5–104
Interior Features
Bluetooth®
NOTE
If the contact is long-pressed when the
favorites list is displayed, the contact
information can be edited (deleted,
moved).
Telephone Number Input
NOTE
Practice this while parked until you are
confi dent you can do it while driving in a
non-taxing road situation. If you are not
completely comfortable, make all calls
from a safe parking position, and only
start driving when you can devote your full
attention to driving.
1. Input the telephone number using the numerical keypad.
2. Select the
icon to make the call.
Numeral or symbol entry
Use the numerical keypad.
Long-press the
icon to input +.
Select the
icon to delete the currently
input value.
Long-press the
icon to delete all input
values.
Mobile 911 (U.S.A./Canada only)
If the vehicle is involved in a moderate
to severe collision, a call is made
automatically to 911 from the connected
device. The “Mobile 911” setting must be
on.
Refer to Communication Settings on page
5-110 .
CAUTION


5–105
Interior Features
Bluetooth®
Receiving an Incoming Call
When an incoming call is received, the incoming call notifi cation screen is displayed. The
“Incoming Call Notifi cation” setting must be on.
Refer to Communication Settings on page 5-110 .
To accept the call, press the pick-up button or select the
icon.
To reject the call, press the hang-up button or select the
icon.
The following icons are displayed on the screen during a call. Icons whi\
ch can be used differ
depending on use conditions.
Icon Function
Displays the Communication menu.
Ends the call.
Transferring a call from hands-free to a mobile phone
Communication between the hands-free unit and a device (Mobile phone) \
is canceled, and
the line can be switched to the device (Mobile phone) as a standard ca\
ll.
Transferring a call from a device (mobile phone) to hands-free
Communication between devices (mobile phone) can be switched to Blueto\
oth ® Hands-
Free.
Mute
The microphone can be muted during a call.
When selected again, the mute is canceled.
A call is made to other person during a call and a 3-way call can be made\
. Select the contact
from the following to make a call.
: Call History is displayed.
: The phonebook is displayed.
: The dial pad is displayed. Input the phone number.
The device may be unusable depending on the contractual content.
The call on hold is made to make a 3-way call.
The device may be unusable depending on the contractual content.
Switches the call on hold.
DTMF (Dual Tone Multi-Frequency Signal) Transmission
This function is used when transmitting DTMF via the Numerical Keypad. The receiver of
a DTMF transmission is generally a home telephone answering machine or a\
company's
automated guidance call center.
Input the number using a numerical keypad.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–107
Interior Features
Bluetooth®
Receiving and Replying to Messages (available only with Email/SMS compatible phones)
SMS (Short Message Service) messages,
MMS (Multimedia Messaging Service)
messages, and E-mail received by
connected devices can be downloaded,
displayed, and played (read by the
system).
Additionally, replies can also be made
to calls and messages in the received
messages.
Downloading messages
Up to 20 new messages can be
downloaded and displayed from a
connected device.
NOTE
For e-mail, 20 messages for each account
can be downloaded.
(Automatic downloading)
The “Auto Download Email” (E-mail)
or “Auto Download Text” (SMS/MMS)
setting must be on. When the hands-free
unit is connected to the device, a message
is downloaded automatically.
Refer to Communication Settings on page
5-110 .
(Manually downloading)
When the “Auto Download Email”
(E-mail) or “Auto Download Text” (SMS/
MMS) setting is off, the phonebook
is downloaded using the following
procedure.
1. Select the
icon on the home screen
and display the Communication screen.
2. Select the
icon or icon to
display the Inbox.
3. Select the
icon.
4. Download will be started from the mobile phone.
NOTE
 y Attached data is not downloaded. y Messages up to 1 kilobyte (e-mail)/160-
bytes (SMS/MMS) can be downloaded.
 y A message list is created for each
device.
 y If the connected device does not
correspond to MAP 1.0, the AT
command is used to download. The
downloaded message indicates that it is
already read.
 y Downloading using the AT command
may not function depending on the
connected device.
