Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Lights-on reminder
*4 The volume of the lights-on reminder warning
alarm can be changed.
Refer to Settings on page 5-55 . Off High/Low/Off
Blind Spot
Monitoring (BSM)
system The volume of the BSM warning beep can be
changed.
*5
Refer to Settings on page 5-55 .
High High/
Low/ Off
Lane Departure
Warning System
(LDWS) The warning sound for the Lane Departure
Warning System (LDWS) can be changed.
*6
Refer to Settings on page 5-55 .
Beep Beep/Rumble Strip
The volume of the warning sound
for the Lane Departure Warning
System (LDWS) can be changed.
Refer to Settings on page 5-55 . Rumble
strip
High High/Mid/Low
Beep High High/Low
The sensitivity of the warning for the Lane
Departure Warning System (LDWS) can be
changed.
Refer to Settings on page 5-55 . Low High/Low
The warning timing in which the Lane
Departure Warning System (LDWS)
determines that the vehicle may be deviating
from its lane can be changed.
Refer to Settings on page 5-55 . Before line At line/Before line
Meter display The distance unit can be changed.
Refer to Settings on page 5-55 .
Miles or Km Miles/Km
The display language can be changed.
Refer to Settings on page 5-55 . English, French,
or Spanish English/
French/
Spanish
The temperature unit can be changed.
Refer to Settings on page 5-55 . F° or C° F°/C°
Forward Obstruction
Warning (FOW) The system can be changed so that Forward
Obstruction Warning (FOW) does not
operate.
*3
Refer to Settings on page 5-55 .
On On/Off
The distance at which the collision warning
activates can be changed.
Refer to Settings on page 5-55 . Near Near/Far
The volume of the collision warning can be
changed.
Refer to Settings on page 5-55 . High High/Low/Off
Smart City Brake
Support (SCBS) The system can be changed so that Smart City
Brake Support (SCBS) does not operate.
*3
Refer to Settings on page 5-55 .
On On/Off
Fuel Economy
Monitor Setting can be changed so that the ending
screen of the Fuel Economy Monitor is
displayed.
Refer to Fuel Economy Monitor on page 4-86 .
OFF ON/OFF
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

9–15
Specifi cations
Personalization Features
Item Feature Factory Setting Available Settings
Fuel economy
resetting procedure Setting can be changed so that the fuel
economy reset is linked with the trip meter
reset.
Refer to Fuel Economy Monitor on page 4-86 .
OFF
ON/OFF
Active driving
display Setting can be changed so that the Turn-by-
Turn (TBT) of the Active driving display is not
displayed.
Refer to Active driving display on page 4-19 .
On
On/Off
*1 If the setting is changed to Off, the following operation is performed according to the headlight switc\
h position:
y At position: Headlights turn off immediately after the ignition is switched off.y At any position other than : Headlights do not turn off after the ignition is switched off.
*2 When set to Off, the lights-on reminder is operable.
*3 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On.
*4 The setting of the lights-on reminder can be changed with the time setti\
ng of auto headlight off function set to Off. Refer to Lights-On Reminder on page 7-36 .
*5 Only the volume of the warning beep during Blind Spot Monitoring (BSM)\
operation can be changed. The volume of the warning beep during Rear Cross Traffi c Alert (RCTA) operation cannot be changed.
