SignalWarning
Charging System Warn‐
ing Indication/Warning Light If the warning light illuminates while driving, it indicates a
malfunction of the alter‐
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Co nsult an Authorized
Mazda Dealer.
CAUTION
Do not continue driving when the charging system warning light is illuminated be‐
cause the engine could stop unexpectedly.
Engine Oil Warning Light This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is
low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the w arning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way o n level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain b ack into the oil pan.
3. Inspect the engine oil level (p age 6-21). If it's low, add the appropriate amount of
engine oil while being careful not to overfill.
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.

If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
(Red)
High Engine Coolant
Temperature Warning Indication/Warning Light The light flashes when the engine
coolant temperature is extremely high, and illumi‐
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe pl ace to stop the vehicle
and wait for the engine to cool down.
Illuminated light
This indicates the possibility of overheating. Park the vehicle in a safe place immedi‐
ately and stop the engine.
Refer to Overheating on page 7-23.
CAUTION
Do not drive the vehicle with the high engine coolant temperature warning light illumi‐
nated. Otherwise, it could resu lt in damage to the engine.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
7-30
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

SignalWarning
Power Steering Mal‐
function Indication*
The message is displayed if the electric power steering has a m alfunction.
If the message is displayed, stop the vehicle in a safe place a nd do not operate the
steering wheel. There is no probl em if the message in the display turns off after a
while. Contact an Authorized Mazda Dealer if the message is dis played continuously.
NOTE
If the message is displayed, the power steering will not operate normally. In this
case, the steering wheel can still be op erated, however, the operation may feel
heavy compared to normal, or the steer ing wheel could vibrate when turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steerin g feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
Power Steering Mal‐ function Indicator
Light
*
The light illuminates/flashes if the electric power steering ha s a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe pl ace and do not operate the
steering wheel. There is no problem if the light turns off afte r a while. Contact an Au‐
thorized Mazda Dealer if the lig ht illuminates/flashes continuously.
NOTE
If the indicator light illuminates/flashes, the power steering will not operate nor‐
mally. If this happens, the steering wheel can still be operated, however, the opera‐
tion may feel heavy compared to normal , or the steering wheel could vibrate when
turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steerin g feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
▼ Contact Authorized Mazda Deale
r and Have Vehicle Inspected
If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.
SignalWarning
ABS Warning LightIf the ABS warning light stays on while you're driving, the ABS
control unit has detected
a system malfunction. If this o ccurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.
NOTE
When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.
The brake assist system does not operate while the ABS warning light is illuminated.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-31
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

SignalWarning Action to be taken
Seat Belt Warning
Light (Front seat) Mexico
The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not
fastened with the ig‐
nition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's
seat is occupied) and the vehicle is driven at
a speed faster than abo ut 20 km/h (12 mph),
the warning light flash es. After a short time,
the warning light stops flashing, but re‐
mains illuminated. If a seat belt remains un‐
fastened, the warning light flashes again for
a given period of time.
NOTE
Placing heavy items on the front pas‐
senger's seat may cause the front pas ‐
senger's seat belt warning function to op ‐
erate depending on the weight of the
item.
To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion on
the front passenger's seat. The sensor
may not function properly because the
additional seat cushion could cause sen ‐
sor interference.
If a small child is seated on the front pas ‐
senger's seat, the warning light may not
operate. Fasten the seat belts.
(Red)
Seat Belt Warning Light (Rear seat) If the rear seat belts are not fastened while
the ignition is switched ON , the driver and
the passenger are alerted by the warning
light.
The warning light operates even if there is
no passenger on the rear seat.
NOTE
If a rear seat belt is not fastened by a cer
‐
tain period of time after the engine has
been started, the warning light turns off. Fasten the seat belts.
Low Washer Fluid
Level Warning Indica‐
tion
*
This warning light indicates that little wash‐
er fluid remains. Add washer fluid (page 6-24).
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-39
CX-9_8LJ2-EA-22H_Edition1_old
2022-6-9 13:33:08

Message Indicated in Multi-information Display*
If there is a notification from the vehicle, a message is displayed in the multi-information
display. Check the information and take the necessary action.

(Display example) Instrument Cluster
Type A
Type B
If the warning light turns on/fla shes simultaneously or a symbol is indicated in the display,
check the information regarding the warning light or symbol.
Refer to If a Warning Light Turns On or Flashes on page 7-28.
