Interior Care
▼Interior Care
WARNING
Do not spray water into the vehicle
cabin:
Spraying water into the vehicle cabin is
dangerous as electrical devices such as
the audio and switches could get wet
resulting in a malfunction or vehicle
fire.
NOTE
Do not wipe the interior using
alcohol, chlorine bleach, or organic
solvents such as thinner, benzene,
and gasoline. Otherwise, it may
cause discoloration or stains.
Rubbing hard with a stiff brush or
cloth may cause damage.
If the vehicle interior becomes soiled
by any of the following, wipe it off
immediately using a soft cloth.
Leaving it uncleaned could cause
discoloration, stains, cracks, or peeling
of the coating , and it will make it hard
to wipe off later.
Beverage or fragranceGrease or oilSoiling
▼ Seat Belt Maintenance
1. Clean the soiled area by lightly
dabbing it with a soft cloth soaked
in a mild detergent (approx. 5%)
diluted with water.
2. Wipe off the remaining detergent using a cloth soaked in clean water
and wrung out well.
3. Before retracting seat belts which have been pulled out for cleaning,
dry them off thoroughly and make
sure there is no remaining moisture
on them.
WARNING
If a seat belt appears frayed or has
abrasions, have it replaced by an
Authorized Mazda Dealer:
If a seat belt is used under such a
condition, it cannot function at its full
capacity which could result in serious
injury or death.
Use a mild detergent to remove
soiling from a seat belt:
If organic solvents are used for cleaning
the seat belts or they become stained
or bleached, there is the possibility of
them becoming weakened and as a
result, they may not function at their
full capacity which could cause serious
injury or death.
NOTE
Clean seat belts diligently if they get
dirty. Leaving them uncleaned will
make it difficult to clean them later,
and it may affect the smooth retracting
of the seat belt.
Maintenance and Care
Appearance Care
6-49
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

▼Vinyl Upholstery Maintenance
Remove dust and dirt from the vinyl
upholstery using a brush or vacuum.
Remove soiling from vinyl upholstery
using a leather and vinyl upholstery
cleaner.
▼Upholstery Maintenance
1. Clean the soiled area by lightly
dabbing it with a soft cloth soaked
in a mild detergent (approx. 5%)
diluted with water.
2. Wipe off the remaining detergent
using a cloth soaked in clean water
and wrung out well.
▼ Leather Upholstery Maintenance*
1. Remove dust and sand using a
vacuum cleaner.
2. Wipe off the soiled area with a soft cloth and a suitable, special cleaner
or a soft cloth soaked in a mild
detergent (about 5%) diluted with
water.
3. Wipe off the remaining detergent using a cloth soaked in clean water
and wrung out well.
4. Remove moisture with a dry, soft cloth and allow the leather to
further dry in a well-ventilated,
shaded area. If the leather gets wet
such as from rain, remove the
moisture and dry it as soon as
possible.
NOTE
Because genuine leather is a natural
material, its surface is not uniform
and it may have natural scars,
scratches, and wrinkles.
To maintain the quality for as long as
possible, periodical maintenance,
about twice a year, is recommended.
If the leather upholstery comes into
contact with any of the following,
clean it immediately.
Leaving it uncleaned could cause
premature wear, mold, or stains.
Sand or dirtGrease or oil, such as hand creamAlcohol, such as in cosmetic or
hair dressing items
If the leather upholstery gets wet,
promptly remove moisture with a dry
cloth. Remaining moisture on the
surface may cause deterioration such
as hardening and shrinkage.
Exposure to direct sunlight for long
periods may cause deterioration and
shrinkage. When parking the car
under direct sunlight for long
periods, shade the interior using
sunshades.
Do not leave vinyl products on the
leather upholstery for long periods.
They may affect the leather quality
and coloring. If the cabin
temperature becomes hot, the vinyl
may deteriorate and adhere to the
genuine leather.
▼ Plastic Part Maintenance
CAUTION
Do not use polishing agents.
Depending on the product ingredients,
they could cause discoloration, stains,
cracks or peeling of the coating.
Maintenance and Care
Appearance Care
6-50*Some models.
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

