bluetooth MAZDA MODEL 3 4-DOOR 2014 Owner's Manual

5–89
Interior Features
Bluetooth®
 y It is not necessary to face the
microphone or approach it. Speak the
voice commands while maintaining a
safe driving position.
 y  Do not speak too slow or too loud. y Speak clearly, without pausing between
words or numbers.
 y  Close the windows and/or the moonroof
to reduce loud noises from outside
the vehicle, or turn down the airfl ow
of the air-conditioning system while
Bluetooth
® Hands-Free is being used. y  Make sure the vents are not directing air
up towards the microphone.
NOTE
If the voice recognition performance is not
satisfactory.
Refer to Voice Recognition Learning
Function (Speaker Enrollment) (Type A)
on page 5-90 .
Refer to Troubleshooting (Type A/Type B)
on page 5-129 .
Security Setting (Type A)
If a passcode is set, the system cannot be
activated unless the passcode is input.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
Passcode setting
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, confi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Passcode”
5. Prompt: “Passcode is disabled. Would you like to enable it?”
6. Say: [Beep] “Yes”
7. Prompt: “Please say a 4-digit passcode. Remember this passcode. It
will be required to use this system.”
8. Say: [Beep] “XXXX” (Say a desired 4-digit passcode, “PCode”.)
9. Prompt: “Passcode XXXX (Passcode, PCode). Is this correct?”
10. Say: [Beep] “Yes”
11. Prompt: “Passcode is enabled.”
Using Bluetooth
® Hands-Free with a
passcode
1. Press the pick-up button or talk button with a short press.
2. Prompt: “Hands-Free system is locked. State the passcode to continue.”
3. Say: [Beep] “XXXX” (Say the set passcode “PCode”.)
4. If the correct passcode is input, voice guidance “XXXXXX... (Ex. “Mary's
device”) (Device tag) is connected” is
announced.
If the passcode is incorrect, voice guidance “XXXX (4-digit passcode,
Pcode) incorrect passcode, please try
again” is announced.
Canceling the passcode
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, confi rmation prompts,
language, passcode, select phone or
select music player.”
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–90
Interior Features
Bluetooth®
4. Say: [Beep] “Passcode”
5. Prompt: “Passcode is enabled. Would you like to disable it?”
6. Say: [Beep] “Yes”
7. Prompt: “Passcode is disabled.”
Confi rmation Prompts
The confi rmation prompt confi rms the
command content to the user before
advancing to the operation requested by
the user. When this function is turned
on, the system reads out the voice
input command previously received
and confi rms whether the command is
correct before advancing to the command
execution.
When the confi rmation prompt function is
turned on:
(Ex. “Calling John's device. Is this
correct?”)
When the confi rmation prompt function is
turned off:
(Ex. “Calling John's device.”)
NOTE
If the confi rmation prompt function is
turned off when making an emergency
call, the system reads out and confi rms the
command before executing it.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, confi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Confi rmation prompts”
5. Prompt: “Confi rmation prompts
are on/off. Would you like to turn
confi rmation prompts off/on?”
6. Say: [Beep] “Yes”
7. Prompt: “Confi rmation prompts are
off/on.”
Voice Recognition Learning Function (Speaker Enrollment)
(Type A)
The voice recognition learning function
enables voice recognition appropriate to
the characteristics of the user's voice. If the
recognition of the voice input commands
to the system is not adequate, this function
can largely improve the system's voice
recognition of the user. If your voice can
be recognized suffi ciently without using
this function, you may not realize the
added benefi t of the function. To register
your voice, the voice input command
list must be read out. Read out the list
when the vehicle is parked. Perform the
registration in as quiet a place as possible
5-88 . The registration must be performed
completely. The required time is a few
minutes. The user needs to be seated in the
driver's seat with the voice input command
list for voice recognition learning open to
the page indicated below.
When voice recognition learning is done
for the fi rst time
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Voice training”
3. Prompt: “This operation must be performed in a quiet environment while
the vehicle is stopped. See the owner's
manual for the list of required training
phrases. Press and release the talk
button when you are ready to begin.