Display Content Action to be taken
Indicated when the push button start is
pressed while the selector lever is not in
the P position. Shift the selector lev
er to the P position.
Indicated when the push button start is
pressed without depressing the brake
pedal. Depress the brake pedal and press the
push button start.
Indicates when the Electric Parking
Brake (EPB) switch is operated without
depressing the brake pedal.Operate the Electric Parking Brake
(EPB) switch while depressing the brake
pedal.
Indicates when there is a problem with
the brake related system while the vehi‐
cle is being held in a stop position by the
AUTOHOLD function or during the
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function) stop hold control.Depress the brake pedal.
Cancel the AUTOHOLD function or the
Mazda Radar Cruise Control with Stop
& Go function (MRCC with Stop & Go
function), and have your vehicle inspect‐
ed at an Authorized Mazda Dealer.
Indicates the possibility of the vehicle
not being held in th
e stopped position by
the AUTOHOLD function or the Mazda
Radar Cruise Control with Stop & Go
function (MRCC with Stop & Go func‐
tion) stop hold control, such as on steep
slopes. Depress and hold your foot on the brake
pedal.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.7-45
CX-9_8LJ2-EA-22H_Edition1_old
2022-6-9 13:33:08

▼Replacing a Tire
WA R N I N G
Always use tires that are in good condition:
Driving with worn tires is dangerous. Reduce
d braking, steering, and traction could result in
an accident.
If a tire wears evenly, a wear i ndicator will appear as a solid band across the tread.
Replace the tire when this happens.
New tread Tread wear indicator
Worn tread
You should replace the tire before the band crosses the entire tread.
NOTE
Tires degrade over time, even when they are not being used on the road. It is recommended
that tires generally be replaced when they are 6 years or older. Heat caused by hot climates
or frequent high load ing conditions can accelerate the aging proc ess. You should replace
the spare tire when you replace the other road tires due to the aging of the spare tire. The
period in which the tire was manufactured (both week and year) is indicated by a 4-digit
number.
Refer to Tire Labeling on page 8-25.
▼ Safety Practices
The way you drive has a great deal to do with your tire mileage
and safety. So cultivate
good driving habits for your own benefit.
Observe posted speed limits and d rive at speeds that are safe for the existing weather
conditions
Avoid fast starts, stops and turns
Avoid potholes and objects on the road
Do not run over curbs or hit the tire against the curb when parking
Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
8-34
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Index
A
Accessory Socket.............................. 5-62
Active Driving Display..................... 4-57
Adaptive Front Lighting System
(AFS)............................................... 4-119
Add-On Non-Genuine Parts and
Accessories........................................ 8-19
Advanced Key
Advanced keyless entry system... 3-10
Operational range........................ 3-11
Advanced Key Removed from Vehicle
Warning Beep.................................... 7-48
Advanced Smart City Brake Support
(Advanced SCBS)........................... 4-171
Collision warning.... .................. 4-173
Stopping the Advanced Smart City
Brake Support (Advanced SCBS)
system operation........................ 4-173
Air Bag Systems............................... 2-69
Air Bag/Front Seat Belt Pretensioner
System Warning Beep....................... 7-47
Antilock Brake System (ABS)........ 4-104
Armrest Box...................................... 5-73
AUTOHOLD..................................... 4-98
AUTOHOLD Warning Beep.............7-49
Automatic Transaxle......................... 4-59
Active Adaptive Shift (AAS)...... 4-62
Automatic transaxle controls....... 4-59
Direct mode................................. 4-69
Driving tips..................................4-70
Manual shift mode.......................4-62
Shift-lock system......................... 4-60
Transaxle ranges.......................... 4-60
B
Battery............................................... 6-31Maintenance.................................6-33
Replacement................................ 6-33
Specifications.................................9-4
Battery Runs Out.............................. 7-19
Jump-starting............................... 7-19
Blind Spot Monitoring (BSM)........ 4-123 Canceling operation of Blind Spot
Monitoring (BSM).....................4-127
Blind Spot Monitoring (BSM) Warning
Beep...................................................7-50
Body Lubrication.............................. 6-25
Bottle Holder..................................... 5-71
Brakes
Brake assist.................................. 4-97
Electric parking brake (EPB)...... 4-95
Foot brake....................................4-94
Pad wear indicator....................... 4-97
Warning light............................... 4-97
Break-In Period................................. 3-47
C
Capacities............................................ 9-5
Carbon Monoxide......... .................... 3-29
Cell Phones....................................... 8-20
Center Console.................................. 5-72
Child Restraint Categories of child-restraint
systems.........................................2-49
Child-restraint precautions.......... 2-44
Child-restraint system
installation................................... 2-49
Child-restraint system suitability for
various seat positions table..........2-51
Installing child-restraint
systems.........................................2-55
ISOFIX child-restraint systems
(Mexico)...................................... 2-64
LATCH child-restraint systems
(Except Mexico).......................... 2-64
Child Safety Locks for Rear Doors... 3-18
Climate Control System...................... 5-2 Dual-zone automatic climate
control............................................ 5-5
10-2
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Index
Panel maintenance....................... 6-62
Plastic part maintenance.............. 6-62
Seat belt maintenance..................6-61
Upholstery maintenance.............. 6-61
Vinyl upholstery maintenance..... 6-61
Interior Lights................................... 5-58 Luggage compartment light.........5-58
Map lights....................................5-58
Overhead lights............................5-58
i-ACTIVSENSE.............................. 4-116
Active safety technology........... 4-116
Adaptive Front Lighting System
(AFS)......................................... 4-119
Advanced Smart City Brake Support
(Advanced SCBS)..................... 4-171
Blind Spot Monitoring (BSM) ............
