light MAZDA CX9 2023 Owners Manual

Interior Equipment (View A)
ƒDoor-lock knob..................................................................................................... page 3-17
„ Turn and lane-change sig nal..................................................................................page 4-78
… Lighting control.....................................................................................................page 4-71
† Wiper and washer lever......................................... ................................................ page 4-79
‡ TCS OFF switch................................................................................................. page 4-106
ˆ Lane-keep Assist System (LAS) & Lane Departure Warning System ( LDWS) OFF
switch.................................................................................................................. page 4 -162
‰ Parking sensor switch......................................................................................... page 4-280
Š 360° View Monitor switch..................................................................................page 4-190
‹ Off-Road Traction Assist switch................................ ......................................... page 4-110
ΠPower liftgate switch.......................................... ................................................... page 3-20
Outside mirror switch.......................................... ..................................................page 3-32
Ž Door-lock switch................................................................................................... page 3-16
Power window lock switch................................................................................... page 3-37
Power window switches.......................................... .............................................. page 3-37
Pictorial Index
Interior Overview
1-2The equipment and installation position varies by vehicle
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Interior Equipment (View D)
ƒSeat belts..................................................... .......................................................... page 2-35
„ SRS air bag............................................................................................................page 2- 69
… Rear door sunshade............................................................................................... page 5-77
† Bottle holder.................................................. ........................................................ page 5-71
‡ Sunvisor....................................................... ..........................................................page 5-57
ˆ Vanity mirror......................................................................................................... page 5-5 7
‰ Overhead lights..................................................................................................... page 5-58
Š Moonroof switch................................................................................................... page 3-40
‹ Rearview mirror................................................ .................................................... page 3-34
ΠAccessory socket............................................... .................................................... page 5-62
Cup holders........................................................................................................... page 5-6 9
Ž Front seat................................................................................................................. pag e 2-5
Center console....................................................................................................... page 5-72
External input terminal........................................ ........................................ page 5-14, 5-34
‘ Seat warmer switches........................................... ................................................. page 2-31
’ Second-row seat................................................ .................................................... page 2-15
“ USB power outlet.................................................................................................. page 5-63
” Third-row seat....................................................................................................... page 2-26
Pictorial Index
Interior Overview
The equipment and installation position varies by vehicle1-5
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

ƒHood........................................................... ........................................................... page 6-17
„ Windshield wiper blades........................................ ............................................... page 6-26
… Moonroof...............................................................................................................page 3- 40
† Door and key......................................................................................................... page 3-12
‡ Fuel-filler lid......................................................................................................... page 3 -30
ˆ Wheels and Tires................................................................................................... page 6-35
‰ Exterior lights................................................ ........................................................ page 6-40
Š Rear window wiper blade........................................ ..............................................page 6-29
‹ Liftgate....................................................... ........................................................... page 3-19
ΠChild safety lock................................................................................................... page 3-18
Outside mirror....................................................................................................... page 3-32
Pictorial Index
Exterior Overview
1-6The equipment and installatio n position varies by vehicle
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Make sure the lever returns to its original position and the seat is locked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the seat to the front or back
and hold it. Release the switch at the desired position.
Height Adjustment
(Manual Seat)
To adjust the seat height, move the lever up or down.
(Power Seat)
To adjust the seat height, move the slide lifter switch up or down.
Height Adjustment for Front Edge of Seat Bottom (Power Seat)*
To adjust the front height of th e seat bottom, raise or lower the front of the slide lifter
switch.
Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
(Power Seat)
To change the seatback angle, pr ess the front or rear side of the reclining switch. Release the
switch at the de sired position.
Lumbar Support Adjustment (Power Seat)*
To increase the seat firmness, p ress and hold the front part of the switch to the desired
position, then release it.
Press the rear part of the switch to decrease firmness.
Before making adjustments to the driving position recommended by Mazda
Before making adjustments, move the steering wheel and seat to their default positions.
How to move the steering wheel to its default position
WA R N I N G
Never adjust the steering wheel while the vehicle is moving:
Adjusting the steering wheel while the vehicle is moving is dangerous. Moving it can very
easily cause the driver to abruptly turn to the left or right. This can lead to loss of control or an
accident.
Essential Safety Equipment
Seats
2-6*Some models.
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

After adjusting the steering wheel position, make sure it is securely locked by trying to move it
up and down:
Driving with the steering wheel not securely locked in position is dangerous. If the steering
wheel moves unexpectedly while driving, you coul d lose control of the steering resulting in an
accident.
Lower the lever, move the steerin g wheel to the lowest position, and then push it down and
all the way back.
Lock release lever
How to move a driver’s seat to its default position
1. Slide the seat all the way back.
2. Lower the seat to its lowest height.
3. Sit squarely in the seat and rest your back against the seatb ack.
Seat adjustment procedure for the driving position recommended by Mazda
Adjusting the seatback angle (reclining)
Adjust the seatback to the angle providing a comfortable seated posture.
1. With your posture slightly slouched, move the seatback forwar d to the angle where your
waist feels sli ghtly cramped.
Manual Seat Power Seat
Essential Safety Equipment
Seats
2-7
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