▼Instrument Panel Top (Soft pad)
Maintenance
Extremely soft material is used for the
soft pad surface. If the soft pad surface
is rubbed harshly with a dry cloth, it
could result in the surface being
damaged and leaving white scratch
marks.
1. Wipe the soiled area with a soft
cloth soaked in a mild detergent
(approx. 5%) diluted with water.
2. Wipe off the remaining detergent using a cloth soaked in clean water
and wrung out well.
▼Active Driving Display
Maintenance*
The dust-proof sheet has a coating.
When cleaning, do not use a hard or
rough-surface cloth, or cleaning
detergent. In addition, if a chemical
solvent gets on the active driving
display, wipe it off immediately. The
dust-proof sheet could be damaged
and the surface coating could be
scratched. Use a fine, soft cloth such as
those used for cleaning eyeglasses.
NOTE
Use of compressed air when cleaning
the dust-proof sheet is recommended.
▼Panel Maintenance
If a panel becomes soiled, wipe it off
with a soft cloth soaked in clean water
and thoroughly wrung out.
If some areas require further cleaning ,
use the following procedure:
1. Wipe the soiled area with a soft
cloth soaked in a mild detergent
(approx. 5 %) diluted with water.
2. Wipe off the remaining detergent using a cloth soaked in clean water
and wrung out well.
NOTE
Be particularly careful when cleaning
shiny surface panels and metallic parts
such as plating as they can be
scratched easily.
Maintenance and Care
Appearance Care
*Some models.6-51
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

▼Cleaning the Window Interiors
If the windows become covered with
an oily, greasy, or waxy film, clean
them with glass cleaner. Follow the
directions on the container.
CAUTION

Do not scrape or scratch the inside
of the window glass. It could
damage the thermal filaments and
the antenna lines.
 When washing the inside of the
window glass, use a soft cloth
dampened in lukewarm water, gently
wiping the thermal filaments and the
antenna lines.
Use of glass cleaning products could
damage the thermal filaments and
the antenna lines.
▼ Cleaning the Floor Mats
Rubber floor mats should be cleaned
with mild soap and water only.
WARNING
Do not use rubber cleaners, such as
tire cleaner or tire shine, when
cleaning rubber floor mats:
Cleaning the rubber floor mats with
rubber cleaning products makes the
floor mats slippery.
This may cause an accident when
depressing the accelerator or brake
pedal or when getting in or out of the
vehicle.
After removing the floor mats for
cleaning, always reinstall them securely
(page 3-48).
Maintenance and Care
Appearance Care
6-52
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Spare Tire and ToolStorage
▼Spare Tire and Tool Storage
Spare tire and tools are stored in the
locations illustrated in the diagram.
1. Tiedown eyelet*
2. Spare tire hold-down bolt
3. Jack lever
4. Lug wrench
5. Jack
6. Spare tire
▼Jack
To r e m o v e t h e j a c k
1. Remove the luggage mat.

2. Remove the jack.
To s e c u r e t h e j a c k
Perform the removal procedure in
reverse.
Maintenance
Always keep the jack clean.Make sure the moving parts are kept
free from dirt or rust.
Make sure the screw thread is
adequately lubricated.
▼Spare Tire
Your Mazda has a temporary spare tire.
The temporary spare tire is lighter and
smaller than a conventional tire, and is
designed only for emergency use and
should be used only for VERY short
periods. Temporary spare tires should
NEVER be used fo
r long drives or
extended periods.
WARNING
Do not install the temporary spare tire
on the front wheels (driving wheels):
Driving with the temporary spare tire
on one of the front driving wheels is
dangerous. Handling will be affected.
You could lose control of the vehicle,
especially on ice or snow bound roads,
and have an accident. Move a regular
tire to the front wheel and install the
temporary spare tire to the rear.
If Trouble Arises
Flat Tire
*Some models.7-3
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

▼Security Indicator Light
If the security indicator light flashes
continuously while you are driving, do
not shut
off the engine. Go to an
Authorized Mazda Dealer and have it
checked. If the engine is shut off while
the indicator light is flashing, you will
not be able to restart it.
Make sure the key is within the
operat ional range for signal
transmission. Switch the ignition off,
and then restart the engine. If the
engine does not start after 3 or more
tries, contact an Authorized Mazda
Dealer.
NOTE
Because the electronic codes are reset
when the immobilizer system is
repaired, the keys are needed. Make
sure to bring all the keys to an
Authorized Mazda Dealer so that they
can be programmed.
▼ High Beam Control System (HBC)
Warning Indication/Warning Light
(Amber)
*
The light remains turned on if there is a
problem with the system. Have your
vehicle inspected at an Authorized
Mazda Dealer.
▼i-ACTIVSENSE Warning
Indication/Warning Light*
The indication displays if the system
has a malfunction.
Check the reason for the indication
displaying on the center display or
multi-information display.
Refer to If a Warning Light Turns On or
Flashes on page 7-20.
▼Exterior Light Warning Indication/
Warning Light
This light illuminates if there is a
malfunction in the exterior lights
(except license plate lights). Have your
vehicle inspected by an Authorized
Mazda Dealer.
CAUTION
Do not drive the vehicle while an
exterior light has a malfunction. Poor
visibility, and not being able to signal
braking and turns may cause an
accident. In addition, if the vehicle is
driven with the lights not turned on, it
may conflict with laws and regulations
due to poor maintenance.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-27
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