Receiving messages
(Method 1)
When a device receives a message, a
message received notifi cation is displayed.
The “E-mail/SMS Notifi cations” setting
must be on.
Refer to Communication Settings on page
5-110 .
Select the
icon and display the
message.
(Method 2)
1. Select the
icon on the home screen
and display the Communication screen.
2. Select the
icon and display
the new message list for e-mail and
SMS/MMS.
3. Select the message you would like to display.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–10 8
Interior Features
Bluetooth®
The following icons are displayed in the lower part of the details on th\
e message. Icons
which can be used differ depending on use conditions.
Icon Function
Displays the Communication menu.
Displays the inbox.
Plays back a message.
When selected again, playback is temporarily stopped.
Displays the previous message.
Displays the next message.
Only replies to the sender of the currently displayed message.
Select the sentence on the displayed reply screen and select the sentenc\
e for sending from
the preset message.
Select the
icon.
(Only E-mail)
Replies to all members including CC.
Select the sentence on the displayed reply screen and select the sentenc\
e for sending from
the preset message.
Select the
icon.
Makes a call to a person who sent a message.
For E-mail, if a phone number of a person who sent a message is in the p\
honebook, a call
can be made.
Deletes a message.
The messages stored in a device is also deleted.
NOTE
Up to three preset messages can be selected.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–109
Interior Features
Bluetooth®
Example of use (verify unread E-mail)
1. Select the
icon on the home screen
and display the Communication screen.
2. Select the
icon to display the
inbox.
3. Select the unread message displayed in bold.
4. The details of the message are displayed and replying to the message,
making a call, or playback can be
performed.
Changing account for displaying
(E-mail only)
1. Select the
icon.
2. Select the account which you would like to display. Only the messages for
the selected account are displayed in
the inbox.
Editing preset messages
1. Select the
icon on the home screen
and display the Communication screen.
2. Select the
icon.
3. Select the
icon.
4. Select the preset message which you would like to edit. The keyboard screen
is displayed.
5. When the message is input and
is
selected, the message is stored as a
preset message.
NOTE
 y  Select the icon to change the
language.
 y  Select the icon to switch between
capitalized and lower-case characters.
 y  Select the icon to return to the
previous screen without storing the edit.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–110
Interior Features
Bluetooth®
Communication Settings
Select the icon on the home screen and display the Communication screen.
Select the
icon to change the setting.
Item Setting Function
Email/SMS
Notifi cations On/Off Notifi
es when a new messages is received.
Incoming Call
Notifi cation On/Off Notifi
es when an incoming call is received.
Auto Download Call
history On/Off Downloads Call History automatically when the hands-free unit is
connected to the device.
Auto Download
Contacts
* On/Off Downloads the phonebook automatically when the hands-free unit is
connected to the device.
Auto Download Text On/Off Downloads SMS/MMS automatically when the hands-free unit is
connected to the device.
Auto Download
Email
* On/Off Downloads E-mail automatically when the hands-free unit is connected
to the device.
Ringtone Fixed/In-band/
Off Changes the ringtone setting.
Phone Volume Adjusts using
the slider. Adjusts the conversation volume.
VR and Ringtone Adjusts using
the slider. Adjusts the voice guidance and ringtone volume.
Contacts Sort Order First Name,
Last Name Displays the contact information in alphabetical order of the fi
rst name.
Last Name, First Name Displays the contact information in alphabetical order of the last name.\

Preset Messages — Edits the preset message.
Refer to Receiving and Replying to Messages (available only with
E-mail/SMS compatible phones) on page 5-107 .
Mobile 911 On/Off Mobile Utilizes the Mobile 911 function.
Reset Communication
Settings — Initializes all Communication Settings.
* Depending on the device, it may be necessary to acquire download permiss\
ion on the
device side.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–111
Interior Features
Bluetooth®
Audio Operation Using Voice Recognition
Main audio operation
When the talk button is pressed and the following command is spoken out,\
the audio can be
operated. The commands in the () can be omitted. The specifi ed name and number are put
into the {}.
