*Some models.4–15
When Driving
Instrument Cluster and Display
Dashboard Illumination
If the light switch is turned to the or
position with the ignition switched ON,
the brightness of instrument panel
illumination is dimmed. If the knob is
rotated at this time, the brightness of
instrument panel and dashboard
illuminations can be adjusted.
 y  The brightness decreases by rotating the
knob to the left. A beep sound will be
heard when the knob has been rotated to
the maximum dim position.
 y  The brightness increases by rotating the
knob to the right.
Dim
Bright
Function for cancelling illumination
dimmer
The illumination dimmer can be cancelled
by rotating the knob to the right until a
beep sound is heard while the light switch
is in the
or position with the
ignition switched ON. If the instrument
cluster's visibility is reduced due to glare
from surrounding brightness, cancel the
illumination dimmer.
NOTE
 y  When the illumination dimmer is
cancelled, the instrument cluster cannot
be dimmed even if the light switch is
turned to the
or position. y When the illumination dimmer is
cancelled, the screen in the center
display switches to constant display of
the daytime screen.
Outside Temperature Display *
When the ignition is switched ON, the
outside temperature is displayed.
NOTE
Under the following conditions, the
outside temperature display may differ
from the actual outside temperature
depending on the surroundings and vehicle
conditions:
 y Signifi cantly cold or hot
temperatures.
 y Sudden changes in outside
temperature.
 y The vehicle is parked. y The vehicle is driven at low speeds.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–16
When Driving
Instrument Cluster and Display
The outside temperature unit can be
switched between Celsius and Fahrenheit
using the following procedure.
1. Press the INFO button with the ignition switched off and continue pressing the
INFO button for 5 seconds or longer
while switching the ignition ON. The
outside temperature display fl ashes.
2. Press the up
or down part of the
INFO switch to change the outside
temperature unit.
3. Press and hold the INFO button for 3 seconds or longer while the outside
temperature display is fl ashing. The
outside temperature display illuminates.
Cruise Control Set Vehicle Speed Display*
The vehicle speed preset using the cruise
control is displayed.
Trip Computer and INFO Switch *
The following information can be selected
by pressing the up
or down part of the
INFO switch with the ignition switched
ON.
 y  Approximate distance you can travel on
the available fuel
 y  Average fuel economy y Current fuel economy y Average vehicle speed
If you have any problems with your trip
computer, consult an Authorized Mazda
Dealer.
Distance-to-empty mode
This mode displays the approximate
distance you can travel on the remaining
fuel based on the fuel economy.
The distance-to-empty will be calculated
and displayed every second.
NOTE
 y  Even though the distance-to-empty
display may indicate a suffi cient amount
of remaining driving distance before
refueling is required, refuel as soon as
possible if the fuel level is very low or
the low fuel warning light illuminates.
 y  The display may not change unless you
add more than approximately 9 L (2.3
US gal, 1.9 Imp gal) of fuel.
 y The distance-to-empty is the
approximate remaining distance the
vehicle can be driven until all the
graduation marks in the fuel gauge
(indicating the remaining fuel supply)
disappear.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–17
When Driving
Instrument Cluster and Display
Average fuel economy mode
This mode displays the average fuel
economy by calculating the total fuel
consumption and the total traveled
distance since purchasing the vehicle, re-
connecting the battery after disconnection,
or resetting the data. The average fuel
economy is calculated and displayed every
minute.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - L/100
km (- - - mpg) will be displayed for about
1 minute before the fuel economy is
recalculated and displayed.
Current fuel economy mode
This mode displays the current fuel
economy by calculating the amount of fuel
consumption and the distance traveled.
Current fuel economy will be calculated
and displayed every 2 seconds.
When you've slowed to about 5 km/h (3
mph), - - - L/100 km (- - - mpg) will be
displayed.
Average vehicle speed mode
This mode displays the average vehicle
speed by calculating the distance and the
time traveled since connecting the battery
or resetting the data.
Average vehicle speed will be calculated
and displayed every 10 seconds.
To clear the data being displayed, press the
INFO button for more than 1.5 seconds.
After pressing the INFO button, - - - km/h
(- - - mph) will be displayed for about
1 minute before the vehicle speed is
recalculated and displayed.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–18
When Driving
Instrument Cluster and Display
Active Driving Display *
Optical receiver
Mirror
Combiner
WARNING
Adjust the brightness or the display position while paying attention to s\
afe driving:
If you do not pay attention to your driving while trying to make the adjustments, it could
lead to an unexpected accident.