Press the hang-up button to cancel at
any time.”
4. Press the talk button with a short press.
5. The voice guidance reads out the voice input command number (refer to the
voice input command list for voice
recognition learning). (Ex. “Please read
phrase 1” )
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–91
Interior Features
Bluetooth®
6. Say: [Beep] “0123456789” (Say the voice input command for voice
recognition learning (1 to 8) according
to the voice guidance.)
7. Prompt: “Speaker enrollment is complete.”
NOTE
If an error occurred in the voice
recognition learning, re-learning can be
done by pressing the talk button with a
short press.
Voice recognition re-learning
If voice recognition learning has already
been done.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Voice training”
3. Prompt: “Enrollment is enabled/ disabled. Would you like to disable/
enable or retrain?”
4. Say: [Beep] “Retrain”
5. Prompt: “This operation must be performed in a quiet environment while
the vehicle is stopped. See the owner's
manual for the list of required training
phrases. Press and release the talk
button when you are ready to begin.
Press the hang-up button to cancel at
any time.”
6. Press the talk button with a short press.
7. The voice guidance reads out the voice input command number (refer to the
voice input command list for voice
recognition learning). (Ex. “Please read
phrase 1”)
8. Say: [Beep] “0123456789” (Say the voice input command for voice
recognition learning (1 to 8) according
to the voice guidance.)
9. Prompt: “Speaker enrollment is complete.”
NOTE
If an error occurred in the voice
recognition learning, re-learning can be
done by pressing the talk button with a
short press.
Voice input command list for voice
recognition learning
When reading out, the following points
must be observed:
 y Read out the numbers one at a time
correctly and naturally.
 (For example, “1234” must be read out “one, two, three, four” not “twelve,
thirty four”.)
 y Do not read out parentheses. “(” and
hyphens “-” are used for separating
numbers in a phone number.
Ex. “(888) 555-1212” must be spoken
“Eight, eight, eight, fi ve, fi ve, fi ve, one,
two, one, two.”
Phrase Command
1 0123456789
2 (888) 555-1212
3 Call
4 Dial
5 Setup
6 Cancel
7 Continue
8 Help
NOTE
 y  The applicable phrase appears in the
audio display.
 y After user voice registration is
completed, voice guidance “Speaker
enrollment is complete” is announced.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–92
Interior Features
Bluetooth®
Voice recognition learning on/off
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Voice training”
3. Prompt: “Enrollment is enabled/ disabled. Would you like to disable/
enable or retrain?”
4. Say: [Beep] “Disable” or “Enable”
5. When “Disable” is spoken, the voice recognition learning is turned off.
When “Enable” is spoken, the voice recognition learning is turned on.
6. Prompt: “Speaker Enrollment is disabled/enabled.”
Bluetooth ® Preparation (Type B)
Device programming (Pairing)
To use Bluetooth
® audio and Hands-Free,
the device equipped with Bluetooth ®
has to be programmed to the unit using
the following procedure. A maximum of
seven devices including Bluetooth
® audio
devices and hands-free mobile phones can
be programmed.
Pairing Procedure
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Turn the Bluetooth ® setting on.
5. Select the
icon to display
the message and switch to the device
operation.
6. Using your device, perform a search for the Bluetooth
® device (Peripheral
device).
7. Select “Mazda” from the device list searched by the device. 8. (Device with Bluetooth
® version 2.0)
Input the displayed 4-digit pairing code into the device.
(Device with Bluetooth
® version 2.1
or higher)
Make sure the displayed 6-digit code on the audio is also displayed on the
device, and touch the
icon.
A connection license agreement may be required depending on the device.
9. If pairing is successful, the profi le list
for the device is displayed.
10. (Devices compatible with Mazda Email / SMS function)
SMS (Short Message Service) messages, MMS (Multimedia
Messaging Service) messages, and
E-mail for the device are downloaded
automatically. A download permission
operation may be required depending
on your mobile device.
NOTE
When Call history and messages are
downloaded automatically, each automatic
download setting must be on.
Refer to Communication Settings on page
5-110 .
