTIV-G 2.5
ItemWeight
FWD AWD
GVWR (Gross Vehicle Weight Rat-
ing) 1,913 kg (4,217 lbs) 1,987 kg (4,381 lbs)
GAWR (Gross Axle
Weigh t Rat ing) Front 1,025 kg (2,260 lbs) 1,050 kg (2,315 lbs)
Rear 890 kg (1,962 lbs) 940 kg (2,072 lbs)
SKYACTIV-G 2.5T
Item
Weight
GVWR (Gross Vehicle Weight Rat-
ing) 2,023 kg (4,460 lbs)
GAWR (Gross Axle
Weigh t Rat ing) Front
1,092 kg (2,407 lbs)
Rear 934 kg (2,059 lbs)
Mexico
SKYACTIV-G 2.0, SKYACTIV-G 2.5
Item Weight
With M Hybrid Without M Hybrid
GVW (Gross Vehicle Weight) 1,955 kg (4,310 lbs)1,939 kg (4,275 lbs)
SKYACTIV-G 2.5T
Item Weight
With moonroof Without moonroof
GVW (Gross Vehicle Weight) 2,042 kg (4,502 lbs)2,039 kg (4,495 lbs)
▼Light Bulbs
Exterior light/Interior light
All the light bulbs are the LED type.
The LED bulb cannot be replaced. Consult an Authorized Mazda Dealer when the
replacement is necessary.
Specifications
Specifications
9-7
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

▼Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type
originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure.
Refer to Tire Pressure Label on page 9-2.Refer to Tire Inflation Pressure on page 6-31.
Standard tire
(U.S.A. and Canada)
Tire size Inflation pressure
Front Rear
215/65R16 98H 250 kPa (36 psi) 250 kPa (36 psi)
215/55R18 95H SKYACTIV-G 2.0, SKYAC-
TIV-G 2.5
250 kPa (36 psi) 250 kPa (36 psi)
SKYACTIV-G 2.5T 260 kPa (38 psi) 250 kPa (36 psi)
(Mexico)
Tire size Inflation pressure
Front Rear
215/65R16 98H 250 kPa (2.5 bar, 36
psi) 250 kPa (2.5 bar, 36
psi)
215/55R18 95H SKYACTIV-G 2.0, SKYAC-
TIV-G 2.5
250 kPa (2.5 bar, 36
psi) 250 kPa (2.5 bar, 36
psi)
SKYACTIV-G 2.5T 260 kPa (2.6 bar, 38
psi) 250 kPa (2.5 bar, 36
psi)
Specifications
Specifications
9-8
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Temporary spare tire
(U.S.A. and Canada)
Tire sizeInflation pressure
T135/80D17 103M 420 kPa (60 psi)
(Mexico)
Tire sizeInflation pressure
185/65R16 93M
* １320 kPa (3.2 bar, 46 psi)
195/55R17 92M
*2320 kPa (3.2 bar, 46 psi)
*1SKYACTIV-G 2.0*2 SKYACTIV-G 2.5, SKYACTIV-G 2.5T
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108―147 N·m (12―14 kgf·m, 80 ―108 ft·lbf)
▼Fuses
Refer to Fuses on page 6-35.
Specifications
Specifications
9-9
CX-30_8KN2-EA-21L_Edition1_new
2021-9-15 19:39:56