................................................... 4-123
Camera and sensors................... 4-117
Distance Recognition Support System
(DRSS).......................................4-135
Driver Attention Alert (DAA)... 4-139
Forward Sensing Camera
(FSC)......................................... 4-239
High Beam Control System
(HBC)........................................ 4-120
Lane-keep Assist System (LAS) &
Lane Departure Warning System
(LDWS)..................................... 4-160
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function)..................4-145
Pre-crash safety technology....... 4-117
Radar sensors (rear)...................4-247
Radar sensor (front)...................4-244
Rear Cross Traffic Alert
(RCTA)...................................... 4-141
Smart Brake Suppor t (SBS)...... 4-182
Smart City Brake Support [Forward]
(SCBS F)................................... 4-174
Smart City Brake Support [Reverse]
(SCBS R)................................... 4-178Traffic Sign Recognition System
(TSR)......................................... 4-129
Ultrasonic sensor (rear)............. 4-249
360°View Monitor (Mazda Connect
(Type A))................................... 4-184
360°view monitor (Mazda Connect
(Type B))................................... 4-211
i-ACTIV AWD Operation............... 4-113
J
Jack...................................................... 7-3
Jump-Starting.................................... 7-19
K
Keyless Entry System......................... 3-4
Keys.....................................................3-2 Key suspend function.................... 3-9
Transmitter..................................... 3-5
Key Left-in-luggage Compartment
Warning beep (With the advanced
keyless function)............................... 7-49
Key Left-in-trunk Warning Beep (With
the advanced keyless function)......... 7-49
Key Left-in-vehicle Warning Beep (With
the advanced keyless function)......... 7-49
Key Removed from Vehicle Warning
Beep...................................................7-48
Key Suspend Function........................ 3-9
L
Label Information............................... 9-2
Lane Departure Warning sound........ 7-51
Lane-change Signals......................... 4-78
Lane-keep Assist System (LAS) & Lane
Departure Warning System
(LDWS)........................................... 4-160
Leaving Home Light......................... 4-75
Liftgate.............................................. 3-18 When Liftgate Cannot be
Opened......................................... 7-52
10-6
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Index
Seat Belt System............................... 2-38Automatic locking....................... 2-37
Emergency locking...................... 2-37
Extender....................................... 2-42
Pregnant women.......................... 2-37
Seat belt precautions................... 2-35
3-point type................................. 2-38
Seat Belt Warning Beep.................... 7-47
Second-Row Seat...... ........................ 2-15
Second-Row Seat (Captain Seat
Type)..................................................2-22
Security System Immobilizer system..................... 3-43
Theft-deterrent system................. 3-45
Shopping Bag Hook.......................... 5-76
Smart Brake Support (SBS)............ 4-182
Collision warning...................... 4-183
Stopping the Smart Brake Support
(SBS) system operation............. 4-183
Smart City Brake Support (SCBS) Collision warning...................... 4-176
Smart City Brake Support (SCBS)
Indicator Light (Red).................4-176
Smart City Brake Support [Forward]
(SCBS F)......................................... 4-174
Stopping the Smart City Brake
Support [Forward] (SCBS F) system
operation.................................... 4-176
Smart City Brake Support [Reverse]
(SCBS R)........................................ 4-178 Stopping the Smart City Brake
Support [Reverse] (SCBS R) system
operation.................................... 4-181
Spare Tire............................................ 7-6
Specifications...................................... 9-4
SRS Air Bags Front passenger occupant
classification system.................... 2-84
How the SRS air bags work........ 2-77
Limitations to SRS air bag.......... 2-82
Monitoring................................... 2-88SRS air bag deployment
criteria.......................................... 2-81
Supplemental restraint system
components.................................. 2-75
Starting the Engine..............................4-5
Steering Wheel Heated steering wh eel................. 2-34
Horn............................................. 4-84
