MAZDA CX90 2024 Owners Manual

Cargo Weight includes all weight added to the Base Curb Weight, including cargo
and optional equipment. When towing, trailer tongue load or king pin weight is also
part of cargo weight.

The cargo weight limit decreases depending on the number of vehicle occupants.
The cargo weight limit can be calculated by subtracting the total weight of the
vehicle occupants from the “combination weight of occupants and cargo should
never exceed” value on the tire label.

Examples: Based on a single occupant weig ht of 68 kg (150 lbs), and a value of 385
kg (849 lbs) for the “combination weight of occupants and cargo should never
exceed”:
The cargo weight limit with one occupant is 385 kg (849 lbs) － 68 kg (150 lbs) =
317 kg (699 lbs)
The cargo weight limit with two occupants is 385 kg (849 lbs) － (68 × 2) kg ( (150
× 2) lbs) = 249 kg (549 lbs)
If the weight of the occupant increases, the cargo weight limit decreases by that
much.

GAW (Gross Axle Weight) is the total weight placed on each axle (front and rear) -
including vehicle curb weight and all payload.

GAWR (Gross Axle Weight Rating) is the maximum allowable weight that can be
carried by a single axle (front or rear). These numbers are shown on the Safety
Compliance Certification Label located on the driver's door frame or door pillar.
The total load on each axle must never exceed its GAWR.

GVW
GVW
GVW (Gross Vehicle Weight) is the Vehicle Curb Weight + cargo + passengers.

Specifications/Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
10-42
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

GVWR (Gross Vehicle Weight Rating) is the maximum allowable weight of the fully
loaded vehicle (including all options, equipment, passengers and cargo). The GVWR
is shown on the Safety Compliance Certification Label located on the driver's
door frame or door pillar. The GVW must never exceed the GVWR.

SAMPLE
WARNING
Never Exceed Axle Weight Rating Limits.
Exceeding the Safety Certification Label axle weight rating limits is dangerous and
could result in death or serious injury as a result of substandard vehicle handling ,
performance, engine, transmission and/or structural damage, serious damage to the
vehicle, or loss of control.
Always keep the vehicle within the axle weight rating limits.

GCW
GCW
Specifications/Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
10-43
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW) plus
the weight of the fully loaded trailer.

GCWR (Gross Combination Weight Rating) is the maximum allowable weight of
the vehicle and the loaded trailer - incl uding all cargo and passengers - that the
vehicle can handle without risking damage. (Important: The towing vehicle's braking
system is rated for operation at GVWR, not at GCWR. Separate functional brakes
should be used for safe control of towed vehicles and for trailers weighing more than
1,500 lbs). The GCW must never exceed the GCWR.

Maximum Loaded Trailer Weight is the highest possible weight of a fully loaded
trailer the vehicle can tow. It assumes a vehicle with only mandatory options, no
cargo (internal or external), a tongue load of 10 －15% (conventional trailer) or king
pin weight of 15 －25% (fifth-wheel trailer), and driver only (150 lbs). Consult your
dealership (or the RV and Trailer Towing Guide provided by your dealership) for
more detailed information.
Tongue Load or Fifth-Wheel King Pin Weight refers to the amount of the weight that
a trailer pushes down on a trailer hitch.

Examples: For a 5000 lb conventional trailer, multiply 5000 by 0.10 and 0.15 to
obtain a proper tongue load range of 500 to 750 lbs. For an 11,500 lb fifth-wheel
trailer, multiply by 0.15 and 0.25 to obt ain a proper king pin load range of 1,725 to
2,875 lbs.
WARNING
Never Exceed GVWR or GAWR Specifications.
Exceeding the GVWR or the GAWR specified on the certification label is dangerous.
Exceeding any vehicle rating limitation could result in a serious accident, injury, or
damage to the vehicle.
Do not use replacement tires with lower lo ad carrying capacities than the originals
because they may lower the vehicle's GVWR and GAWR limitations. Replacement
tires with a higher limit than the orig inals do not increase the GVWR and GAWR
limitations.
Never exceed the GVWR or the GAWR specified on the certification label.
Specifications/Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
10-44
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Steps for Determining the Correct Load Limit
Steps for Determining Correct Load Limit-
(1) Locate the statement “The combined weight of occupants and cargo should
never exceed XXX kg or XXX lbs.” on your vehicle's placard.
(2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
(3) Subtract the combined weight of the dr iver and passengers from XXX kg or XXX
lbs.
(4) The resulting figure equals the available amount of cargo and luggage load capacity. For example, if the “XXX” amount equals 1400 lbs. and there will be
five 150 lb passengers in your vehicle, the amount of available cargo and
luggage load capacity is 650 lbs. (1400 － 750 (5 × 150) = 650 lbs.)
(5) Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load
capacity calculated in Step 4.
(6) If your vehicle will be towing a trailer, load from your trailer will be transferred to
your vehicle. Consult this manual to determine how this reduces the available
cargo and luggage load capacity of your vehicle.
Specifications/Customer Information and Reporting Safety Defects
Tire Information (U.S.A.)
10-45
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04

Keyless Entry System/Immobilizer System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-46
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

HomeLink Wireless Control System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-47
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Charging
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-48
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Tire Pressure Monitoring System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-49
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Front Radar Sensor System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-50
CX-90_8KG7-EA-22L_Edition1_new2022-11-17 16:05:04

Front Side Radar Sensor System/Rear Side RadarSensor System
Specifications/Customer Information and Reporting Safety Defects
Declaration of Conformity
10-51
CX-90_8KG7-EA-22L_Edition1_new 2022-11-17 16:05:04