After a device is registered, the system
automatically identifi es the device. By
activating Bluetooth
® Hands-Free again, or
by activating Bluetooth ® Hands-Free fi rst
after switching the ignition from OFF to
ACC, the device connection condition is
indicated in the audio display.
IMPORTANT note about pairing and
automatic reconnection:
 y If pairing is to be redone, fi rst clear
the programmed device indicated as
“Mazda”.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–93
Interior Features
Bluetooth®
 y When you update the operating
system of your mobile device (such
as Windows/Android/iOS) the pairing
information may be invalidated.
Therefore, the device may need to be
reprogrammed to the hands-free unit.
 y  Before you pair your device, make sure
that Bluetooth ® is “ON”, both on your
phone and on the vehicle.
Device selection
If several devices have been programmed,
the Bluetooth
® unit links the device last
programmed. If you would like to link
a different programmed device, it is
necessary to change the link. The order
of device priority after the link has been
changed is maintained even when the
ignition is switched off.
Connecting other devices
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Turn the Bluetooth ® setting on.
5. Select the name of the device you would like to connect.
6.
icon selection
Connects both devices as hands-free and Bluetooth
® audio.
icon selection
Connects as a hands-free device.
icon selection
Connects as Bluetooth ® audio.
When the connection is completed, the
profi le list for the device is displayed.
Select the
icon to display the device list
screen and display the
or icon in the
newly connected device.
Disconnecting a device
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Turn the Bluetooth ® setting on.
5. Select the device name which is currently connected.
6. Select the
icon.
Deleting a device
Selecting and deleting devices
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Turn the Bluetooth ® setting on.
5. Select the device name which you would like to delete.
6. Select the
icon.
7. Select the
icon.
Deleting all devices
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Select the
icon.
5. Select the
icon.
6. Select the
icon.
Changing PIN code
PIN code (4 digits) can be changed.
1. Select the
icon on the home screen
and display the Settings screen.
2. Select the
tab.
3. Select the
icon.
4. Select the
icon.
5. Select the
icon.
6. Input the new PIN code to be set.
7. Select the
icon.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–94
Interior Features
Bluetooth®
Available Language (Type B)
The Bluetooth ® Hands-Free System
applies to the following languages:
 y  English y Spanish y French
Refer to Settings on page 5-55 .
Voice Recognition (Type B)
The Mazda Bluetooth ® Hands-Free system
can be used to make calls or operate the
audio unit using voice recognition which
includes numerous convenient commands.
In this section, the basic operation of the
voice recognition is explained.
Activating Voice Recognition
Press the talk-button.
Ending Voice Recognition
Use one of the following methods:
 y  Press the hang-up button. ySay: [Beep] “Cancel” y Perform the touch panel operation or
commander switch operation while the
vehicle is stopped.
Skipping Voice Guidance (for faster
operation)
Press and release the talk-button.
NOTE
 y  Switch the ignition to ACC or ON
and the Bluetooth ® Hands-free system
becomes operational within 30 seconds.
 y  When operating the audio unit or the
A/C while using Bluetooth ® Hands-
Free, the beep sounds or voice
guidance (audio unit)/cannot be heard.
Troubleshooting for Voice Recognition
If you do not understand an operation
method while in the voice recognition
mode, say “Tutorial” or “Help”.
Commands useable anytime during
voice recognition
“Go Back” and “Cancel” are commands
which can be used at anytime during voice
recognition.
Returning to previous operation
This command is for returning to the
previous operation while in the voice
recognition mode.
Say: [Beep] “Go Back”
Cancel
The Bluetooth
® Hands-Free system
transitions to standby status if the
following operation is performed while the
system is activated.