Storage Box.......................................5-73
Storage Compartments ...................... 5-71
Armrest box................................. 5-73
Center console............................. 5-72
Glove compartment..................... 5-72
Luggage Compartment................ 5-74
Overhead console........................ 5-72
Rear coat hooks........................... 5-76
Shopping bag hook.... ..................5-76
Storage Box................................. 5-73
Sunshade............................................3-42
Sunshade (Rear door window).......... 5-77
Sunvisors........................................... 5-57
T
Theft-Deterrent System ..................... 3-45
Third-Row Seat................................. 2-26
Three-flash Turn Signal.................... 4-78
Tires................................................... 6-35 Flat tire.......................................... 7-3
Replacing a tire........................... 6-37
Replacing a wheel....................... 6-39
Snow tires.................................... 3-50
Specifications.................................9-7
Temporary spare tire....................6-38
Tire chains................................... 3-51
Tire inflation pressure................. 6-36
Tire rotation................................. 6-36
Uniform tire quality grading system
(UTQGS)..................................... 8-23
Tire Inflation Pressure Warning
Beep...................................................7-50
10-9
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Index
Tire Information................................ 8-25
Tire Pressure Monitoring System.... 4-256
To w i n gHook.............. .............................. 7-26
Recreational towing.....................3-63
Trailer towing (U.S.A. and
Canada)........................................ 3-55
Towing Description........................... 7-25
Traction Control System (TCS)...... 4-105 TCS OFF Indicator Light.......... 4-106
TCS OFF Switch....................... 4-106
TCS/DSC indicator light........... 4-105
Traffic Sign Recognition System
(TSR)............................................... 4-129
Trailer Stability Control (TSC)....... 4-108
Transmitter.......................................... 3-5
Trouble
Battery runs out........................... 7-19
Emergency starting...................... 7-22
Emergency towing....................... 7-25
Flat tire.......................................... 7-3
Overheating................................. 7-23
Parking in an emergency............... 7-2
When Liftgate Cannot be
Opened......................................... 7-52
Turn Signals...................................... 4-78
U
Ultrasonic Sensor (Rear)................. 4-249
USB Power Outlet............................ 5-63
V
Vanity Mirrors................................... 5-57
Vehicle Information Labels................. 9-2
W
Warning Sound is Activated............. 7-47 Advanced Key removed from vehicle
warning beep............................... 7-48
Air bag/front seat belt pretensioner
system warning beep................... 7-47
AUTOHOLD warning beep........ 7-49
Blind Spot Monitoring (BSM)
warning beep............................... 7-50
Collision warning...... .................. 7-51
Electric Parking Brake (EPB)
Warning Beep.............................. 7-49
Excessive speed warning.............7-50
Ignition not switched off (STOP)
warning beep............................... 7-48
Key left-in-luggage compartment
warning beep (With the advanced
keyless function)..........................7-49
Key left-in-trunk warning beep (With
the advanced keyless function).... 7-49
Key left-in-vehicle warning beep
(With the advanced keyless
function).......................................7-49
Key removed from vehicle warning
beep..............................................7-48
Lane Departure Warning sound... 7-51
Lights-on reminder...................... 7-47
Mazda Radar Cruise Control with
Stop & Go function (MRCC with
Stop & Go function) system
warnings.......................................7-50
Power Liftgate Warning Beep..... 7-49
Power steering warning buzzer....7-50
Request switch inoperable warning
beep (With the advanced keyless
function).......................................7-49
Seat belt warning beep................ 7-47
Tire inflation pressure warning
beep..............................................7-50
Warranty............................................ 8-16
Weights................................................ 9-6
Windows Power windows........................... 3-37
Windshield Washer........................... 4-82
Windshield Wipers............................ 4-79
10-10
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08