2. Move the seatback backward to a comfortable seated posture without any feeling of
cramping in your waist.
Manual Seat Power Seat
Adjusting the seat position forward and back (sliding)
Adjust the seat to the position best for operating the accelera tor and brake pedals.
1. Place your left foot on the fo otrest, your right foot between the accelerator and brake
pedals, and position your heel to the position allowing easy sw itching between the
pedals.
2. With your heel set on the fl oor, set your right foot on the b rake pedal and move the seat
forward as far as possible until you feel a slight cramping in your ankle.
Manual Seat Power Seat
3. With your right foot set on the brake pedal, move the seat ba ck until you no longer feel
cramping in your ankle.
4. With your heel set on the floor, make sure you can move your foot between the brake
pedal and accelerator pedal smoothly.
Essential Safety Equipment
Seats
2-8
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

▼Adjusting the Fron
t Passenger's Seat
Power operation
Seat Slide
(Manual Seat)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
(Power Seat)
To slide the seat, move the slide lifter switch on the outside of the seat to the front or back
and hold it. Release the sw itch at the desired position.
Height Adjustment (Power Seat)*
To adjust the seat height, move the slide lifter switch up or down.
Seat Recline
(Manual Seat)
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
(Power Seat)
To change the seatback angle, press the front or rear side of t he reclining switch. Release the
switch at the desired position.
Essential Safety Equipment
Seats
*Some models.2-13
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

Second-row Seat (6:4 Split Adjustable-type Bench SeatTy p e )
▼Seat Operation
Seat Slide (Forwar
d-back adjustment)
To move a seat forward or backward, raise the lever and slide t he seat to the desired position
and release the lever.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
Seat Recline
To change the seatback angle, lean forward slightly while raisi ng the lever. Then lean back
to the desired position and release the lever.
The lever can also be used when flattening down the seats.
Refer to Split Fold ing the Second-row Seats on page 2-20.
Make sure the lever returns to i ts original position and the seatback is locked in place by
attempting to push it forward and backward.
Third-row Seat Access
(Lever)
Pull up the lever on the side of the head restraint to fold the seatback and slide the seat
forward.
Refer to Third-row Seat Access on page 2-16.
Make sure the lever returns to i ts original position and the seat is locked in place by
attempting to push it forward and backward.
Essential Safety Equipment
Seats
2-15
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

There is a system problem.
CAUTION
Do not operate the lever on the side of a
second-row seat while the seatback is
folded down and the se at is slid forward.
If the lever is forcefully operated, it could
damage the lever.
 After entering/exiting the third-row seat
area, return the second-row seatback to
its upright position and lock it after
sliding it rearward.
Make sure it is locked by attempting to
lightly move it back and forth.
Otherwise, it could move unexpectedly
and cause injury.
After getting in or out of the vehicle
Move the seatback rearward, slide the seat
rearward, and lock the seat.
Entering/exiting the third-row seat area
with child-restraint system installed
(Right-side seat only)
Access to the third-row seats is possible
even when a child-restraint system is
installed to the second-row seat.
(Lever)
Pull up the lever on the side of the head
restraint to lower the front side of the seat
and slide the seat forward.
(Switch)
To unlock the seat, press the switch
continuously until a sound is activated,
release it, fold the seatback forward, and
slide the seat forward.
NOTE
When any of the following conditions is
met, a beep sound is activated
continuously and the switch operation is
canceled.
The door on the side where the switch
was operated is closed.
The switch is pressed continuously for 5
s or more.
The vehicle is being driven.
The selector lever is in a position other
than P, and the parking brake is off.
The battery has deteriorated.
Essential Safety Equipment
Seats
2-19
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08

There is a system problem.
CAUTION
After entering/exiting the third-row seat
area, lock the seat after sliding it rearward.
Make sure it is locked by attempting to
lightly move it back and forth.
Otherwise, it could move unexpectedly and
cause injury.
Second-row seat
fixed position Third-row seat
in
gress/egress
NOTE
The second-row seat cannot be moved
forward while the seat belt is securing the
child-restraint system.
After getting in or out of the vehicle
Move the seatback rearward, slide the seat
rearward, and lock the seat.
▼
Split folding the
Second-row Seats
To create a flat luggage compartment
space, fold the seatbacks forward.
Folding the seatbacks
WA R N I N G
Make sure the adjustable components of a
second-row seat are locked after folding
down the seatback:
A second-row seat that is not securely
locked is dangerous. In a sudden stop or
collision, the second-row seat could move,
causing injury.
After folding down the seatback of a
second-row seat, make sure the adjustable
components of the seat are locked in place
by attempting to slide the seat forward and
backward.
CAUTION
 When folding the seatback forward,
always support the seatback with your
hand. If it is not supported by a hand,
fingers or the hand raising the lever
could be injured.
 Check the position of a front seat before
folding a second-row seatback.
Depending on the position of a front
seat, it may not be possible to fold a
second-row seatback all the way down
because it may hit the seatback of the
front seat which could scratch or
damage the front seat or its pocket.
Remove the head restraint on the
second-row outboard seat if necessary.
Essential Safety Equipment
Seats
2-20
CX-9_8LJ2-EA-22H_Edition1_old 2022-6-9 13:33:08