MEMO
9-10
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

10Index
10-1
CX-30_8KN2-EA-21L_Edition1_new2021-9-15 19:39:56

Index
A
Accessory Socket....................... 5-42
Active Driving Display................4-35
Adaptive Front Lighting System
(AFS)........................................ 4-99
Add-On Non-Genuine Parts and
Accessories............................... 8-17
Advanced KeyAdvanced keyless entry
system................................. 3-10
Operational range................ 3-11
Advanced Keyless Entry System... 3-10
Antilock Brake System (ABS).......4-84
Assist Grips............................... 5-45
AUTOHOLD.............................. 4-78
AUTOHOLD Warning Beep........ 7-42
Automatic Transmission Active Adaptive Shift (AAS)... 4-40
Automatic transmission
controls................................4-37
Direct mode.........................4-47
Driving tips.......................... 4-48
Manual shift mode............... 4-41
Shift-lock system...................4-38
Transmission ranges.............. 4-39
B
Battery...................................... 6-27Maintenance........................ 6-28
Replacement........................ 6-28
Specifications......................... 9-4
Battery Runs Out....................... 7-13
Jump-starting....................... 7-13
Blind Spot Monitoring (BSM)....4-105 Canceling operation of Blind Spot
Monitoring (BSM)...............4-109
Blind Spot Monitoring (BSM) Warning
Beep.........................................7-42
Body Lubrication....................... 6-21
Bottle Holder............................ 5-44
Brakes Brake assist.......................... 4-77
Brake override system........... 4-77
Electric Parking Brake (EPB)....4-72
Foot brake............................4-72
Pad wear indicator................4-76
Parking brake....................... 4-72
Warning light........................4-76
Brake Override System............... 4-77
Brake Override Warning Beep.....7-41
Brake System Warning Beep....... 7-41
Break-In Period......................... 3-50
C
Capacities...................................9-5
Cell Phones.............................. 8-18
Center Console......................... 5-47
Child Restraint Categories of child-restraint
systems................................ 2-35
Child-restraint precautions.... 2-30
Child-restraint system
installation........................... 2-35
Child-restraint system suitability
for various seat positions
table.................................... 2-37
Installing child-restraint
systems................................ 2-40
ISOFIX child-restraint systems
(Mexico).............................. 2-47
LATCH child-restraint systems
(Except Mexico)................... 2-47
Climate Control System Fully automatic type..............5-10
Manual type...........................5-6
Operating tips........................ 5-2
Vent operation....................... 5-3
Collision warning...................... 7-43
Coming Home Light.................. 4-56
10-2
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Index
Cruise Control........................ 4-208Cruise control switch.......... 4-208
Cruise standby indication (white)/
cruise set indication (green) ..........
......................................... 4-208
Cup Holder.............................. 5-43
Customer Assistance (Canada)..... 8-6
Customer Assistance (Mexico)... 8-10
Customer Assistance (Puerto
Rico).......................................... 8-9
Customer Assistance (U.S.A.)....... 8-2
D
Daytime Running Lights............. 4-58
Defogger.................................. 4-64 Mirror.................................. 4-65
Rear window........................ 4-64
Dimensions.................................9-6
Display..................................... 4-18
Distance & Speed Alert (DSA).. 4-116 Indication on display...........4-117
Door Locks............................... 3-12
Door-ajar Warning Beep............ 7-43
Driver Attention Alert (DAA).... 4-117
Driver Monitoring Camera....... 4-207
Driver Monitoring (DM)...........4-119
Drive Selection..........................4-90
Driving In Flooded Area............. 3-55
Driving on Uneven Road............ 3-56
Driving Position Memory........... 2-10
Driving Tips...............................3-50 Automatic transmission......... 4-48
Break-in period.................... 3-50
Driving in flooded area......... 3-55
Driving on uneven road.........3-56
Floor mat............................. 3-52
Hazardous driving.................3-51
Overloading......................... 3-56
Rocking the vehicle...............3-53
Saving fuel and protection of the
environment.........................3-50
Turbocharged vehicles (SKYACTIV-
G 2.5T)................................ 3-57
Winter driving...................... 3-53
Dynamic Stability Control
(DSC)....................................... 4-87 TCS/DSC indicator light........4-87
E
Electric Parking Brake (EPB)........ 4-72
Electric Parking Brake (EPB) Warning
Beep.........................................7-42
Emergency StartingPush-starting........................ 7-16
Starting a flooded engine...... 7-16
Emergency Towing Tiedown hooks..................... 7-20
Towing description............... 7-19
Emission Control System............ 3-31
Engine Coolant............................... 6-18
Engine compartment
overview.............................. 6-14
Exhaust gas.......................... 3-31
Hood release....................... 6-12
Oil....................................... 6-16
Starting.................................. 4-5
Essential Information................... 6-2
Event Data Recorder.................. 8-19
Excessive Speed Warning........... 7-43
Exterior Care............................. 6-43 Aluminum wheel
maintenance........................ 6-47
Bright-metal maintenance..... 6-47
Maintaining the finish........... 6-44
Plastic part maintenance....... 6-48
F
Flasher
10-3
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Index
Hazard warning.................... 4-66
Headlights............................4-53
Flat Tire Changing a flat tire................. 7-5
Mounting the spare tire........ 7-10
Removing a flat tire................ 7-6
Floor Mat................................. 3-52
Fluids Brake................................... 6-20
Classification .......................... 9-4
Washer................................ 6-20
Foot Brake................................ 4-72
Forward Sensing Camera (FSC) ..........
.............................................. 4-197
Front Camera/Side Cameras/Rear
Camera.................................. 4-206
Front Cross Tra ffi c Alert (FCTA) ..........
.............................................. 4-121
Front Cross Tra ffi c Alert (FCTA)
Warning Beep........................... 7-42
Front Radar Sensor.................. 4-201
Front Side Radar Sensor........... 4-203
Fuel Filler lid and cap...................3-32
Requirements....................... 3-30
Tank capacity......................... 9-5
Fuses........................................ 6-35 Panel description.................. 6-38
Replacement........................ 6-35
G
Gauges..................................... 4-18
Glove Compartment..................5-46
H
Hazardous Driving.....................3-51
Hazard Warning Flasher............. 4-66
HeadlightsComing home light...............4-56
Flashing................................4-56
High-low beam.................... 4-56
Leaving home light............... 4-57
Leveling................................4-57
Head Restraint.......................... 2-16
High Beam Control System
(HBC)..................................... 4-100 High Beam Control System (HBC)
indicator light (green)......... 4-101
Hill Launch Assist (HLA)............. 4-82
HomeLink Wireless Control
System...................................... 4-66
Hood Release........................... 6-12
Horn........................................ 4-65
I
If a Warning Light Turns On or
Flashes......................................7-22
If the Active Driving Display Does Not
Operate.................................... 7-45
Ignition Not Switched Off (STOP)
Warning Beep........................... 7-39
Ignition Switch............................ 4-4
Illuminated Entry System............ 5-41
Immobilizer System................... 3-46
Inspecting Brake Fl uid Level........6-20
Inspecting Coolan t Level............ 6-18
Inspecting Engine Oil Level.........6-17
Inspecting Washer Fluid Level..... 6-20
Instrument Cluster..................... 4-18 Average fuel economy...........4-25
Compass display.................. 4-27
Current fuel economy........... 4-26
Dashboard illumination........ 4-24
Deceleration regeneration charge
display................................. 4-26
Distance-to-empty................4-25
Engine coolant temperature
gauge...................................4-22
Fuel gauge........................... 4-23
Indication/indicator lights..... 4-31
10-4
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56