CAUTION


4–19
When Driving
Instrument Cluster and Display
The active driving display indicates the following information:
 y Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings Refer to Mazda Radar Cruise Control (MRCC) on page 4-90 . y Lane Departure Warning System (LDWS) Operation Conditions and Warnings Refer to Lane Departure Warning System (LDWS) on page 4-118 . y Smart City Brake Support (SCBS) Operation Conditions and Warnings Refer to Smart City Brake Support (SCBS) on page 4-71 . y Forward Obstruction Warning (FOW) Operation Conditions and Warnings Refer to Forward Obstruction Warning (FOW) on page 4-115 . y Vehicle Speed Setting Using Cruise Control Refer to Cruise Control on page 4-99 . y Turn-by-Turn (TBT) (Direction and Distance) and Lane Guidance y Vehicle Speed
Each setting/adjustment for the active driving display can be performed \
on the center
display (Type B audio).
1. Select the (
) icon on the home screen and display the Settings screen.
2. Select the AD-Disp tab.
3. Select the desired item and perform the setting/adjustment.
yHeight : Active driving display positionyBrightness Control : Method for adjusting screen brightness (Automatically/Manually)yCalibration : Brightness initialization setting (when selecting automatic adjustment\
)yBrightness : Brightness adjustment (when selecting manual adjustment)yNavigation : On/OffyActive Driving Display : On/OffyReset
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










4–20
When Driving
Instrument Cluster and Display
Warning/Indicator Lights
Instrument Cluster varies depending on model and specifi cations.
Warning/Indicator lights will appear in any of the highlighted areas
Type A
Type B
Type C
Center of Dashboard (Digital Speed Meter Type)
(Analog Speed Meter Type (With Tachometer))
(Analog Speed Meter Type (Without Tachometer))
Instrument Cluster
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–21
When Driving
Instrument Cluster and Display
Warning Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Warning Lights Page
Master Warning Light *1 7-24
Brake System Warning Light *1*2 7-24
ABS Warning Light *1 7-24
Charging System Warning Light *1 7-24
Engine Oil Warning Light *1 7-24
Check Engine Light *1 7-24
(Red) High Engine Coolant Temperature Warning Light
*1
7-24
* Automatic Transaxle Warning Light *1 7-24
Power Steering Malfunction Indicator Light *1 7-24
Air Bag/Front Seat Belt Pretensioner System Warning Light *1 7-24
Low Fuel Warning Light 7-24
Check Fuel Cap Warning Light *1 7-24
Seat Belt Warning Light 7-24
Door-Ajar Warning Light 7-24
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–22
When Driving
Instrument Cluster and Display
Signal Warning Lights Page
* Low Washer Fluid Level Warning Light 7-24
* Tire Pressure Monitoring System Warning Light *1 7-24
(Red) KEY Warning Light
*1
7-24
(Amber)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Warning Light *1 7-24
(Amber)
* Lane Departure Warning System (LDWS) Warning Light *1*3 7-24
* Headlight Auto-Leveling Malfunction Indicator Light *1 7-24
(Amber)
* High Beam Control System (HBC) Warning Light *1 7-24
(Amber)
* Mazda Radar Cruise Control (MRCC) Warning Light *1 7-24
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
*2 The light turns on continuously when the parking brake is applied.
*3 The light turns on when the system on stand-by. The light fl ashes when the system has a malfunction.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–23
When Driving
Instrument Cluster and Display
Indicator Lights
These lights turn on or fl ash to notify the user of the system operation status or a system
malfunction.
Signal Indicator Lights Page
* BSM OFF Indicator Light 4-113
(Green)
* Lane Departure Warning System (LDWS) Indicator Light 4-121
(Green) KEY Indicator Light 3-9
(Green)
* High Beam Control System (HBC) Indicator Light
4-49
Wrench Indicator Light *1 4-25
TCS/DSC Indicator Light *1 4-79 ,
4-80
DSC OFF Indicator Light *1 4-81
* AFS OFF Indicator Light *1 4-45
(Red)
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS)
Indicator Light *1 4-117 , 4-77
* Forward Obstruction Warning/Smart City Brake Support (FOW/SCBS) OFF
Indicator Light *1 4-77
* i-ELOOP Indicator Light 4-84
(Blue) Low Engine Coolant Temperature Indicator Light 4-25
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.4–24
When Driving
Instrument Cluster and Display
Signal Indicator Lights Page
* Shift Position Indication 4-30
* SPORT Mode Indicator Light 4-88
Headlight High-Beam Indicator Light 4-44 ,
4-44
Turn Signal/Hazard Warning Indicator Lights 4-50 ,
4-58
Security Indicator Light *1 3-42
(Green) * Mazda Radar Cruise Control (MRCC) Indicator Light 4-94
(Amber)
* Cruise Main Indicator Light 4-100
(Green)
* Cruise Set Indicator Light 4-100
Lights-On Indicator Light 4-40
*1 The light turns on when the ignition is switched on for an operation che\
ck, and turns off a few seconds later or when the engine is started. If the light does not turn on or remains tur\
ned on, have the vehicle inspected at an
Authorized Mazda Dealer.