*6 For vehicles with an audio system other than the on-screen function type\
, the warning sound cannot be changed. The warning sound is only a beep.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–2
Index
A
Accessory Socket .............................. 5-136
Active Driving Display ....................... 4-19
Adaptive Front Lighting System
(AFS).................................................. 4-46
Add-On Non-Genuine Parts and
Accessories ......................................... 8-18
Advanced Key Advanced keyless entry system ...... 3-9
Advanced Key removed from vehicle
warning beep ....................................... 7-37
Operational range .......................... 3-10
Air Bag/Front Seat Belt Pretensioner
System Warning Beep ......................... 7-36
Air Bag Systems ................................. 2-40
Ambient Temperature Display ............ 4-16
Antilock Brake System (ABS) ............ 4-79
Audio Control Switch Adjusting the Volume .................... 5-58
Mute Switch .................................. 5-59
Seek Switch ................................... 5-58
Audio System ...................................... 5-16 AUX/USB/iPod mode ................... 5-59
Antenna ......................................... 5-16
Audio Control Switch ................... 5-58
Audio Set (Type A) ....................... 5-26
Audio Set (Type B) ....................... 5-38
Operating Tips for Audio System ... 5-17
Satellite Radio ............................... 5-48
Automatic Transaxle ........................... 4-30 Active Adaptive Shift (AAS) ........ 4-32
Direct Mode .................................. 4-39
Driving tips.................................... 4-40
Manual shift mode......................... 4-33
Shift-lock system ........................... 4-32
Shift position indication ................ 4-31
Warning light ................................. 4-31
B
Battery ................................................. 6-37 Maintenance .................................. 6-38
Specifi cations .................................. 9-4
Battery runs out ................................... 7-15 Jump-Starting ................................ 7-15
Blind Spot Monitoring (BSM)
System ............................................... 4-108 BSM OFF switch......................... 4-114
BSM warning light ...................... 4-113
Blind Spot Monitoring (BSM) .... 4-109
Care of radar sensors ................... 4-114
Blind Spot Monitoring (BSM) System
warning beep ....................................... 7-38
Blind Spot Monitoring (BSM) system
Rear Cross Traffi c Alert (RCTA) ... 4-111
Bluetooth® ........................................... 5-75
Bluetooth® Audio (Type A) ......... 5-114
Bluetooth® Audio (Type B) ......... 5-116
Bluetooth® Hands-Free (Type A) ... 5-95
Bluetooth® Hands-Free (Type B) ... 5-102
Troubleshooting .......................... 5-129
Body Lubrication ................................ 6-32
Bottle Holder ..................................... 5-138
Brakes Brakes assist .................................. 4-70
Foot brake...................................... 4-68
Pad wear indicator ......................... 4-69
Parking brake ................................ 4-69
Warning light ................................. 4-69
Break-In .............................................. 3-45
C
Capacities .............................................. 9-5
Carbon Monoxide ............................... 3-29
Cell Phones ......................................... 8-19
Center Console .................................. 5-140
Child Restraint
Child-restraint precautions ............ 2-22
Installing child-restraint systems... 2-28
LATCH child-restraint systems ..... 2-36
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–3
Index
Child Safety Locks for Rear Doors ..... 3-20
Climate Control System ........................ 5-2 Automatic Climate Control ............. 5-9
Dual-Zone Automatic Climate
Control........................................... 5-12
Gas specifi cations ............................ 9-8
Manual Climate Control .................. 5-5
Operating Tips ................................. 5-2
Vent Operation ................................ 5-3
Clock ................................................... 5-30
Collision warning ................................ 7-39
Control Status Display ........................ 4-87
Cruise Control ................................... 4-100 Cruise Control Switch ................. 4-100
Cruise Control Set Vehicle Speed
Display ................................................ 4-17
Cup Holder ........................................ 5-137
Customer Assistance ............................. 8-2
D
Dashboard Illumination ...................... 4-16
Daytime Running Lights ..................... 4-47
Defroster Mirror ............................................ 4-57
Rear window ................................. 4-56
Dimensions ........................................... 9-6
Direct Mode Automatic transaxle ...................... 4-39
Door Locks .......................................... 3-11
Drive selection .................................... 4-88
Driving In Flooded Area ..................... 3-49 Driving Tips