Index
i-ACTIVSENSE display........... 4-27
Message Display................... 4-28
Message indicated on multi-
information display............... 7-35
Multi-information display...... 4-20
Odometer............................ 4-22
Outside temperature
display................................. 4-25
Speedometer....................... 4-18
Tachometer.......................... 4-19
Trip meter............................ 4-22
Warning indication/warning
lights....................................4-29
Interior Care............................. 6-49 Active driving display
maintenance........................ 6-51
Cleaning the floor mats......... 6-51
Cleaning the window
interiors............................... 6-51
Instrument panel top (Soft pad)
maintenance........................ 6-50
Leather upholstery
maintenance........................ 6-50
Panel maintenance............... 6-51
Plastic part maintenance....... 6-50
Seat belt maintenance.......... 6-49
Upholstery maintenance....... 6-50
Vinyl upholstery
maintenance........................ 6-50
Interior Lights............................ 5-40 Luggage compartment light... 5-40
Map lights............................5-40
Overhead lights.................... 5-40
i-ACTIVSENSE........................... 4-95 Active safety technology........ 4-95
Adaptive Front Lighting System
(AFS)................................... 4-99
Blind Spot Monitoring
(BSM)................................ 4-105
Camera and sensors............. 4-96Distance & Speed Alert
(DSA)................................ 4-116
Driver Attention Alert
(DAA)................................ 4-117
Driver monitoring camera....4-207
Driver Monitoring (DM)...... 4-119
Forward Sensing Camera
(FSC)................................. 4-197
Front camera/side cameras/rear
camera...............................4-206
Front Cross Tra ffi c Alert
(FCTA)............................... 4-121
Front radar sensor...............4-201
Front side radar sensor........ 4-203
High Beam Control System
(HBC)................................ 4-100
i-ACTIVSENSE OFF Switch..... 4-98
i-ACTIVSENSE status symbol
(warning/risk avoidance support
system)................................ 4-97
Lane Departure Warning System
(LDWS).............................. 4-102
Lane-keep Assist System
(LAS)..................................4-152
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)........... 4-128
Pre-crash safety technology... 4-95
Rear Cross Tra ffi c Alert
(RCTA)............................... 4-124
Rear side radar sensor......... 4-204
Smart Brake Support (SBS)...4-156
Traffic Jam Assist (TJA)......... 4-138
Tra ffi c Sign Recognition
System (TSR)...................... 4-110
Ultrasonic sensor................ 4-206
360°view monitor...............4-164
i-ACTIV AWD Operation........... 4-92
i-stop....................................... 4-11 Indicator light (Green).......... 4-16
i-stop OFF switch................. 4-14
10-5
CX-30_8KN2-EA-21L_Edition1_new 2021-9-15 19:39:56