8
Customer Information and Reporting
Safety Defects
Important consumer information including warranties and add-
on equipment.
Customer Assistance................. 8-2 Customer Assistance
(U.S.A.).................................8-2
Customer Assistance
(Canada).............................. 8-6
Customer Assistance (Puerto
Rico).....................................8-8
Customer Assistance
(Mexico)............................... 8-9
Mazda Importer/Distributors ..........
............................................ 8-11 Importer/Distributor............8-11
Reporting Safety Defects.......... 8-12 Reporting Safety Defects
(U.S.A.)...............................8-12
Reporting Safety Defects
(Canada)............................ 8-13
Warranty................................8-14 Warranties for Your Mazda ..........
.......................................... 8-14
Outside the United States/
Canada............................... 8-14
Registering Your Vehicle in A
Foreign Country (Except United
States and Canada).............. 8-15
Add-On Non-Genuine Parts and
Accessories......................... 8-16
Cell Phones............................ 8-17Cell Phones Warning............ 8-17
Event Data Recorder................ 8-18 Event Data Recorder (U.S.A. and
Canada)..............................8-18
Recording of Vehicle Data........ 8-19 Recording of Vehicle Data.... 8-19
Uniform Tire Quality Grading System
(UTQGS)................................ 8-20 Uniform Tire Quality Grading
System (UTQGS).................. 8-20
Tire Information (U.S.A.).......... 8-22 Tire Labeling........................ 8-22
Location of the Tire Label
(Placard)............................. 8-25
Tire Maintenance................. 8-27
Vehicle Loading................... 8-29
Steps for Determining the Correct
Load Limit........................... 8-32
Declaration of Conformity....... 8-33 Declaration of Conformity ...........
.......................................... 8-33
8-1
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

road when it's mounted on the
vehicle.

Seating capacity means the total
allowable number of vehicle
occupants. Seating capacity is
described on the tire label.

Production options weight is the
combination weight of installed regular
production options weighing over 2.3
kilograms in excess of the standard
items which they replace, and not
previously considered in the curb
weight or accessory weight, including
heavy duty brakes, ride levelers, roof
rack, heavy duty battery, and special
trim.

Rim is the metal support (wheel) for a
tire or a tire and tube assembly upon
which the tire beads are seated.Tire Maintenance
▼ Tire Maintenance
Improper or inadequate vehicle
maintenance can cause tires to wear
abnormally. Here are some important
maintenance points:
▼Tire
Inflation Pressure
Inspect all tire pressure monthly
(including the spare) when the tires are
cold. Maintain recommended
pressures for the best ride, top
handling , and minimum tire wear. Use
the pressures specified on the vehicle
tire information placard or tire label for
optimum service.
▼Tire Rotation
To equalize tread wear, rotate the tires
every 16,000 km (10,000 miles) at the
latest or sooner if irregular wear
develops. Mazda recommends to
rotate every 8,000 km (5,000 miles) to
help increase tire life and distribute
wear more evenly.
1. Forward
Do not include (TEMPORARY USE
ONLY) spare tire in rotation.

Inspect the tires for uneven wear and
damage. Abnormal wear is usually
caused by one or a combination of the
following:
Incorrect tire pressure
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-27
CX-50_8KB8-EA-22A_Edition2_new
2022-1-6 14:55:18