Voice command Function Corresponding audio
source
(Go to/Play) AM (Radio) Switches the audio source to AM radio. All
(Go to/Play) FM (Radio) Switches the audio source to FM radio. All
(Go to/Play) Bluetooth (Audio) Switches the audio source to BT audio. All
(Go to/Play) Pandora Switches the audio source to Pandora
® All
(Go to/Play) Aha (Radio) Switches the audio source to Aha™ Radio. All
(Go to/Play) Stitcher Switches the audio source to Stitcher™ Radio. All
(Go to/Play) USB 1 Switches the audio source to USB 1. All
(Go to/Play) USB 2 Switches the audio source to USB 2. All
Play Playlist {Playlist name} Plays the selected playlist. USB
Play Artist {Artist name} Plays the selected artist. USB
Play Album {Album name} Plays the selected album. USB
Play Genre {Genre name} Plays the selected genre. USB
Play Folder {Folder name} Plays the selected folder. USB
Play Audiobooks Displays the list at the top level of the Audiobooks. USB
Play Podcasts Displays the list at the top level of the Podcasts. USB
NOTE
 y The above commands are examples of the available commands. y Some commands cannot be used depending on devices and use conditions. y If the Bluetooth ® device, USB, or AUX is not connected, the related commands cannot be
used.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–112
Interior Features
Bluetooth®
Gracenote Database
When a USB device is connected to this unit and the audio is played, the\
album name,
artist name, genre and title information are automatically displayed if \
there is a match in
the vehicle's database compilation to the music being played. The information stored in this
device uses database information in the Gracenote music recognition serv\
ice.
CAUTION
For information related to the most recent Gracenote database which can be used and
how to install it, go to the Mazda Hands Free Website:
http://www.mazdahandsfree.com
Introduction
Music recognition technology and related data are provided by Gracenote \
® . Gracenote is the
industry standard in music recognition technology and related content de\
livery. For more
information visit www.gracenote.com.
CD and music-related data from Gracenote, Inc., copyright © 2000 to p\
resent Gracenote.
Gracenote Software, copyright © 2000 to present Gracenote. One or mor\
e patents owned
by Gracenote apply to this product and service. See the Gracenote websit\
e for a non-
exhaustive list of applicable Gracenote patents. Gracenote, CDDB, MusicI\
D, MediaVOCS,
the Gracenote logo and logotype, and the “Powered by Gracenote” lo\
go are either registered
trademarks or trademarks of Gracenote in the United States and/or other \
countries.
Gracenote ® End User License Agreement
This application or device contains software from Gracenote, Inc. of Eme\
ryville, California
(“Gracenote”. The software from Gracenote (the “Gracenote Software” enables thi\
s
application to perform disc and/or fi le identifi cation and obtain music-related information,
including name, artist, track, and title information (“Gracenote Dat\
a” from online servers
or embedded databases (collectively, “Gracenote Servers” and to perform other functions.
You may use Gracenote Data only by means of the intended End-User functio\
ns of this
application or device.
You agree that you will use Gracenote Data, the Gracenote Software, and G\
racenote Servers
for your own personal non-commercial use only. You agree not to assign, copy, transfer or
transmit the Gracenote Software or any Gracenote Data to any third party\
. YOU AGREE
NOT TO USE OR EXPLOIT GRACENOTE DATA, THE GRACENOTE SOFTWARE, OR
GRACENOTE SERVERS, EXCEPT AS EXPRESSLY PERMITTED HEREIN.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–113
Interior Features
Bluetooth®
You agree that your non-exclusive license to use the Gracenote Data, the \
Gracenote
Software, and Gracenote Servers will terminate if you violate these rest\
rictions. If your
license terminates, you agree to cease any and all use of the Gracenote \
Data, the Gracenote
Software, and Gracenote Servers. Gracenote reserves all rights in Gracen\
ote Data, the
Gracenote Software, and the Gracenote Servers, including all ownership r\
ights. Under no
circumstances will Gracenote become liable for any payment to you for an\
y information
that you provide. You agree that Gracenote, Inc. may enforce its rights under this Agreement
against you directly in its own name.