Automatic transaxle ...................... 4-40
Break-in ......................................... 3-45
Driving in fl ooded area.................. 3-49
Driving on uneven road ................. 3-51
Floor mat ....................................... 3-46
Hazardous driving ......................... 3-46
Money-saving suggestions ............ 3-45
Overloading ................................... 3-50
Rocking the vehicle ....................... 3-47
Winter driving ............................... 3-47
Driving on Uneven Road .................... 3-51
Dynamic Stability Control (DSC) ....... 4-81 DSC OFF Indicator Light.............. 4-82
DSC OFF Switch........................... 4-82
TCS/DSC Indicator Light ............. 4-81
E
Emergency Starting Push-Starting ................................. 7-18
Starting a Flooded Engine ............. 7-18
Emergency Towing Tiedown Hooks ............................. 7-22
Towing Description ....................... 7-21
Emission Control System .................... 3-28
Ending Screen Display ........................ 4-87
Engine Coolant .......................................... 6-29
Engine Compartment Overview .... 6-26
Exhaust gas.................................... 3-29
Hood release .................................. 6-24
Oil .................................................. 6-27
Starting ............................................ 4-5
Essential information ............................ 6-2
Event Data Recorder ........................... 8-20
Exhaust Gas ........................................ 3-29
Exterior Care ....................................... 6-63 Aluminum Wheel Maintenance .... 6-68
Bright-Metal Maintenance ............ 6-67
Maintaining the Finish .................. 6-65
Plastic Part Maintenance ............... 6-69
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–4
Index
F
Flasher Hazard warning ............................. 4-58
Headlights ..................................... 4-41
Flat Tire ................................................. 7-3 Mounting the Spare Tire................ 7-11
Removing a Flat Tire ....................... 7-7
Floor Mat ............................................ 3-46
Fluid Brake/Clutch ................................. 6-31
Washer ........................................... 6-31
Fluids Classifi cation ................................... 9-4
Fog Lights ........................................... 4-51
Foot Brake ........................................... 4-68
Forward Obstruction Warning
(FOW) ............................................... 4-116 Collision Warning ....................... 4-118
Rader Sensor ............................... 4-118
Forward Sensing Camera .................... 4-63
Front Seat .............................................. 2-5
Fuel Filler lid and cap............................ 3-30
Gauge ............................................ 4-15
Requirements................................. 3-27
Tank capacity .................................. 9-5
Fuel Consumption Display ................. 4-86
Fuel Economy Monitor ....................... 4-86 Control status display .................... 4-87
Ending screen display ................... 4-87
Fuel consumption display ............. 4-86
G
Gauges ................................................. 4-12
Glove Compartment .......................... 5-139
H
Hazard Warning Flasher ...................... 4-58
Hazardous Driving .............................. 3-46
Head Restraint ..................................... 2-10 Headlights
Control........................................... 4-41
Flashing ......................................... 4-45
High-low beam .............................. 4-45
Leveling......................................... 4-45
High Beam Control System (HBC) .... 4-48
Hill Launch Assist (HLA) ................... 4-70
HomeLink Wireless Control System ... 4-59
Hood Release ...................................... 6-24
Horn .................................................... 4-58
I
i-ELOOP ............................................. 4-83 Control status display .................... 4-85
Display .......................................... 4-83
i-ELOOP indicator light ................ 4-85
i-ELOOP warning beep ....................... 7-38
If a Warning Light Turns On or
Flashes................................................. 7-24
If the Active Driving Display (ADD)
does not operate .................................. 7-42
Ignition Switch .............................................. 4-4
Ignition not switched off (STOP)
warning beep ....................................... 7-37
Immobilizer System ............................ 3-41
Indicator Lights ................................... 4-24 AFS OFF ....................................... 4-46
BSM OFF .................................... 4-114
Low engine coolant temperature ... 4-26
Wrench .......................................... 4-26
Inside Trunk Release Lever ................ 3-25
Inspecting Brake/Clutch Fluid Level .. 6-31
Inspecting Coolant Level .................... 6-29
Inspecting Engine Oil Level ............... 6-28
Inspecting Washer Fluid Level............ 6-31