Index
A
Accessory Socket....................... 5-41
Active Driving Display................4-35
Adaptive Front Lighting System
(AFS)........................................ 4-93
Add-On Non-Genuine Parts and
Accessories............................... 8-16
Advanced KeyAdvanced keyless entry
system................................... 3-9
Operational range................ 3-10
Advanced Keyless Entry System..... 3-9
Antilock Brake System (ABS).......4-78
Assist Grips............................... 5-48
AUTOHOLD.............................. 4-73
AUTOHOLD Warning Beep........ 7-39
Automatic Transmission Active Adaptive Shift (AAS)... 4-40
Automatic transmission
controls................................4-37
Direct mode.........................4-47
Driving tips.......................... 4-48
Manual shift mode............... 4-41
Shift-lock system...................4-38
Transmission ranges.............. 4-39
B
Battery...................................... 6-27Maintenance........................ 6-28
Replacement........................ 6-28
Specifications......................... 9-4
Battery Runs Out....................... 7-11
Jump-starting....................... 7-11
Blind Spot Assist......................4-141
Blind Spot Monitoring (BSM)..... 4-99
Canceling operation of Blind Spot
Monitoring (BSM)...............4-103
Blind Spot Monitoring (BSM) Warning
Beep.........................................7-39
Body Lubrication....................... 6-22
Bottle Holder............................ 5-48
Brakes
Brake assist.......................... 4-72
Brake override system........... 4-72
Electric Parking Brake (EPB)....4-68
Foot brake............................4-67
Pad wear indicator................4-72
Parking brake....................... 4-68
Warning light........................4-72
Brake Override System............... 4-72
Brake Override Warning Beep.....7-38
Break-In Period......................... 3-46
C
Capacities...................................9-5
Cell Phones.............................. 8-17
Center Console......................... 5-50
Child Restraint Categories of child-restraint
systems................................ 2-36
Child-restraint precautions.... 2-31
Child-restraint system
installation........................... 2-36
Child-restraint system suitability
for various seat positions
table.................................... 2-38
Installing child-restraint
systems................................ 2-41
ISOFIX child-restraint systems
(Mexico).............................. 2-47
LATCH child-restraint systems
(Except Mexico)................... 2-47
Climate Control System Fully automatic type..............5-10
Manual type...........................5-6
Operating tips........................ 5-2
Vent operation....................... 5-3
Collision warning...................... 7-40
Coming Home Light.................. 4-52
10-2
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18

Index
Cruise Control........................ 4-198Cruise control switch.......... 4-198
Cruise standby indication (white)/
cruise set indication (green) ..........
......................................... 4-198
Cup Holder.............................. 5-47
Customer Assistance (Canada)..... 8-6
Customer Assistance (Mexico)..... 8-9
Customer Assistance (Puerto
Rico).......................................... 8-8
Customer Assistance (U.S.A.)....... 8-2
Cylinder Deactivation................ 4-10
D
Daytime Running Lights............. 4-53
Defogger.................................. 4-59 Mirror.................................. 4-60
Rear window........................ 4-59
Dimensions.................................9-6
Display..................................... 4-18
Distance & Speed Alert (DSA).. 4-110 Indication on display...........4-111
Door Locks............................... 3-11
Door-ajar Warning Beep............ 7-40
Driver Attention Alert (DAA).... 4-111
Driving In Flooded Area............. 3-51
Driving on Uneven Road............ 3-52
Driving Position Memory........... 2-10
Driving Tips...............................3-46 Automatic transmission......... 4-48
Break-in period.................... 3-46
Driving in flooded area......... 3-51
Driving on uneven road.........3-52
Floor mat............................. 3-48
Hazardous driving.................3-47
Overloading......................... 3-51
Rocking the vehicle...............3-49
Saving fuel and protection of the
environment.........................3-46
Turbocharged vehicles (SKYACTIV-
G 2.5T)................................ 3-52
Winter driving...................... 3-49
Dynamic Stability Control
(DSC)....................................... 4-81 TCS/DSC indicator light........4-81
E
Electric Parking Brake (EPB)........ 4-68
Electric Parking Brake (EPB) Warning
Beep.........................................7-39
Emergency Lane Keeping (ELK) ..........
.............................................. 4-141Blind Spot Assist................. 4-141
Road Keep Assist................ 4-144
Emergency Starting Push-starting........................ 7-14
Starting a flooded engine...... 7-14
Emergency Towing Tiedown hooks..................... 7-18
Towing description............... 7-17
Emission Control System............ 3-28
Engine Coolant............................... 6-19
Engine compartment
overview.............................. 6-14
Exhaust gas.......................... 3-28
Hood release....................... 6-12
Oil....................................... 6-16
Starting.................................. 4-5
Essential Information................... 6-2
Event Data Recorder.................. 8-18
Excessive Speed Warning........... 7-40
Exterior Care............................. 6-43 Aluminum wheel
maintenance........................ 6-48
Bright-metal maintenance..... 6-47
Maintaining the finish........... 6-44
Plastic part maintenance....... 6-48
10-3
CX-50_8KB8-EA-22A_Edition2_new 2022-1-6 14:55:18