Say: [Beep] “Cancel”
To prevent a deterioration in the voice
recognition rate and voice quality, the
following points should be observed:
 y  Phone related commands are available
only when your phone is connected via
Bluetooth
® . Make sure your phone is
connected via Bluetooth ® before you
operate phone related voice commands.
 y  Music play commands, such as Play
Artist and Play Album can be used only
in USB audio mode.
 y  Do not speak too slowly or loudly (no
loud voice).
 y  Speak clearly, without pausing between
words or numbers.
 y  The hands-free system cannot perform
voice recognition while voice guidance
or a beep sound is operating. Wait until
the voice guidance or the beep sound is
fi nished before saying your commands.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

*Some models.5–95
Interior Features
Bluetooth®
 y Dialects or different wording other
than hands-free prompts cannot be
recognized by voice recognition. Speak
in the wording specifi ed by the voice
commands.
 y  It is not necessary to face the
microphone or approach it. Speak the
voice commands while maintaining a
safe driving position.
 y  Close the windows and/or the moonroof
to reduce loud noises from outside
the vehicle, or turn down the airfl ow
of the air-conditioning system while
Bluetooth
® Hands-Free is being used. y  Make sure the vents are not directing air
up towards the microphone.
NOTE
If the voice recognition performance is not
satisfactory.
Refer to Troubleshooting (Type A/Type B)
on page 5-129 .
Bluetooth ® Hands-Free
(Type A)
*
Making a Call
Phonebook Usage
Telephone calls can be made by saying
the name of a person (voice tag) whose
phone number has been registered in
Bluetooth
® Hands-Free in advance. Refer
to Phonebook registration.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Call”
3. Prompt: “Name please.”
4. Say: [Beep] “XXXXX... (Ex. “John's phone”)” (Say a voice tag registered in
the phonebook.)
5. Prompt: “Calling XXXXX... (Ex. “John's phone”) XXXX (Ex. “at
home”). Is this correct?” (Voice tag and
phone number location registered in
phonebook).
6. Say: [Beep] “Yes”
7. Prompt: “Dialing”
NOTE
The “Call” command and the voice tag
can be combined.
Ex. In Step 2, say, “Call John's phone”,
then, Steps 3 and 4 can be skipped.
Phonebook registration
Phone numbers can be registered to the
Bluetooth
® Hands-Free phonebook.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–96
Interior Features
Bluetooth®
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following: New entry, edit, list names, delete,
erase all or import contact.”
4. Say: [Beep] “New entry”
5. Prompt: “Name please.”
6. Say: [Beep] “XXXXX... (Ex. “Mary's phone”)” (Say a voice tag for the name
registered.)
7. Prompt: “Adding XXXXX... (Ex. “Mary's phone”) (Registered voice tag).
Is this correct?”
8. Say: [Beep] “Yes”
9. Prompt: “Home, Work, Mobile, or Other?”
10. Say: [Beep] “Mobile” (Say “Home” , “Work”, “Mobile”, or “Other”, for
the desired location to be registered.)
11. Prompt: “Mobile (Location to be registered). Is this correct?”
12. Say: [Beep] “Yes”
13. Prompt: “Number, please.”
14. Say: [Beep] “XXXXXXXXXXX” (Say the phone number to be
registered.)
15. Prompt: “XXXXXXXXXXX (Phone number registration). After the beep,
continue to add numbers, or say
Go-Back to re-enter the last entered
numbers, or press the Pick-Up button to
save the number.” 16. (Registration)
Press the pick-up button or say “Enter”,
then go to Step 17.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 15.
(Telephone number correction)
Say, “Go Back”. The prompt replies, “Go Back. The last entered numbers
have been removed.”. Then go back to
Step 13.
17. Prompt: “Number saved. Would you like to add another number for this
entry?”
18. Say: [Beep] “Yes” or “No”.
19. If “Yes”, an additional phone number registration can be made for the same
entry.
If “No”, the system returns to standby status.
(Import contact)
Phonebook data from your device (Mobile
phone) can be sent and registered to your
Bluetooth
® Hands-Free phonebook using
Bluetooth® .
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following: New entry, edit, list names, delete,
erase all or import contact.”
4. Say: [Beep] “Import contact”
5. Prompt: “The hands free System is ready to receive a contact from a
phone. Only a home, a work, and a
mobile number can be imported, This
process requires operation of a mobile
phone. refer to the phone's manual for
more information”
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–97
Interior Features
Bluetooth®
6. Device (Mobile phone) operation: Select one entry from the phonebook
and send it using Bluetooth
® .