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–5
Index
Interior Care ........................................ 6-69 Cleaning the Lap/Shoulder Belt
Webbing ........................................ 6-71
Cleaning the Upholstery and Interior
Trim ............................................... 6-70
Cleaning the Window Interiors ..... 6-71
Dashboard Precautions .................. 6-69
Maintenance of the Active Driving
Display .......................................... 6-71
Interior Lights ................................... 5-134 Luggage Compartment Light ...... 5-134
Map Lights .................................. 5-134
Overhead Lights .......................... 5-134
J
Jack ....................................................... 7-4
Jump-Starting ...................................... 7-15
K
Key Suspend Function .......................... 3-8
Key left-in-luggage compartment
warning beep (With the advanced keyless
function) .............................................. 7-37
Key left-in-vehicle warning beep (With
the advanced keyless function) ........... 7-38
Keyless Entry System ........................... 3-3
Keys ...................................................... 3-2 Key suspend function ...................... 3-8
Transmitter ...................................... 3-4
L
Label Information ................................. 9-2
Lane-Change Signals .......................... 4-52
Lane Departure Warning System
(LDWS) ............................................. 4-119 Canceling the system................... 4-123
LDWS warning ........................... 4-124
When the system operates ........... 4-122
Lane departure warning system (LDWS)
warning sound ..................................... 7-38 Liftgate ................................................ 3-21
Light Bulbs
Replacement .................................. 6-45
Specifi cations .................................. 9-9
Lighting Control.................................. 4-41
Lights-on reminder .............................. 7-36
Lubricant Quality .................................. 9-4
Luggage Compartment Light ............ 5-134
M
Maintenance Information ...................................... 6-2
Scheduled ........................................ 6-4
Maintenance Monitor .......................... 6-20
Manual Transaxle Operation ............... 4-27
Recommendations for shifting ...... 4-29
Map Lights ........................................ 5-134
Mazda Radar Cruise Control (MRCC) ... 4-91
Close Proximity Warning .............. 4-94
Display Indication ......................... 4-94
Radar Sensor Handling ................. 4-99
Setting the System ......................... 4-95
Shift-up/Shift-down Request
Display .......................................... 4-99
Mazda Radar Cruise Control (MRCC)
System warnings ................................. 7-39
Meters and Gauges .............................. 4-12
Mirror Defroster .................................. 4-57
Mirrors Outside mirrors.............................. 3-33
Rearview mirror ............................ 3-34
Money-Saving Suggestions ................ 3-45
Moonroof ............................................ 3-39
O
Odometer and Trip Meter .................... 4-13
Outside Mirrors ................................... 3-33
Outside Temperature Display .............. 4-16
Over Rev. buzzer ................................. 7-39
Overhead Console ............................. 5-139
Overhead Lights ................................ 5-134
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–6
Index
Overheating ......................................... 7-19
Overloading ......................................... 3-50
Owner Maintenance Battery replacement ...................... 6-39
Closing the Hood........................... 6-24
Engine Compartment Overview .... 6-26
Opening the Hood ......................... 6-24
Owner Maintenance Precautions... 6-22
P
Parking Brake ...................................... 4-69
Personalization Features ..................... 9-12
Power Steering .................................... 4-90
Power Windows .................................. 3-36
Power steering warning buzzer ........... 7-39
R
Radar Sensor ....................................... 4-65
Rear Coat Hooks ............................... 5-140
Rear Cross Traffi c Alert (RCTA) ...... 4-111
Rear Door Child Safety Locks ............ 3-20
Rear Seat ............................................... 2-8
Rear View Monitor............................ 4-125 Displayable range on the screen .. 4-127
Picture quality adjustment ........... 4-132
Rear view monitor operation ....... 4-128
Rear view parking camera
location ........................................ 4-126
Switching to the rear view monitor
display ......................................... 4-126
Variance between actual aoad
conditions and displayed Image
... 4-131
Viewing the display ..................... 4-128
Rear Window Defroster ...................... 4-56
Rear Window Washer .......................... 4-56
Rear Window Wiper ............................ 4-56
Rearview Mirror .................................. 3-34
Recommended Oil .............................. 6-27