The Gracenote service uses a unique identifi er to track queries for statistical purposes. The
purpose of a randomly assigned numeric identifi er is to allow the Gracenote service to count
queries without knowing anything about who you are. For more information\
, see the web
page for the Gracenote Privacy Policy for the Gracenote service.
The Gracenote Software and each item of Gracenote Data are licensed to y\
ou “AS IS.”
Gracenote makes no representations or warranties, express or implied, re\
garding the
accuracy of any Gracenote Data from in the Gracenote Servers. Gracenote \
reserves the right
to delete data from the Gracenote Servers or to change data categories f\
or any cause that
Gracenote deems suffi cient. No warranty is made that the Gracenote Software or Gracenote
Servers are error-free or that functioning of Gracenote Software or Gracenote Servers wil\
l
be uninterrupted. Gracenote is not obligated to provide you with new enh\
anced or additional
data types or categories that Gracenote may provide in the future and is\
free to discontinue
its services at any time.
GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT WARRANT THE RESULTS THAT
WILL BE OBTAINED BY YOUR USE OF THE GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL GRACENOTE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES OR FOR ANY LOST PROFITS OR
LOST REVENUES.
© 2000 to present. Gracenote, Inc.
Updating the database
The Gracenote media database can be updated using USB device.
1. Connect a USB device containing the software for updating Gracenote.
2. Select the
icon on the home screen and display the Settings screen.
3. Select the
tab and select the icon.
4. Select the
icon. The list of the update package stored in the USB device and the
version are displayed.
5. Select the package to use the update.
6. Select the
icon.
NOTE
Gracenote can be downloaded from the Mazda Hands-free Website.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.5–114
Interior Features
Bluetooth®
Bluetooth® Audio (Type A) *
Applicable Bluetooth ® specifi cation
Ver. 2.0 or higher
Response profi le
 y A2DP (Advanced Audio Distribution
Profi le) Ver. 1.0/1.2
 y AVRCP (Audio/Video Remote Control
Profi le) Ver. 1.0/1.3
A2DP is a profi le which transmits only
audio to the Bluetooth
® unit. If your
Bluetooth® audio device corresponds only
to A2DP, but not AVRCP, you cannot
operate it using the control panel of the
vehicle's audio system. In this case, the
Bluetooth
® audio device can be operated
by controlling the device itself, the same
as when a portable audio system without
the Bluetooth
® communication function is
connected to the AUX terminal.
Function A2DP AVRCP
Ver. 1.0 Ver. 1.3
Playback — X X
Pause — X X
File (Track) up/down — X X
Reverse — — X
Fast-forward — — X
Text display — — X
X: Available
—: Not available
NOTE
 y  The battery consumption of Bluetooth ®
audio devices increases while
Bluetooth® is connected. y If a general mobile phone device is
USB connected during music playback
over the Bluetooth
® connection, the
Bluetooth® connection is disconnected.
For this reason, you cannot have music
playback over a Bluetooth
® connection
and music playback using a USB
connection at the same time.
 y  The system may not operate normally
depending on the Bluetooth ® audio
device.
How to Use the Bluetooth ® Audio
System
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded
to a Bluetooth
® audio device, switch to
the Bluetooth ® audio mode to operate
the audio device using the audio system
control panel. Any Bluetooth
® audio
device must be programmed to the
vehicle's Bluetooth
® unit before it can be
used.
Refer to Bluetooth
® Preparation (Type A)
on page 5-78 .
1. Turn on the Bluetooth
® audio device's
power.
2. Switch the ignition to ACC or ON.
Make sure that the “
” symbol is
displayed in the audio display. The
symbol is not displayed if an un-
programmed Bluetooth
® audio device
is being used or the vehicle's
Bluetooth
® unit has a malfunction.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