7. Prompt: “X (Number of locations which include data) numbers have been
imported. What name would you like to
use for these numbers?”
8. Say: [Beep] “XXXXX... (Ex. “Mary's phone”)” (Say a voice tag for the name
registered.)
9. Prompt: “Adding XXXXX... (Ex. “Mary's phone”) (Voice tag). Is this
correct?”
10. Say: [Beep] “Yes”
11. Prompt: “Number saved. Would you like to import another contact?”
12. Say: [Beep] “Yes” or “No”
13. If “Yes”, the procedure proceeds to Step 5.
If “No”, the procedure proceeds to Step 14.
Editing phonebook
The data registered to the Bluetooth
®
Hands-Free phonebook can be edited.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following: New entry, edit, list names, delete,
erase all or import contact.”
4. Say: [Beep] “Edit”
5. Prompt: “Please say the name of the entry you would like to edit or say,
“List names”.” 6. Say: [Beep] “XXXXX... (Ex. “Mary's
phone”)” (Say the voice tag for the
registered name to be edited in the
phonebook.)
7. Prompt: “Home, Work, Mobile, or Other?”
8. Say: [Beep] “Home” (Say the registered location to be edited:
“Home”, “Work”, “Mobile”, or
“Other”.)
9. Prompt: “XXXXX... (Ex. “Mary's phone”) (Registered voice tag) XXXX
(Ex. “Home”) (Registered location). Is
this correct?”
10. Say: [Beep] “Yes”
11. Prompt: The current number is XXXXXXXXXXX (Ex. “555-1234”)
(Currently registered number). New
number, please.”
NOTE
If there was no previous phone number
registered to a location (Ex. “Work”),
the prompt will only read out “Number,
please”
12. Say: [Beep] “XXXXXXXXXXX (Ex. “555-5678”)” (Say the new phone
number to be registered.)
13. Prompt: “XXXXXXXX (Telephone number) After the beep, continue to add
numbers, or say Go-Back to re-enter
the last entered numbers, or press the
Pick-Up button to save the number.”
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD

5–98
Interior Features
Bluetooth®
14. (Number Change)
Press the pick-up button, then go to Step 15.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 13.
(Telephone number correction)
Say, “Go Back”. The prompt replies, “Go Back. The last entered numbers
have been removed. Number, please.”.
Then go back to Step 12.
15. Prompt: “Number changed.”
Phonebook data deletion
(Erasing individual phonebook data)
Individual data registered to the
Bluetooth
® Hands-Free phonebook can be
cleared.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following: New entry, edit, list names, delete,
erase all or import contact.”
4. Say: [Beep] “Delete”
5. Prompt: “Please say the name of the entry you would like to delete or say,
“List names”. ”
6. Say: [Beep] “XXXXX... (Ex. “John's phone”) ” (Say the registered voice tag
to be deleted from the phonebook.)
7. Prompt: “Deleting XXXXX... (Ex. “John's phone”) (Registered voice tag)
Home (Registered location). Is this
correct?”
8. Say: [Beep] “Yes” 9. Prompt: “XXXXX... (Ex. “John's
phone”) (Registered voice tag) Home
(Registered location) deleted.”
(Complete deletion of the phonebook
data)
All data registered to the Bluetooth
®
Hands-Free phonebook can be erased.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
3. Prompt: “Select one of the following: New entry, edit, list names, delete,
erase all or import contact.”
4. Say: [Beep] “Erase all”
5. Prompt: “Are you sure you want to erase everything from your Hands Free
system phonebook?”
6. Say: [Beep] “Yes”
7. Prompt: “You are about to delete everything from your Hands Free
system phonebook. Do you want to
continue?”
8. Say: [Beep] “Yes”
9. Prompt: “Please wait, erasing the Hands Free system phonebook.”
10. Prompt: “Hands-Free system phonebook erased.”
Read-out of names registered to the
Bluetooth
® Hands-Free phonebook
Bluetooth
® Hands-Free can read out the
list of names registered to its phonebook.
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Phonebook”
/C\FCA&('#*A'FKVKQPKPFD/C\FCA&('#*A'FKVKQPKPFD