Recreational Towing ........................... 3-52
Registering Your Vehicle in A Foreign
Country ............................................... 8-17 Replacement
Electrical battery ........................... 6-39
Fuse ............................................... 6-58
Light Bulbs .................................... 6-45
Tires ............................................... 6-43
Wheel ............................................ 6-44
Wiper ............................................. 6-33
Rocking the Vehicle ............................ 3-47
S
SRS Air Bags Front passenger occupant
classifi cation system ...................... 2-56
How the SRS air bags work .......... 2-49
Limitations to SRS air bag ............ 2-54
Monitoring..................................... 2-61
SRS air bag deployment criteria ... 2-53
Supplemental restraint system
components ................................... 2-47
Safety Defects, Reporting ................... 8-13
Satellite Radio ..................................... 5-48
Scheduled Maintenance ........................ 6-4
Seat Belt System 2-point type ................................... 2-18
3-point type ................................... 2-15
Automatic locking ......................... 2-14
Emergency locking ........................ 2-14
Extender ........................................ 2-20
Pregnant women ............................ 2-14
Seat belt warning beep ........................ 7-37
Seats Front seat ......................................... 2-5
Head restraint ................................ 2-10
Rear seat .......................................... 2-8
Seat warmer ..................................... 2-7
Security System Immobilizer system ....................... 3-41
Theft-deterrent system .................. 3-43
Sensor
Radar Sensor ................................. 4-65
Service Publications ............................ 8-49
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

10–7
Index
Smart City Brake Support (SCBS) ..... 4-72
Deactivating the Smart City Brake
Support (SCBS) System operation
... 4-78
Laser sensor handling .................... 4-76
Smart City Brake Support (SCBS)
Warning Light (Red) ..................... 4-78
Spare Tire .............................................. 7-5
Specifi cations ........................................ 9-4
Speed Unit Selector ............................. 4-13
Speedometer ........................................ 4-13
Starting the Engine ................................ 4-5
Steering Wheel .................................... 3-32
Horn............................................... 4-58
Storage Compartments ...................... 5-139 Center console ............................. 5-140
Glove compartment ..................... 5-139
Overhead console ........................ 5-139
Rear coat hooks ........................... 5-140
Sunshade ............................................. 3-40
Sunvisors ........................................... 5-133
T
Tachometer .......................................... 4-14
Theft-Deterrent System ....................... 3-43
Tiedown Hook .............................................. 7-22
Tire Information .................................. 8-23
Tire Pressure Monitoring System ..... 4-104
Tire infl ation pressure warning beep ... 7-38
Tires .................................................... 6-41
Flat Tire ........................................... 7-3
Replacing a Tire ............................ 6-43
Replacing a Wheel ........................ 6-44
Snow tires ...................................... 3-48
Specifi cations ................................ 9-10
Temporary Spare Tire .................... 6-43
Tire Infl ation Pressure ................... 6-41
Tire Rotation ................................. 6-42
Tire chains ..................................... 3-48
Uniform tire quality grading system
(UTQGS) ....................................... 8-21 Towing
Recreational towing ...................... 3-52
Trailer Towing ............................... 3-52
Towing Description ............................. 7-21
Traction Control System (TCS) .......... 4-80
TCS/DSC Indicator Light ............. 4-80
Transmitter ............................................ 3-4
Trip Computer ..................................... 4-17
Trip Meter ........................................... 4-13
Trouble Battery runs out ............................. 7-15
Emergency Starting ....................... 7-18
Emergency Towing........................ 7-21
Flat Tire ........................................... 7-3
Overheating ................................... 7-19
Parking in an Emergency ................ 7-2
When liftgate/trunk lid cannot be
opened ........................................... 7-40
Trunk Lid ............................................ 3-21 Inside trunk release lever .............. 3-25
V
Vanity Mirrors ................................... 5-133
Vehicle Information Labels ................... 9-2
W
Warning Lights .................................... 4-22
Warning Message Indicated on
Display ................................................ 7-34
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
